FREESTANDING DISHWASHER –AQUA 12S
Juggling numerous tasks at home and work can be a bit overwhelming especially when you do not have
the right appliances that help take care of your daily mundane activities at home. Häfele’s premium
appliances range equips you with the choice of concentrating on activities that really need your attention.
With our range of appliances you can go about your day without the added stress of doing that big batch of
laundry or cleaning your utensils. Häfele now introduces Aqua 12S - a new freestanding dishwasher which
is a hygienic and quiet alternative to your regular washing.
This dishwasher has an impressive capacity with a 12 place setting, aptly suited for an average Indian
household. The adjustable upper and lower baskets along with the separate cutlery basket guarantee
maximum space optimization inside the dishwasher! Besides, it also has the option of functioning at half
load, which is an energy saving solution when you have less dishes to wash! The SoftTouch shelves of the
dishwasher prevent scraping and scratching of utensils thus leading to a long life of your precious china.
The new Aqua 12S Dishwasher comes with built-in programs which provide you with the flexibility of
washing your dishes depending on their material and how soiled they are. There is a glass care program
especially designed for your delicate glassware and an intensive program to take care of the toughest
stains on your pots and kadhais. The temperatures and time duration for different programs vary according
to the dishes you choose, such as pots, glasses, plates etc., ensuring 99.9% germ-free cleaning of any
utensil you put inside. Each washing cycle is followed by an efficient drying cycle which gives you dishes
which are ready-to-use.
To keep your dishwasher safe from prying hands, you can turn on the child lock to block the usage of the
control panel. The sound engineering technology of this dishwasher doesn’t cause a disturbance in the
background when all you want to do is spend some time with your family or take an afternoon siesta!
Time and peace are luxuries you can now afford with Häfele's new Aqua 12S Dishwasher!

FEATURES
Low Water Consumption
11 L
Washing dishes by hand
may feel like an
achievement, but the
environment ends up
paying a price for it.
Washing dishes by hand
consumes more litres of
water for the same load
that can be cleaned with
as little as 11 litres of
water using Häfele’s
Aqua 12 S Dishwasher.
Additional Cutlery
Basket
Your cutlery usually gets
lost in the sea of larger
utensils when placed in
the same basket. To
make sure that these
small but essential
tableware are looked
after properly, Aqua 12S
provides you with a
dedicated cutlery basket
which offers you
immense flexibility and
convenience to take
good care of your knives,
spoons and forks.
99.9% Germ-free
Cleaning
It isn’t enough that your
dishes are visibly clean,
they need to be germ-
free too! The Aqua 12S
Dishwasher delivers a
hygienic wash capable
of eliminating 99.9%
germs and bacteria. The
high temperature inside
the dishwasher
accompanied with the
water pressure removes
all the sticky residue,
bacteria and germs.
No More Wet Utensils
The drying cycle in the
Aqua 12S Dishwasher
leaves your dishes
perfectly dry without any
water residue or moisture
deposit!
The residual drying
technology incorporated
in Aqua 12S dries the
dishes with the help of
the steam is generated
during the washing cycle
without the introduction
of external air. As a
result, the drying is faster
and more hygienic
compared to other drying
methods.
Glass Care Program
The most delicate things
need the greatest care.
With our Aqua 12S
Dishwasher, your
glassware have a
dedicated glass care
program which is a 40
°C, 60 minute gentle
cycle. Now your
champagne flutes, wine
glasses and glass bowls
will get the best
treatment possible!
SoftTouch Shelves
The racks and spikes in
the Aqua 12S
Dishwasher are coated
with nylon which
provides a gentle hold
for fragile glassware and
essential crockery during
active washing and
drying cycles. Moreover,
compared to normal
racks, these racks are
more hygienic and last
longer.
Pro-tip: To maintain the shine and texture of your
glassware, increase the amount of rinse-aid than what
you would normally add.
The drying cycle in the
Aqua 12S Dishwasher
leaves your dishes
perfectly dry without any
water residue or moisture
deposits!
The residual drying
technology incorporated
in Aqua 12S dries the
dishes with the help of the
steam that has been
generated during the
washing cycle without the
introduction of external
air. As a result, the drying
is faster and more
hygienic compared to
other drying methods.

