HACKADAY SUPERCONFERENCE BADGE User manual

HACKADAY SUPERCONFERENCE BADGE
Pasadena, 2016 Nov. 5+6 Ver 1 Rev 0

1. INTRODUCTION
Hackaday Superconference Badge is a special goft for every conference visitor. It also acts as a
hacking tool, so that everyone gets a chance to display their creativity and programming skills
during the conference. Hacking will be mainly through software, but hardware hacking is also
possible.
To program an embedded system, you normally need programmer hardware, but not in this
case - you don't need any hardware to flash your own code in MCU program memory. The
badge comes with a pre-programmed bootloader, so all you need is a USB Micro-B cable.
To keep the badge "alive" during the conference and before the hacking event, it comes with a
couple of pre-programmed applications, mainly to demonstrate some of the possibilities of the
hardware. By default, there is a Tetris game, a moving message display and an accelerometer
demo. There will be a special computer with infrared interface at the venue, which anyone can
use to load a custom message to their own badge. We encourage everyone to keep their badge
in Display mode with their own message, so that we can all enjoy the scene of hundreds of
personal moving messages running around.
We will also be hosting a challenge event. This time, the task will consist of four independent
tasks, with the special fifth task which will use all previous results to complete the final result.
Every visitor is challenged to try to solve the problem during the conference, and the first one
who gets the "Congratulations" message on their badge, will win a prize.

2. HARDWARE
The display consists of a red 8×16 LED matrix. There is also an infrared transceiver and five
tactile buttons, plus a RESET key. MCU is Microchip's 8-bit PIC18LF25K50 in 28-pin case, and the
power is supplied by two AAA batteries. There is one USB Micro-B connector and two groups of
pads, ready for connectors. One of them is 5-pole ICSP (In-Circuit Serial Programmer), and the
other one is 9-pole I/O connector.
PCB dimensions are 46×139 mm. 8×16 LED matrix is built of 128 discrete SMD LEDs and
refreshed by SCT2024CSSG constant current driver, permanently assisted by MCU. CPU clock is
48 MHz (which is 12 MIPS), so display refresh takes about 1% of processor time. Infrared
transmitter is a single 940 nm LED, and the receiver is TSOP6240TTCD, which contains a photo
detector, an AGC preamplifier, and a 40KHz band-pass filter and demodulator.
Here is the complete schematic diagram of the badge:

2. SOFTWARE
The badge comes pre-programmed with three basic firmware modules:
Bootloader, which normally stays resident and ready for loading any other .HEX
firmware via USB cable only
Kernel, which is also resident, and which may be used as a BIOS for user's application
Demo application, which is loaded by the Bootloader, and supported by Kernel. Demo
application is easily removable, so if Bootloader is used to write the new firmware,
demo application will automatically be cleared from the program memory. Of course, it
can programmed again using DEMO 2.HEX file
You can also use your PIC programmer if you wish to start programming the MCU from scratch.
That way you won't need the bootloader, but if you want to use the Kernel source file to
support your application, you’ll have to rearrange it at some critical points, predominantly its
ISR vectors. The easiest way to do it is to change its OFFSET variable, which is defined in
RAMDEF.INC file, and to comment out the line
#include <BootLoader 2b.inc>
which is in the KERNEL 2.INC file.
The whole project (hardware and all source files for all modules) is open, so you are free to use
it, copy and modify and redistribute it.
2.1. CONFIGURATION BITS
Internal RC oscillator 16 MHz (primary oscillator disabled)
PLL with 3× clock multiplier (3×16=48MHz)
System clock at 48 MHz (which is 12 MIPS operation)
Brown Out Reset disabled
Watchdog Timer disabled
MCLR pin enabled
Extended instruction set disabled
Single-Supply ICSP disabled
Background debugger disabled, B6 and B7 are I/O pins
It is possible to change configuration bits via Table Write process, but note that it may be
critical, as some other oscillator settings may render the USB interface and bootloader
unusable. In that case, the only way to unlock the unit is to reprogram it with an external
programmer.

