Haier Full Touch 2 Series User manual

CANDYHOOVERGROUP – ViaComolli16,Brugherio – Italy
haier.com

User Instructions
MICROWAVE OVEN
EN
4
Bedienungsanleitung
MIKROWELLENOFEN
DE
26
Istruzioni per l’uso
FORNO A MICROONDE
IT
48
Instrucciones de uso
HORNO DE MICROONDAS
ES
70
Mode d’emploi
FOUR À MICRO-ONDES
FR
92
Instrukcje użytkownika
KUCHENKA MIKROFALOWA
PL
114
Instruções para o utilizador
FORNO MICRO-ONDAS
PT
136
Uputstvo za upotrebu
MIKROTALASNA PEĆNICA
SR
158
Pokyny pro uživatele
MIKROVLNNÁ TROUBA
CS
180
Návod na použitie
MIKROVLNNÁ RÚRA
SK
202
Navodila za uporabnika
MIKROVALOVNA PEČICA
SL
224

EN 4
User Instructions
MICROWAVE OVEN EN
Summary
5Important safety indications
12 Product description
14 How the product works
15 Use of the appliance
19 Cleaning and maintenance
20 Environmental protection and disposal
21 Installation
Dear Customer,
We would like to thank you and
congratulate you on your choice. This new
product has been carefully designed and
built using high-
quality materials, and
meticulously tested to ensure that it meets
all your culinary requirements.
Please read and observe these simple
instructions, which will enable you to
achieve excellent results from the very first
use. This state-of-the-art appliance comes
to you with our very best wishes.

EN 5
Important safety indications
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
•Do not attempt to operate this oven with the door open
since this can result in harmful exposure to microwave
energy. It is important not to break or tamper with the
safety interlocks.
•Do not place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
•WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
IMPORTANT SAFETY INSTRUCTIONS WARNING
To reduce the risk of fire, electric shock, injury to persons or
exposure to excessive microwave oven energy when using
your appliance, follow basic precautions, including the
following:
•Read and follow the specific: “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY”.

EN 6
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
•Keep the appliance and its cord out of reach of children
less than 8 years.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
•WARNING: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave
energy.
•WARNING: Liquids and foods must not be heated in
sealed containers since they are liable to explode.
•When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
•Only use utensils that are suitable for use in microwave
ovens.
•If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.

EN 7
•Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
•The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
•Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
•Details for cleaning door seals, cavities and adjacent
parts.
•The oven should be cleaned regularly and any food
deposits removed.
•Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
•Only use the temperature probe recommended for this
oven. (For ovens provided with a facility to use a
temperature-sensing probe).
•The microwave oven must be operated with the
decorative door open. (For ovens with a decorative
door).
•This appliance is intended to be used in household and
similar applications such as:
- staff kitchen areas in shops, offices and other
working environments;
- by clients in hotels, motels and other residential
type environments;
- farm houses;

EN 8
- bed and breakfast type environments.
•The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
•Metallic containers for food and beverages are not
allowed during microwave cooking.
•The appliance shall not be cleaned with a steam cleaner.
•The appliance must not be installed behind a decorative
door in order to avoid overheating. (This is not
applicable for appliances with decorative door).
•The microwave oven is intended to be used built-in.
•The appliance must be operated with any cabinet door
open.
•Care should be taken not to displace the turntable when
removing containers from the appliance. (For fixed
appliances and built-in appliances being used equal or
higher than 900mm above the floor and having
detachable turntables. But this is not applicable for
appliances with horizontal bottom hinged door).
•Surface of a storage drawer can get hot.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years of
age shall be kept away unless continuously supervised.

EN 9
•During and after use the appliance becomes hot. Care
should be taken to avoid touching heating elements
inside the oven.
•WARNING: Accessible parts may become hot during
and after use. Young children should be kept away.
•WARNING: When the appliance is operated in the
combination mode, children should only use the oven
under adult supervision due to the temperatures
generated.
TO REDUCE THE RISK OF INJURY TO PERSONS
GROUNDING INSTALLATION
DANGER
•Electric Shock Hazard
•Touching some of the internal components can cause
serious personal injury or death. Do not disassemble
this appliance.
WARNING
•Electric Shock Hazard
•Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is
properly installed and grounded.
•This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current.
•This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be

EN 10
plugged into an outlet that is properly installed and
grounded.
•Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood
or if doubt exists as to whether the appliance is properly
grounded.
•If it is necessary to use an extension cord, use only a 3-
wire extension cord.
- A short power-supply cord is provided to reduce the
risks resulting from becoming entangled in or
tripping over a longer cord.
- If a long cord set or extension cord is used:
The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance.
The extension cord must be a grounding-type 3-
wire cord.
The long cord should be arranged so that it will
not drape over the counter top or tabletop
where it can be pulled on by children or tripped
over unintentionally.

