Hailink EXOB03R User manual

HDMI Extender Over 2 x Cat5e/6/7
User Manual
EXOB03R
Full 3D Pass-through
Support IR Control
30M Solution

INTRODUCTION
•1 x HDMI Transmitter unit, 1x HDMI Receiver unit
•2 x 5V DC power supply
•1 x User Manual
•HDMI, HDCP 1.2 and DVI compliant
•Support full 3D pass-through
•Support high resolution up to 1080P
•Super IR control system, IR transport channel can be forward or backward
per your installation
•Extend to 30M over 2 x Cat5e/6/7
•Support CEC bypass
•External and internal EDID settings
FEATURES
PACKAGE CONTENTS
If you are looking for a way to extend an HDMI signal, then this HDMI
Transmitter and Receiver is what you have been searching for. This HDMI
extender allows you to use two Cat.5e/6/7 cables to extend the HDTV display
up to 30M for 1080P without any loss. It is equipped with HDMI connector
and is capable of supporting DVI equipment when used with an HDMI to DVI
adaptor. And if that weren’t enough, you can use a remote to control your
device from over 30m away through an IR blaster.
It follows the standard of IEEE-568b, Cat.5e/6/7 cable can substitute HDMI
cable to achieve long distance transmission. It is designed for use in home
theater, professional A/V and personal computer switching applications.

PANEL DESCRIPTION
Transmitter Unit
Receiver Unit
1 POWER SUPPLY INPUT
2 HDMI INPUT
3 IR OUTPUT
4 CAT5E/6/7 OUTPUT
1 CAT5E/6/7 INPUT
2 IR INPUT
3 HDMI OUTPUT
4 POWER SUPPLY INPUT
1
DC 5V
HDMI Extender Over CAT 5E/6/7
TX
HDMI Source IR Channel
Cat5e/6/7-1 Cat5e/6/7-2
DC 5V
HDMI Extender Over CAT 5E/6/7
RX
HDMI LCD IR Channel
Cat5e/6/7-1 Cat5e/6/7-2
2
4
3
4
1
3
2

INSTALLATION
CONNECTION DIAGRAM
•Connect HDMI input port on transmitter to the signal source equipment
such as DVD player.
•Connect the 2x CAT5e/6/7 output of the transmitter with 2 CAT5e/6/7
cables to the CAT5e/6/7 inputs of the receiver.
•Connect to the IR blaster cable (not included in the package) for IR signal
transmission. Place the IR blaster in direct line-of-sight of the equipment to
be controlled.
•Plug the 5VDC power supply into the unit and connect the adaptor to
AC outlet.
•Connect HDMI input port on receiver to HDMI displays.
•Connect to the IR receiver cable (not included in the package) for IR
signal reception. Make sure that the remote being used is in direct
line-of-sight of the IR receiver.
•Plug the 5VDC power supply into the unit and connect the adaptor to
AC outlet.
DC 5V
DC 5V
30 M Extension Over 2 x CAT5e/6/7
08：08 PLAY
HDMI Extender Over CAT 5E/6/7
TX
HDMI Source IRChannel
HDMI Extender Over CAT 5E/6/7
RX
Cat5e/6/7-1 Cat5e/6/7-2

SPECIFICATION
Transmitter
Input Port
Output Port
Receiver
Input Port
Output Port
Bandwidth
Output Resolution
Operating Temperature
Deep Color
Chassis
Dimension
Weight
Power Supply
1 x HDMI (Female Connector)
1 x IR Channel, 2 x Cat5e/6/7
1 x IR Channel, 2 x Cat5e/6/7
1 x HDMI (Female Connector)
10.2Gbps
480i~1080P@50/60,1080P@24/50/60,
VGA~UXGA
-15℃~55℃/5°F~131°F
36bit
Metal
83mm(L)x46mm(W)x22mm(H)
210g
DC 5V

Please read the following safety precautions carefully before you unpack
and install this equipment.
1.Do not expose the unit to rain, moisture or any other dripping liquids. And
keep it away from any wet locations such as fishing tanks, vases.
2.Do not install the unit close to fire or any other heat sources.
3.Keep the unit in dry and ventilated area. Do not install in bookcase,
cabinet or any other confined space.
4.Stop using the unit during thundering or lightening storms.
5.Avoid the power cable to be stepped on or pinched. Position the unit
carefully to avoid damage or accident.
6.Clean the unit only with dry cloth.
7.Only use accessories specified by the manufacturer.
8.Unplug the equipment when unused for a long period of time.
9.Do not try to open any non-serviceable parts. Contact your authorized
servicing center and personnel.
SAFETY PRECAUTIONS
Tel:[phone]
Fax:[phone]
Email:[email protected]
Http:www.hailink.cn
Danger Electric
Shock Risk
Keep Dry
Keep Away
from Heat
