Haier Access Plus User manual

(Appearance May Vary per Model)
Dual Zone Freezer
Congélateur a Deux Zones
Congélador Doble Compartimiento
User Manual
Model # LW110 / LW120 / LW150
Guide de l’Utilisateur
Modéle # LW110 / LW120 / LW150
Manual del Usuario
Para Modelo de # LW110 / LW120 / LW150
Quality • Innovation • Style

SAFETY PRECAUTIONS
Read all of the instructions before using this appliance. When
using this appliance, always exercise basic safety precautions,
including the following:
1) Use this appliance only for its intended purpose as described in this use
and care guide.
2) This freezer must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
3) Never unplug your freezer by pulling on the power cord. Always grasp
the plug firmly and pull straight out from the outlet.
4) Repair or replace immediately, all electric service cords that have
become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the connector
end.
5) Unplug your freezer before cleaning or before making any repairs.
Note: If for any reason this product requires service, we strongly
recommend that a certified technician performs the service.
6) Do not use any electrical device or any sharp instrument in
defrosting your freezer.
7) If your old freezer is not being used, we recommend that you remove
the doors and leave the shelves in place. This will reduce the possibility
of danger to children.
8) After your freezer is in operation, do not touch the cold surfaces in the
freezer compartment, particularly when hands are damp or wet. Skin
may adhere to these extremely cold surfaces.
9) Do not refreeze foods, which have been thawed completely.The United
States Department of Agriculture in Home and Garden Bulletin No. 69
reads: "…You may safely refreeze frozen foods that have thawed if they
still contain ice crystals or if they are still cold-below 40˚F".
"…Thawed ground meats, poultry, or fish that have any off-odor or off-
color should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat."
"…Even partial thawing and re-freezing reduce the eating quality of
foods, particularly fruits, vegetables, and prepared foods. The eating
quality of red meats is affected less than that of many other foods. Use
refrozen foods as soon as possible, to save as much of its eating quality
as you can."
English
1

Thank you for using our Haier
product. This easy-to-use manual
will guide you in getting the best
use of your freezer.
Remember to record the model and
serial number. They are on a label
in back of the freezer.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain
warranty service.
2
10) This freezer should not be recessed or built-in an enclosed cabinet. It
is designed for freestanding installation only.
11) Do not operate your freezer in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
For Future Use
DANGER
Risk of child entrapment. Before you throw away your old
refrigerator or freezer,take off the door. Leave the shelves in
place so that children may not easily climb inside.
English

Table Of Contents
PAGE
Safety Precautions ..........................................................................1
Parts And Features .........................................................................4
Installing Your Freezer ....................................................................5
Unpacking Your Freezer ......................................................................5
Adjusting Your Freezer..........................................................................5
Proper Air Circulation...........................................................................5
Electrical Requirements.........................................................................6
Use of Extension Cord .........................................................................6
Installation Limitation ...........................................................................6
Freezer Features And Use ..............................................................7
Operating Your Freezer ........................................................................7
General Features ................................................................................7
Fast Freeze ..........................................................................................7
Defrosting And Draining ......................................................................8
Installing Casters..................................................................................8
Food Storage Information ....................................................................9
Normal Operating Sounds ..................................................................9
Proper Freezer Care and Cleaning..............................................10
Cleaning and Maintenance ................................................................10
Power Interruptions ............................................................................11
Vacation and Moving Care ................................................................11
Troubleshooting ............................................................................12
Warranty Information....................................................................13
3
English

LW120W
LW120GBC
LW150W
LW110B
Casters
2Baskets
Security Lock
Fast Freeze
Power On Light
Grip Handle
LW110W
Parts And Features
4
1. Food Basket
(quantity may vary per model)
2. Bottom Freezer Drawer
3. Handle
4. Casters (quantity 4)
(not in all models)
5. Fast Freeze (orange light switch)
(not in all models)
6. Temperature Control Adjustment
7. Power ON Light (green light)
(not in all models)
8. Lock and Key (not in all models)
1
2
3
4
5
6
7
(Appearance and Features may vary by model)
8
•••••
•
••
••• ••
•••••
••
English

