Microwave oven
SERVICE MANUAL
Models
EA-1770M
EA-1770MG
 Features
 Safe to use
The door adopts unique anti-choke structure and integrated punch forming, and thus
effectively prevents the microwave from leaking.
It is controlled by two-step interlock switch.The power will be switched off automatically
when the door is open,therefore it is much safer to use.
 Shining appearance
The door shell and operation panel frame shell adopt imported high-quality stainless steel material,
and will never get rust and change color. It has modern appearance and superior quality,and thus
becomes the best choice for the household microwave oven.
 High-temperature grill
It has two-step grill function ,and can grill food quickly and high-efficiently.It has
two-step’’microwave+grill”combined grill function, and can produce perfect grill food.
Serial Number: 0050501770 Version:00.00 Edition: 2005-11-16

- 1 -
Contents
Contents
1. Contents……………..…………………………………………………………………1
2. Product Code illumination and Series Introduction……………………...…...2
3. Specifications……..…………………………………………...………………….3
4. Safety Precaution…………………………………………..………………………4
5. Warning and Cautions……………………………………………………………..5
6. Installation and Accessory Parts…………………………………………………8
7. Parts and Functions………………………………………………………………..10
8. Maintenance Service and Trouble Shooting…………………………………...11
9. Circuit Diagram and Circuit Explanation………………………………………..22
10.Exploded View and List of Parts……………………………………………………24

- 2 -
Product Code illumination and Series Introduction
2.Product Code illumination and Series Introduction
Model Identification
E□-□□ □□ □□□
A BC D E F G
A: E ――For Europe.
B: Appearance feature
C: Code name of Nominal cavity capacity.
22—means the cavity capacity is 22 liter,
17—means the cavity capacity is 17 liter,
24--- means the cavity capacity is 24 liter,
D: One tenth of the microwave output power consumption.
E: Code name of operation pattern: E means the operation pattern is electronic,
M means the operation pattern is mechanical.
F:Function code:G---with grill
G:Type of cavity: S—stainless steel default--painted
Examples:
EA-2O8OM
-It represents made for Europe mechanical microwave oven without grill , the cavity
capacity is 20 liter , the microwave output power consumption is 800 Watts.
A appearance.
EA-1770M
-It represents made for Europe mechanical microwave oven without grill , the cavity
capacity is 17 liter , the microwave output power consumption is 700 Watts.
A appearance.
EB-2485EG
-It represents made for Europe electronic microwave oven with grill , the cavity capacity is
24 liter , the microwave output power consumption is 850 Watts. B

- 3 -
appearance
specifications
Item Description
Model EA-1770M EA-1770MG
Power source ～230V/50Hz ～230V/50Hz
Input Power consumption 1200W 1200W
output Power consumption 700W 700W
Power consumption
For grill -------- 1000W
Oscillating frequency 2450MHz
Timing range 30’
Power level 5 6
Unit Dimension
(W×D×H)mm
345×449×259 345×449×259
Cavity Dimension
(W×D×H)mm
290×284×180 290×284×180
Carton Dimension
(W×D×H)mm
382×508×333 382×508×333
Volume/
effective volume 17L 17L
Weight(unit/carton) 12.3Kg 12.5Kg
Accessories Instruction manual ,glass tray, turn
plate-bracket groupware, turn axis
4.Specifications

- 4 -
Safety Precaution
5.Safety Precaution
Only professional technicians can do the maintenance. Please refer to the proper
maintenance procedures in the service manual for safe operations, so as to avoid
unexpected injury.
Points of attention during maintenance:
1.Do not operate the microwave oven while the door of the oven is open.
2.Please check following before operation: (1) the door lock is flexible; (2) the door
works well in opening and closing; (3) the door is sealed well (without deforming and
bending); (4) identify any damage and loosening of the components and accessories;
(5) identify damages owing to abnormal usage or dropping.
3.Please confirm that the magnetron, microwave conductor pipe and wire are installed
and connected well before switch on the power to do maintenance or check the
functional components.
4.In case that the door lock, seal gasket, microwave radiating and transmission system
are damaged, or something wrong in debugging, please make repair, replacement or
adjustment according to the requirement of this manual before usage.
Components detachable that may
touch voltage higher than 250V Components that may cause excessive microwave leakage
1.Magnetron
2.High-voltage transformer
3.High-voltage capacitor
4.High-voltage diode
5.AK rectifier
1.The magnetron is not properly installed on the
wave guide;
2.The door hook, door body and the up/down
hinge are not properly adjusted;
3.The door body or the shell is damaged;
The above reasons may cause excessive
microwave leakage.
During maintenance, the technicians shall pay attention that:
Attention
Microwave radiation
Do not expose to the radiation emitted by the microwave generator or other parts
transmitting the microwave.

