BUILT-IN DISHWASHER

A design that reveals
ASKO’s inner values
The ASKO dishwashers by Hafele are made of
steel. This has been a well-known fact for decades
and when you open the door, you will see more
steel than in any other dishwasher on the market.
With our new generation of dishwashers we want to
emphasise this fact even more. Take a look at the
door and you will see only high-quality steel with no
division between door and panel. It expresses itself
as a sturdy and reliable machine, yet retains elegant,
sleek and sophisticated lines stemming from the
minimalism of the Scandinavian mindset.
2

We have created different modes to make it easy for you to adapt your favourite dishwashing programme to new
situations. Instead of choosing from a long list of programmes and then a long list of different options and settings, you
can now easily choose one appropriate mode and press start.
Green mode
Green mode saves both water and
energy. The temperature is lowered
and each stage of the cycle is
extended to save water and achieve
the same perfect washing results as a
normal programme.
Intensive mode
Select this mode when you have dirty
dishes with dried food. Intensive
mode increases the spray arm
pressure and more heat and water is
used during the cycle.
Speed mode
If you want your dishes ready faster,
select the speed mode to reduce the
programme time by 50%. To achieve
the best possible washing results in
the time available, more water and
energy are used.
Designed for different situations
3

For all of us who let the dishwasher work while we sleep, we have created
the Night Mode. With this mode the water pressure in the spray arms
is lowered, reducing the noise level by as much as 2 dB compared to
the tested value. This mode is also perfect for open plan solutions with
seamless kitchen and living spaces.
Silent night
4

DISHWASHER FEATURES
5

Our unique and improved Super Cleaning System
(SCS+) is an intelligent feature that will save you
time, electricity, water and effort. With this patented
cleaning system you don’t need to rinse your dishes
before putting them into your dishwasher. SCS+
cleans the fine filter and all the interior surfaces after
pre-wash, before running the main wash. This means
that the wash starts with rinsed dishes, a clean
machine, an empty filter and fresh, clean water.
Aqua Safe™is an advanced safety system with
16 control points which continuously monitor
the machine for leaks. If there is a potential leak
detected, this system immediately stops the
machine.
If it leaks it’s not an ASKO!
Super Cleaning System
(SCS+)
Aqua Safe™
The Asko Dishwashers by Hafele include eight
of the most important components made of
high-quality steel rather than plastic
1. Container 2. Loading Racks
3. Spray pipe 4. Spray arms
5. Strainers 6.Outer base
7. Feet 8. Heating Element
8 Steel™
6

The Line Concept™ is an easy to use interactive
concept with buttons following a sequence from
left to right. You start from the left by turning the
machine on, then choose the desired program,
mode and options. After which you finish by
pressing the start button on the extreme right.
These buttons are extremely responsive to
touch, delivering results faster.
We have fitted our dishwashers with extra
reliable and quiet brushless motors. No brushes
mean fewer parts that can break and it also
makes the engine quieter, down to 39dB(A).
You will get higher efficiency which results in
reduced energy consumption. With increased
reliability, your dishwasher will get an extended
life.
Easy to use Line
Concept™
Less noise with
brushless motor
7

A place for everything
Our dishwashers will meet your current and future
needs and demands when it comes to loading and
cleaning your dirty dishes. In fact it will meet the
needs you didn’t even know you had! Once you
have experienced this companion in your kitchen
you will never want to do without it. With its four
level rack system, which are height adjustable,
divisible, removable and foldable, a ASKO
Dishwasher by Hafele is precisely what you want
and need it to be.
8