FEATURES
High Capacity
The new Aqua 12S Dishwasher has an impressive capacity with a 12-place setting. This is enough not only
for an average Indian family but also for when there are guests over. The loading capacities and position
of different utensils in the lower and upper baskets are demonstrated below. To accommodate taller
utensils, cooking pots, kadhais and woks, the spikes in the lower basket can be folded and racks in the
upper basket can be adjusted or removed.
Sound Engineered
You wouldn’t want the humming of the dishwasher to affect your quiet afternoon siesta or your post dinner
conversations. Häfele’s new Aqua 12S Dishwasher has been designed keeping this in mind. The sound
reducing material, massive insulation, quality of components and the science of hydraulics integrated
within the Aqua 12S Dishwasher ensures silent washing and drying cycles.
Half Load
The Half Load function in Aqua 12S lets you wash half the capacity of utensils, perfect for small
households. This feature helps save 20% more water and 10% more energy as compared to operating the
dishwasher on full load.
Lower Basket Loading
Cutlery Basket Loading
Cutlery Basket
Upper Basket Loading
12 Cups
12 Saucers
12 Glasses
1 Regular Serving Bowl
3 Medium Serving Bowls
3 Big Serving Bowls
Sensor for Water Pressure
The sensor in the dishwasher detects the spray intensity and water quantity at all times and incase there is
a perceived loss in either, the dishwasher immediately compensates it by ensuring optimal circulation of
water. The ideal quantity of water that should be present in the dishwasher at a time is determined by the
program that is selected.
Effective Filtration System
Häfele’s Aqua 12S Dishwasher has a three-fold filtration system: Coarse Filter, Fine Filter and Micro Filter.
These filters efficiently work together to prevent all food particles and solid residue from flowing into the
drainage system which protects your drainage pipe from clogging and ensuring efficient circulation of
water. Since water is continuously drained out, the volume of water inside the dishwasher is always
maintained at an optimal level, enabling the spray arms to spray water at the required intensity to clean the
dishes. The filters need to be cleaned regularly for them to perform at their optimal level.
12 Dessert Dishes
12 Dinner Plates
12 Soup Plates
1 Big Oval Rice Plate
12 Soup Spoons
12 Forks
12 Knives
12 Tea Spoons
12 Dessert Spoons
2 Serving Spoons
1 Serving Fork
1 Gravy Ladle