- 5 -
Warning and Cautions
6.Warning and Cautions

- 6 -
Danger Warning
Danger
Attention
Do not use the microwave oven for purposes
other than for cooking food.
Do not cook eggs in their shell as they may
burst.
warning
Do not apply excessive force to the door.
It may cause distortion of the door and
result in microwave leakage.
warning
warning
Electric
shock
hazard
Do not use a metal rod to enter the interlock
switch hole on the front side of the cavity.
interlock switch hole
No
dismantle
Danger
This appliance must be earthed.
Remember to clear away excess grease
form the inside the cavity. Otherwise it may
cause smoke or fire during heating.
Do not use sealed containers. For those
foods with skin, please prick holes on the
skin.
warning
warning
warning
safe and
reliable
Warning and Cautions

- 7 -

- 8 -
Warning and Caution
POINTS OF ATTENTION
Not like the other household appliances, the microwave oven is a kind of
high-voltage appliance. Although common operations will not risk the user in
hazard, please operate it carefully.
1.Do not use duplex receptacle in usage and maintenance.
2.Do not touch any components and circuit when the microwave is running.
3.Be sure to switch off the power before you touch the inside structure of the oven.
4.The high-voltage capacitor may still maintain electricity even 30 seconds after the
microwave oven stops working. To make replacement or checking at this time, be sure
to use insulated screwdriver to short out the two ends of the capacitor and discharge
the stored electricity.
5.Prevent the wristwatch from touching the microwave oven.
6.Do not operate the microwave oven when there is no food or water inside.
7.Protect the seal gasket and front board of the oven door from damage.
8.Do not put metal tools on the magnetron.
9.Do not put any items into the hole of the door lock or the door lock switch.
10. Confirm that the magnetron is installed properly and firmly.
Only professional technicians can do the maintenance of this
microwave oven.

- 9 -
Installation and Accessory Parts
7.Installation and Accessory Parts
7.1 Installation
attention
Do notinstall the microwave oven in
an environment that is humid or with
high temperature.
Attention
7.2 key Point In Installation Adjustment
Please read following before installation.
7.2.1 Install the microwave oven
1. Clear all of the items inside the oven, then wipe the cavity with wet soft cloth. Check if
the door is even, and if there’s damage on the inner/outer side of the door.
2. The microwave oven, the food and the cooking tools shall be placed on firm and stable
table, desk or shelf. During delivery please note that the side with control panel is much
heavier.
3. Do not block the ventilation hole and air inlet. Otherwise it may damage the oven or
cause poor cooking. Confirm that the oven shelf is placed properly to guarantee the
ventilation.
4. Avoid high temperature and vapor. Protect the appliance and the mechanical part from
damages.
5. The ambient temperature shall be lower than 40℃.
6. The plane bearing the oven shall be even and firm.
7. Keep the microwave oven away from the TV, radio, computer, etc. to avoid
interference.
7.2.2 Installation of the earth wire
The microwave oven must be earthed before use. Please pay special attention on that.
Warning: This microwave oven must be earthed.
Installation and Accessory Parts

- 10 -
Hint:
Connect the wires as indicated below:
The yellow/green wire is earth wire; the blue wire is null wire; the brown wire is live wire.
If the colors of the wires are not in accordance with the power source terminals, please
operate as per below:
Connect the yellow/green wire to the wire marked with “E” or the green wire; connect the
blue wire to the wire marked with “N” or the black wire; connect the brown wire to the
wire marked with “L” or the red wire.
7.3 Accessory parts

- 11 -
Ventilationspaceis required in installation
of the microwave oven. Do not install the microwave oven in
environment that is humid or with high
temperature.
Openthe
carton user's
manual
card
guarantee
certificate
bakingmesh
glass rotarytray
rotarytraysupport
Install
Put the microwave oven levelly at the
position you choose. Keep good
ventilation.
Select independent special socket,
with current at least 10A. Be sure to
grounditreliable.
The gaps shallbe all above 15cm
attention attention
Installation Environment
Open the Package Carton* Installation

- 12 -
Parts and Functions
8.Parts and Functions
name of part
waveguide cover
cavity
Door contro
panel
door seal
door hook hole of door hook
(only for EA-1770MG)
baking
mesh
glassrotary
tray
tray support
diagrammtic sketch for
the accessory installation
turnaxis

