Haier UA-0770E User manual

Haier
R
What The World Comes Home To
TM
Microwave Oven
User Manual
UA-0770E
BAKED
POTATO
REHEAT
PIZZA
FROZEN
DINNER
POPCORN
Timer
Clear/Stop
Start
Clock
Microwave

IMPORTANTSAFETYINSTRUCTIONS
When using electrical appliances, basic safety precautions should
be followed, including the following:
1.
2. Read and follow the specific"PRECAUTIONS TOAVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" on page 3.
3. This appliance must be grounded.Connected only to properly
grounded outlet. See "GROUNDING INSTRUCTIONS" on page 8.
4. Install this applianceonly in accordance with theprovided
installation instructions.
5. Someproducts such as whole eggs and sealed containers, for
example,closed glass jars may explode and should not be heated
in this oven.
6. Usethis appliance only for its intended use as described in this
manual. Do not use corrosive chemicals orvapors in this
appliance.This type of oven is specifically designedto heat, cook
or dry food. It is not designed for industrial orlaboratory use.
7. As withany appliance, close supervision is necessary when used
by children.
6. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend appliance if paper, plastic
or other combustible materials areplaced insidetheoven to
facilitate cooking.
b. Remove wire twist-ties from paper or plastic bags before placing
bag in oven.
c. If materials insidetheoven should ignite, keep oven doorclosed,
WARNING -To reduce the risk of burns, electric shock, fire, injury
to persons or exposure to excessive microwave energy:
Read all instructions before using the appliance.
8. Do notoperate this appliance if it has a damaged cord or plug,
if it is not working properly or if it has been damagedor dropped.
9. Only qualified service personnel should service this appliance.
Contact the nearestauthorized service center torepairor
adjustment.
10. Do not coveror block any vents on this appliance.
15. When cleaning surfaceof thedoorand oven thatcome together
when closed the door, use only mild, non-abrasive soaps, or
detergents apply with a sponge or softcloth.
11. Do not store or use this appliance outdoors. Do not use this
product near water, for example, near a kitchen sink, ina wet
basement, or near a swimming pool.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cordhangover edge of a table or counter.
1
1

2
SAVETHESEINSTRUCTIONS
WARNING : It is hazardous for anyone other than a trained personto
carry outany service or repair operation which involves the removal
ofany coverwhichgives protection against exposure tomicrowave
energy. If there is any damage, do notoperate theoven and contact
your dealer or Haier authorized service.
turn oven off, and disconnect the power cord or shut off
power at the fuse or circuit breaker panel.
d. Do not use the cavity for storage purposes. Do not leave paper
products, cooking utensils or food in the cavity when not in use.
17.Do not use the microwave oven toheat corrosive chemicals (for
example, sulfides and chlorides). Vapors from the corrosive
chemicals may interact with the circuitry and affect the operation
ofoven.
18.Microwave heating ofbeverage can resultin delayed eruptive
boiling, therefore care has to be taken when handle the container.
19.Do notdeep fryfoodin the microwave.It is difficult to control the
fatwhich could cause a fire hazard.
20. Pierce foods with heavy skins such as potatoes,whole squash,
apples and chestnuts before cooking.
21. The contents of feeding bottles and baby jars should be stirred or
shaken and the temperature should bechecked before serving in
order to avoid burns.
22.Be certain theglasstray and roller ring are in place whenyou
operatethe oven.
Thank you for using our Haier product.
his easy-to-use manual will guide you in
getting the best use of your microwave
oven
Remember to record the model and serial
number.They are an a label in back of the
microwave oven.
Model number
Serial number
Date of purchase
Staple your receipt to your manual.
YOUWILLNEEDITTO OBTAINWARRANTYSERVICE.

3
PRECAUTIONS TOAVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do notattempt to operate this ovenwith thedoor-open since
open-door operationcan resultin harmful exposure to microwave
energy. It is important not to defeat or tamper with the safety
interlocks.
(b) Do not place any objectbetween theoven front face and the
door or allow soil or cleaner residue to accumulate on sealing
surfaces.
(c) Do not operate the oven ifit is damaged. Itis particularly
important that the oven door close properly and that there is no
damage to the :
1 Door ( bent ),
2 Hinges and latches ( broken or loosened),
3 Door seals andsealing surfaces.
(d)The oven should not be adjusted or repaired by anyone
except properly qualifiedservice personnel.
LIMITED WARRANTY
Whatis covered and for how long?
12 months (labor and parts)
10 years Magnetron Tube(parts only)
Whatis covered?
What will be done?
This warranty covers all defects in workmanshipor materials for a
periodof:
Thewarranty commenceson the date the item was purchased and
the originalpurchase receipt must bepresented to authorized
service center before warranty repairs are rendered.
1.The mechanical and electrical parts, which serve as a functional,
purpose of this appliance for a period of 12 months.This includes
all parts exceptfinish, and trim.
2.Ifthe magnetron tubefails because of defectiveworkmanship or
material,the parts will be replaced. Laborand inhome service costs
arenotcovered.
1. We will repair orreplace, at our discretionany mechanicalor
electrical part which proves to be defective in normal usageduring
the warranty period so specified.
2.There will be nochange to thepurchaser for parts on any covered
items during the initial 12 month period.
3. Contact yournearest authorized service center. For the name of
the nearest authorized service center please call 1-800-637-7567

