Haier HWM90-0577 User manual

Please read this manual carefully
before using.
Retain it for future reference.
User's manual
This manual is for
HWM90-0577
Environmental-friendly Double
Drive Washing Machine

Names of the parts 1
Safety precautions 2
Installation and adjustment 4
Install the water inlet hose 6
Preparation before washing 8
Put in the laundries 9
Usage of the detergent
Use the operation buttons 10
Finish washing 13
Disposal after washing 14
Trouble shooting Answer to question 15
Packing list *Specifcation 16
9
Close the top lid 9
CONTENTS

~
0.03MPa 0.78MPa
Rated washing /
spinning capacity
Water Injection pressure
1
Packing list
Water level/Water
Standard water consumption
Top lid component
Control pannel
Balance ring
Filter cover
Lint filter
Inner tub
Pulsator
Front control board
Cabinet
Meaning and description of the symbols
Contents marked with that symbol are actions forbidden
to perform. Performing of those action may result in damage of
the machine or influence the personal safety of the users.
Contents marked with that symbol are related to the
safety of the product and the personal safety of the users.
Please operate in strict conformity to the contents.
Names of the parts
Warning sign
Forbidden sign
quantity (about)
Specification
User's manual One
Component of the
water inlet hose
One
One
Name Quantity
Bottom cover
(Inside the inner tub of washing machine)
The end connecting to
the washing machine
Jointer connecting the
water inlet hose and
the water faucet
The end connecting to the
water inlet hose jointer
One
Accessory
two
Inner cover component
Detergent box
Outer tub cover
Front door
Adjustable leg
Drain hose frame
Water inlet valve
Water absorption
cushion
Power cord
Handle
Drain hose
Back cover
Fixed leg
(3 pieces)
Cabinet base
One
Inner cover component
Screw cover
Drain bushing
Hook
Environmental-friendly Double
Drive Washing Machine

2
Safety precautions
Phenomena The reason How to settle
Trouble-shooting Answer to question
(If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes.
Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department
or after-sale service department of our company. Do not repair it by yourself.
The digitron displays E0.
The safety switch acts, and the
spinning cannot work. The
digitron displays E3.
The water filling does not work, or is
slow. After about 15 minutes later,
the digital displays E4.
The drainage cannot work, or is too slow.
The digitron displays E1.
It stops running in midway. The digitron
displays E2.
The top lid is not closed.
The top lid is opened during reserve procedure.
Close the top lid.
Close the top lid.
Is the drain hose put down?
Is the drain hose blocked?
Put down the drain hose. Open and close the top lid once.
Clean the foreign material. Open and close The top Lid Once.
Are the laundries put slantingly?
Is the machine slanting?
Reorder the laundries. Close the top lid.
Th machine will start running after 10
seconds of being placed horizontally.
Is the water tap opened, or is there water
supply failure?
Is the water inlet valve blocked?
Is the water pressure too low?
Open the water tap. Push the start/Pause
button once.
Clean the water inlet valve then push
the Start/Pause button once.
Push the Start/Pause button once.
The water level sensor is bad. Please contact the after-sales
service department.
The digitron displays E6.
The machine does
not act
Not wash
Not spin
Is there power failure?
Is the power plug inserted tightly?
Is the water level reached preset position?
Please use it when there's power supply.
Insert the power plug tightly.
Fill water to the preset position.
Is the power plug inserted tightly?
Is the top lid closed reliably?
Are the laundries set flat?
Insert the power plug tightly.
Close the top lid.
Set the laundries flat.
There's abnormal sound
inside the machine
The water tap leaks
Is the machine slanting?
Are the laundries put slantingly in spinning?
Are there any foreign materials?
Adjust the machine to be even
Reorder the laundries and close the top lid.
Remove the foreign materials.
Is the screw of the jointer of water
inlet hose loose or awry? Fasten the screw of the jointer properly.
Common phenomena
Phenomena Explanation
Balance the laundries to avoid slanting.
The cloth sensor is checking the cloth, it willadd waterafter 48 seconds.
The program is setting the drain time. Some time is needed
before it starts spinning.
The spinning is intermittent when it starts.
The wash procedure is paused.
The pulsator pauses during water inlet
in wash and rinse.
