GVM-VAC GVM6600-CM User manual

Automated Self Contained
Leaf Collector
GVM6600-CM
GVM6600-CM
Owner's Manual
Safety Manual
Pre-Operating Manual
Operating Manual
Maintenance Manual
Service Manual
Parts Catalog
Automated Self Contained
Leaf Collector
2014 Edition
416011
Sold and Serviced by:
www.gvm-vac.com

GVM
IMPROPER USE OF ANY MACHINE CAN
RESULT IN SERIOUS INJURY!
STUDY AND FOLLOW ALL SAFETY
PRECAUTIONS BEFORE OPERATING OR
REPAIRING UNIT
www.gvm-vac.com
DO NOT ATTEMPT TO OPERATE
OR REPAIR
THE LEAF COLLECTOR WITHOUT FIRST
READING AND UNDERSTANDING THIS
MANUAL
IF YOU HAVE ANY QUESTIONS CONCERNING THE
INSTALLATION OR OPERATION OF THIS UNIT, PLEASE CALL
GVM FOR ASSISTANCE BEFORE ATTEMPTING TO REPAIR OR
OPERATE THE UNIT.
THIS MANUAL IS AN INTEGRAL PART OF THE LEAF COLLECTOR AND SHOULD
BE KEPT WITH THE UNIT WHEN IT IS SOLD.

3
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
Read and understand this entire manual before operating, maintain-
ing or repairing the leaf vacuum.
DO NOT RIDE, SIT OR STAND ON UNIT
DO NOT MODIFY THE UNIT FOR RIDERS IN ANY
WAY. SERIOUS INJURY OR DEATH MAY OCCUR
If the decal above is missing or damaged call GVM immediately and we will send you a replacement free of
charge. Never operate a unit with damaged or missing safety decals.
GVM’s leaf collectors are NEVER to be used to accommodate riders. If your unit has been modied
to accommodate riders, remove these modications immediately as this can result in serious injury or
death.

4
GVM-VAC
www.gvm-vac.com
GVM
www.gvm-vac.com
Thank you and Congratulations on your purchase of your GVM Leaf Collector. Your GVM leaf
collector has been carefully designed and manufactured to give you a maximum amount of depend-
ability and years of trouble-free operation.
Please take the time to thoroughly read this manual, as well as the engine manual, in its entirety be-
fore operating, maintaining, servicing or repairing your leaf collector. Please thoroughly review and
follow all the safety procedures located in this manual.
Whenever you need replacement parts, service information or any question regarding your GVM
product please feel free to contact your dealer or us at 800-632-7989 or www.gvm-vac.com.
Please record the following information for future reference:
THANK YOU
Model No.:
Serial No.:
Vin No:
Engine Serial No.:
Date of Purchase:

5
GVM-VAC
www.gvm-vac.com
TABLE OF CONTENTS
Read and understand this entire manual before operating, maintaining or repair-
ing the leaf vacuum.
Contents
1.0 GENERAL SAFETY
1.1 Safety Symbol Denitions ....................................................................................................................10
1.2 Do’s and Do Not’s:................................................................................................................................. 11
1.3 Training:.................................................................................................................................................13
1.4 Safety Decals ......................................................................................................................................14
1.4 Safety Decals ......................................................................................................................................15
1.4 Safety Decals - Part Numbers .............................................................................................................16
1.5 VIN And Serial Number Locations........................................................................................................18
2.0 PRE-OPERATING SECTION
2.1 Instruments And Control: ......................................................................................................................20
2.1 Instruments and Controls, cont.: ...........................................................................................................21
2.1 Instruments And Controls, continued: ..................................................................................................22
2.2 Safe Operations:.....................................................................................................................................23
2.3 Preparation For Operation......................................................................................................................25
2.4 PRE-TRANSPORT CHECKS ...............................................................................................................26
2.5 Personal Protective Equipment and Clothing ........................................................................................27
2.6 Work Site Preparation ............................................................................................................................28
3.0 OPERATING SECTION
3.1 Starting Engine.......................................................................................................................................30
3.1 Starting Engine, continued.....................................................................................................................31
3.2 Engaging the PTO..................................................................................................................................32
3.3 Dumping the Body.................................................................................................................................34
3.3 Dumping the Body, continued ...............................................................................................................35
3.4 Hose Boom Operation - 3 Axis..............................................................................................................36
3.4 Hose Boom Operation - 3 Axis, cont. ....................................................................................................37
4.0 MAINTENANCE SECTION
4.1 Maintenance Overview:.........................................................................................................................39
4.2 Maintenance and Lubrication ...............................................................................................................40
4.3 Lubrication:............................................................................................................................................41
4.3 Lubrication, continued; .........................................................................................................................42
4.3 Lubrication, continued; .........................................................................................................................43
4.3 Lubrication, continued; .........................................................................................................................44
4.4 Preventative Maintenance......................................................................................................................45
4.5 Torque Values ........................................................................................................................................50
4.6 Quick Reference Chart...........................................................................................................................51
5.0 SERVICE SECTION
5.1 Removing Blower Housing Face...........................................................................................................55
5.2 Replacing the Drive Belt .......................................................................................................................56
5.2 Replacing the Drive Belt (if equipped), continued;...............................................................................57
Table of Contents

