Haden 198136 User manual
Product Code: 198136
STEAM IRON
INSTRUCTION MANUAL
www.haden.com
SAFETY INSTRUCTIONS
When using electrical appliances, the following basic safety
precautions should always be taken.
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
•Children should be supervised to ensure that they do not play with
the appliance.
•Cleaning and user maintenance shall not be made by children
without supervision.
•Keep the appliance and its mains cord out of the reach of children
younger than 8 when the appliance is switched on or is cooling
down.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or a similarly qualified person.
•Keep the appliance and its mains cord out of the reach of children
when the appliance is switched on or is cooling down.
•Never use the appliance if it is damaged in any way.
•Remove the plug from the socket before filling the iron with water
or pouring out the remaining water after use. Always use the cup
provided to fill with water.
•Never immerse the iron in water.
•When you have finished ironing or leave the iron for a short period
of time;
- set the variable steam knob to the position of no steam;
- stand the iron upright;
- remove the mains plug from the wall socket.
Note: the soleplate may become damaged if the iron is stored
with the soleplate facing downwards.
www.haden.com
•Some parts of the iron have been slightly greased and as a result
the iron may smoke slightly when switched on for the first time.
After a short time, the smoking will cease.
•Before using for the first time remove any sticker or protective foil
from the soleplate. Clean the soleplate with a soft cloth.
•Do not put vinegar or other descaling agents into the water
reservoir.
•Do not use chemically descaled water.
•The cord-set should not be allowed to touch the hot soleplate.
•Do not use the appliance if the plug, cord or the appliance itself
shows visible damage or if the appliance has been dropped or is
leaking. For electrical safety, any repairs to the appliance must be
carried out by a qualified electrical engineer only.
•This is an attended appliance. Never leave the iron unattended
when in use.
•Always use and rest the iron on a stable, level, heat resistant
surface.
•Burns can occur from touching the hot sole plate, hot water or
steam.
•To protect against injury never iron or steam fabrics whilst they
are being worn.
•To protect the cord do not wind it tightly when stored and avoid the
cord rubbing or touching the hot sole plate in use.
•This appliance is intended for household use only and not for
commercial, industrial or outdoor use.
•Never leave the appliance unattended when in use.
•Please ensure the wall outlet in your house is well earthed.
www.haden.com
KNOW YOUR IRON
A. Spray Nozzle F. Temperature Indicator
B. Water Filler Cap G. Temperature Dial
C. Steam Control Dial H. Water Tank
D. Spray Button I. Soleplate
E. Steam Burst Button
www.haden.com
BEFORE USE
Some parts of the iron have been slightly greased. When the iron is
used for the first time you may notice a slight emission of smoke and
heat some sound made by the expanding plastics. this is quite normal
and it stops after a short period of time.
Remove any stickers, protective foil or storage cover from the sole
pate.
Textile which has been applied (gloss, crinkle relief etc. is best ironed
at lower temperatures and on the reverse.
Sort the laundry to be ironed according to the international symbols
on the garment label or if this is missing, according to the fabric type.
FILLING WITH WATER
Never immerse the iron in water.
1. Make sure the appliance is unplugged.
2. Set the steam control to the “No Steam” position.
3. Tilt the iron backwards.
4. Open the water filler lid.
5. Fill the water tank with tap water. However, if the water in your
area is very hard, it’s advisable to use distilled water.
Do not fill the water tank beyond the MAX indication.
Do not put perfume, vinegar, starch, descaling agents, ironing aids or
other chemicals in the water tank.
6. Close the water filler cap.
7. When your finished ironing, empty the water tank. Do not store
the iron with water in the tank.
www.haden.com
HOW TO USE
SETTING THE TEMPERATURE
1. Place the iron on its heel.
2. Check the laundry care label for the required ironing
temperature and then turn the temperature dial to align with
the appropriate fabric type on the iron according to the
following:
• Synthetics
•• Silk, Wool
••• Cotton
MAX Linen
If you do not know what kind of fabric an article is made of, you
will need to determine a suitable ironing temperature by ironing
a part that will not be visible when worn.