1. Remove all packaging material. This includes the foam base and all
adhesive tape holding the freezer accessories inside and
outside.
2. Inspect and remove any remains of packing, tape or printed
materials before powering on the freezer.
• Your freezer is designed for freestanding installation only.
It should not be recessed or built-in.
•Place the freezer on a floor strong enough to support it fully loaded.
• When moving the freezer,never tilt it more than a 45-degree angle.
This could damage the compressor and the sealed system.
• If the freezer is tilted let it stand in an upright position for at least 24
hours prior to plugging. This is to allow the refrigerant to settle.
• To assure your freezer works at the maximum efficiency it
was designed for, you should install it in a location where there
is proper air circulation, plumbing and electrical connections.
• The following are recommended clearances around the refrigerator:
Sides……………4" (102mm)
Top....................4" (102mm)
Back..................4" (102mm)
Installing Your Freezer
Unpacking Your Freezer
Adjusting Your Freezer
Proper Air Circulation
5
English

6
Electrical Requirement
•Make sure there is a suitable power Outlet (115 volts, 15 amps out-
let) with proper grounding to power the freezer.
• Avoid the use of three plug adapters or cutting off the third grounding
in order to accommodate a two plug outlet. This is a dangerous prac-
tice since it provides no effective grounding for the freezer and may
result in shock hazard.
• Avoid the use of an extension cord because of potential safety haz-
ards under certain conditions. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade grounding
plug and a 3-slot outlet that will accept the plug. The marked rating
of the extension cord must be equal to or greater than the electrical
rating of the appliance.
• Do not install your freezer in any location not properly insulated or
heated e.g.garage etc. Your freezer was not designed to operate in
temperature settings below 55˚ Fahrenheit.
• Select a suitable location for the freezer on a hard even
surface away from direct sunlight or heat source e.g.radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness
should be corrected.
Install Limitations
Use of Extension Cord
English

Freezer Features And Use
General Features
Adjustable temperature dial:
Your freezer will automatically main-
tain the temperature level you select.
The temperature control dial has 6 set-
tings plus OFF. “I” is the warmest, “6”
is the coldest. Turning the dial to OFF
stops cooling the freezer. Set the dial
to “3” and allow 24 hours to pass
before adjusting the temperature to
your needs.
(Note: If the freezer has been
placed in a horizontal or
tilted position for any period
of time wait 24 hours before
plugging the unit in.)
7
•Once the freezer is in its proper place, plug it in an electrical outlet
having 115 volts and 15 amps.
• Set the temperature, on the temperature control knob. “1” being the
warmest and “6” being the coldest. Initially set the temperature on
“3”. Place food inside the freezer. After using the freezer for 24 hours
set the freezer to your desired setting.
• In case you unplug your freezer or experience an electrical outage,
allow 5 minutes before plugging it back in.
• Temperature should be 0˚F (-18˚C) or below in the upper compart-
ment and range from 5˚F to 20˚F in the drawer section.
Operating Your Freezer
• Your freezer may be equipped with a Fast Freeze switch (orange
switch), which will allow you to deep freeze food when you have
added a lot of food at one time. Flip the orange Fast Freeze switch on
and the compressor will run continuously. Turn off the Fast Freeze fea-
ture once food has reached desired temperature.
Note: Do not forget to turn off the fast freeze switch when not
required. Doing so will avoid unnecessary energy use.
Fast Freeze (not in all models)
The upper compartment is recommended for deep freezing long term
storage. It is for such items as meat, poultry and fish.
The lower compartment operates at a higher temperature than that of
the upper compartment, making it ideal for short term frozen storage
such as frozen prepared foods, ice cream and other frequently used
food products. Due to the higher temperature, the bottom compartment
is not recommended for long term storage as it will decrease storage
shelf life.
Your Freezer Provides Dual Zone Storage
English