There may be some water flowing out of the
drain hose in the first use of the machine.
Push the PROGRAM button to select SPIN,
but it doesn't work.
It is to avoid splashing during water inlet.
It is the water remained in the factory inspection of performance.
The ventilation
holes at the bottom
Carpet
Do not let the machine share one receptacle with other
electric appliances. If the plugging into the receptacle
is loose, do not use the plug any more.
Do not wash water-proof laundries like
the raincoat, bike covers etc. to avoid
abnormal vibrations in spinning.
Please plug the power plug on special
receptacle. Be sure to use three-pins
power receptacle. Ensure that the earthing
prong of the power receptacle is earthed
reliably. Use leakage protector if possible.
Do not bend ,extend, twist, bind by force. Do not press or nip it with weight.
Keep the pin of the power plug clean, if the power plug is polluted with dust, please wipe with
dry cloth carefully.
If the power cord or the power plug is bad, to avoid risk it is required to have it replaced by
the technicians of our special shop or the after-sale service department.
Do not put the machine at damp place like
the bathroom. Never wash it with water. Do
not put wet laundries on the control panel.
Do not use water hotter than 50 .
In case the washing machine is installed on ground with
carpet, do not block the ventilation hole with carpet.
The washing machine must be positioned
so that the plug is accessible. Be sure to pull the
plug off and close the water faucet in
following cases: power failure, delivering
the machine, setting the machine idle or
cleaning the machine. Do not plug
or pull the power plug with wet hand.
The digitron displays E7.
The digitron displays EE.
The communication is bad. Please contact the after-sales service
department.
Is the water inlet valve blocked?
Is the water pressure too low?
Clean the water inlet valve then push
the start/Pause button once.
Push the Start/Pause button once.
Select the No Washing Powder or Disinfect
There may be some water flowing out of the
drain hose in the use of the machine.
When NO Detergent is selected, water drained from the drain pipe during the filing
process is sterilizing and can be used to sterilize the sewerage or mops. When
Disinfection is selected, water drained from the drain pipe during the filling process
is disinfecting and can be used to disinfect the sewerage or mops.

Disposal after washing
After using, please clean the lint and foreign materials of the lint filter etc. in time.
Otherwise it may influence your using the machine.
Please first pull off the power plug from the receptacle before cleaning.
Clean the detergent box and set it on
the control panel seat.
1.The method of dismantle: Push it up aslant and gently.
2.The method of install : install it upwards and aslant
and push it in .
Dismantle Install
The filter screen of the water inlet valve is likely to be
blocked by foreign materials and influence the water
inlet.
Please clean it with brush every two months.
If the cabinet is dirty, wipe it with wet cloth
Do not flush it directly with water.
Wipe it with neutral detergent.
Do not wipe it with thinner, petrol, alcohol etc.
Lint filter:
The lint filter must be used during washing.
It must be cleaned in time after each using.
Figure 1 Figure 2
Down
Dismantle
Install
The back cover of lint filter
Install
Dismantle
Down
Up
Up
The front cover oflint filter
1.Push down the spring piece of the top lint filter
to make the claws out of the filter cover, and then
pull out the lint filter to get it down. figure1
2.Pull the back of the lint filter, and then you can
get down it off the front cover of the lint filter. figure2
3.Sweep the rubbish in the lint filter.
4.Put the back of the lint filter into the front cover .
5.Put the lint filter into filter cover, and make it
tight .
6.Make sure the lint filter well installed, or it can
influence your use.
1.After washing, close the water faucet. ( If needed, you can dismantle the water inlet hose).
5.Wipe off the water drops on the surface of the machine and inside the tub. Open the top lid for some time
(about 1 hour), then close the top lid.
4.Hang up the power cord and drain hose.
3.Be sure to pull off the power plug before maintenance.
2.Do not store water in the washing machine for a long period. Drain the water completely after each using.
Safety precautions
Do not put hand into the rotating tub. It is dangerous
even if the rotation speed is slow. Take special care of
the children. Keep children away from the washing
machine to avoid them climbing on.
Do not decompose, repair or alter the machine by
yourself.
Do not put any hot or heavy items (such as the
kettle with hot water) on the washing machine.
Do not wash laundries with volatile materials
(such as thinner, petrol etc.).