Maintenance Service and Trouble Shooting
9.Maintenance Service and Trouble Shooting
9.1SERVICE GUIDE AND REPLACING PARTS
9.1.1 Tools and gauges
9.1.2 Necessary tools 9.1.3 Necessary gauges
Generally, the tools used in maintenance of (1) Universal meter
the TVs are suitable for the maintenance of (2) Microwave leakage detector:
the microwave oven. The standard set of (3) Ruler
toolsis: (4)Glassthermometer100℃
(1) Angle pliers
(2) Nipper pliers
(3) Cross Screwdriver
(4) Monkey-spanner
(5) Iron, solder
(6) 6mm box spanner
Leakage test of the microwave oven Measurement
Points of attention: (1) Set the gauge according to the
(1) Please first check the leakage of the user’s manual.
Microwave oven after maintenance and (2) Add 15-275ml, 5℃-20℃water
before usage. into a container, and put the
(2) If the microwave oven can operate container at the center of the tray.
while the door is open, STOPANY (3) Set the oven at the highest
OPERATION OF THE OVEN. power level to start working.
(3) The leakage standard of the microwave (4) Measure the leakage with the
oven is <5mW / cm ×cm. leakage detector. The detecting
gasket is 5mm thick, and the probe
shall be perpendicular against
- 13 -

Maintenance Service and Trouble Shooting
measured part.
9.2. Checking under decomposed condition
9.3 Installation and adjustment
A. Dismantle the shell
In replacing the magnetron, after all the ①Switch off the power.
Parts are replaced and measured, and before②First loosen the rear screw. Take
the shell is installed, check the energy leakage off the shell towards upper rear
of the microwave oven. Please pay special side.
attention to the following parts:
- Around the magnetron Attention: Be sure to pull off the
- Wave guide pipe power plug
Warning: Do not touch any high-voltage parts. B.
Power cord
①After dismantle the shell, loosen
the two earth screws.
2. Checking under fully installed condition ②Pull off the two jointers on the
(1) After all of the parts are installed to properfilter seat.
Position including the shell, the parts needed ③Lift it up slightly to take off the
Checking are: the view window, air outlet power cord.
and air inlet.
(2) During working, pull the door slightly to Attention: The power cord must
do checking. be replaced with the special
(3) The leakage of the microwave shall not power cord offered by the
exceed the standard in any cases. manufacturer.
C. Control panel
3. Record and notice of the checking result ①Dismantle the plug wire of the
(1) After checking of the leakage, the result control panel.
data shall be recorded as reference and ②Loosen the fixing screw with the
input into the service record. cross screwdriver. Take out the
(2) If the checking result is: all of the parts control panel from the microwave
are normal and work well. At the same time
the replaced parts are chosen as per this
D. Dismantle of the oven door
manual, the leakage shall not exceed the ①Loosen the two hexagonal screws
standard. of the up hinge with monkey-
(3) Please check the leakage of the microwave spanner orФ5 box spanner.
oven with microwave leakage detector in a ②Loosen the two screws of the
- 14 -

year. down hinge with cross screwdriver.
Maintenance Service and Trouble Shooting
②Pull up the door towards you to
take off it.
Attention:
After installation of the oven door, please check if the first/second lockout switch and
monitoring switch work well.
After oven door is installed, check the leakage with leakage detector.
Attention: In installation, please install gasket on the up/down hinge. In installing the door, the
position of the door can be calibrated by adjusting the up/down hinge. At the same time
please note that 0.4mm gap is required between the inside surface of the door and the front
board of the cavity. (You can add 3-4 pieces of paper between the door and the front board.
Too big gap may cause excessive leakage of microwave; too small gap may cause
overheating of the door and the front board.)
10
E. Dismantling of the high-voltage transformer
①Discharge the electricity of the high-voltage capacitor. ②Dismantle the connecting
high-voltage wires of the magnetron, the high-voltage transformer and the high-voltage
capacitor.
③Loosen the four screws connecting the high-voltage transformer to the bottom plate with
cross screwdriver.
F. Dismantling of the fan motor
①Discharge the electricity of the high-voltage capacitor.
②②Dismantle the connecting wires between the fan motor, filter and high-voltage capacitor.
③Loosen the screw connecting the high-voltage diode to the bottom plate with cross
screwdriver.
④Loosen the four screws connecting the flare, fan motor and rear board.
⑤Lift the flare up to take out the flare group. Pull off the fin and take out the fan motor
backward.
G. Dismantling of the high-voltage capacitor, diode and AK rectifier
①Take off the flare group ②Loosen the screw connecting the flare to the high-voltage
capacitor.
③Take off the high-voltage group ④Pull off the plug of the high-voltage diode and the AK
rectifier with nipper pliers.
Maintenance Service and Trouble Shooting
- 15 -

