Häfele Connect Mesh User manual

732.28.425
HDE 25.06.20
1/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
Connect Mesh 6-way Distributor
Version 1.0

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
2/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
1. Change history
Version Date Changes
1.0 • Initial Documentation

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
3/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
2. Table of Contents
1. Change history _________________________________________________________________________________________________________2
2. Table of Contents_______________________________________________________________________________________________________3
3. Connect Mesh 6-way Distributor ________________________________________________________________________________________4
3.1. General information _____________________________________________________________________________________________________4
3.2. Power Supply __________________________________________________________________________________________________________ 4
3.3. Ports _________________________________________________________________________________________________________________4
3.4. Sensor Port ___________________________________________________________________________________________________________4
Supported Sensor Models ___________________________________________________________________________________________________5
LED IR Dimmer Switch__________________________________________________________________________________________________ 5
 IR-SensorSwitchOn/O ________________________________________________________________________________________________5
Door Sensor Switch ____________________________________________________________________________________________________5
Motion Detector _______________________________________________________________________________________________________5
IR Sensor Switch ______________________________________________________________________________________________________6
IR Sensor Switch Modular _______________________________________________________________________________________________ 6
IR-Dimmer Modular ____________________________________________________________________________________________________6
Capacitive Switch ______________________________________________________________________________________________________6
Capacitive Dimmable Switch_____________________________________________________________________________________________7
Switch Door___________________________________________________________________________________________________________7
Switch Door Modular ___________________________________________________________________________________________________7
Switch Foot ___________________________________________________________________________________________________________7
Switch Rocker _________________________________________________________________________________________________________8
Switch Push___________________________________________________________________________________________________________8
3.5. Provisioning ___________________________________________________________________________________________________________8
3.6. Update Mode __________________________________________________________________________________________________________ 8
3.7. Reset_________________________________________________________________________________________________________________9
3.8. Status LED ____________________________________________________________________________________________________________9
4. Q&A __________________________________________________________________________________________________________________10

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
4/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
3. Connect Mesh 6-way Distributor
3.1. General information
Ports
Mounting holes
Status LED
Power Supply OUT Power Supply IN
Reset Button
Sensor Port
[image 3.1.1]
The Connect Mesh 6 way distributor acts as a node in your BLE Mesh network and manages connected devices
suchasLEDproductsandelectricalfurniturettings.
3.2. Power Supply
ConnectthedevicetothepowersupplybypluggingitintoaHäfeleLooxLEDDriver.Pleasenotethespecied
maximumallowedpowervaluesoftheDriverandtheConnectMesh6waydistributor.Thisinformationinuencesthe
maximum performance of the connected devices.
3.3. Ports
The Connect Mesh 6 way distributors have 6 controllable outputs and one output that outputs the supply voltage on
the input side unchanged.
3.4. Sensor Port
Each Connect Mesh 6 way distributor has a standard Loox sensor input. Hereby, various sensors can be connected
with this. This can be e.g. dimmer and switch. See the “Questions and Answers” section.

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
5/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
Supported Sensor Models
LED IR Dimmer Switch
Product number: 833.89.126
Youcantoggledevicesonandoor
dim lights by holding.
IR-SensorSwitchOn/O
Product number: 833.89.127
Youcantoggledevicesonando.
Door Sensor Switch
Product number: 833.89.128
If the sensor is covered, the signal turns
ootherwiseon.
Motion Detector
Product number: 833.89.135
The signal turns on for 30 seconds if
motionisdetectedandthenturnso
again.

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
6/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
IR Sensor Switch
Product number: 833.89.136
Youcantoggledevicesonandoby
approaching the IR-sensor on the side.
IR Sensor Switch Modular
Product number: 833.89.137
Youcantoggledevicesonandoby
approaching the IR-sensor on the side.
IR-Dimmer Modular
Product number: 833.89.129
Youcantoggledevicesonandoordim
lights by approaching the IR-sensor on
the side and or holding.
Capacitive Switch
Product number: 833.89.087
Youcantoggledevicesonandoby
touching the enclosure.