Keep the machine away from direct sunlight and
heat source like the heater.
Please keep the lint filter in good condition,
and install it to proper position during
washing. If the lint filter is lost or
damaged, please contact the local
after-sales service department
of our company.
To protect your laundries and washing machine,
please take out all of the coins, buttons, sand, hairpin
and other foreign materials before washing.
Please check if the water faucet is open, and if the connection of the water inlet pipe is proper.
It is suggested to use foamless washing powder.
Benzene
Petrol
The handicapped or children without care shall not use
the machine.
Install
Dismantle
Please don t use the washer in the environment below 0 C; if the washer has been stored below 0 C,
please be sure to ensure the washer is placed under the room temperature for 24 hours and then use
otherwise the washing effects may be lowered or the washer may be damaged.
To change the direction of drain pipe, please contact the after-sales service department.

After you open the package, please lean
the washing machine gently down on soft
items ( like the towel cloth, blanket, etc. ).
Install the bottom plate to the bottom of
the machine with the eight screws by
a cross screwdriver, then lift the machine
up gently. See to the figure:
Back
Front
Soft items
Bottom plate
Please install and adjust the machine according to the requirement of the manual.
It is very important to your security and correct operating the machine.
Install the bottom plate
Installation and adjustment
4 Push the " WATER LEVEL "button, select
suitable water level
After switching on the power, the washing machine will execute fuzzy program automatically to detect the cloth.
After defection, it can set the water level automatically. To select other water level, first push the "START/PAUSE"
button, then push the "WATER LEVEL" button to set the water level.
5 Push the "RESERVE" button to select suitable
reserve wash program
After switching on the power, the reserve program is set to off mode automatically. If you need to
set the washing procedure to be finished at reserved time, please push the " RESERVE " button to
set the reserve wash program. Refer to reserve button in Page 10 for selection.
Confirm the operation of reserve program
When the "RESERVE" function is activated, the indicator light of the program you
have set will be off. The "reserve (hour)" and "time remain" indicator lights will
be on. During reserve procedure, push the "RESERVE" button to display the reserve mode.
To change the running program or cancel the reserve setting, you
need to switch off the power and make new selection.
6 Push the "START/PAUSE" button
6 Finish washing
After finishing wash it'll alarm automatically
I
Attention
Even there's no water in the tub, a certain period is required before spin starting.
Separate the laundries that are not colorfast from other laundries in washing.
The soak procedure can work in cooperation with automatic programs like standard, carpeting
chemical fiber. There is intermittent pulsator stirring during soak.
After the machine starts operation, you can only set the program and procedure during washing,
and can not make setting in other cases.
If the water pressureis too low,in order to washthe closes cleanly,the machine will change
from " SAVING WATER"to "storing water "automatically.
3 Push "SOAK/FUCTION" "WASH/SPEED" "RINSE"
"SPIN/SPEED" button to select suitable procedure program
Install the Inner cover component
RESERVE
WATER LEVEL
START/PAUSE
1.Open the top lid of the washing machine.
2.Put the inner cover component on the outer tub cover, aiming
the inner cover shaft to the installation hole of the
corresponding outer tub cover shaft groove.
3.Firstly insert the inner cover shaft of one side into the corresponding
outer tub cover shaft groove, then push the another inner cover shaft
into the corresponding outer tub cover shaft groove. Please install to
designated position to guarantee there are no dropping or abnormal
sound in opening and closing of the inner cover, and the operation shall
be smooth. Do not dismount the inner cover component after washing.
Outer tub cover
Outer tub cover shaft groove
Inner cover shaft
Inner cover
Section I enlarging
Damping cushion
Push
Section I enlarging
Two claws at the bottom cover shall
be inserted in two bar-shaped holes
in the stand. Make sure the claws
are firmly in place.
Before initial use of the machine, assemble the inner cover as described below:

<10cm <1.5m
5
12
> 30mm
b
1.Push "POWER" button to switch on the power
Power
Program
2.Push "PROGRAM" button to select suitable
full-auto program
After the power is switched on, "STANDARD" is automatically set. To select other full-auto program, please push
the "PROGRAM" button till the corresponding indicator is on. Refer to the "PROGRAM" button on Page 11.