•Defrost whenever the frost becomes 1/4" thick. Never use a sharp or
metallic instrument to remove the frost as it may damage the cooling
coils. (A punctured coil will void the warranty)
• Turn the temperature control to OFF position and unplug the unit.
Defrosting usually takes a few hours. To defrost faster keep the
freezer door and drawer open.
• Wipe the interior of the freezer and replace the electrical plug in
the electrical outlet.
•Reset the temperature control to the desired setting.
• Casters are to be installed on the 4 bottom corners. Slide caster in the
provided slot. Once the caster is in place, secure it with a provided
screw.
Note: 1Phillips Head screwdriver required.
• Your freezer has a lock and key feature to secure the freezer. Close
the lid and turn key to lock. Turn key in opposite direction
to unlock.
8
Defrosting and Draining The Freezer
Installing Casters (not in all models)
Lock and Key (not in all models)
Screw
English

9
Frozen Food:
•Wipe containers before storing to avoid needless spills.
• Hot food should be allowed to cool before storing in the freezer.
This will prevent unnecessary energy use.
• When storing meats, keep in the original
packaging or rewrap as necessary.
• Proper freezer storage requires correct packaging. All foods must be
in packages, which do not allow the flow of air or moisture in, or out.
Improper storage will result in odor and taste transfer and will result
in the drying out of the improperly packaged food.
•Follow package or container instructions for proper storage.
•Packaging Recommendations:
Plastic containers with air tight lids
Heavy duty aluminum foil
Plastic wrap made from saran film
Self-sealing plastic bags
•Do not refreeze defrosted/thawed foods.
•It is recommended that the freezing date be marked on the packag-
ing.
Food Storage Information
•Boiling water, gurgling sounds or slight vibrations that are the result
of the refrigerant circulating through the cooling coils.
•The thermostat control will click when it cycles on and off.
Normal Operating Sounds You May Hear
English

10
Proper Freezer Care and Cleaning
Cleaning and Maintenance
Door Gaskets:
Warning: To avoid electric shock always unplug your
freezer before cleaning. Ignoring this warning may result
in death or injury.
Caution: Before using cleaning products, always read and
follow manufacturer’s instructions and warnings to avoid
personal injury or product damage.
General:
• Prepare a cleaning solution of 3-4 tablespoons of
baking soda mixed with warm water. Use sponge or soft
cloth, dampened with the cleaning solution, to wipe
down your freezer.
•Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlo-
rine bleach,concentrated detergents, solvents or metal
scouring pads. Some of these chemicals may
dissolve, damage and/or discolor your freezer.
• Clean door gaskets every three months according to
general instructions. Gaskets must be kept clean and
pliable to assure a proper seal.
• Petroleum jelly applied lightly on the hinge side of
gaskets will keep the gasket pliable and assure
a good seal.
English

11
•Occasionally there may be power interruptions due to thunderstorms
or other causes. Remove the power cord from AC outlet when a
power outage occurs. When power has been restored, replug power
cord to AC outlet. If outage is for a prolonged period, inspect and
discard spoiled or thawed food in freezer. Clean freezer before
reusing.
•For long vacations or absences, empty food from freezer, move the
temperature DIAL to the OFF position and clean the door gaskets
according to "General cleaning" section. Prop door open, so air can
circulate inside. When moving always move the freezer
vertically. Do not move with the unit lying down. Possible damage to
the sealed system could occur.
Power Interruptions
Vacation and Moving Care
English

