Haloview BT12 User manual

10.2" 1080P Carplay Monitor
BT12

1. Functions of each part -----------------------------
2. Package contents ----------------------------------
3. Specifications ---------------------------------------
4. TF card requirements -----------------------------
5. Installation -------------------------------------------
6. Smart box --------------------------------------------
7. Menu --------------------------------------------------
8. Carplay/Android auto connection tutorial------
12
11
10
7
6
2
1
1

The Haloview BT12 vehicle observation carplay monitor carry two 1080P cameras installed
inside/outside of the vehicle to capture images around the vehicle while navigating and music
listening. It’s a combination of carplay, dashcam and rear view real-time observation. With this
system, drivers can intuitively see the obstacles and pedestrians around the vehicle, which
effectively reducing the occurrence of accidents such as scratches and collisions. The video
recording function it has can record the driving picture as valid evidence.
Power Button
Microphone
TF Card Slot
Item Picture Description Quantity
Carplay Monitor
10.2"(1600*600)
carplay monitor
support 2 channels
of cameras
1
Cameras Wired 1080P Dashcam
Wireless 1080P Camera 2
Smart Box BMW connector x 1
5V output port x 2 1
Camera
Extension
Cable
3.5m x 1
1.5m x 1
2
1. Functions of each part
2. Package contents
1

Mount Base 1
TF Card 64G C10/U1
Suction Mount 1
1. Static Sticker for
Dashcam
2. Anti-glare film for
display
2
Introduction Function
Language English/Simplified Chinese/Traditional Chinese/
Japanese/Korean/French/Italian/Spanish, etc
Interface Graphic MENU
Operation
Touch screen/Push button
Short press to standby the screen.
Long press to turn ON/OFF
Monitor (BT-M12)
Video
Input
Video Input 2 Channels 1080P Cameras
Default boot recording, no missing seconds,
automatic recording after 15 seconds of no operation
Recording
Recording format TS, video saved separately, dashcam recorded file is
2.5K/1080P/720P optional, rear view cameras recorded
file default 1080P.
3. Specifications
2
1

Display
Real-time display
Display Mode
Playback
Screen Saver
10.2" 1600*600MIPI
Single channel display and split display
Local playback can be viewed at any time,
or select the playback button to urgent-record,
lock or delete files, support real-time viewing
and playback via mobile phones.
1 minute/3 minutes/5 minutes/off
Storage SD Card CLASS10 U1 or above, minimum 64GB,
maximum support 256GB
Wireless
Connection
WIFI Support IOS carplay/Android auto
Supports RoadCam wireless connection
Bluetooth Support bluetooth music, bluetooth calling
FM Support FM range 87.5-108.0MHz,
the minimum unit is 0.1MHz
Audio
Microphone Support audio recording. Audio recording can
be set ON/OFF.
Voice Control
Temporarily only English is supported.
A variety of voice control commands.
Note: The voice control may be affected
in noisy environment.
The working voltage is DC11-18V, with
vehicle-grade surge, overload, overvoltage,
undervoltage, short circuit and other power
protection circuits, suitable for various vehicles.
Power input
Power
Others
Working Temperature -20~65℃
video duration
Mirror/Flip
Video recording time can be set
Split display can respectively set mirror and flip
license plate settings Supported
Time Setting Supported
Brightness Setting Supported
Volume Adjusment Supported
3

Smart Box (BTR100)
Output Pixels
Operation Frequency
Transmission Distance (barrier free)
Transmission Power
Video Codec
Spread Spectrum
Latency
RF Bit Rate
Power Supply
1920 ×1080
2400-2483MHz
300m (984ft)
18dBm
H.265
DSSS
120ms
12Mbps
DC11~18V
Dashcam (CA617)
Image Device
TV System
Effective Pixels
Pixel Size
Video Output
Scanning System
Sync. System
Gamma Consumption
AGC
White Balance
BLC
Electronic Shutter
1/2.9” CMOS
25fps/30fps
1920x1080
2.8umx2.8um
10bits MIPI
Progressive Scanning
Internal
0.45
Auto
Auto
Auto
Electronic Rolling Shutter
4

Viewing Angle
Audio
LED
Power Supply
Waterproof rating
Minimum Illumination
Operating Temperature
Storage Temperature
140°
No
No
DC10~32V
IP69K
0.5Lux
-30℃ ~ 80℃, RH95%MAX.
-20℃ ~ 70℃, RH95%MAX.
Wireless Rear View Camera (BTC128)
Image Device
TV System
Effective Pixels
Pixel Size
Video Output
Scanning System
Sync. System
Gamma Consumption
AGC
White Balance
BLC
Electronic Shutter
Operation Frequency
Transmission Distance (barrier free)
1/2.9" CMOS
25fps/30fps
1920×1080
2.8um×2.8um
8bits YUV
Progressive Scanning
Internal
0.45
Auto
Auto
Auto
Electronic Rolling Shutter
2400-2483MHz
300m (984ft)
5

The quality of the SD card has a great influence on the stability of the video recording.
In order to record the video safely, please choose the best SD card such as SanDisk,
Kingston, Toshiba and Samsung. The speed must be at least Class10/ U1.
Transmission Power
Video Codec
Spread Spectrum
Latency
RF Bit Rate
Minimum Illumination
Power Supply
Night vision distance
Waterproof rating
Viewing Angle
Audio
LED
Operating Temperature
Transmission Distance (barrier free)
18dBm
H.265
DSSS
120ms
12Mbps
0Lux
DC10~32V
8~10m (26-32ft)
IP69K
120°
Yes
6 x LED
-30℃ ~ 80℃, RH95%MAX.
-20℃ ~ 70℃, RH95%MAX.
4. TF card requirements
6

Installation Method 1:
Mount Carplay Monitor on Rearview Mirror
Installation Method 2:
Mount Carplay Monitor on Front Windshield by Provided Sunction Bracket
Wired Dashcam
1.5m or 3.5m cable
RX BOX Wireless Camera
RX BOX Wireless Camera
Suction Mount
Wired Dashcam
1.5m or 3.5m cable
5. Installation
7

Dashcam installation
1. Please wipe the front windshield with cleaning paper before installation.
2. Paste the provided static sticker on windshield.
3. Tear off the film of 3M glue, and then stick it on the static sticker
4. Turn the camera up and down to adjust to the appropriate angle.
Reaview Camera installation
