Hama 00176547 User manual

GB
Operating instruction
WiFi Devices
WiFi-Geräte
00176547
00176548
00176549
00176550
00176551
00176552
00176553
00176554
00176555
00176556
00176558
00176559
00176565
00176566
00176567
00176568
00176570
00176571
00176573
00176574
00176575
00176576
00176577
00176578
00176579
00176581
00176582
00176583
00176584
00176585
00176586
00176587
00176588
00176589
00176590

2
1. Read first ..............................3
1.1 Explanation of Warning Symbols and Notes3
1.2 Safety Notes .........................3
2. Introduction............................3
3. System Requirements ....................3
3.1 Preparation ..........................4
Loading the Hama Smart Solution app .......4
3.2 Dual-band routers (2.4 GHz / 5 GHz). . . . . . .4
4. Mounting and getting Started .............5
4.1 WiFi LED bulbs .......................5
4.1.1 Product features......................5
4.1.2 Integrating lamps in the Hama Smart Solution
app ....................................5
4.2 WiFi wallswitch.......................7
4.2.1 Product features......................7
4.2.2 Mounting ...........................7
4.2.3 Integrating devices in the Hama Smart Solution
app ....................................7
4.3 WiFi Power Socket/Power Strip ..........8
4.3.1 Product features......................8
4.3.2 Integrating devices in the Hama Smart Solution
app ....................................8
4.4 WiFi Door / Window Contact ............9
4.4.1 Product features......................9
4.4.2 Mounting ...........................9
4.4.3 Integrating devices in the Hama Smart Solution
app ...................................10
4.5 WiFi Motion Detector .................11
4.5.1 Product features.....................11
4.5.2 Mounting
......................................12
4.5.3 Integrating devices in the Hama Smart Solution
app ...................................13
4.6 WiFi camera ........................13
4.6.1 Product features.....................13
4.6.2 Installation.........................14
4.6.3 Integrating devices into the Hama Smart
Solution app ............................14
4.7 WiFi controller for LED strips ...........15
4.7.1 Product features.....................15
4.7.2 Installation.........................15
4.7.3 Integrating devices into the Hama Smart
Solution app ............................15
5. Timer, automation and 1-click control ......16
5.1. Timer*.............................16
5.2 1-click control and automation .........16
6. Integration in Amazon Alexa .............17
7. Integration in Google Home ..............17
8. FAQs and support ......................18
10. Care and Maintenance .................23
11. Warranty Disclaimer ...................23
13. Declaration of Conformity...............23

3
GOperating instruction
1. Read first
Thank you for choosing a Hama product.
Take your time and read the following instructions and
information completely. Please keep these instructions in a
safe place for future reference. If you sell the device, please
pass these operating instructions on to the new owner.
1.1 Explanation of Warning Symbols and Notes
Risk of electric shock
This symbol indicates product parts energized with a
dangerous voltage of sufficient magnitude to constitute a
risk of electric shock.
Warning
This symbol is used to indicate safety instructions or to
draw your attention to specific hazards and risks.
Note
This symbol is used to indicate additional information or
important notes.
1.2 Safety Notes
•This product is intended for private, non-commercial use
only.
•Use the product for its intended purpose only.
•Protect the product from dirt, moisture and overheating,
and only use it in a dry environment.
•Do not drop the product and do not expose it to any
major shocks.
•Do not operate the product outside the power limits
given in the specifications.
•Do not use the product in the immediate vicinity of
heaters or other heat sources or in direct sunlight.
•Do not open the device or continue to operate it if it
becomes damaged.
•Do not attempt to service or repair the product yourself.
Leave any and all service work to qualified experts.
•Use the item only in moderate climatic conditions.
•Do not use the product in moist environments and avoid
splashes.
•Buy special or suitable installation material from a
specialised dealer for wall-mounting.
•After the product has been mounted, check that it
is sufficiently secure. You should repeat this check at
regular intervals.
•Before mounting, check that the wall you have chosen
is suitable for the weight to be mounted. Also make
sure that there are no electric, water, gas or other lines
running through the wall at the mounting site.
•Do not modify the product in any way. Doing so voids
the warranty Children are not permitted to play with the
device. Children may not clean the product or perform
user maintenance without supervision.
•Keep this product, as all electrical products, out of the
reach of children!
•Dispose of packaging material immediately according to
locally applicable regulations.
•The product is intended for indoor use only.
•The product may only be operated with the type of power
supply network described on the name plate.
•Benutzen Sie das Produkt nicht in Bereichen, in denen
elektronische Produkte nicht erlaubt sind.
2. Introduction
Control your smart devices very easily using an app, a
switch or your voice. Our smart products can be easily
connected to your wireless home network via WiFi. No
additional gateway is required; they work with every
WLAN router. They can be controlled using a mobile device
(mobile phone/tablet) and using the Amazon Alexa/Echo
and Google Home voice services (not 00176553).
3. System Requirements
Note - Alexa*
To use the product with Amazon Alexa, you need a de-
vice that supports Amazon Alexa (for example, Amazon
Echo/Echo Dot, etc.). The device must be integrated in
your home network and connected to the Internet.
Note - Google*
To use the product with Google, the Google Assistant
must be integrated in your home network and connected
to the Internet.
Note - IFTTT
The service for the support of the IFTTT software through
the products listed here has been discontinued. However,
it is possible that printed operating instructions or pack-
aging still refer to this discontinued service.
Note
The following requirements must be fulfilled for success-
ful startup and operation:
•A functioning wireless home network (WiFi/WLAN)
that is turned on
•Please note that only 2.4 GHz WiFi is currently
supported for the network integration. Check whether
your network is a 2.4 GHz network.
•A mobile device (smartphone, tablet, etc.) that is WiFi/
WLAN-enabled and connected to your home network
•The Hama Smart Solution App, installed on your
mobile device
*Does NOT affect the motion detector 00176554