E.g. Set to "POSTHASTE" program for small quantity of laundries with light soil.
The drainage shall be smooth with the drain hose.
1.The height of the drain hose shall be less than
10cm, or the drainage will not be smooth, and
cost such long time that the machine may stop
at mid way.
2.Do not step on or press the drain hose.
4.If extra drain hose is needed, please make
separate purchase. The inner diameter of the
extra hose shall not less than 30mm, and the
length shall not exceed 1.5m.
3. If the drain hose is too long, cut it at mid point.
To make smooth drainage, cut the front end of
the hose slantingly.
Usage the drain hose
5.If the extra hose is too long, cut it either at A
or at B.
AIR DRY
Steps of using the operation buttons and description
of the steps
2
SOAK
FUCTION
4
7
3
DISINFECT
20MIN
10MIN
180MIN
120MIN
60MIN
30MIN
WASH
SPEED RINSE SPIN SPEED
WATER
LEVEL
RESERVE PROGRAM POWER
ON/OFF
POWER
ON/OFF
NO WASHING
POWDER
Figure 1
The largest allowable slope of the shank base of the machine is 2 .The slanting or rough ground will result in
unstable running or stoppage of the machine. Please adjust it with following methods:
Confirm it's horizontal:
Hang the lead line to check if it is
horizontal.
Adjust the adjustable leg:
Fasten
Loosen
High Low
the adjustable nut
the adjustable feet
1 .To twist the adjustable leg, please first lift up the
side of the leg slightly, loosen the adjustable nut,
and twist the leg.
2 . After adjustment, fasten the nut.
Adjust the Installation position
SAVING
WATER
STANDARD
WOOLLEN
CARPETING
QUICK WASH
JEAN
POSTHASTE
COMMON
START
PAUSE
PROGRAM
When a standard cycle is selected, the fuzzy program is run. The water level and the washing time can be
selected according to be texture and volume of the laundry. The washing cycle is automatically controlled.
Notes:
The washing machine has a Cashmere program and a Carpet program, intended for high-grade fabrics such
as cashmere and carpet. First, make sure the laundry can be washed with water or not. If not, do not use the
washing machine to wash the laundry. If yes, select the washing cycle recommended by the fabric man
ufacturer. The Cashmere program can be used to wash fine clothes such as cashmere sweater, linen blouse,
woolen pants; the Carpet program can be used to wash carpets or heavy fabrics indicated as hand wash or
machine wash compatible. For clothes with local stains, such as sticky stains at collar or cuff, lay the clothes
upon a towel and spread neutral detergent (for washing machine) on the stains. Use a soft brush topat at the
clothes gently before putting the clothes into the machine. Do not rub the clothes hard.
Before washing, please fold up the laundry as needed, then put the laundry into the inner tub, flat and neat.
These fabrics are not washable:
1. Fabrics that deform when soaked in water;
2.Fabrics that shrink, discolor or go through other exterior changes when soaked in water;
3.Fabrics that lose original texture when soaked in water;
4.Fabrics that discolor when soaked in water;
5.Fabrics that have pilling or pressed pile when soaked in water;
6.Fabrics that have damage when soaked in water.
Upon completion of washing, iron the laundry with a steam iron.
Hold the steam iron above
the laundry and do not touch
the laundry. Reshape the
laundry. (As illustrated
in Fig 1)
Figure 2
Pin
When shrinkage occurs
Stretch the laundryto its original
size and locateit with pins.Use
a steam ironto dry thelaundry
completely. Donot touch the
laundry. (Asillustrated in Fig 2)

Reserve, remain time digitron
It displays "--" during detecting.
It displays remained reserve time (hour).
It displays total remained time (min). If the total time
exceeds 99 minutes, it uses "A" on tens digit to
represent100 minutes, and uses "b" to represent 110
minutes. E.g. "A3" represents 103 minutes.
It displays abnormal symbol in abnormal situation.
(See to Page15)
>10mm
About less than 2mm after twisting
Figure 3
Connection between the water inlet hose jointer and the water faucet
Bushing
About 4mm before twisting
2. Loosen the screw till the water faucet can be accessed. Put the jointer of the water inlet hose on the faucet.
See to Figure 2. (If the faucet is too large and the jointer can not be set on the water faucet, please loosen
the four screws and take out the bushing in the jointer. The front end of the faucet must be smooth,
otherwise it may leak water. See to Figure 3.)