6
GVM-VAC
www.gvm-vac.com
TABLE OF CONTENTS
Read and understand this entire manual before operating, maintaining or repair-
ing the leaf vacuum.
5.3 Replacing the Drive Bearings(if equipped) ................................................................................................ 58
5.3 Replacing the Drive Belt (if equipped), ..................................................................................................... 59
5.3 Replacing the Drive Bearings (if equipped), continued.............................................................................. 60
5.4 Impeller Installation and Removal.............................................................................................................. 61
5.4 Impeller Installation and Removal, continued............................................................................................ 62
5.5 Replacing the Blower Housing Liners........................................................................................................ 63
5.5 Replacing the Blower Housing Liners; continued,..................................................................................... 64
5.6 Auto Mfg. Clutch Adjustment - 2008 and after .......................................................................................... 65
5.7 Engine Electrical Troubleshooting............................................................................................................. 66
5.10 WIRING DIAGRAMS
5.10.1 GVM6600-SM Truck Wiring - Overall ................................................................................................. 68
5.10.2 Instrument Panel Joystick Connector..................................................................................................... 69
5.10.3 Instrument Panel Wiring Diagram (non computer) ............................................................................... 70
5.10.4 Relay Harness - Switch Diagram .......................................................................................................... 71
5.10.5 Engine Wiring Harness ......................................................................................................................... 72
5.10.6 Engine Wiring Harness Descriptions..................................................................................................... 73
5.10.7 Remote Throttle / Clutch Wiring Harness ............................................................................................. 74
5.10.8 Valve Body Wiring Harness Descriptions.............................................................................................. 75
5.20 HYDRAULIC DIAGRAM
5.20.1 Hoist Hydraulic Diagram....................................................................................................................... 77
6.0 ENGINE GROUP
6-0 ..................................................................................................................................................................... 79
6.1 Instrument Panel Group ............................................................................................................................. 80
6.2 In-Cab Instrument Panel Mounting Group ................................................................................................ 81
6.3 In-Cab Joystick Group ............................................................................................................................... 82
6.4 Joystick Breakdown .................................................................................................................................. 83
6.5 Air Cleaner Group....................................................................................................................................... 84
6.6 Sheet Metal Group, SCL 3X ....................................................................................................................... 85
6.7 Engine Mount Group .................................................................................................................................. 86
6.8 Mufer Group ............................................................................................................................................. 87
6.9 Radiator Group............................................................................................................................................ 88
6.10 Engine Senders and Switches ................................................................................................................... 89
6.11 Engine Miscellaneous Parts Group ........................................................................................................... 90
6.12 John Deere Common Engine Parts Group................................................................................................ 91
6.13 Battery Group............................................................................................................................................ 92
6.14 Remote Clutch / Throttle Circuit Board Assembly................................................................................... 93
6.15 Remote Clutch and Remote Throttle Assembly........................................................................................ 94
6.16 Chaffe Eliminator Assembly, hinged ........................................................................................................ 95
7.0 CLUTCH GROUP
7-0 ..................................................................................................................................................................... 96
7.1 AutoHD PTO Clutch Group........................................................................................................................ 97
Table of Contents