2.2. BOOTLOADER
There is a Microchip's bootloader at MCU side, so when you connect the badge to your
computer via USB port, it is recognized as the external disc drive. However, to achieve this, you
must firs switch the badge to the bootloader mode. Here is how to do that:
Press both white buttons (RESET and ON-OFF)
Release the left button first, an the release the right button
At this moment, the LED in the top left corner of the badge should blink, and the new drive
named HackABadge should appear on your computer's screen. All you have to do is to drag and
drop the HEX file on the HackABdge icon. After the taskbar finishes its its job and disappears,
you have to start your application on the badge, by pressing the ON-OFF (the right white
button) on the badge, or simply disconnecting the USB cable.

2.3. MEMORY ORGANIZATION
PIC18LF25K50 contains 32 K (0x8000) Program Flash memory, 2 K (0x0800) Data RAM memory
and 256 (0x0100) bytes Data EEPROM memory. Program Flash memory and Data RAM memory
are directly accessible, but Data EEPROM memory acts as a peripheral device, since it is
accessed through a set of control registers.
Kernel uses Data EEPROM memory as non-volatile storage for Brightness control (1 byte) and as
a buffer for data received via the infrared communication channel (255 bytes).
2.3.1. PROGRAM MEMORY ORGANIZATION
Bootloader and kernel are integrated and they are used as the main firmware module, taking
0x3300 bytes of MCU's program space. User application must start at 0x3300 and must contain
redirection vectors for HIgh Priority ISR (Interrupt Service Routine) at the address 0x3308, and
for Low Priority ISR at the address 0x3318. By default, they should contain jumps to 0x2B08,
where the ISR routine which does most of the Kernel job is located. Low Priority ISR is not used
in this version of Kernel, so it also points to the High Priority ISR, but this jump should never
happen.
Another way is to redirect those interrupt vectors to the alternative user ISR routine, located
inside the User Code area. In that case, the new ISR code should be written, or it may act as the
expansion of the existing High Priority Interrupt.
There are a few subroutines which are available to the user. One of them is a 32-bit
pseudorandom number subroutine, with the entry point at the address 0x2B04. The execution
time for this subroutine is 79 T cycles (which is 6.6 µs), including Call to this subroutine and
Return. It uses Data RAM locations 0x730...0x733 as 32-bit SEED, and locations 0x734...0x737 as
the internal arithmetic registers. At the end, before RETURN, this subroutine XORs and ADDs all
SEED bytes to produce the pseudorandom number in W register. Also, it XORs contents of
TMR0 and TMR2 Special Function Registers in a single 8-bit random result in W register.
The following drawing represents program memory organization of the bootloader, kernel and
user application.