FEATURES
Intensive Program
For the Indian style of cooking which entails a lot of frying and tempering, Aqua 12S offers an intensive
program which takes care of your highly soiled cooking utensils, pots and pans and removes the most
stubborn oil stains. When the dishwasher is operated in the intensive program, the items in the lower rack
are subjected to 20% spray pressure at a higher temperature as compared to the 15% spray pressure at
lower temperatures in other programs. The upper rack is subjected to the same amount of pressure as
that in other programs.
Häfele’s Aqua 12S Dishwasher gives you a 100% leak proof guarantee. If ever a leak occurs, the water
pressure sensor shuts down the dishwasher automatically preventing any further damage.
Leak-proof
You can’t control children from being curious and fidgeting with things, but you can make your dishwasher
secure with the help of the child lock feature available in Aqua 12S. Child lock prevents people who are
unaware about the function of the dishwasher from accidentally opening the door or changing the
program when it is in use.
Child Lock
CONTROLS AND OPERATION
1 2 3 4 5
1 Power Button
2 Half Load
3 Delayed Start
4 Program Selector
5 Start/Pause
Power Button
Power Button
Press this button to turn on your dishwasher. The indicator
above the button will start.
-------------------------------------------------------------------------------
Half Load
For small loads of utensils this special half load function can
activate either of the racks, unlike the standard half load
function that only activates the bottom racks spray zones.
This is a great energy, time and water saving function.
-------------------------------------------------------------------------------
Delayed Start
Press the button multiple time to time the start of the wash
program. You can choose between 3 / 6 / 9 hours of
delayed start depending upon your desired wash time
-------------------------------------------------------------------------------
Program Selector
Press the program button multiple times to select the
desired program cycle you wish to run.
-------------------------------------------------------------------------------
Start / Pause
You can confirm and start the cycle by pressing this button.
This is done after your selection of desired program, start
time and full / half cycle load. You can also pause the cycle
by pressing this same button.
-------------------------------------------------------------------------------
Child Lock
This option allows you to lock the buttons on the control
panel - except the Power button to avoid any tampering
during the washing cycle. To lock or unlock the buttons on
the control panel, press and hold the Delay button +
Program button for 3 seconds simultaneously..
-------------------------------------------------------------------------------
To start the dishwasher, you need to press the power button. When the dishwasher is switched on, the LED indicator
above the button switches on.
Half Load
You don’t need to wait for a full load of utensils to start washing your dishes. The half load function is a great energy,
time and water saving solution for small loads of dishes. Unlike the standard half load function present in the other
dishwashers available in the market which only activates the spray zones of the bottom racks, the half load function in
the Aqua 12S Dishwasher can activate either one of the racks. Thus, you can choose a rack depending on the type of
utensils you intend to wash.
Delayed Start
Don’t want your dishes to be washed and kept in the dishwasher for a long time before you arrive home? The delayed
start function helps you to set the time at which you want your washing to begin. Press the button multiple times to
delay the time of the wash program by 3/6/9 hours accordingly.
Program Selector
Washing habits depend on eating and cooking routines and the lifestyle of an individual. The new Aqua 12S
Dishwasher comes with 6 different washing programs offering you a range of dishwashing choices. Press the program
selector button multiple times to select the program that would best suit your need! (more info about this on the next
page)
6 Child Lock
6
1
2
3
4

CONTROLS AND OPERATION
Child Lock
To activate child lock, press and hold the ‘Delayed Start’ and ‘Program Selector’ buttons together for 3 seconds. This
will lock all the buttons on the control panel –except the power button to avoid any accidental tampering during
washing cycle. To unlock the function, repeat the same procedure.
PROGRAMS AND APPLICATION
>Most economical program for medium soiled daily
dishes
>Cycle: Pre-wash Wash (45 °C) Rinse (65 °C)
Dry
>Degree of Soiling: Medium
>Wash Time: 190 mins
>Power Consumption: 0.90 kWh
>Water Consumption: 11 L
ECO
>Suitable for lightly soiled daily dishes that are
scraped or pre-cleansed
>Cycle: Wash (45 °C) 2 × Rinse (55 °C)
>Degree of Soiling: Low
>Wash Time: 30 mins
>Power Consumption: 0.75 kWh
>Water Consumption: 11 L
RAPID 30
>Designed for highly soiled wash loads, such as
pots, serving utensils and woks
>Cycle: Pre-wash (50 °C) Wash (60 °C) 
3 × Rinse (70 °C) Dry
>Degree of Soiling: High
>Wash Time: 170 mins
>Power Consumption: 1.6 kWh
>Water Consumption: 18 L
INTENSIVE
>Ideal for daily wash of a load of utensils used for
regular cooking which are medium-high soiled
>Cycle: Pre-wash (45 °C) Wash (55 °C) 
2 × Rinse (65 °C) Dry
>Degree of Soiling: Medium-High
>Wash Time: 180 mins
>Power Consumption: 1.3 kWh
>Water Consumption: 15 L
NORMAL
>For medium soiled loads that do not need
excellent drying efficiency
>Cycle: Wash (65 °C) 2 × Rinse (65 °C) Dry
>Degree of Soiling: Medium
>Wash Time: 90 mins
>Power Consumption: 1.02 kWh
>Water Consumption: 12 L
90 MINS WASH
>For delicate glassware like bowls, plates, wine
glasses, etc.,
>Cycle: Pre-wash (30 °C) Wash (40 °C) 
2 × Rinse (60 °C) Dry
>Degree of Soiling: Light
>Wash Time: 60 mins
>Power Consumption: 0.9 kWh
>Water Consumption: 14 L
GLASS
Note:
Use dishwasher detergent for effective washing of the dishes
Ensure that the slots for salt, detergent and rinse-aid are filled before starting any program
When washing glassware, add more rinse-aid than normally required for other utensils
The Aqua 12S Dishwasher is equipped with 6 different programs to take care of all your washing needs. Details of the
programs are given below.
ECO
Start / Pause
After you have selected your desired washing program, start time and full/half load; you can confirm and start the cycle
by pressing the start button. You can also pause the cycle in between by pressing the same button.
5
Start/Pause
6
Child Lock