7
GVM-VAC
www.gvm-vac.com
7.2 AutoHD PTO Assembly Group .................................................................................................................... 98
7.3 AutoHD PTO Linkage Group ....................................................................................................................... 99
7.4 Clutch Assist Group .................................................................................................................................... 100
7.5 Kraft Fluid Drive Group (Optional)............................................................................................................ 101
7.6 Kraft Fluid Drive Installation (Optional).................................................................................................... 102
7.7 Kraft Fluid Drive Breakdown (Optional) ................................................................................................... 103
7.8 Kraft Fluid Drive Maintenance (Optional) ................................................................................................. 104
8.0 BLOWER HOUSING GROUP
8-0 ..................................................................................................................................................................... 105
8.1 Blower Housing Group............................................................................................................................... 106
9.0 Hydraulic Group
9-0 ..................................................................................................................................................................... 107
9.1 Hydraulic Tank Assembly - 3X................................................................................................................... 108
9.2 Valve Body Assembly - 3X......................................................................................................................... 109
10.0 Chassis and Hopper Group
10-0 ................................................................................................................................................................... 110
10.1 Fuel Tank Group ....................................................................................................................................... 111
10.2 Box Container Screens.............................................................................................................................. 112
10.3 Chassis Group ........................................................................................................................................... 113
10.4 Light and Reector Group ........................................................................................................................ 114
10.5 Light Bar Group (Optional) ...................................................................................................................... 115
10.6 Automated Door Latch Group (Optional)................................................................................................. 116
10.7 Manual Top Hinged Door (Optional)........................................................................................................ 117
10.8 Side Hinge Manual Doors (Optional)....................................................................................................... 118
10.9 Side Hinge Manual Door Interior (Optional)............................................................................................ 119
10.10 Bottom Exhaust Group (Optional).......................................................................................................... 120
10.11 Hood Scoop Group (Optional)................................................................................................................ 121
10.12 Chipper Door Group (Optional).............................................................................................................. 122
10.13 Chipper Hitch and Camera Group (Optional)......................................................................................... 123
10.14 Backup Camera Group (Optional).......................................................................................................... 124
11.0 HOSE BOOM GROUP
11-0 ................................................................................................................................................................... 125
11.1 Boom Assembly, 3 Axis ............................................................................................................................ 126
11.2 Hinged Boom Frame Assembly - 3 Axis .................................................................................................. 127
TABLE OF CONTENTS
Read and understand this entire manual before operating, maintaining or repair-
ing the leaf vacuum.
Table of Contents

8
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
Read and understand this entire manual before operating, maintain-
ing or repairing the leaf vacuum.
1.0 GENERAL SAFETY
1.0
GENERAL
SAFETY
Contents
1.0 GENERAL SAFETY
1.1 Safety Symbol Denitions ......................................................................10
1.2 Do’s and Do Not’s:...................................................................................11
1.3 Training:...................................................................................................13
1.4 Safety Decals ........................................................................................14
1.4 Safety Decals ........................................................................................15
1.4 Safety Decals - Part Numbers ...............................................................16
1.5 VIN And Serial Number Locations..........................................................18

9
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
Read and understand this entire manual before operating, maintain-
ing or repairing the leaf vacuum.
DO NOT RIDE, SIT OR STAND ON UNIT
DO NOT MODIFY THE UNIT FOR RIDERS IN ANY
WAY. SERIOUS INJURY OR DEATH MAY OCCUR
If the decal above is missing or damaged call GVM immediately and we will send you a replacement free of
charge. Never operate a unit with damaged or missing safety decals.
GVM's leaf collectors are NEVER to be used to accommodate riders. If your unit has been modied
to accommodate riders, remove these modications immediately as this can result in serious injury or
death.

10
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
!
The purpose of safety symbols are to attract your attention to possible
dangers. The safety symbols, and their explanations, deserve your careful
attention and understanding. The safety warnings do not by themselves
eliminate any danger. The instructions or warnings they give are not sub-
stitutes for proper accident prevention measures.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates danger, warning or caution. At-
tention is required in order to avoid serious personal injury. May be used in
conjunction with other symbols or pictographs.
Read and understand this entire manual before operating, maintain-
ing or repairing the leaf vacuum.
Disregarding this safety warning WILL result in serious equipment
damage, injury or possible death.
Disregarding this safety warning CAN result in serious equipment
damage, injury or possible death.
Disregarding this safety warning MAY result in minor or moderate
injury or property damage.
1.1 Safety Symbol Denitions
This manual provides the owners/operator with procedures for safe opera-
tion, maintenance and repair of GVM’s leaf collectors. As with any ma-
chine, there are hazards associated with their operation. For this reason
safety is emphasized throughout this manual. To highlight specic safety
information the following safety denitions are provided to assist the read-
er.