If the fabric contains several kinds of fibres, always select the
temperature most applicable. If a garment contains 60%
polyester and 40% cotton, you must always choose the material
requiring the lowest temperature i.e. Polyester
Silk, woolen and synthetic materials; iron the reverse side of the
fabric to prevent shiny patches. Avoid using the spray function to
prevent stains.
Start ironing garments that require the lowest ironing
temperature, such as those made of synthetic fibres.
3. Plug the iron into an earthed wall socket, and the temperature
light goes on.
4. When the temperature light goes out, wait a while before you
start ironing.
The temperature light will go on and off during ironing, this is
normal.
www.haden.com
STEAM IRONING
1. Make sure that there is enough water in the water tank.
2. Select the recommended ironing temperature
3. Plug the iron into the mains
4. Steam ironing is only possible when the temperature setting
is set to ●●● or MAX. Otherwise, hot water may escape
through the soleplate.
5. After the temperature light has gone out, set the steam
control to the appropriate steam position. The iron will start
steaming as soon as the set temperature has been reached.
6. Keep the material to be ironed very smooth and avoid
running the iron over metal or foreign objects, such as;
buttons, zips, etc.
7. When the ironing is finished or during breaks, place the iron
in an upright position.
8. Disconnect the iron from the mains supply and pour out any
remaining water and leave the iron to cool off.
IRONING WITHOUT STEAM
1. Set the steam control to “No steam” position
2. Select the recommended ironing temperature
SPRAYING
You can use the spray function to remove stubborn creases at any
temperature.
1. Make sure that there is enough water in the water tank.
2. Press the spray button several times to moisten the article to
be ironed
www.haden.com
BURST STEAM
This function provides extra steam to remove very stubborn creases.
1. Set the temperature dial to the MAX position and wait until
the temperature light has gone out.
2. Press the Burst of steam button to produce extra steam. Wait
a few seconds for the steam to penetrate the material before
pressing again. For the best steam quality, do not use more
than three successive bursts each time.
3. Excessive use of this feature will cause the iron to cool, wait
at least 1 minute before using this function again to prevent
water from dripping out of the sole-plate. Always ensure that
you consider the temperature setting for the type of fabric
being ironed. To prevent water leaking from the soleplate, do
not keep the steam control button depressed for more than 5
seconds.
CLEANING
•Before cleaning remove the mains plug from the wall socket
and allow the iron to cool down sufficiently.
•Scale and other residue can be wiped off the soleplate with a
damp cloth and some non-scratching proprietary cleaner.
STORAGE
•Before storing remove the mains plug from the wall socket
and allow the iron to cool down sufficiently.
•Pour any remaining water out of the water reservoir, taking
care to avoid splashing as the water may still hot.
•Set the steam lever to the no steam position.
•Stand the iron upright before storage.
012
www.hadenappliances.com
WASTE ELECTRICAL RECYCLING
This symbol indicates the product is classed as
Electrical or Electronic Equipment and should
not be disposed of with other household waste.
The Waste Electrical and Electronic (WEEE)
Directive has been
introduced across the EU:
•to recycle waste electrical products using the
best available recovery and recycling
techniques in order to minimise the
•impact on the environment
•to treat any hazardous substances and
•to avoid increasing landfill.
WEEE product should be disposed of by
handing it over at a designated collection point.
For more information about where you can
drop off your waste product for recycling please
contact your local authority.
Warranty
This product is guaranteed for two years from the date of original
purchase. Proof of purchase will be required.
The guarantee is subject to the following provisions:
•Doesn’t cover accidental damage, misuse, unit parts, knobs or
consumable items.
•The product must be correctly stored and operated in
accordance with the instructions contained in this manual.
•Product must be used solely for domestic purposes
The guarantee will be rendered invalid if the product is re-sold or if
damaged by an inexpert repair.
Specifications are subject to change without prior notice. The
manufacturer disclaims any liability for incidental or consequential
damages.
The guarantee is in addition to, and does not affect your statutory or
legal rights
TECHNICAL DETAILS
Model Steam Iron
Rated Voltage 220V - 240V 50 – 60HZ
Rated Power 1600-2000W
Protection Class I
