Haier WSD-1416 User manual

..........
11
1111
2121
..........
..........
HTX14S33
HTX14S33
110/220V, 50/60Hz

EnglishEnglish
Setup OPTION...........................................................................................6Setup OPTION...........................................................................................6
Setup TIME................................................................................................7Setup TIME................................................................................................7
1
.

353
IMPORTANT SAFETY INSTRUCTIONSIMPORTANT SAFETY INSTRUCTIONS
e
ar
2
insert
S
provides information with respect to proper
English
EnglishEnglish EnglishEnglish

5
4
Back
Features
Front
1.VIDEO IN: Video input
2.AUDIO IN: Audio input
3.TV/AV:TV/AV select
4. MENU: Access/Exit Main M(MENU)
5. VOL-: Decrease sound
6. VOL+:Increase sound
7.CH-: Select next lower channel
8.CH+:Select next higher channel
9.Power Indicator
10.Remote sensor
11.POWER: Power on/off
12.ANT: Antenna
13.EARPHONE
Features
Front
Back
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
DO NOT OPEN
RISK OF ELECTRIC SHOCK
CAUTION
12
1. : Power on/off
2. MENU: Access/Exit Main M
3. CH+/-: Select next higher or lower channel
4. VOL+/-: Increase or decrease sound
5. CHANNEL NUMBER BUTTON: Direct channel
tuning (TV channel 02-69, CATV channel 01-125.)
6. RECALL: Return to previous channel
7. DISPLAY: Display receiving channel
8. TV/AV: TV/AV selection
9. RATING: V-chip Set
10. MUTE: Press key to Activate/deactivate Mute Function
11. P.STD: Select Personal, Vivid, Light, Standard, Soft
12. SLEEP: Sleep timer
( ) ( )
1
6
789
23
45
0
REC ALL
TV/ AV
RATIN G
MUT E
P.STD SLE EP
HY F- 23 A
DIS PLAY
MENU CH+
VOL- VOL+
CH-
(1)
(2)
(3)
( )4
(5)
(6) (7)
(8)
(9)
(10)
(11) (12)
Remote Control Functions
Haier
English
EnglishEnglish EnglishEnglish
TV/AV
MENU
- VOLUME +
- CHANNEL +
3 5
4
6
78
9
10
11
1 2
EARPHONE
VIDEO IN
AUDIO IN
13
POWER
EARPHONE VIDEO IN AUDIO IN
TV/AV MENU - VOLUME + - CHANNEL +
POWER