11
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
DO NOT operate, maintain or repair this unit without having fully read
and understood ALL the aspects of this manual.
DO NOT ride, sit or stand on unit at anytime.
DO NOT modify the leaf vacuum for any reasons to allow for riders.
DO NOT operate the unit in a state of disrepair.
DO NOT operate the unit with ANY guards or safety devices broken,
missing, or inoperable.
DO NOT operate the unit without wearing proper safety equipment.
DO NOT operate this unit while under the inuence of any alcohol or
medication.
DO NOT operate this unit if you have a record of mental instability or
dizziness which could result in injury to yourself or others.
DO NOT operate this unit if you are under 18 years of age.
DO NOT operate this unit without fully inspecting the unit for any dam-
age or leakage.
DO NOT operate if the unit has any excessive vibration.
DO NOT operate unit with the inspection door limit switch damaged or
missing.
DO NOT operate unit unless it is properly connected to a leaf collection
box.
DO NOT ll fuel tank with engine running. Allow engine to cool for 5
minutes before refueling.
DO NOT operate unit if fuel is spilled or with fuel cap off.
DO NOT smoke or weld near the unit.
DO NOT run engine in an enclosed area.
DO NOT place hands or feet near moving or rotating parts.
DO NOT operate engine with an accumulation of grass, leaves or other
debris on the engine.
Read and understand this entire manual before operating, maintain-
ing or repairing the leaf vacuum.
1.2 Do’s and Do Not’s:
This section contains some general safety precautions to do and not to do.
This is not an all inclusive list and it is the responsibility of the operator to
have proper training and use common sense in work situations.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
DO NOT:

12
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
DO NOT run engine with air cleaner removed.
DO NOT leave leaf machine unattended while in operation.
DO NOT park machine on steep grade or slope.
DO NOT vacuum a leaf pile without looking for foreign objects such as
metal, glass, plastic or large pieces of wood.
19.
20.
21.
22.
Do Not, continued;
Do’s:
DO completely read and understand the owner’s manual before operat-
ing, maintaining or repairing the leaf collector.
DO follow engine and PTO manufacturer operating and maintenance
instructions.
DO check fuel lines and ttings frequently for cracks or leaks. Replace
if necessary.
DO completely inspect the unit before leaving the service garage.
DO inspect and be attentive to what is being vacuumed.
DO check the impeller, liners and blower housing for cracks or holes
daily.
DO wear proper safety equipment as described in this manual.
DO watch for pedestrians, animals and other foreign material when
vacuuming leaves.
DO replace any worn or missing safety stickers immediately.
1.
2.
3.
4.
5.
6.
7.
8.
9.

13
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
Improper use of the GVM leaf collector CAN result in severe per-
sonal injury or death. All personnel using this leaf vacuum must
be trained and qualied with all the operations, maintenance, repair
and safety procedures dened in this manual.
1.3 Training:
The warnings and procedures regarding safety in this manual are to be
used as a guideline only. It is impossible to cover all the events that could
happen in the vacuuming process. For this reason, it is vital that the
owner accept the responsibility to implement a training program that will
provide every operator or mechanic the basic skills and knowledge to make
good judgement in all situations.
This training program must include the entire scope of hazards, precau-
tions and government regulations encountered in the vacuuming process.
The program should stress the need for regularly scheduled preventive
maintenance and detailed equipment safety checks.
GVM strongly recommends all training programs be documented to ensure
all operators and mechanics receive initial training on not just the operation
but the safety features of the leaf collector.

14
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
1.4 Safety Decals
Decal Kit - Trucks (includes 1 -15)
Danger--Rotating Parts
Caution- Pinch Point
Caution - Do Not Operate ... without reading manual
Caution - Allow Engine to Idle
Caution - Do not use Dielectric grease
Danger - Explosion hazard
GVM sticker
Clean Hopper screens
Warning - Head, Eye and Ear Protection
Do Not Over-Lubricate
Danger - Do Not Ride, Sit or Stand
Big Sticker
wide sticker
Warning - Flammable
Warning - Do not open cover while in operation
Caution - Unload Body Prop
Caution - Body must be braced
Caution - Operation of body prop
*
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
ITEM
NO.
PART
NUMBER DESCRIPTION
TRUCKDK
200183
200106
200192
200193
200194
200178
Call
200195
200181
200109
200179
Call
Call
200177
200182
*200190
*200187
*Call
Decals shown on next page
*Not in TruckDK
Kit
2,8,9
1,2,3,4,5,6,9,
10,11,15
*Read and Follow all Safety
Sticker Warnings--Replace
all damaged or missing
stickers immediately.