EN 11
Materials you can use in microwave oven
Utensils
Remarks
Browning dish
Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do
not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most
glass jars are not heat resistant and may break.
Glassware
Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags
Follow manufacturer’s instructions. Do not close with metal
tie. Make slits to allow steam to escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Parchment paper
Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled “Microwave Safe”. Some plastic containers
soften, as the food inside gets hot. “Boiling bags” and tightly
closed plastic bags should be slit, pierced or vented as directed
by package.
Plastic wrap
Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Thermometers
Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Materials to be avoided in microwave oven
Utensils
Remarks
Aluminum tray
May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handle
May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-
trimmed utensils
Metal shields the food from microwave energy. Metal trim may
cause arcing.
Metal twist ties
May cause arcing and could cause a fire in the oven.
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven and may
split or crack.

EN 12
Product description
A) Control panel
B) Turntable shaft
C) Observation window
D) Door assembly
E) Safety interlock system
F) Oven cavity
Serial number
Write here your serial number for future reference.
ACCESSORIES
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass Tray
Turntable Ring Assembly
Instruction Manual
Higher Wire Rack
. (For grilling, e.g. steaks,
sausages and for toasting bread.
As a
support for shallow dishes)
.
Turntable Shaft
Lower Wire Rack. (For baking and
roasting in the oven)
.

EN 13
TURNTABLE INSTALLATION
Cleaning the cooking compartment and putting the turntable in place. For
new installations, make sure all packaging and shipping tape has been
removed from the turntable shaft. Before using the appliance to prepare
food for the first time, you will need to put the turntable in place correctly.
You must clean the cooking compartment and accessories.
How to put the turntable in place:
1. Place the turntable ring assembly ③into
the recess in the cooking compartment.
2. Place the glass tray ①on the turntable
ring assembly ③. Fit the raised, curved
lines in the center of the glass tray
bottom between the three spokes of the
shaft. Make sure that the glass tray ①
engages in the turntable shaft ②in the
centre of the cooking compartment
floor. The rollers on the shaft should fit
inside the turntable bottom ridge.
Note：
1. Never use the appliance without the turntable. Make sure that it is
properly engaged. The turntable can turn clockwise or anti-clockwise.
2. Never place the glass tray upside down. The glass tray should never be
restricted.
3. Both glass tray and turntable ring assembly must always be used
during cooking.
4. Some food and containers of food are always placed on the glass tray
for cooking.
5. Never restrict the movement of the turntable.
6. If glass tray or turntable ring assembly cracks or breaks, contact your
nearest authorized service center.

EN 14
How the product works
CONTROL PANEL
Symbol
Function
Microwave
Function
Clock/Kitchen Timer
Auto Menu
Lock/Cancel
Start/+30Sec./Confirm

EN 15
Use of the appliance
OPERATION
Name
Description
Setting the clock
(1) Press “Clock/Kitchen Timer” once and then “00:00”
will display.
(2) Move the slider or press “+” or “-” to set the hour
figures. The time should be within 0-23.
(3) Press “Clock/Kitchen Timer” to confirm.
(4) Move the slider or press “+” or “-” to set the minute
figures. The time should be within 0-59.
(5) Press “Clock/Kitchen Timer” to confirm.
Kitchen Timer
(1) Press “Clock/Kitchen Timer” twice and then “00:00”
will display.
(2) Move the slider or press “+” or “-” to set the time.
The time should be within 0:05～95:00.
(3) Press “Start/+30Sec./Confirm” to confirm.
Microwave
Power Level
100%
80%
50%
30%
10%
Display P10 P8 P5 P3 P1
(1) In waiting state, Press “Microwave” and then “P10”
will display.
(2) Press “Microwave” repeatedly to adjust the power
level, 5 power levels are available.
(3) Move the slider or press “+ “or”-” to set the cook
time.
(4) Press “Start/+30Sec./Confirm” to start cooking.
Grill
(1) Press “Function” once and then “G-1” will display.
(2) Move the slider or press “+” or “-” to set the cook
time.
(3) Press “Start/+30Sec./Confirm” to start cooking.
Note: When half of the time has passed, the buzzer
will sound to remind you to turn the food over.
If no operation, the oven will continue working.
Combination
(1) Press “Function” once and then “G-1” will display.
Press “Function” repeatedly to choose the power
you want, and “C-1”, “C-2”, “C-3” and “C-4” will
display in order.
(2) Move the slider or press “+” or “-” to set the cook
time.
(3) Press “Start/+30Sec./Confirm” to start cooking.
Note: Combination instructions