- 16 -
Attention: Be sure to discharge the high-voltage capacitor to do dismantling
immediately after working.
H: Dismantling of the duct and lamp
(1) Cut off the connecting wire of the lamp (2) Loosen the screw fixing the duct and the
magnetron
(3) Open the hook at the middle of the duct connecting to the magnetron installation board
with a screwdriver
(4) Move outward slowly to take out the duct
(5) Nip the barb fixing the lamp with nipper pliers to take out the lamp upward
I: Dismantling the magnetron
(1) Cut off the connecting wire between the high-voltage transformer and the capacitor
(2) Loosen the four screws fixing the magnetron
(3) Move outward slowly to take out the magnetron
Attention: Never damage the ends of the magnetron
J: Dismantling of the rotary tray motor
(1) Take out all of the accessories in the cavity
(2) Put the oven upside down
(3) Cut off the die part of the bottom plate with angle pliers and take it off
(4) Cut off the connecting wire of the tray motor
(5) Loosen the two screws fixing the tray motor with a cross screwdriver. Take off the tray
motor
(6) In installing, first fix the motor. Connect the wire. Then invert the die block of the bottom
plate. Put one end into the interface on the bottom plate, and fix the other end with M4
screw.
Attention: When dismantling the leading wire, remember to nip the connecting
terminal to pull out. Do not nip the wire.
K. Dismantling of the timer Dismantling of the control panel
(1) Pull off the two knobs on the control (1) Loosen the two screws fixing
panel with nipper pliers. The computer board with cross
(2) Loosen the four screws fixing the timer screwdriver.
with a cross screwdriver. (2) Pull off the interface of the film
Maintenance Service and Trouble Shooting

(3) Take off the timer from the rear of the switch on the computer board.
control panel. (3) Take off the computer board
from the rear of the control panel.
L: Dismantling of the lockout device
1. Function of the lockout mechanical structure: The door lockout is a special design to stop
the microwave emission completely when the door is open, so that it can prevent the
hazard of microwave leakage.
2. Installation position of the first/second/monitoring switch is indicated in the figure
3. Connection between the lockout board and the oven body:
①Install the lockout group on the door body. Twist the two screws on the installation holes
with cross screwdriver without fastening.
②Close the oven door. Adjust the lockout to guarantee that there’s no gap between the door
and the front board after the door is closed.
③Fasten the screws.
④Open the door to check. The loosen range shall not exceed 0.5mm. the micro-switch shall
be closed normally. The door shall be opened and closed smoothly. The micro-switch shall
act as following: Open the door Æthe first lockout switch (micro-motion switch1)Æthe
second lockout switch(micro-motion switch2) Æmonitoring switch (micro-motion
switch3)act in turn. The turn is in counter sequence when closing the door. Please observe
carefully.
M: Dismantling of the heater pipe
(1) Cut off the connecting wire of the heater pipe.
(2) Loosen the three hexagonal screws fixing the heater pipe with M6 hexagonal box
spanner.
(3) Take off the heater pipe from the cavity slowly.
Attention: In installing the heater pipe, be sure to fix the screw tightly.
Otherwise it may cause microwave leakage.
8.4. Components Test
Attention:
1.Be sure to switch off the power any time before dismantling the shell;
discharge the high-voltage capacitor before test; cut off the primary circuit
connecting to the high-voltage transformer.
2.All of the test on the emission of the microwave shall be performed in the
container with one liter water.
A. Conduction test of the lockout switch
Test of the lockout switches
If trouble appears in use of the oven, please first check the mode of the lockout
Maintenance Service and Trouble Shooting
switches: - 17 -

When the door is open, the first/second lockout switch is off. The monitoring switch is
on. When the door is close, the switches are in counter mode. You can observe by sight. If
you are not sure, please measure with gauges.
In maintenance, pull the door with hands as slowly as possible to see if the
microswitches act in following turn: in opening: the first lockout switch – the second lockout
switch – monitoring switch; in closing: monitoring switch – the second lockout switch – the
first lockout switch.
If there’s abnormal phenomenon, please adjust the lockout holder.
B.Test of the high-voltage transformer
Item Position Normal value
Primary coil About 1-2Ω
Secondary coil About 100-200Ω
lamp winding About 0Ω
Primary coil – shell of the
transformer Infinite
Resistance
value
lamp winding – shell of the
transformer Infinite
C.Test of the magnetron
primary coil
lamp coil
second coil
Maintenance Service and Trouble Shooting
- 18 -

Item Position Normal value
Two ends of the heater About less than 1Ω
End and shell of the
heater Infinite
Attention: In test of the magnetron, confirm that the gasket is in good condition
and installed well.
D.
Test of the high-voltage capacitor
Under normal condition: 1. The resistance value of the two terminals shall be several
ohm at the beginning of the test, then return to infinite.
2. The resistance value between the terminal and the shell is
infinite.
E.Test of the high-voltage diode
Measure with RX1000 range. The conduction resistance value shall be several ohm.
No matter which step is used in the measurement, the result shall be infinite.
F. Measurement of the fan motor
The resistance value of the two terminals shall be 200~300ohm
G. Measurement of the rotary tray motor
Maintenance Service and Trouble Shooting
The resistance value of the two terminals shall be 14k~15kohm
antenna
shileding
lamp terminal
- 19 -