12
Freezer Does Not Operate:
•Check if thermostat control is in the “OFF” position.
•Check if freezer is plugged in.
• Check if there is power at the ac outlet, by checking the
circuit breaker.
• Wait for 30-40 minutes to see whether freezer will start. Compressor
cycle must be complete to operate.
Food temperature appears too warm:
•Frequent door and drawer openings.
• Allow time for recently added warm food to reach
freezer temperature.
•Check gaskets for proper seal.
•Adjust temperature control to colder setting.
Food temperature is too cold:
•If temperature control setting is too cold, adjust to a warmer setting
and allow several hours for temperature to adjust.
Freezer runs too frequently:
•This may be normal to maintain constant temperature during
high temperature and humid days.
• The door or drawer may have been opened frequently or for an
extended period of time.
•Check gasket for proper seal.
•Check to see if the door or drawer is completely closed.
• Check freezer compartment for blockage from
frozen food packages, containers, etc.
Freezer has an odor:
•Interior needs cleaning.
•Foods improperly wrapped or sealed are giving off odors.
TroubleShooting
English

13
Limited Warranty
What is covered and for how
long?
This warranty covers all defects in
workmanship or materials for a period
of:
12 months labor (In Home Service)
12 months parts
5years sealed system
The warranty commences on the date
the item was purchased and the origi-
nal purchase receipt must be presented
to the authorized service center before
warranty repairs are rendered.
EXCEPTIONS: Commercial or
Rental Use warranty
90 days labor (carry-in only)
90 days parts
No other warranty applies
What is covered.
1. The mechanical and electrical parts,
which serve as a functional, purpose
of this appliance for a period of 12
months. This includes all parts
except finish, and trim.
2. The components of the sealed sys-
tem e.g. hermetic compressor, con-
denser and evaporator from manu-
facturing defects for a period of 5
years from the date of purchase.
Any damages to such components
caused by mechanical abuse or
improper
handling or shipping will not be
covered.
What will be done?
1. Wewill repair or replace, at our dis-
cretion any mechanical or electrical
part which proves to be defective in
normal usage during the warranty
period so specified.
2. There will be no charge to the
purchaser for parts and labor on
any covered items during the initial
12
month period. Beyond this period
only parts are covered in the remain-
ing warranty. Labor is not provided
and must be paid by the customer.
3. Contact your nearest authorized
service center. For the name of the
nearest service center please call
1-877-337-3639
THIS WARRANTY COVERS
APPLIANCES WITHIN THE
CONTINENTAL UNITED STATES,
PUERTO RICO AND CANADA.
IT DOES NOT COVER
THE FOLLOWING
Damages from improper installation.
Damages in shipping.
Defects other than manufacturing.
Damage from misuse, abuse, accident,
alteration, lack of proper care and
maintenance or incorrect current or
voltage.
Damage from other than household
use.
Damage from service by other than an
authorized dealer or service center.
Decorative trims or replaceable
lightbulbs.
Transportation and shipping.
Labor (after the initial 12 months).
THIS LIMITED WARRANTY IS GIVEN IN
LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR, INCLUDING THE
WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR
PURPOSE
The remedy provided in this warranty is
exclusive and is granted in lieu of all
other remedies.
This warranty does not cover incidental
or consequential damages, so the
above limitations may not apply to
you. Some States do not allow limita-
tions on how long an implied warranty
lasts, so the above limitations may not
apply to you.
This warranty gives you specific legal
rights, and you may have other rights,
English

LW110/LW120LW150-03
Issued: February 05
IMPORTANT
Do Not Return This Product To The Store
If you have a problem with this product, please contact the "Haier Customer Satisfaction
Center" at 1-877-337-3639.
DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE
IMPORTANT
Ne pas Réexpédier ce Produit au Magasin
Pour tout problème concernant ce produit, veuillez contacter le service des
consommateurs ‘Haier Customer Satisfaction Center’au 1-877-337-3639.
UNE PREUVE D’ACHAT DATEE EST REQUISE POUR BENEFICIER DE LA GARANTIE.
IMPORTANTE
No regrese este producto a la tienda
Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al
Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A).
NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA
115V,60 Hz
Made in China
Fabriqué en Chine
Hecho en China
Haier America
New York, NY 10018
Printed in China
RF-9999-130