EN 16
Instructions Display Microwave Grill Convection
1 C-1 
2 C-2 
3 C-3 
4 C-4 
Defrost by Weight
(1) Press “Function” thrice and then the screen will
display “0.1kg”.
(2) Move the slider or press “+” or “-” to set the
weight.it should be within 100-2000g.
(3) Press “Start/+30Sec./Confirm” to start defrosting.
Defrost by Time
(1) Press “Function” four times and then the screen will
display “1:00”.
(2) Move the slider or press “+” or “-” to set the time.
(3) Press “Start/+30Sec./Confirm” to start defrosting.
Note: When the half time of defrost has elapsed,
buzzer will sound，turn the food over. If no
operation, the oven will continue working.
Speed cooking
(1) In waiting state, press “Start/+30Sec./Confirm” to
cook food with 100% power level for 30 seconds.
Each press on the same key can increase 30
seconds and the maximum time value is 95 minutes.
Note: Speedy cooking cannot be set in defrost by
weight, multi-stage and auto menu.
Lock Function for
Children
You can use this function to prevent children from
accidentally turning the oven on. To activate the lock:
In waiting state, press and hold “Lock/Cancel” for three
seconds. A long beep sounds and the locked icon will
display.
To deactivate the lock:
In locked state, press and hold “Lock/Cancel” for three
seconds. A long beep sounds.
Inquire function
(1) If the clock has been set, the current time will
display for three seconds by pressing
“Clock/Kitchen Timer” in the cooking state.

Auto Menu
(1) In waiting state, press “Auto Menu”, the screen will
display “A-1”.
(2) Press “Auto Menu” repeatedly to choose the menu
you need.8 auto menus are available.
(3) Move the slider or press “+” or “-” to set the weight
of the food.
(4) Press “Start/+30Sec./Confirm” to start cooking.
EN 17

EN 18
AUTO MENU CHART
Menu
Weight(g)
Display
Power
POTATO
1 (about 230 g) 1
P1002 (about 460 g) 2
3 (about 690 g) 3
MEAT
150 g 150 g
300 g 300 g
450 g 450 g
600 g 600 g
FISH
150 g 150 g
P80
250 g 250 g
350 g 350 g
450 g 450 g
650 g 650 g
VEGETABLE
150 g 150 g
P100
350 g 350 g
500 g 500 g
BEVERAGE
1 cup (240 g) 1
P100
2 cup (480 g) 2
3 cup (720 g) 3
PASTA
50 g (cold water 450 g) 50 g
P80
100 g (cold water 800 g) 100 g
150 g (cold water 1200 g) 150 g
POPCORN 100 g 100 g P100
PIZZA 200 g 200 g
400 g 400 g
P80
P100+G-1
A-1
A-2
A-3
A-4
A-5
A-6
A-7
A-8

EN 19
Cleaning and maintenance
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly
damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must
be cleaned carefully with a damp cloth when they are
dirty.
4. Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls
that the food cooked can touch: Place half a lemon in a
bowl, add 300ml (1/2 pint) water and heat on 100%
microwave power for 10 minutes. Wipe the oven clean
using a soft, dry cloth.

EN 20
Environmental protection and disposal
TROUBLE SHOOTING
Normal
Microwave oven interfering TV
reception
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the
interference of small electrical appliances, like
mixer, vacuum cleaner, and electric fan.
It is normal.
Dim oven light In low power microwave cooking, oven light may
become dim. It is normal.
Steam accumulating on door,
hot air out of vents
In cooking, steam may come out of food. Most will
get out from vents. But some may accumulate on
cool place like oven door. It is normal.
Oven started accidentally with
no food in.
It is forbidden to run the unit without any food
inside. It is very dangerous.
Trouble Possible Cause Remedy
Oven cannot be started.
(1) Power cord is not
plugged in tightly.
Unplug. Then plug again after 10
seconds.
(2) Fuse blowing or
circuit breaker works.
Replace fuse or reset circuit
breaker (repaired by professional
personnel of our company)
(3) Trouble with outlet. Test outlet with other electrical
appliances.
Oven does not heat.
(4) Door is not closed
well. Close door well.
According to Waste of Electrical and Electronic
Equipment (WEEE) directive, WEEE should be
separately collected and treated. If at any time in
future you need to dispose of this product please
do NOT dispose of this product with household
waste. Please send this product to WEEE
collecting points where available.
