Haiku L3127-X5 User manual

INSTALLATION GUIDE
INSTALLATION GUIDE

CONTACT US
By selecting a Haiku®fan, you’ve chosen quality design, heightened comfort and eortless conservation. Use this
guide to safely install your fan. Please contact us with any questions you may have.
United States
2348 Innovation Drive
Lexington, KY 40511
855 694 2458
Australia/Oceania
Unit 22, 1029 Manly Road
Tingalpa QLD 4173, Australia
1 300 BIG ASS
Asia Pacific
18 Tampines Industrial Crescent #06-07
Singapore 528 605
+65 6709 8500
East Asia
Room 808, Tai Yau Building
181 Johnston Road
Wan Chai, Hong Kong
+852 2836 5808
Scan for online Haiku Home app help

Topic Page
Technical Specifications 2
Tools Needed 2
Parts 3
Hardware 4
Prepare the Fan Site 5
Install Your Fan 6
READ AND SAVE THESE INSTRUCTIONS
Installation Guide
For operation, maintenance, and
troubleshooting information, visit
haikuhome.com/help

2
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
Disconnect power to the fan location before installing the fan! Do not use the fan with a dimmer
switch!
If required by your local electrical code, a licensed electrician must install the fan.
The ground wire must be connected to the supply ground and its length must be longer than the
safety cable!
Technical Specifications
Check the fan label to make sure it is the correct voltage.
Model Operating voltage Diameter Weight Operating frequency
L3127-X5 120 VAC, 1 Φ 132 cm 5 kg 60 Hz
L3127-X6 220/240 VAC, 1 Φ 132 cm 5 kg 50/60 Hz
Tools Needed
• Ladder
• Wire Strippers
• Phillips Screwdriver (provided)
• Hex Key (provided)
• Wrenches (provided)
Box Contents
As you remove the fan from its packaging, make sure you are not missing any components required for
assembly and operation. If you ordered multiple fans, be sure to keep the components of each fan together!
!
!
!

3
HAIKU® HOME
Mounting Bracket
Control Box
Wiring Cover
LED Diuser Ring
Mounting Ball and Hardware†
Lower Cover Trim
Lower Cover Ring
Extension Tube††
Motor Unit
(3) Airfoils
Remote Control
Hardware Pack
Wiring Harness†††
Wall Control Wi-Fi Module††††
PARTS
See the following page for hardware.
a
b
c
d
e
f
g
h
i
j
k
l
m
a
b
c
d
e
f
g
h
i
j
k
l
m
See Hardware page
Two lengths provided
Packaged with control box
Packaged with wall control
†
††
†††
††††
n
n

4
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
HARDWARE
Hardware and tools needed for installation are packaged in the hardware pack. Hardware below shown at
actual size.
Mounting Hardware
M8 Bolt M8 Washer M8 Nylock Nut
Airfoil Hardware
(6) M5 Screws with Tooth Washer
Lower Cover Hardware
Mounting Ball and Hardware
Steel Pin
Wedge 4 mm Self-Tapping
Screw
Mounting Ball
(2) Painted M3.5 Screws
or
BlackWhite
Wiring Cover Hardware
(4) M4 Socket Head Cap Screws

5
HAIKU® HOME
1PREPARE THE FAN SITE
Installation requires basic electrical knowledge. Contact a licensed electrician if you are uncomfortable
performing electrical work or if legally required in your area.
Disconnect Power!
If you are installing the fan directly
to the building structure or to a
ceiling-mounted outlet box, the
structure or outlet box must be
suitable for fan support.
For softer lighting, remove the white
lens and install the smoky lens before
attaching the airfoils.
1. Twist to uninstall white lens.
2. Twist smoky lens to lock in place.
Mounting Structure 3
2
1Black Fans Only
Disconnect power to the fan
location before wiring fan!
A readily accessible disconnect
device shall be incorporated
external to the equipment.
A means for disconnection
must be incorporated in the
fixed wiring in accordance with
the wiring rules.

6
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
2CONNECT THE WIRING HARNESS
AC HOT/L1
AC NEUTRAL/L2
GREEN
BLUE
BROWN
PE/EARTH GROUND
Do not connect the green (Earth/Ground)
wire on the wiring harness at this step.
To supply
power
a