2.3.2. DATA RAM ORGANIZATION
Kernel uses Data RAM GPR (General Purpose Register) area locations 0x000...0x029 for
housekeeping registers. Locations 0x600...0737 are used for special purpose.
addr name bit description
0x00 KeyEdge 0 = set by kernel if key INT edge detected (user must clear)
1 = set by kernel if key LEFT edge detected (user must clear)
2 = set by kernel if key UP edge detected (user must clear)
3 = set by kernel if key DOWN edge detected (user must clear)
4 = set by kernel if key RIGHT edge detected (user must clear)
5...7 Not used
0x01 Rotor0 Used for key INT debouncer (rotate left, bit = 0 if key pressed)
0x02 Rotor1 Used for key LEFT debouncer (rotate left, bit = 0 if key pressed)
0x03 Rotor2 Used for key UP debouncer (rotate left, bit = 0 if key pressed)
0x04 Rotor3 Used for key DOWN debouncer (rotate left, bit = 0 if key pressed)
0x05 Rotor4 Used for key RIGHT debouncer (rotate left, bit = 0 if key pressed)
0x06 Flag 0 = set by kernel: Pause mode, clr by kernel: Run mode (do not modify)
1 = Timer 0 interrupt (1200 Hz) handshaking (user must reset)
2 = Full display scan (150 Hz) handshaking (user must reset)
3 = set: EEPROM RX buffer function disabled (set/clr by user)
4 = Timer 0 interrupt in 2nd phase (LED OFF period) (do not modify)
5 = set: Disable pause mode
6 = Flag that display message was received (user must reset)
7 = Not used
0x07 RXFlag 0 = set: Enable RX to RAM 0x601...0x6FF and EEprom (set/clr by user)
1 = set: RX header reception is in progress (do not modify)
2 = set: RX message reception is in progress (do not modify)
3 = set: RX message received (internal use, do not modify it)
4...7 Not used
0x08 Brightness Display PWM, user presets to 0...15 for dimming
0x09 GPreg General purpose register, may be used by user
0x0A Anode Count display multiplex column counter 0...7
0x0B BitMask 10000000...00000001, shift reg used for anode scan
0x0C T0period Total Timer 0 period, may be modified to alter scan frequency
0x0D InnerInt Loop counter, used by interrupt routine
0x0E OuterInt Loop counter, used by interrupt routine
0x0F OuterPlusInt Loop counter, used by interrupt routine

0x10 RXptr Low RXD buffer pointer (high is always =6)
0x11 RXpatience Patience counter, preset when byte received, count down
0x12 PowerOFF Auto Power Off period (×6 sec), preset here to alter timing
0x13 PowerCount Auto Power Off count down
0x14 Inner GP register, may be used by user
0x15 Outer GP register, may be used by user
0x16 Uniform (2 bytes) 150 Hz divider, count up for 6 sec timing
0x18 RXserial (2 bytes) Received serial number (binary), ready for comparison
0x1A MySerial (2 bytes) unit serial number copied from ROM address 0x100E
0x1C FSR0temp (2 bytes) Temporary FSR0 during INT
0x1E AccX ; Accelerometer X data (Little Endian, Left justified)
0x20 AccY ; Accelerometer Y data (Little Endian, Left justified)
0x22 AccZ ; Accelerometer Z data (Little Endian, Left justified)
0x1E...0x5FF User data RAM space
0x600...0x6FF RX Buffer, used by infrared port routine (bytes loaded here)
0x700...0x70F Display buffer, upper row first, bit 7 = left column (user writes here)
0x710...0x71F Aux buffer (not displayed by interrupt display refresh, used by user)
0x720...0x72F Pause display buffer (displayed only during pause)
0x730...0x733 RND seed (don't modify)
0x734...0x737 RND internal arithmetic registers (may be used for another purpose)
0x738...0x7FF User data RAM space
3. KERNEL
Kernel supports LED matrix multiplex. It also contains an initialization routine (which is normally
executed only once after RESET) and Timer 2 Interrupt routine, which should always be active.
This routine executes uniformly at 1200Hz rate in 8 steps, so it enables a 150Hz display refresh
rate. Within this routine, there is a key scanning subroutine with a debouncer and an edge
detector, and full ON-OFF-Pause control. So, MCU sleeps in Interrupt routine and user does not
have to take care of that. There is also UART RX manager, which automatically loads received
string in RX buffer (0x601-0x60E), if all conditions are met.
Frame buffer is in RAM, and everything that the user writes in 0x700-0x70F will be immediately
displayed on the LED screen. There is one more auxiliary buffer, which is not displayed and is
free to be used by the user routine. The third buffer (0x720-0x72F) is a special frame buffer
which will be displayed only in Pause mode. It may be useful for score displaying, pause symbol
or any message.