5
6
Brightness 84Brightness 84
Contrast 80Contrast 80
Color Color
Tint 00Tint 00
C1 C2 TEXT1 TEXT2 OFF
C1 C2 TEXT1 TEXT2 OFF
Preset
Red
1.Presss MENU two times, then enter the
OPTION menu.
2.Select item with CH+ and CH-, the selected
item will highlighted red.
3.Select the language you would like to see
on your screen (English/Francais/Espanol)
with VOL+ and VOL-.
4.Press CH+ and CH- to select C.CAPTION,
the selected item highlighted with red.
When OFF displays, C.CAPTION is set off.
When C1 displays, C.CAPTION is set active.
Press VOL+ repeatedly , the option will display
followed on the screen in turn:
OPTIONOPTION
Language English Language English
C.Caption OffC.Caption Off
Setup PICTURESetup PICTURE
Brightness 84Brightness 84
Contrast Contrast
Color Color
Sharpness Sharpness
Tint 00Tint 00
Getting Started With
Personalized Setup
Getting Started With
Personalized Setup
Setting up this TV can be personalized, please refer to
this manual. It contains instructions to help you. The TV
is preset with default setting preset by manufacturer. To
get personalized setting, please read on.
1. Page 5 a brief introduction to the key functions.
2. Page 6 PICTURE.
3. Page 6 OPTION
4. Page 7 TIME
5. Page 7 PRESET
6. Page 7 V-CHIP
7
Setup TIME Setup TIME
1.Press MENU three times, then enter the CLOCK menu.
2.TIME, selected item will highlight to red;
3.Use VOL+ to adjust minute and use VOL- to adjust hour.
4.Press CH+ and CH- to change the selected parameter
as you wish; Similarly, you can set a Time On/Time
Off/Reminder/Choice;
5.You can also set a time on a channel you want, enter the
channel menu, press VOL+ or VOL- to change the
number of the channel.
Setup PRESETSetup PRESET
1.Press the MENU four times, then enter the PRESET menu.
2.Channel: press VOL+ to change the channel you want to
preset.
3.Add/Erase: use CH+ and CH- to select the option, press
VOL+ and VOL- to add or erase TV channels to/from the
program.
4.Antenna: the default parameter is Air, which indicates
the signal receiving method is through the antenna of the
TV. Use VOL+ to change it to CATV(IRC)/CATV(HIR)/
CATV(DDD) if you are using cable service.
5.AUTO SEARCH: press the VOL+ or VOL-, it will
automatically search for TV channels. (When
available signal is detected, the channel locked in will
release the lock, press VOL+, and the search resumes).
Setup V-CHIP Setup V-CHIP
Pressing Rating on your remote controller will bring
V-CHIP to set up display on TV. You will see the
following on your TV screen.
This function enables you to block certain TV
channels in according to the V-CHIP requirements
established by the FCC.
Follow the procedure below to set the V-CHIP:
Press the Rating button, you will see the V-CHIP
menu on your TV screen:
1. Press CH+ and CH- to go up and go down the menu.
2. Press VOL+ and VOL- to enter password and then
go into TV Rating and Movie Rating menu.
3. Press VOL+/- to set the BLOCK ON and BLOCK OFF.
When TV Rating is selected, press VOL+, then you
will find you need enter password, after entering the
default password 0000, you will see the following
rating table on your TV screen.
When MPAA Rating is selected, press VOL, then you
will find you need enter password, after entering the
default password 0000, you will see the following
rating table on your TV screen.
CLOCKCLOCK
Time 0:00Time 0:00
On Time --:--On Time --:--
Off Time --:--Off Time --:--
Reminder --:--Reminder --:--
Choice --:--Choice --:--
On Channel --On Channel --
PRESETPRESET
Channel 69Channel 69
Add/Erase AddAdd/Erase Add
Antenna AirAntenna Air
Auto SearchAuto Search
V-CHIP
BLOCK OFF
TV RATING
MPAA RATING
CHANGE PASSWORD
V-CHIP
BLOCK OFF
TV RATING
MPAA RATING
CHANGE PASSWORD
MPAA Rating MPAA Rating
Movie RatingMovie Rating
G UG U
PG PG UU
PG-13 PG-13 UU
R R UU
NC-17 NC-17 UU
X X UU
Age based rating Age based rating
Rating FV D L S VRating FV D L S V
TV RatingTV Rating
TV-Y TV-Y UU
TV-Y7 TV-Y7 UU
TV-G TV-G
TV-PG TV-PG UUUUUUUU
TV-14 TV-14 UUUUUUUU
TV-MA TV-MA UUUUUU
Adult languageAdult language
UU
UU
UU
UU
UU
Setup OPTION Setup OPTION
CH key
key
VOL
Turning The TV OnTurning The TV On
Note: When block ON is selected, you will see V-CHIP
function is activated .You can press MENU button
to exchange B and U under TV Rating and MPAA
Rating. When block OFF is selected, you will
see V-CHIP function is not be activated .
Note: When block ON is selected, you will see V-CHIP
function is activated .You can press MENU button
to exchange B and U under TV Rating and MPAA
Rating. When block OFF is selected, you will see
V-CHIP function is not be activated .
PICTURE parameters:
Press M(MENU) key and select PICTURE.
Press CH- and CH+ to select an item (menu will
roll and show those hidden items with the action
of the CH+ and CH-).
When a certain item is selected, it will be
highlighted red, use VOL+ and VOL- to change
the parameter to your preference.
8080
5050
5050
5050
5050
.
EnglishEnglish EnglishEnglish

English
9
8
the TV on
This Haier brand product when shipped in original
container,will be free from defective workmanship
and material,and agrees that it will,at its discretion,
eithier repair the defective product with an equivalent
new,refurbished,or similar unit at no charge to the
purchaser,for parts or labor for the periods set fourth
below.
EnglishEnglish EnglishEnglish

Espanol
~
10
HTX14S33HTX14S33
355X360X310(mm) 355X360X310(mm)
9.2Kg9.2Kg
11
110/220V, 50/60Hz110/220V, 50/60Hz
1313
EnglishEnglish EnglishEnglish

English
!!
!!
11
1212
1515
1515
1616
1616
1616
1616
1717
1717
18 18
1919
2020
1717

12 13