FlexiracksTM - World's largest and most flexible
With our range of XL and XXL dishwashers we give you the best solution ever. They are the most flexible dishwashers on the
market with intelligent loading options and unique benefits. The smart four level rack system with the unique middle rack affords
unique flexibility, endless possibilities and a loading height and capacity that are unmatched on the market. So choose the model
that fits your kitchen best, and whatever your choice you will always get a solution of endless loading options and opportunities.
The XL model is 82 cm high and the XXL model is 86 cm high. The internal loading capacity of 58 cm for XXL and 54 cm for XL
makes room for larger plates and taller glasses. It also means you can load 40 % more compared to a standard dishwasher.
Loading height Label load Tallest glass in upper / lower
basket*
Largest plate in
lower basket**
EU labelling:
Energy/Cleaning/ Drying
XXL 86 cm 58 cm 17 pls 27 cm 40 cm A++/A/A
XL 82 cm 54 cm 15 pls 25 cm 33 cm A+++/A/A
Our dishwashers are the largest ones on the inside but not on the outside. You don’t have to worry that they won’t fit into
your kitchen. They will fit into cabinets of 863 - 913 mm (XXL) and 823 - 873 mm (XL).
9

Top tray
Upper basket
Lower basket
Cutlery basket
Middle basket
10

ASKO’s dishwashers by Hafele are renowned for their exceptional washing results. The secret is our carefully designed and tested rinsing
system, comprising of no fewer than 11 spray zones* that cover every corner of the dishwasher compartment. The flexible top cutlery tray
comes with its own spray arm and space for seventeen place settings of cutlery, or other utensils. The height of the top cutlery tray has
been optimised to make room for tall glasses in the upper basket. If even more space is required, the top cutlery tray can also be removed.
Cutlery tray with top performance
Instant Lift™ - smart height adjustment
With our unique Instant Lift™ height adjustment system, you
can adjust the top cutlery tray for higher or lower loads and
free up more space in the upper basket through a simple
operation. In the raised position, the space is 40 mm and in
the lowered position it can be up to 58 mm. Simple, smart
and flexible.
*Instant Lift™ is always an option when Top cutlery tray is chosen.
11

Placement in our exclusive upper baskets can be modified in any way you want. Place wine glasses in the wine glass holders, put plates
in the plate rack or fold down all the support and load the entire basket with gratin dishes. Fold up all the support once again and fill with
just glasses. If you need more space in the baskets below, it can be raised up easily and then lowered again when you want to load
taller objects.
Flexibility and freedom to load what you want
12

Each basket comes with its own rinsing system. The middle basket is where you will find the Twin Tubes™, which is a dedicated spray zone
especially designed to provide excellent cleaning result in the middle basket.
Double performance with Twin Tubes™
13

Lower basket wine glass
shelf
We have created a unique opportunity to wash delicate
but bulky glasses in the lower basket. With the wine
glass shelf, you can safely wash up to six additional
extra-tall wine glasses at the same time. The glasses
rest safely in the extra-deep steel-loops and are angled
so that any residual moisture disappears without
leaving unsightly marks behind. The wine glass shelf is
available as an accessory.
14

11 Spray™
Our spray system is designed for precision, reaching every corner of the dishwasher. The result is perfect washing result
for all kinds of loads and soiling.
Cutlery in the top rack are sprayed from above
Dishes in the upper rack are sprayed from below
A Power Zone™ cleanes the cutlery basket
Dishes and cutlery in the lower basket are also sprayed from above
Left spray zone for the middle basket
Right spray zone for the middle basket (can be ordered as accessory)
Dishes and cutlery in the lower basket is sprayed from below
A Power Zone™ cleans pots and pans
A Power Zone™ cleans bottles and wases
The bottom and strainer for improved filtration (lower spray arm)
The strainer is rinsed from the lower spray tower
1
2
3
4
5
6
7
8
9
10
11
1
2
3
56
8
9
10
11
7
4
15