4
3.1 Preparation
Loading the Hama Smart Solution app
•Download the Hama Smart Solution app from the
Apple App Store or the Google Play Store using your
mobile device.
•Open the Hama Smart Solution app.
•If you’re using it for the first time, you’ll have to register
and create a new account. If you already have an
account, log in using your login details.
•Click Create family.
•Enter a family name. After that, you can deactivate
rooms that are not being used by clicking the ticks. You
can add or remove rooms at any time; to do so, simply
click the cog wheel at the top right.
•Click Finish.
Note - Family location
To complete a family, it is not necessary to define the
family location manually. Based on the IP address and
the time zone set on the smartphone, the app also works
without further information. Should you need more
precise location determination at a later time, you can
add the details previously omitted (under Profile/Family
Management).
3.2 Dual-band routers (2.4 GHz / 5 GHz)
Many of the current routers transmit on two different
frequency bands (sometimes even in parallel): 2.4 GHz and
5 GHz. The advantages of the 2.4 GHz frequency are the
longer range and compatibility with older terminal devices
that do not support 5 GHz. Please note that our smart
products currently only support 2.4 GHz. If you use a dual-
band router and this results in connection problems, there
are three possible ways to resolve them:
•Deactivate 5 GHz frequency
You will find a control for both frequency bands in the
router settings (WLAN item), depending on model.
Select the 2.4 GHz frequency (or deactivate the 5 GHz
frequency) there. If necessary, consult the operating
instructions of your router.
•Change the name of the wireless local area
network (SSID)
You will find a control for both frequency bands in the
router settings (WLAN item), depending on model. There
you can change the names (SSID) of the frequencies –
for example, by simply including the frequency (such as
‘2.4’, for example) in the name. This will allow you to
specifically select the 2.4 GHz frequency. If necessary,
consult the operating instructions of your router.
•Add compatibility mode (Access Point mode)
If you have no means of ensuring that your smartphone
is on a 2.4 GHz network, you can add your smart product
using the compatibility mode (Access Point mode).
To do so, open the Hama Smart Solution app and click + at
the top right. Next select the device you want to integrate,
and, in the upper-right area, select ‘Otherwise’. Then select
‘AP Mode’ and confirm the following instructions. Enter
your WLAN password (Pic 2) and confirm with OK.

5
Pic 1 Pic 2
Brief instructions will now appear.
Click Connect now (Pic 3), and, in the WLAN network
overview (Pic 4), select the network with the name
SmartLife_XXXX.
Pic 3 Pic 4
Then click your smartphone’s Back button to return to the
app. Your lamp will now be connected.
4. Mounting and getting Started
4.1 WiFi LED bulbs
4.1.1 Product features
Safety Notes
Warning
•Use this product only with lights and fittings that are
approved for the application and appropriate for the
product. Please check that the product is in perfect
working order before making use of it.
•Whenever changing the light, always ensure that the
light or fitting in question is current-free. Switch it off
and/or pull the mains plug.
•Please note that lights (even LEDs) can generate heat
and may become hot. Always let the light cool off for a
few minutes before touching it or changing it.
Risk of electric shock
Using damaged or inappropriate lights or fittings carries
the risk of electric shocks.
This WiFi LED lamp is used for indoor home lighting, effect
lighting, or for creating personalised lighting atmospheres.
Depending on the model, you can select from 16 million
different colours or different colour temperatures (for
example, daylight for your workspace). Further possible
settings are: Switch on/off and smooth dimming.
The following selection of voice commands is also available:
•Turn on/off
‘Alexa/OK Google, turn on/off the light.’
•Dim to X%
‘Alexa/OK Google, decrease the light to X%.’
•Dim by X%
‘Alexa/OK Google, decrease the llight to X%.’
•Selection of colour temperature or colour
‘Alexa/OK Google, turn the light warm white.’ (red, white,
etc.)
4.1.2 Integrating lamps in the Hama Smart Solution
app
•Twist the smart lamp into a suitable fixture.
•The smart LED lamp should begin to flash quickly. If this
is not the case, quickly turn the lamp ON and OFF three
times using the light switch.
•Now open the Hama Smart Solution app and log in.
•Press +in the upper-right corner (Pic 1) to add a new
device.
•Select Lighting in the list.
•Now confirm that the lamp flashes quickly (Pic 2).