!
Food
!
!
Arcing
Arcing is the microwave term that is defined as Sparks in the oven “”
> Cooking time given in the cooking guide is approximate. Factors
that may effect are the starting temperature, altitude, volume,
size and shape of food, and container used. As you become
familiar with the oven, you will be able to adjust for these factors.
> Do not boil eggs in their shells. Pressure may build up and explode.
> Potatoes, apples, egg yolks and whole acorn squash are example
of food with "NONPOROUS SKINS.",Tthese must be pierced
before cooking to prevent bursting.
> popcorn must be popped in a microwave corn popper. Microwave
popped the corn produces a lower yield than conventional
popping. DO NOT use oven for popcorn unless popped in a
microwave approved popcorn container or unless it is
commercially packaged and recommended for microwave ovens.
DO NOT use the oil unless specified by the manufacturer.
> DO NOT attempt to deep fry in your oven.
> DO NOT heat liquids in your microwave oven without the
stirring.
4

TableofContents
ImportantSafetyInstructions
Limited
1
Warranty
FeaturesOfMicrowaveOven
InstallingMicrowaveOven
GroundingInstructions
OperatingMicrowaveOven
ProperMicrowave OvenCareandCleaning
FoodFactsInMicrowaveCooking
LanguageOfMicrowaveOven
specifications
Troubleshooting
3
6
7
8
9
13
14
15
15
16
Unpacking Microwave Oven
Placement of Microwave Oven
Proper Air Circulation
Electrical Requirement
TableofContentsTableofContents
5

FeaturesofMicrowaveOven
BAKED
POTATO
REHEAT
PIZZA
FR OZ EN
DINNER
POPCORN
Timer
Clear/Stop
Start
Clock
Microwave
BAKED
POTATO
REHEAT
PIZZA
FROZEN
DINNER
POPCORN
Timer
Clear/Stop
Start
Clock
Microwave
Glass rotary tray
Rotary tray support
Rotary axis
Sketch for the accessory installation
1
54
3
2
1.Safety screenwindow
2. Sketch fortheaccessory installation
3.Touch pad control panel
4.Ovenvents
5. Doorsafety lock system
6

Installing MicrowaveOven
UnpackingMicrowaveOven
PlacementMicrowaveOven
ProperAirCirculation
ElectricalRequirement
1) Unpack the oven, remove all packing material, and examine
the oven any damage such as dents, broken door latches or
crocks in the door. Notify the dealer immediately if the unit is
damaged. Do not install the oven if the unit is damaged.
2) Inspect and remove any remains of packing, tape or printed
materials before powering the microwave oven.
> The oven must be placed on a flat, stable surface.
> The oven may possibly cause reception interference on
the radios and/or televisions.
> In order to eliminate or minimize interference to radio and
televisions from the microwave oven, the oven should be
plugged into a separate electrical socket. In addition, the
oven should be physically as far away from the radios or
televisions as possible.
> For proper operation, the oven must have sufficient air-flow.
The following is recommended clearances around the oven:
Sides
Top
Back
2”(50mm)
1”(25mm)
1”(25mm)
>Make surethereissuitablepoweroutlet(120Volt,15Amps
Outlet) with proper grounding to power the microwave oven.
> Avoid the use of three plug adapters or cutting off the third
grounding prong in order to accommodate a two-plug outlet.
This is a dangerous practice since it provides no effective
grounding for the microwave and may result in shock hazard.
> The electrical power cord must be kept dry and must be not
pinched and crushed in any way.
7

O
p
eratin
g
YourMicrowaveOve
n
Please read and fully understand the instructions before operating
the oven
1. Make sure that oven is plugged in and
door is closed.
2. Touch pad, to set clock.
3. To enter the correct time of the day.
For example, if you want to set 12:00
A.M. or P.M., Please follow the right chart:
This is 12-hour clock, if you attempt to
enter incorrect time, the control
board beeps three sounds. Touch
keypad and reenter the time.
this keypad allows you to do the following:
Cancel if you made any programming mistake.
Cancel cookingtime.
Stop the oven for a short time during cooking.
Return to the time of the day display.
Cancel any program/selection you do not want during cooking
by touching thekeypad twice.
You can set up your cooking time up to 99 minutes 99 seconds.
You always enter the minutes before the seconds, even if they
are both zeros.
For example, if you want to enter to cook
for 5 minutes:
1. Enter the cooking time by selecting
number keypad : , , .
2. Touch the keypad, this will set the
cooking time.
Setting the clock
Clear/Stop Pad
Time cooking time
Clock
Note:
Clear/Stop
500
start
·
·
·
·
·
Whenthe cookingis finished, thebuzzer of
control panel will remind you with three alarms,
and the screen display .
End
12:00
Clock
Clock
5:00
Start
9