15
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
1.4 Safety Decals

16
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
#PART # DESCRIPTION
* Call Decal Kit - GVM Trucks
1 200183 Danger--Rotating Parts
2 200106 Caution- Pinch Point
3 200192 Caution - Do Not Operate ... reading manual
4 200193 Caution - Allow Engine to Idle
5 200194 Caution - Do not use Dielectric grease
6 200178 Danger - Explosion hazard
7 200109 Do Not Over - Lubricate
8 200195 Clean Hopper screens
9 200181 Warning - Head, Eye and Ear Protection
10 Call GVM Sticker
11 200179 Danger - Do Not Ride, Sit or Stand
12 200177 Warning - Flammable
13 200182 Warning - Do not open cover ... operation
14 *200190 Caution - Unload Body Prop
16 *200187 Caution - Body must be braced
17 *Call Caution - Operation of body prop
18 200189 Check Impeller
19 65.1801 Do Not Operate Unit without Hose Attached
20 200188 Do Not Go Under Raised Body ...
21 200196 Do Not Overtighten Belt
22 200186 Do Not Open Doors While Unit is in Operation
23 Call Warning - Hitch Capacity
1.4 Safety Decals - Part Numbers

17
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
1.4 Safety Decals - Decal Layout for GVM6600-SM
1
2
34
5
67
8
9
10
11
12
13
14
15
16

18
GVM-VAC
www.gvm-vac.com
SAFETY PRECAUTIONS
1.5 VIN And Serial Number Locations
The serial number tag is located on the chassis on boom
side of the unit. It should be in front of the fenders going
toward the front of the unit. (See gure 1.5a).
gure 1.5a
Make sure each operator knows and understands the
load ratings of the towed vehicle and that he/she is
qualied to tow the vehicle.
Thoroughly read and understand the safety and pre-
operating sections of this manual before starting the
engine.

19
GVM-VAC
www.gvm-vac.com
Read and understand this entire manual before operating, maintain-
ing or repairing the leaf vacuum.
2.0 PRE-OPERATING SECTION
2.0
Pre-Operating
Section
2.0 PRE-OPERATING SECTION
2.0 PRE-OPERATING SECTION
2.1 Instruments And Control: .................................................................................. 20
2.1 Instruments and Controls, cont.: ....................................................................... 21
2.1 Instruments And Controls, continued: .............................................................. 22
2.2 Safe Operations:................................................................................................. 23
2.3 Preparation For Operation.................................................................................. 25
2.4 PRE-TRANSPORT CHECKS ........................................................................... 26
2.5 Personal Protective Equipment and Clothing .................................................... 27
2.6 Work Site Preparation ........................................................................................ 28

20
GVM-VAC
www.gvm-vac.com
Pre-Operating Section
2.1 Instruments And Control:
Always make sure the PTO is
disengaged before starting unit.
Ignition Switch:
Used to power the accessories and start the unit. Unit will
not start without Murphy switch depressed.
ACCESSORIES - rst position
STARTER ENGAGE - second position (springs return to
rst position)
ENGINE HEATER - left most position - used to heat the
engine
Murphy Switch:
This switch overrides the low oil pressure and high tem-
perature cutoff control. This switch must be depressed
before the starter engages. After the engine starts, wait
for oil pressure to rise before releasing the button.
Tachometer:
This gauge indicates the engine r.p.m’s. The sender is
located on the alternator.
Volt Meter:
The gauge shows the status of the engine charging sys-
tem. When the charging system is operating properly it
should read approximately 14 volts. If the gauge reads
below 13 volts, the alternator is not charging the battery
and the system should be checked by a qualied techni-
cian.
Oil Pressure Gauge:
Conrms and indicates the presence and pressure of en-
gine oil. If the gauge reads low, it should be checked by a
qualied technician.
Engine Temperature:
Indicates the engine coolant temperature. If the gauge
reads over 240 degrees the unit should be checked by a
qualied technician.
Hour Meter:
Indicates the accumulated hours of the engine. This
should be used to schedule maintenance.
Figure 2.1A