1.Press the lower end of the lock lever and push down the slider. Take off the water inlet hose jointer from the
water inlet hose component. See to Figure 1.
Water faucet,not suitable
Install the water inlet hose
Screw
It is required that the front end shall be longer than 10mm.
The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage.
remark: Before installation, the threading is 4mmabove the upper surface of the nut.
After installation, the threading is 2mm above the upper surface of the nut. See to figure 6.
Figure 6
Sign plate
4 Take off the nameplate. Twist the fastening nut as per the indication of the figure
to seal up the exit end face of the faucet. See to Figure 5.
Figure 2
Screw nut
Screw knife
3.Fasten the four screws evenly. See to Figure 4.
water inlet hose jointer
Figure 5
Outlet end surface
Slider
Figure 1
Water faucet,suitable
water inlet hose
Figure 4
Lock level
Confirm the water faucet
""RESERVE button
WATER LEVEL button""
Posthaste
Jean Washing for big and thick laundries
Carpet Washing for carpet and wearing bigger
Woollen Washing for the woollen laundries,
Saving
water
Normal Washing for normal laundries
Attention Adelegates 10
The washing machine can detect the laundries automatically.
After detection, it will set the water level to suitable value among
4, 6, 8,and 10 automatically.
You can also set water level by yourself. After the machine is
started, it will not set water level automatically. You shall push the
start/pause button to make new setting.
If there's water inside the tub, the machine cannot detect the
laundries and will display water level 6 .If wet laundries are put
in, it may display water level A. You must set suitable water level
by yourself.
If posthaste program is selected, it will display water level 3 .
When water level 2 is reached in water filling, it will perform
washing while filling water. When water level 3 is reached, it will
change to normal washing.
During operation of wash and rinse program, you can push down
the water level button to add water. When you release the button, or
it reaches the overflow water level, the machine will stop adding
water.
The water level decided may be different from actual value because
of the different moisture level of the laundries.
All the program that When water level 1 is reached,it will perform
washing while filling water.When water level set is reached, it will
change to normal washing.
You can set posthaste woollen carpet water saving program
by yourself, never changed. It is to set water level 8 highest during
the standard program.
The digitron displays the time
remained (in minute) before
the washing is finished.
Push down the reserve
button. The reserve indicator
light is on the digitron displays
the reserve time of finishing
washing (in hour).The time
remain indicator light is on,
indicating that the reserve
function is running.
Push the reserve button can
display the reserve state.
"PROGRAM" button
Following full-auto program is available
Standard
Program
Quick
Application
Quick washing for normal laundries
POWER
ON/OFF
WATER LEVEL RESERVE PROGRAM
"POWER" button
Push the "POWER" button to switch on the power.
Under power-on mode, push it to switch off the power.
Push the "POWER" button to switch on the power. If
the "START/PAUSE" button is not pushed, the machine
will switch off the power automatically after 5 minutes.
Saving washing for light-soil laundries
Standard saving washing for normal laundries
Washing for light-soil a few laundries
under 2.5kg
Laundries, under 3.0kg
Child lock function
Push and hold thereserve button and spin button, then pushdown the
power on/off button.The digitron displays C L .You can continue setting
desired washing procedures.After setting ,pushdown the start/pause
button. The childlock function is activated. all of thebuttons are locked
and cannot make selection .
Release the child lock function :push down reserve button and spin
button at the sametime for more 2seconds .After a beepsound ,the child
lock function is released.
SAVING
WATER
STANDARD
WOOLLEN
CARPETING
QUICK WASH
JEAN
POSTHASTE
COMMON
The function isintended for children safety and preventing the washing
program from accidentalchanges by children.

Connection between the water inlet hose and the washer
1.Do not take off the water absorption cushion. Please check if the
cushion is dropped or damaged before each usage. If it happens
please contact our after-sale department immediately.
2 .Put the nut of the water inlet hose on the valve jointer.
3 .Fasten the nut. Swing it gently to confirm if it's suitable.
nut of the water
inlet hose
jointer of the
water inlet valve
water absorption
cushion.