6
•.
Pic 1 Pic 2
•Next enter your WiFi password and confirm with OK.
•Your lamp will now be connected.
Pic 3 Pic 4
•Once the connection has been established, the lamp
stops flashing and the app confirms that your lamp was
connected. You can now give your lamp a name.
•Click Finish (Pic 4) to complete the process.
•Now you can control the lamp.
•Various options are available to you (see Pic 5):
-White Mode (Pic 6)
Setting the brightness
-Colour Mode (Pic 7)
Colour selection using the outer ring
Setting the saturation of the selected colour
Setting the brightness of the selected colour
-Scene Mode (Pic 8)
Selection of various light colour modes, for example,
reading or night mode
Pic 5 Pic 6
Pic 7

7
4.2 WiFi wallswitch
4.2.1 Product features
Safety Notes
•Small splinters of glass can lead to injuries if touched.
Dispose of the product immediately if it is damaged or
splintered during application or use.
•Only touch the damaged or splintered product on
undamaged areas and the edge.
•Be very careful while doing so, thoroughly wash your
hands afterwards and avoid contact with face and eyes.
Warning
•Do not use any heat-generating devices (such as
electric blankets, coffee machines, etc.) with this
product. There is a risk of fire and injury.
•Do not use this product with any devices that are
motorised or any devices that have a rotating
component or workpiece. There is a risk of injury.
•The device may only be operated on a 230 V 50 Hz
AC voltage supply. Work with the 230 V mains supply
may only be carried out by electricians certified in your
country. The applicable accident prevention regulations
are to be observed.
•To avoid an electric shock from the device, please
disconnect the mains voltage (switch off circuit
breaker). Failure to observe the installation instructions
can cause fires or other hazards.
Risk of electric shock
Do not open the product. Do not continue to operate
the product if it is damaged, which may be indicated by
smoke, odour or loud noises. Immediately contact your
dealer or our service department (see item “Service and
Support”).
This WiFi wall switch controls up to two ceiling lamps in
the home (switch on/off). Existing wall switches can be
simply replaced with it; maximum total load of 1000 W.
The following voice command is available:
•Turn on/off
‘Alexa/OK Google, turn on/off the light in the living room.’
4.2.2 Mounting
•Switch off the fuse (fuse box) that corresponds to the
room in which you want to install the switch.
•Verify that the wires are dead using a suitable measuring
device (for example, multimeter).
•Connect the WiFi touch wall switch as illustrated below:
•
L IN
neutral
Lamp 2Lamp 1
Install the switch in a suitable in-wall or surface-mount
box.
•Put the glass cover back onto the switch, and check
whether the cover has snapped firmly into place.
4.2.3 Integrating devices in the Hama Smart Solu-
tion app
•Switch the fuse back on.
•The two buttons should now flash, alternating between
blue and red.
•If this is not the case, touch one of the switches for
longer than 5 seconds.
•Now open the Hama Smart Solution app and log in.
•Press +in the upper-right corner to add a new device.
•Select Switches in the list.
•Now confirm that the control light flashes quickly.
•Next enter your WiFi password and confirm with OK.
•The WiFi touch wall switch will now be connected.

