Hall Research Technologies 200 User manual

U
Us se e
r
r’ ’s s M Ma an nu ua al l
2, 4, and 8-Channel
VGA Video Splitter / Distribution Amplifier
UMA1005 Rev. B
Order toll-free in the U.S. 800-959-6439
FREE technical support, Call 714-641-6607 or fax [phone]
Mail order: Hall Research, 1163 Warner Ave. Tustin, CA 92780
Web site: www.hallresearch.com E-mail: in[email protected]
CUSTOMER
SUPPORT
INFORMATION

Page 2of 4
Description
The Models 200, 400 and 800 are VGA video splitters that employ the latest technologies in
high-resolution video distribution. The devices are compact, lightweight, low power, and highly
reliable. The splitters terminate, buffer and amplify the computer's video signal with wide-
bandwidth integrated circuits for display on multiple monitors. Depending on the length of the
cable used, each output can reproduce a sharp and crisp image at any resolution up to 1920
x 1440.
The Splitters are capable of driving video extension cables to 150 feet or more depending on
the resolution being displayed. Included with the device are a small power adapter and a 6 ft
multi-coaxial cable for connection to the PC’s video.
Features
•Supports any resolution up to 1920x1440 at refresh rates from 60 to 85 Hz
•Rugged, Reliable, Economical
•No software required
•Drives cables to 150 ft or more
•Easily expand outputs by daisy-chaining
Setup
This section gives you setup information on the Model 200, 400, and 800 video splitters. Your
package should include a six foot VGA-Type video cable, a power adapter, and the Video
Splitter unit itself. Please take inventory of all items received and ensure that you have the
above items.
Locate the Video output connector on the Computer. This connector is generally a HD15
female with three rows of contacts. Using the cable supplied, connect the input of the Splitter
to the computer.
Connect the monitors directly to the outputs of the Splitter, or use high-quality extension
cables to remotely locate the monitors. Connect the supplied AC power adapter to the Splitter
and plug it in the AC source.
Do Not Substitute Any Other DC Power Source (See Specifications for Details)
If you are using long video cables (greater than 25 feet) on the output of the splitter, it is best
to ensure that the cable is connected to a monitor (which properly terminates the signals),
otherwise disconnect the cable from the Splitter.
The Splitters are cascadable (i.e. connected in series) to provide large number of outputs if
desired.
Standard Splitters can drive 150 feet of video cable without appreciable loss of resolution. For
longer runs, Model 400-DX or VGA-to-CAT5 converters are recommended.

Page 3of 4
Plug-and-Play
DDC (Direct Data Channel) is a standard by which a compatible monitor sends its
identification and other parameters to a PnP operating system such as Windows 98 etc. Only
one of the monitors connected to the splitter is allowed to communicate with the operating
system. This means that the user should ensure that either all the monitors can support the
resolution which will be set or disable the DDC and force any desired resolution and refresh
rate from the “Display Properties” screen of the operating system. If upon connecting the
Splitter you get a blank screen, it could be that your PC is looking for a monitor but cannot find
any. In this case, either plug a monitor directly to the PC and disable PnP (by choosing a
different standard-type monitor), or have at least one monitor plugged in to the specific output
of the splitter that is assigned to the DDC channel (see Specifications for details).
Connection Diagram
Specifications
Equipment included:
•UL approved 110 VAC adapter (6 VDC @ 300 or 800 mA output)
•6 ft, high-resolution (multi-coaxial) video input cable
•User’s Manual
Dimensions: L x W x H:
Model 200 - 4¼ x 2¾ x 1¼ Model 400 - 7¼ x 2¾ x 1¼ Model 800 - 7¼ x 2¾ x 2¼
Video Specs:
Connectors Input and Outputs: HD15 female
Coupling DC
Signal Level Video: 0.7 v p-p
Bandwidth: Range: DC to 250 MHz
Input impedance: Video: 75 ohms on RGB, 1K ohms on H, V
Plug-n-Play: DDC-Channel from Monitor to PC is on the following output positions:
Model 200 – Output #1 Model 400 - Output #4 Model 800 - Output #8

Page 4of 4
Power Requirements:
The splitters rely on the AC power adapter, which is supplied with the unit. The adapters
generate 6V DC power for the device. If you intend to use a different external DC power
supply, the splitters may not function properly.
Hall Research manufactures Splitters that can operate from customer supplied external DC
power supplies from 5 v to 24 v DC. Please contact factory or your distributor for details and
pricing information.
Federal Communications Commission Statement
This equipment generates, uses and radiates radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. This equipment has been tested and found to comply with the limits for a Class
A computing device, pursuant to Part 15 of the FCC rules. Harmful interference when operated in a commercial environment. Operation of
this equipment in a residential area is likely to cause interference, in which case the user, at his own expense, will be required to take
whatever measures are necessary to correct the interference.
If necessary, you should consult the place of purchase or and experienced radio/television technician for additional suggestions.
Warranty
Hall Research warrants that the supplied equipment is free from defective workmanship and material. Subject to the
agreements set forth, will repair or replace, at its option, the defective components for a period of 2 years after purchase.
The following conditions apply to the Warranty:
•Warranty void if item subject to improper use, negligence, or unauthorized modification
•Instructions must be followed in obtaining RMA number as explained below
•Any defective part should be returned, insured and freight prepaid, to Hall Research, with the following:
Return Material Authorization Number (RMA#)
Description of failure, as detailed as possible
Shipping address and contact name and phone number
Limited Liability
IN NO EVENT SHALL THE DIRECT VENDOR’S LIABLITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL
INCIDENTAL OR CONSEQUENTIAL DAMANGES RESULTING FROM THE USE OF THE PRODUCT OR ITS DOCUMENTATION