Connection between the jointer of the water inlet hose and the water inlet hose
1.Push down the slider. Insert the water inlet hose into the jointer.
2 Hang the lock lever to the jointer. Release the slider till a click
sound is heard.
Locking level
the jointer of the
water inlet hose
Slider
Check the connection between the jointer of the water inlet hose
and the water faucet
1.Swing the hose gently to confirm if it is fastened stable.
2.After installation, open the faucet to check if it leaks.
3.Do not bend the hose with overstrain.
4.Before each usage please check if the connection
between the jointer of the water inlet hose and the
water faucet, and the installation of the water inlet
hose are firm, so as to prevent dropping from
improper installation position.
Dismantle the water inlet hose
1. Close the water faucet.
2. Press the locking lever. Push down the slider. Then pull of the water inlet
hose.
If the machine is used frequently, the jointer of the water inlet hose can be
kept
on the faucet to prevent damaging the fixing screw.
Locking level
Slider
Description of operation button
5 Use the operation button
Indicator mode and meaning
Flashing, indicating the running program
On, indicating the program about to run or the selection mode
"START/PAUSE" button
After the poweris switched on, press it to
start the machine
During working, pushit to pause.
During pause, pushthis button to restart
and go onworking
a
START
PAUSE AIR DRY RINSE
SOAK
FUNCTION
WASH
SPEED
SP IN
SPEED
""RINSE button
"AIR- "DRY button
Push the D button ,then the D
is on, D
The purpose isdrying the
inner tub andthe outer tub, which can avoid
growing mildew onthe outer tub and the inner
tub.
"AIR- RY" "AIR- RY"
indicator light that means the "AIR- RY"
program is chosen.
"SOAK/FUNCTION "button
"WASH/SPEED " button
"SPIN/SPEED " button
NO WASHING
POWDER
DISINFECT
180MIN
120MIN
60MIN
30MIN 10MIN
20MIN
Press the Soak/Function buttonto
select a soakprocedure.
The button can beused to select the
desired soak time, i.e.,0, 10, 20 or30
minutes from the Basicprogram or the
Jeans program.
The button is unavailablefrom the Fast,
Extra Fast, Standard, Cashmere,
Carpet and WaterSaving programs.
From the Basic, Fast,Extra Fast or
Jeans program, press thebutton for 2
seconds. There is abuzz that indicates
the machine is readyfor function
selection. Press the buttonagain to
select No detergent orDisinfection.
When No Detergent isselected, the
related indicator lamp ison. In this case,
the maximum washing capacityis 4.0kg
and the maximum waterlevel is 8. When
Disinfection is selected, therelated
indicator lamp is onand the disinfection
function is initiated.
When No Detergent isnot selected, i.e.
the No Detergent indicatorlamp is off, a
detergent-dependent cycle is inplace.
Press the button for2 seconds. There is
a buzz that indicatesthe function
selection is complete. Thenthe soak
time can be selected.
Press the Washbutton to select a
wash .procedure
The button can beused to select
the desired wash time,i.e., 0-25
minutes from the Basicprogram or
the Jeans program.The button is
unavailable from the Fast, Extra
Fast, Standard, Cashmere,Carpet
and Water Savingprograms.
For a pause duringoperation or an
initial operation, press thebutton
for 2 seconds tostart wash speed
selection. The Washindicator lamp
is on and thespeed from 1 toA is
available for selection.The default
value is 8.After restart, the machine
is back to washselection.
Press the button for2 seconds.
There is a buzzthat indicates the
speed selection is complete. Then
the wash cycle canbe selected.
Note: 1. No speedselection from
the Cashmere, Carpet and
Water Saving programs.
2. A = 10
Press the Rinse buttonto select a
rinse .procedure
The button can beused to select
the desired number ofrinse cycles,
i.e., 0, 1, 2or 3 times fromthe
Basic program or theJeans program.
The button is unavailablefrom the
Fast, Extra Fast, Standard,
Cashmere, Carpet and Water
Saving programs.
For the Basic program,the Water
Saving mode is selected
automatically. Ifthe button is
pressed before operation,it will
change to WaterFilling mode.