8
•The control light stops flashing and the app confirms that
your wall switch was connected. You can now give the
wall switch a name.
•Click Finish to complete the process.
•You can now control the WiFi wall switch with the app.
4.3 WiFi Power Socket/Power Strip
4.3.1 Product features
Safety Notes
Risk of electric shock
•Do not open the product. Do not continue to operate
the product if it is damaged, which may be indicated
by smoke, odour or loud noises. Immediately contact
your dealer or our service department (see item
“Service and Support”).
•Do not use the product if the
AC adapter, the adapter cable or the mains cable are
damaged.
•Do not attempt to service or repair the product
yourself. Leave any and all service work to qualified
experts.
Warning
•Only connect the product to a socket that has been
approved for the device. The socket must be installed
close to the product and easily accessible.
•The product has replaceable fuse. Always replace this
fuse with the same type of fuse with the same electrical
values.
•When using a multi-socket power strip, make sure that
the sum power draw of all the connected devices does
not exceed its maximum throughput rating.
•If you will not be using the product for a long period
of time, disconnect it from mains power.
Warning
•Do not use any heat-generating devices (such as
electric blankets, coffee machines, etc.) with this
product. There is a risk of fire and injury.
•Do not use this product with any devices that are
motorised or any devices that have a rotating
component or workpiece. There is a risk of injury.
•Never connect multiple units of this product in series.
This WiFi socket controls electrical devices (for example, a
floor lamp) in the home (switch on/off).
The following voice command is available:
•Turn on/off
‘Alexa/OK Google, turn on/off the light.’
4.3.2 Integrating devices in the Hama Smart
Solution app
•Connect the Wifi socket adapter or the wifi power strip to
a properly installed and easily accessible mains socket.
•Press and hold the button on the front side for approx. 5
seconds until the blue LED begins to flash quickly.
•Open the Hama Smart Solution app and log in.
•Press +in the upper-right corner to add a new device.
•Select ‘Sockets’ or ‘Multiple Sockets’ in the list.
•Now confirm that the LED flashes quickly.
•

9
•Next enter your WiFi password and confirm with OK.
•Your power socket will now be connected.
•Once the connection has been established, the LED stops
flashing quickly and the app confirms that your socket
was connected. You can now give the socket a name.
•Click Finish to complete the process.
•You can now control the WiFi Smart socket.
4.4 WiFi Door / Window Contact
4.4.1 Product features
This WiFi door/window contact is used for monitoring
(push message to smartphone on triggering) and querying
the status of windows and doors (open/closed).
The following voice command is available:
•Status query
‘Alexa/OK Google, is my window/door open/closed?’
Battery compart-
ment closure
Pairing-
button Manipulation protectionLED
4.4.2 Mounting
•We recommend attaching the sensor on the window or
door frame and the device directly on the window or door.
•Ensure that the markings (triangles) on the device and
the sensor are lined up and separated by no more than
10 mm when the door or window is closed.
Device Sensor
•You can fix the device and the sensor with screws, or
attach them using adhesive pads.

10
•If a door leaf or window sticks out, the sensor can also
be attached at the side, and the device can be attached
flat on the frame.
Warning - Installation with adhesive pad
•All parts are intended for indoor use only. Do not
install them outdoors.
•Please note that the installation surface you choose
should be free of dust and grease. Use a suitable clean-
ing agent from a specialised dealer to clean the surface.
•Note that the adhesive pad attachment is permanent.
To remove the adhesive pad, carefully pull it off the
installation surface.
•Various environmental factors such as ambient
humidity, sunlight or cold can impair the durability of
the adhesive pad.
•We cannot guarantee that residue will not be left on the
mounting surface after the adhesive pad is removed.
4.4.3 Integrating devices in the Hama Smart Solu-
tion app
Now insert the two AAA batteries supplied, observing
correct polarity. When you press the anti-theft protection,
the LED should briefly light up blue; if not, please replace
the batteries
Warning - Batteries
•When inserting batteries, note the correct polarity (+
and - markings) and insert the batteries accordingly.
Failure to do so could result in the batteries leaking or
exploding.
•Only use batteries (or rechargeable batteries) that
match the specified type.
•Before you insert the batteries, clean the battery
contacts and the polar contacts.
•Do not allow children to change batteries without
supervision.
•Do not mix old and new batteries or batteries of a
different type or make.
•Remove the batteries from products that are not being
used for an extended period (unless these are being
kept ready for an emergency).
•Do not short-circuit batteries.
•Do not charge batteries.
•Do not throw batteries in a fire.
•Keep batteries out of the reach of children.
•Never open, damage or swallow batteries or allow
them to enter the environment. They can contain toxic,
environmentally harmful heavy metals.
•Immediately remove and dispose of dead batteries
from the product.
•Avoid storing, charging or using the device in extreme
temperatures and extremely low atmospheric pressure
(for example, at high altitudes).
•Now press the Pairing button for 5 seconds. The LED
begins to flash red quickly. If it flashes slowly, press the
button again for 5 seconds.
•Open the app and log in.
•Press +in the upper-right corner to add a new device.
•Select Sensors in the list.
•Now confirm that the LED flashes quickly.