3.1. KERNEL OUTSIDE INTERRUPT
The part of kernel which is outside of the interrupt routine, is located in the file kernel.asm. It
also includes files p18lf25k50.inc (with processor definitions), macros.inc (with macro
definitions) and int.inc (the part of kernel which is executed in interrupt).
First, it presets Special Function Registers:
OSCCON and OSCCON2: Sleep mode enabled, all other bits are unchanged, as defined in
configuration words
ANSEL: all inputs all digital, except C2, which is AN14 (Note: ANSEL registers are in
BANKED address space!)
INTCON2: Internal pull-ups enabled, int0 on falling edge of PORTB,0 input. This interrupt
will be used inside TIMER 0 interrupt routine, for wake-up after sleep
WPUB: Only PortB,6 pull-up enabled (that's key1...key4 input, driven by A0...A3 output
ports)
LATx and TRISx bits preset as hardware requires
T0CON: Timer 0 defined as 8-bit timer, prescaler = 128, software interrupt on overflow.
This interrupt is used for LED display refresh support, with dynamically adjusted timing
for display dimming (LED intensity control)
T2CON: Timer 2 with 1:4 prescaler and no postscaler. Used for PWM peripheral which
generates a 40 KHz carrier for infrared transmitter. PWM peripheral is defined with
CCP2CON (which selects PWM mode) and CCP2L which defines signal/pause ratio to
approximately 50:50
TXSTA1, RCSTA1, BAUDCON1, SPBRGH1, SPBRG1: UART TX/RX programmed to 2400
baud, no parity, 8 data bits, 1 stop bit

After register presetting, program erases (presets to 0x00) all data memory, using uninitialized
Data RAM to preset RND Seed registers. Four RND Seed registers are preset with random
contents, each of them by XORing 512 bytes of Data RAM before erasing.
Next, it loads the binary serial number from program memory address 0x100E (assuming that
Offset is preset to 0x1000) to data memory 2-byte location MYserial. Every badge has its unique
serial number defined in the Bootloader, but if you want to redefine it, you can just change the
kernel definition.
Next, it loads the Brightness value from internal EEPROM at address 0x00. This EEPROM
contents will be modified every time when brightness is modified by the keyboard.
Next, it loads the display text from internal EEPROM at addresses 0x01-0xFF to data RAM text
buffer at fixed addresses 0x600-0x6FE. If the first character is 0x00 or 0xFF, it loads the default
greeting message from program memory.
At last, it enables TIMER 0 interrupt and jumps to user's program at 0x3300.
Port C2 (which is used by Bootloader to blink one LED) will be left as dummy analogue input for
the whole operating time - if you define it as output it will disturb normal multiplex operation,
and if it is digital input, the voltage on this pin will be outside the allowed range.
There is also an "rnd" subroutine which is not used by kernel, but can be used by user software.
It is a 32-bit pseudorandom generator routine, which executes function SEED = SEED *
0x41C64E6D + 0x00006073. SEED is defined as Ma0, Ma1, Ma2 and Ma3 in data memory. It also
uses arithmetic temporary registers Mc0, Mc1, Mc2 and Mc3 in data memory. At the end, this
routine XORs or ADDs all SEED registers and TMR0 and TMR2 also, to scramble the W register
and increase its entropy, so W should be considered as 8-bit random output.
3.2. KERNEL INSIDE INTERRUPT
Interrupt nesting is disabled, so both the External Interrupt 0 (INT key) and TIMER 0 use the
same Interrupt vector 0x0008, which is redirected to 0x2B08 by the bootloader routine.
Routine first tests INTCON,INT0IF bit to determine if the interrupt was caused by INT0 (kernel
will not allow such external interrupts except inside TIMER 0 interrupt during processor
sleeping, but this test is executed in case user uses it for some purpose). By default, this is a
dummy interrupt routine, as it does nothing except reset the interrupt flag.