Press the Spin/Speed button to
select a spin .procedure
The button can beused to select
the desired spin time,i.e., 0-9
minutes from the Basicprogram
or the Jeans program.
The button is unavailablefrom the
Fast, Extra Fast, Standard,
Cashmere, Carpet and Water
Saving programs.
For a pause duringoperation or
an initial operation, pressthe
button for 2 secondsto start spin
speed selection. TheSpin
indicator lamp is onand the
speed from 1 toA isavailable for
selection. The defaultvalue is 8.
After restart, the machine is back
to spin selection.
Press the button for2 seconds.
There is a buzzthat indicates the
speed selection is complete.
Then the spin cyclecan be selected.
Note: 1. No speedselection from
the Cashmere, Carpetand
Water Saving programs.
2. A = 10

As the top lid opened, the washer will automatically given alarm and stop running, exclusively during draining.
4. Close the top lid
The capacity of washing of the machine refer to the largest weight of the
standard laundries under dry condition that can be washed in one
time. Laundries quantity in one washing cycle shall be lower than
the rated capacity.
The thickness ,size , type of the cloth will influence the actual washing capacity.
It is suitable to put in reasonable amount of laundries and the laundries can be turned
round in washing for one time washing.
Do not select " 4" water level for laundries less than 1.0kg ,so as to avoid
splashing of water.
2.Put in the laundries
Add washing powder and softener into the
box directly as per indicated in left figure.
After adding, close the box.
How to use whitener
How to use washing powder
Washing powder with poor quality or long-time storage may
get caked. Please clean the detergent box duly in usage.
Dissolve directly inside the washing machine: (not
applicable for fuzzy and reserve program)
1.Add some water
2.Add washing powder. Run for about 30s to fully dissolve
the Powder. Then push the"START/PAUSE" button.
3.Put in laundries. Select suitable water level. Push the
"START/PAUSE" Button again.
Quick dissolving of washing powder:
1.Prepare warm water of 30 C and container.
2. Add washing powder while stirring to dissolve it completely.
It is not recommended to use rich-foam washing powder.
Washing powder inlet
Washing powder box
Softener inlet
Control panel seat
3. Usage of detergent
Liquid detergent
inlet
If you select POSTH ASTE program, it is suggested to use
liquid detergent instead of washing powder to guarantee
the washing effect.
""
Please add suitable washing powder as per the laundries
quantity, the set water level and water quantity.
It is suggested to add washing powder into the box
directly under fuzzy program and reserve program.
The whitener shall not touch laundries directly.
Add water to stipulated level. Dilute the whitener with container,
and then pour it into the liquid whitener inlet slowly.
Laundries with color or pattern is not colorfast, thus not applicable.
For whitener in powder, dissolve it before use.
See to the manual of whitener for the usage and dosage.
Confirm if there's
special requirement
for the laundries.
Clear the pocket.
Take out the coins ,
sand, hairpins etc.
Fasten the buttons
and zippers.
When the pulsator is
running ,the buttons of
the laundries may cause
noise. For the sake of
discretion ,please put
the laundries with
buttons into other
laundries.
The quantity of the
laundries shall not
exceed the rated
value. The big
laundries like the
jeans shall be put
in loosely.
a. Check if the laundries are applicable for washing with machine.
b. Divide the laundries with unfast color from other laundries.
c. Put those laundries difficult to absorb water into water with hand.
d. For those laundries with heavy soil, please first remove the dirt like mud or dust. For the parts with heavy soil,
please apply detergent in advance, which can make it easier to remove the soil.
e. For those laundries that may get lint ball and those with long fur, turn it over before putting in.
f. Do not put those laundries polluted by chemicals directly into the washing machine.
For those small laundries and those may get twisting or worn, and woolen/fur laundries, please put them into
mesh bag for washing.
1 Preparation before washing
Preparation before washing
1.Connect the water inlet hose.
2.Confirm that the washing machine is earthed
reliably. Then insert the power plug into the
receptacle. Do not connect the earth terminal
to the gas pipe and tap water pipe.
3.Put down the drain hose.
4.slanting or uneven ground may result in
unstable working or abnormal noise. Please
make the machine stand horizontally.
Pay attention to followings before washing the laundries
When choosing the " No washing powder" program, the
usage of softener or bleacher is same as using detergent.