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
7/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
Capacitive Dimmable Switch
Product number: 833.89.133
Youcantoggledevicesonandoor
dim lights by touching the enclosure
constantly.
Switch Door
Product number: 833.89.059
If the sensor is pressed, the signal turns
ootherwiseon.
Switch Door Modular
Product number: 833.89.143
If the sensor is pressed, the signal turns
ootherwiseon.
Switch Foot
Product number: 833.89.046
Youcantoggledevicesonandoby
pressing the physical button.

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
8/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
Switch Rocker
Product number: 833.89.106
Youcantoggledevicesonandoby
changing the rockers state.
Switch Push
Product number: 833.89.108
Youcantoggledevicesonandoby
pressing the button.
3.5. Provisioning
TheHäfeleConnectMesh6waydistributorcanbeprovisionedwhentheredStatus-LEDonthetopsideashes.Startthe
Connect Mesh app and tap on “Add devices”. The box will be displayed in the list of devices found. Tap the icon to start
the provisioning mode. Follow the instructions in the app. After provisioning, you can assign the individual functions to the
box in the app. Read the detailed instructions for the Connect Mesh App.
3.6. Update Mode
Option 1: Update Mode Through App
• Incasethermwareisoutdated,theuserwillbenotiedinsidetheConnectMeshApp.Theretheusercanstartand
perform the update of the mesh device.
Option2:ManualUpdatebyPowerOn/O
• Start the device by connecting to the LOOX Driver while pressing the reset button.
• Switch ON/OFF the Connect Mesh 6 way distributor 4 times at consistent interval of 2 seconds each. (Attention: Wait
untiltheredstatusledisobeforeswitchingONagain).
• The status LED will light constantly signify Update Mode.
Now use the Häfele Connect Mesh App to update the device.
Option 3: Manual Update by Reset Button - press for 6 seconds
• Press the status button for 6 seconds and release it.
• This will keep the Connect Mesh 6 way distributor in update mode for 60 seconds and can be updated using the
Häfele Connect Mesh App.

732.28.425 732.28.425
HDE 25.06.20 HDE 25.06.20
9/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
3.7. Reset
Option 1: Reset by App
• In case the device is provisioned and connected to the app, the user can reset the mesh device via the Connect Mesh
App(moreinformationinthespecicHäfeleConnectMeshApp).
Option2:ManualResetbyPowerOn/O
• Switch ON/OFF the mesh device 8 times at consistent intervals of 2 seconds each. (Attention: Wait until the red status
ledisobeforeswitchingONagain.)
ThestatusLEDwillstartashingtosignifythesuccessofhardwarereset.Thisidentiesthatthedeviceisresetand
can again be provisioned.
Option 3: Manual Reset by Reset Button – press for at least 8 seconds
• Press the status button for at least 8 seconds and release it.
• This will reset the mesh device.
Now use the Häfele Connect Mesh App to provision the device.
3.8. Status LED
The status LED is located on the top of the device.
Status LED Behavior Meaning
Off TheConnectMesh6waydistributorisswitchedo.
Flashing The Connect Mesh 6 way distributor is in provisioning mode and is ready to be added
to an existing Connect Mesh network.
On The Connect Mesh 6 way distributor is either in normal operation mode or in OTA
update mode.
If it is OTA update mode, it will remain in OTA update mode for 60 seconds or until the
power is uninterrupted.

732.28.425
HDE 25.06.20
10/10
en
Subject to
alteration
© 2020 by Häfele GmbH & Co KG
Adolf-Häfele-Str. 1 · D-72202 Nagold www.hafele.com
4. Q&A
Question Answer
My RGB-LED-Band/Multi White LED-Band is
not working like it should. The control sliders
behave strangely.
Checkthechannelorderconnections.Besurethatthecongurationofthe
device channels match the order of how the device is connected.