Orrefors is a Swedish company that manufactures premium crystal glassware.
One of the goals of partnership between ASKO and Orrefors is to finally put an end to the myth that crystal glasses cannot be cleaned
in a dishwasher. While this is true for some dishwashers, crystal can certainly be washed in an ASKO.
The secret is the Crystal glass programme, which ensures that the water temperature increases gradually and is then maintained evenly,
with a difference of just ±1°C. Place your valuable crystal in the secure wine glass holders in the upper basket. From now on, it is safer
to wash your sensitive crystal glasses in an ASKO than by hand.
Orrefors recommends ASKO
Tested for thousands of cycles
To be sure that our Crystal Glass programme keeps what we promise we exposed
several Orrefors crystal glasses for extensive testing (according to standard test SS
EN 12875-12005). Our initial goal was to keep glass corrosion under level two on a
four-step assessment scale after 1000 cycles. But after 1000 cycles we decided to run
another 1000 cycles since we couldn´t find any glass corrosion. The same assessment
was made after 2000 cycles with the same result.
16

The dishwashers have a completely
integrated drying system where it
first uses the heat from the dishes to
evaporate the remaining water. The
fan leads the steam through a duct
in the door where the cooler room air
is used to re-condensate it and then
lead the water down to the
dishwasher's bottom well, from
where it is then pumped out.
An extra fan is present as well, that
blows indoor tempered air into the
dishwasher compartment in order to
boost the drying process. This will
shorten the program time and will
dry even plastic objects.
Turbo Drying
Express™ -
Fan forced
drying
17

Asko Dishwashers by Hafele offer multiple programmes that best suit the need of the user whether its getting the best cleaning result in an
hour, a deep hygienic cleaning that could last up to 2 hours or just running a cleaning cycle for a few utensils at a time. We have got you
covered!
SPECIALLY DESIGNED PROGRAMMES
18

A programme intended for washing plastic items that are
dishwasher safe. Thanks to our Turbo Drying Express™
even your plastic items will be dry. This programme has an
extra long drying cycle.
The Self-cleaning programme ensures that the tub, water
recycling tank and spray system are thoroughly cleaned.
Regular cleaning is essential for both washing performance
and the machine’s longevity. Use standard detergent, citric
acid or a special dishwasher cleaning agent.
The hygiene programme can be used for effective cleaning
of baby bottles and other objects that can be good to keep
extra clean. To prevent the growth of bacteria and remove
odours from chopping boards, for example, we raise
the temperature to 70°C in the main wash and final rinse
programmes. This is also ideal for thorough washing of
jars for people who make their own jam or marmalade. The
result is extra clean and hygienic.
Plastic
Self-cleaning
Hygiene
This is a programme inspired by the world of professional
dishwashers where speed is the key. The Quick Pro Wash
programme is perfect when you know that you will need the
same crockery, glasses or other utensils several times on
the same occasion.
After starting the programme and the first water intake, the
water is heated to approximately 65°C and kept there for
up to three hours. The washing cycle then starts from this
preheated stand-by mode, enabling very short programme
times down to 20 minutes.
Quick Pro Wash
We have created different dishwashing programme to meet all your needs. Choose a suitable programme and press start!
Shortcut to clean dishes
19

The normal wash programme is for daily use when
you want to clean up plates, cutlery and glasses after
the evening dinner. It removes dried-in leftovers from
your dishes as well as cleans pots and pans. With this
programme you get maximum rinse effect.
A powerful yet short programme (shorter than the wash
programme), that removes dried-in leftovers from your
dishes and provides maximum rinse effect.
Use the Rinse and Hold programme to instantly
rinse your dishes while you wait for the dishwasher to
become fully loaded.
The Lower half programme is great when you only want
to wash plates and cutlery in the lower basket. Slightly
dirty dishes can also be placed in the upper basket.
If you have cups and glasses that need washing in
the upper basket, you should use our upper half load
programme. Slightly dirty dishes can also be placed in
the lower basket.
Normal Wash
Daily programme
Rinse and Hold
Half load
Our Eco programme is intended for cleaning normally
dirty dishes and is extremely effective. It is designed to
save excessive energy and water consumption.
Eco
20