IMPORTANT INFORMATION
Changing the program in the middle of the cycle
A wash cycle can only be changed if it has been running for a short time. Otherwise, the detergent may have already
been released and the dishwasher may have already drained the wash water. If this is the case, then the dishwasher
needs to be reset and the detergent dispenser must be refilled. To reset the dishwasher, follow the instructions below:
•Press the start/pause button for more than 3 seconds. This will cancel the program.
•Press the program selector button to select the desired program.
•Press the start/pause button. After 10 seconds, the dishwasher will start in the new program.
Adding a utensil after the wash cycle starts
You can add a forgotten utensil any time before the detergent dispenser opens (within 30 seconds of starting the cycle).
The instructions for the same are given below:
•Press the start/pause button to pause the washing.
•Wait for 5 seconds; then open the door.
•Add the forgotten dishes and close the door.
•Press the start/pause button. After 10 seconds, the dishwasher will restart.
Do not operate your dishwasher unless all enclosure panels are properly in place
Open the door very carefully if the dishwasher is operating, there is a risk of water squirting out
Knives and other utensils with sharp edges must be placed in the basket with their pointed ends facing down or in a
horizontal position
Check that the detergent powder is empty after the completion of wash cycle
Do not wash plastic utensils/containers unless they are marked ‘dishwasher safe’
The salt container must only be refilled when the salt warning light ( ) in the control panel comes on. If the salt has
spilled, run a quick program (‘RAPID 30’) to remove it
If cleaning of the doors or control panel is required, clean with a soft damp cloth only
Check the condition of the filters regularly and clean them if necessary under running water. While placing the filters
back in the dishwasher follow the proper sequence ; coarse fine micro (from top)
After every wash, turn off the power supply and leave the door of the dishwasher slightly open so that moisture and
odours are not trapped inside
Allow your dishes to cool for 15 minutes with the door open and then unload the dishes beginning with the lower
basket
SAFETY INSTRUCTIONS

PRODUCT SPECIFICATIONS
>Article No: 538.21.060
>Freestanding Dishwasher
>Material: Stainless Steel (Drum) and Mild Steel (Exterior)
>Finish: Silver
>Capacity: 12 Place Settings
>Energy Consumption (kWh): 258
>Water Consumption (ECO program): 11 L/Cycle
>Energy Efficiency: A++
>Drying Efficiency: A
>Noise Level: 49 dBA
>Push Button Functions:
>On/Off
>Start/Pause
>Delayed Start
>Half Load
>Child Lock
>Functions of Indicator:
>Program
>Salt (when the quantity of salt falls below the minimum
required level, this indicator switches on)
>Low Rinse Aid
>Child Lock
>Half Load
>Delayed Start (3/6/9 hours)
>Programs
>Eco
>Rapid 30
>Intensive
>Normal
>90 mins wash
>Glass
845
Price (INR): 49,900/-

Häfele India Private Limited | Office No. 3, Building “A”, BETA, I Think Techno Campus, Off J.V.L.R, Opp.
Kanjurmarg East, Mumbai –400 042. | Tel.: [phone] | Fax: [phone]
New Delhi | Kolkata | Chennai | Hyderabad | Bangalore | Pune | Ahmedabad | Srilanka | Bangladesh | Nepal |
Bhutan
Toll Free Customer Care No.:1800 266 6667 | SMS HAFELE to 56070 | [e-mail]
www.hafeleindia.com