7
HAIKU® HOME
Make sure power is disconnected before wiring the fan!
If required by your local electrical code, a licensed electrician must install the fan.
Do not connect the fan to a damaged power source! Do not attempt to resolve electrical failures on
your own. Consult a qualified electrician if uncertain of the electrical installation of this fan.
Make the electrical connections by securing the supply power wires to the loose ends of the wiring
harness (a) with the provided wire nuts or a terminal strip (or the means of connection required by your
local electrical code).
Test the connection by lightly tugging on the wires. Do not connect the green (Earth/Ground) wire on
the harness at this step!
Tuck the power wiring into the outlet box or building structure so that only the harness and the supply
Earth/Ground wire hang through.
AC HOT/L1
BROWN
AC NEUTRAL/L2
BLUE
PE/EARTH GROUND
GREEN
AUSTRALIA Brown or Red Black or Light Blue
Green with Yellow Tracer
ALL OTHER REGIONS Brown Blue
!
!
!
3
2
1

slope
open side
slope
8
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
Outlet Box
If your local electrical code requires the fan to be installed on a ceiling-mounted outlet box, the outlet box
must be suitable for fan support. If there is not an outlet box at the fan location, one should be installed on
a ceiling joist or beam and properly wired.
Concrete Ceiling
If installing your fan on a concrete ceiling, ensure
power wiring has been routed to the fan site. Attach
the mounting bracket directly to the ceiling using four
Ø 6 mm anchor bolts (not supplied). If required by
your local building and safety code, install an Ø 8 mm
anchor hook (not supplied) for the safety cable.
Wood Ceiling Joist
If installing your fan on a wood ceiling joist, ensure
power wiring has been routed to the fan site.
Attach the mounting bracket directly to the joist
using two wood screws (not supplied). Haiku Home
recommends using corrosion-resistant 12-11 x 45 mm
hex head timber screws with seal.
INSTALL THE MOUNTING BRACKET
3
Sloped Ceilings
If mounting to a sloped ceiling, install the mounting
bracket so that the open side faces upward with the
slope.

9
HAIKU® HOME
3a Outlet Box
Page 10
3c Wood Ceiling Joist
Page 14
3b Concrete Ceiling
Page 12

10
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
INSTALL THE MOUNTING BRACKET (OUTLET BOX)
3a
b
a
c
Installation may vary. Refer to the outlet box instructions.

11
HAIKU® HOME
STEP COMPLETED
Make sure power is disconnected before installing the mounting bracket!
Secure the mounting bracket (a) to the outlet box (b) with the screws supplied with the outlet box (c).
Outlet Box Hardware:
c. Screw (supplied with outlet box)
!

≥ 50 mm
b b b b
12
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
INSTALL THE MOUNTING BRACKET (CONCRETE CEILING)
3b
c
≥ 65 mm
aØ11–12 mm
Use the mounting bracket as a template to mark
drill locations for the four mounting holes.
Install an anchor hook for the
safety cable if required by your
local building and safety code.

13
HAIKU® HOME
STEP COMPLETED
!Make sure power is disconnected before installing the mounting bracket!
Using the mounting bracket (a) as a template, mark drill locations for the four mounting holes on the
concrete ceiling. Drill four Ø 11–12 mm holes into the marks. The hole depth should be at least 50 mm.
Remove any dust from the holes. Insert four anchor bolts (b) into the holes. Strike the heads of the
anchor bolts with a hammer, ensuring the bolt sleeves are flush with the ceiling surface.
Concrete Ceiling Hardware:
b. (4) Ø 6 mm anchor bolts (not supplied)
Position the mounting bracket on the anchor bolts. Ensure all four anchor bolts are fully tightened to
expand and lock the anchors.
If required by local building and safety codes, install an anchor
hook (c) for the safety cable. Drill a Ø 13–14 mm hole for the
anchor hook. The hole depth should be at least 65 mm. Remove
any dust from the hole, and then insert the anchor hook and
fully tighten. Refer to the Safety Cable instructional sheet included
with this guide.
Concrete Ceiling Hardware:
c. Ø 8 mm anchor hook (not supplied)
3
2
1
4

14
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
INSTALL THE MOUNTING BRACKET (WOOD CEILING JOIST)
3c
a
b(not supplied)
ceiling joist

15
HAIKU® HOME
Make sure power is disconnected before installing the mounting bracket!
Secure the mounting bracket (a) to the joist with two (2) 12-11 x 45 mm hex head timber screws with seal (b).
Wood Ceiling Joist Hardware:
b. (2) 12-11 x 45 mm hex head timber screws with seal (not supplied)
!
STEP COMPLETED

16
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
CONNECT THE EARTH/GROUND WIRES
4
db
a
c

17
HAIKU® HOME
Secure the supply ground wire (a) to the ground wires from the wiring harness (b) and the mounting bracket
(c) with the terminal strip (or other means of connection required by your local electrical code).
Tuck the terminal strip into the mounting bracket so that only the wiring harness hangs through.
STEP COMPLETED

18
REV. C ●© 2015 HAIKU HOME. ALL RIGHTS RESERVED.
INSTALL THE AIRFOILS
5
b
c
a
Make sure the stickers on the airfoils match the
stickers on the fan hub!