If the interrupt was triggered by TIMER0 overflow, the routine first presets TMR0L counter to
desired timing until the next overflow. This timing depends on the Brightness register, which is
in range 0x00 (lowest intensity) to 0x0F (highest intensity). As PWM regulation is used, one
Anode period (or 1/8 of total display refresh cycle) contains two interrupts: ON period, and OFF
period. Flag,4 is toggled at every interrupt, and it determines if ON or OFF cycle is in progress.
In the first cycle, one Anode is active, and in the second one, all Anodes are OFF. Both timings
are determined by register Brightness: ON period is (Brightness+1) × 52µs, and OFF period is
(16-Brightness). The whole period is always 833 µs. Individual timings for each Brightness
setting is read from lookup table, so that the intensity regulation is approximately logarithmic.
If Pause flag (which is in Flag,0) is reset, display routine will output Buffer (16 bytes), and if it is
set, BufferPause (16 bytes) contents will be output.
After display driving, Interrupt routine tests all keys (except for the Reset key, of course).
Debouncer uses registers ROTOR0...ROTOR4, to shift left each key input. If ROTORx state is =
11111110, the falling edge is detected and debounced (after seven "key off" states) so one of
bits 0...4 in register KeyEdge will be set. If user routine has to test if some key was JUST pressed
(signal transition from HIGH to LOW), it should test one of those bits and reset it after it detects
that it was set (it is not automatically reset). If user routine has to test if some key is
permanently pressed, it has to test bit 0 in one of ROTOR0...ROTOR4 registers. It is NOT
recommended to test port pins directly (except for the INT key), as keys 1...4 have only one
common input.
Special test is made for Left+Right+Up and for Left+Right+Down keys, as those combinations
are used for display brightness adjusting. Left and Right key are tested for permanent pressing
(bit 0 in Rotor1 and in Rotor4), and Up and Down keys for edge detection (bit 2 and 3 in
KeyEdge register), so it is required that user holds down keys Left and Right at the same time,
and presses keys Up and Down to adjusts brightness. If those conditions are met, the new
Brightness contents are written in Eeprom, at address 0x00. After the Reset condition, on
power up, kernel will return this value in register Brightness.
Key INT has a special function. When pressed (which is still not detected via Interrupt process,
but via simple polling), kernel will set the Pause flag (which is in Flag,0) and display routine will
redirect from Buffer (16 bytes) to BufferPause (16 bytes) contents.
If Pause flag is already set and INT key is pressed, kernel will execute Sleep process. It will
switch off all anodes and power supply to all external devices, then pull all other outputs low.
Then it will reset INTCON,INT0IF flag, to avoid false wake up and INTCON,TMR0IE. It will also set
INTCON,INT0IE to enable wake-up. Then it will enter sleep mode. So it slleps inside the
interrupt routine.

When the INT key is pressed again, external interrupt will wake up the processor and kernel will
execute all operations in the inverse order and sense. As external interrupt is impossible to
debounce by software, special test is made before sleeping and after wake-up to ensure that
INT key is OFF (200ms before and 50 ms after sleeping).
If RXFlag,0 is set by user software, then kernel will automatically receive bytes from the infrared
port and write them to the RX input buffer, which is in data RAM, at addresses 0x600...0x6FE. If
a string longer than 254 bytes is received, only the first 254 bytes will be detected, and the rest
will be ignored.
Message header contains ASCII "[", one to five ASCII digits (which represent recipient's serial
number in decimal form) and ASCII"]". So, header can vary from [0] to [65535]. Only if RXFlag,0
is set, valid header is detected and if the serial number matches, the message will be received,
otherwise it will be ignored. When the new message is received, the old one is automatically
cleared.
Message terminator is pause, which is at least 200ms long. At the end of the the message,
terminator 0x00 will be inserted automatically to the received string in data memory. Thus, the
maximal message is 255 bytes, although the maximal received message is 254 bytes. Header is
not written, so it should not be counted in maximal message length.
At the same time, while the message is written in Data RAM, it is also written in EEPROM, at
locations 0x01...0xFF (EEPROM location 0x00 is used for brightness setting).
This process of message reception is used in the moving message demo application. Message
can be transferred from the computer via the infrared terminal and it will be received by
moving message firmware and immediately displayed.
Some aspects described here are represented on the following drawing:
