Hamilton Beach 49983A Instruction sheet

2-Way FlexBrew®
Coffeemaker
Cafetière à double
usage FlexBrewMD
Cafetera Doble
FlexBrew®
English ...................... 2
Français................... 17
Español ................... 33
READ BEFORE USE
LIRE AVANT UTILISATION
LEA ANTES DE USAR
Visit www.hamiltonbeach.com for our
complete line of products and Use and
Care Guides – as well as delicious recipes,
tips, and to register your product online!
Rendez-vous sur www.hamiltonbeach.ca
pour notre liste complète de produits et de
nos manuels utilisateur – ainsi que nos
délicieuses recettes et nos conseils !
¡Visite www.hamiltonbeach.com ( EE. UU.)
o www.hamiltonbeach.com.mx (México)
para ver otros productos de Hamilton Beach
o para contactarnos!
Questions?
Please call us – our friendly
associates are ready to help.
USA: 1.800.851.8900
¿Preguntas?
Por favor llámenos – nuestros
amables representantes están
listos para ayudar.
EE. UU.: 1.800.851.8900
MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.
Questions ?
N’hésitez pas à nous appeler –
nos associés s’empresseront
de vous aider.
CAN : 1.800.267.2826
840219701 ENv04.indd 1 1/29/14 4:45 PM

2
IMPORTANT SAFEGUARDS
1. Read all instructions.
2. This appliance is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or lack of experience and knowledge,
unless they are closely supervised and instructed
concerning use of the appliance by a person responsible
for their safety.
3. Close supervision is necessary when any appliance is
used by or near children. Children should be supervised to
ensure that they do not play with the appliance.
4. Do not touch hot surfaces. Use handles or knobs. Care
must be taken, as burns can occur from touching hot parts
or from spilled, hot liquid.
5. To protect against electric shock, do not place cord, plug,
or coffeemaker in water or other liquid.
6. Unplug from outlet when either the coffeemaker or clock
is not in use and before cleaning. Allow to cool before
putting on or taking off parts and before cleaning the
appliance.
7. Coffeemaker must be operated on a flat surface away from
the edge of counter to prevent accidental tipping.
8. Do not operate any appliance with a damaged cord or
plug, or after the appliance malfunctions or is dropped
or damaged in any manner. Call our toll-free customer
service number for information on examination, repair,
or adjustment.
9. The use of accessory attachments not recommended
by the appliance manufacturer may cause injuries.
10. Do not use outdoors.
11. Do not let cord hang over edge of table or counter or
touch hot surfaces, including stove.
12. Do not place coffeemaker on or near a hot gas or electric
burner or in a heated oven.
13. The carafe is designed for use with this coffeemaker. It
must never be used on a range top or in a microwave
oven.
14. Do not set a hot carafe on a wet or cold surface.
15. Do not use a cracked carafe or one with loose or weakened
handle.
16. Do not clean carafe with cleansers, steel wool pads, or
other abrasive materials.
17. Be certain carafe lid is securely in place during brew cycle
and when pouring coffee. Do not use force when placing
lid on carafe.
18. To disconnect coffeemaker, turn controls to OFF (O) and
then remove plug from wall outlet.
19. WARNING! To reduce the risk of fire or electric shock, do
not remove the bottom cover. No user-serviceable parts
are inside. Repair should be done by authorized service
personnel only.
20. Do not use appliance for other than intended use.
21. CAUTION! Cut Hazard: Removable single-serve pack
holder contains a sharp blade. Use caution when handling.
22. CAUTION! Cut Hazard: Piercing nozzle is sharp. Use caution
when cleaning.
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock,
and/or injury to persons, including the following:
SAVE THESE INSTRUCTIONS!
840219701 ENv04.indd 2 1/29/14 4:45 PM

3
Other Consumer Safety Information
This appliance is intended for household use only.
WARNING! Shock Hazard: This appliance has a polarized plug
(one wide blade) that reduces the risk of electric shock. The
plug fits only one way into a polarized outlet. Do not defeat the
safety purpose of the plug by modifying the plug in any way or
by using an adapter. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, have an electrician
replace the outlet.
The length of the cord used on this appliance was selected to
reduce the hazards of becoming tangled in or tripping over
a longer cord. If a longer cord is necessary, an approved
extension cord may be used. The electrical rating of the
extension cord must be equal to or greater than the rating of
the appliance. Care must be taken to arrange the extension
cord so that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally tripped
over.
To avoid an electrical circuit overload, do not use another high-
wattage appliance on the same circuit with your appliance.
840219701 ENv04.indd 3 1/29/14 4:45 PM

4
Parts and Features
Carafe*
Cord Stuff Storage
Piercing Nozzle
(punches hole in top of
single-serve pack)
Water Window
Brew Basket
Handle
Removable Single-Serve Pack Holder*
(punches hole on bottom of pack)
Control
Panel
Water
Window
Brew
Selector
Dial
Brew
Basket*
Single-Serve Brew
Basket With Hinged
Lid (for ground
coffee and soft pod)
Brew Basket* Display
Multilevel Cup
Rest*
Water Reservoir
Warming Plate HOT Indicator
(turns red when hot)
*To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico: 01 800 71 16 100
840219701 ENv04.indd 4 1/29/14 4:46 PM

5
How to Use Single-Serve Side –
Brewing Single-Serve Packs
1
Plug in coffeemaker. Rotate brew
selector dial to the right to select
Single-Serve ( ). Press BREW
OPTIONS button to select .
Burn Hazard.
To avoid contact with hot coffee or water:
• Do not use more than 10 oz. (300 ml) of water for a single-serve pack. Adding too much water to the water reservoir will cause an error
message to appear in the display, along with a long beep. Place carafe on warming plate. Turn brew selector dial to Carafe ( ) and push
BREW NOW button to remove water. Wait for 3 beeps and blue power light to turn off. Restart the Single-Serve process.
• Fill reservoir with cup or travel mug of water into which the coffee will be brewed.
• Fully insert cup or travel mug under brew basket.
• For best results, use K-Cup®* packs.
NOTES:
• The unit will only brew on one
side at a time.
• For Hotter Coffee: Rinse the
mug with hot water before
brewing.
• The Brew Mode selection will
stay in the last mode used,
unless unplugged.
• Coffee may continue to drip
after brewing is complete (after
3 beeps) when using finely
ground coffee.
• Programming mode cannot be
used on Single-Serve side.
wWARNING
2
Remove brew basket. Place a
pack into the single-serve pack
holder.
CAUTION! Cut Hazard: Single-
serve pack holder has a sharp
blade. Handle with care.
3
Press down on edge of the pack
until the pack snaps into place and
hole is punched in the bottom. Do
not remove foil.
*K-Cup is a registered trademark of Keurig, Inc. Use of the K-Cup trademark does not imply any affiliation with or
endorsement by Keurig, Inc.
840219701 ENv04.indd 5 1/29/14 4:46 PM

6
How to Use Single-Serve Side –
Brewing Single-Serve Packs (cont.)
8
64
97
65
Fill reservoir with cup or travel mug
into which the coffee will be brewed
(maximum 10 oz. [296 ml] water).
Ensure the multilevel/flip cup rest is firmly secured and snapped into
place.
After brewing, pull up on brew
basket handle to unlock and
remove.
Coffeemaker will shut off
automatically and light will go off
when brew cycle is completed
(3 beeps will sound).
Allow 2 minutes to cool in
between brews.
Brew basket and single-serve
pack holder should be rinsed after
every use. Pressing down on the
brew basket handle punctures the
pack before brewing.
Press ON/OFF (I/O) button. The blue power ON indicator light will
light up to show that the coffeemaker is on. CAUTION! Burn Hazard:
Warming plate is hot even when brewing on Single-Serve side.
For removal of cup rest: Push up
cup rest; tilt up. Push down to
release.
Press down on brew basket
handle to lock and puncture the
foil lid on the pack.
OR
840219701 ENv04.indd 6 1/29/14 4:47 PM

7
How to Use Single-Serve Side –
Brewing Coffee Grounds or Soft Pods
Burn Hazard.
To avoid contact with hot coffee or water:
• Do not use more than 14 oz. (414 ml) of water for ground coffee or Melitta®†Pods. Adding more than 14 oz. of water to the water reservoir will
cause an error message to appear in the display, along with a long beep. Place carafe on warming plate. Turn brew selector dial to Carafe
( ) and push BREW NOW button to remove water. Wait for 3 beeps and blue power light to turn off. Restart the Single-Serve process.
• Fill reservoir with cup or travel mug of water into which the coffee will be brewed.
• Fully insert cup or travel mug under brew basket.
• Remove single-serve pack holder before adding coffee grounds to brew basket.
This unit can be used with
Melitta®
†
soft pods, available
in the coffee aisle of your local
grocery store.
NOTE: It can take up to 2
minutes before brewed coffee
starts dispensing into your cup
or travel mug.
wWARNING
21 3
To remove single-serve pack
holder, grasp the single-serve
pack holder cup; slide towards
the back and then lift out.
CAUTION! Cut Hazard: Removable
single-serve pack holder has a
sharp blade. Handle with care.
Plug in coffeemaker. Rotate brew
selector dial to the right to select
Single-Serve ( ). Press BREW
OPTIONS button to select GROUND
mode.
Add ground coffee (3 Tablespoons
[44 ml] is the MAX amount of
ground coffee for brew basket)
or soft pod to brew basket.
WARNING! Burn Hazard: To
avoid overflow, keep ground
coffee below MAX fill line.
Melitta is a registered trademark of Melitta Haushaltsprodukte GmbH & CoKG. Use of the Melitta trademark
does not imply any affiliation with or endorsement by Melitta Haushaltsprodukte GmbH & CoKG.
†
840219701 ENv04.indd 7 1/29/14 4:48 PM

8
How to Use Single-Serve Side –
Brewing Coffee Grounds or Soft Pods (cont.)
8 9
7
10
CAUTION! Burn Hazard: Warming
plate is hot even when brewing on
Single-Serve side.
Coffeemaker will shut off
automatically and light will go off
when brew cycle is completed
(3 beeps will sound).
Press the ON/OFF (I/O) button
again to STOP brewing midcycle.
Allow 2 minutes to cool in
between brews.
Brew basket should be rinsed after
every use.
6
Fill reservoir with cup or travel mug into which the coffee will be brewed
(maximum 14 oz. [414 ml] water). Ensure the multilevel/flip cup rest is
firmly secured and snapped into place.
Press ON/OFF (I/O) button. The
blue power ON indicator light
will light up to show that the
coffeemaker is on.
54
840219701 ENv04.indd 8 1/29/14 4:48 PM

9
How to Use Carafe Side
2
6
1
5
Plug in coffeemaker. Rotate dial
to the left to select carafe ( ).
Press BREW OPTIONS button to
select REGULAR or BOLD modes.
REGULAR is the default.
3
74
Place a cupcake-style paper filter
in brew basket. A permanent
filter may also be used.
For each cup of coffee being
made, place one level
Tablespoon (15 ml) of coffee into
filter.
Please visit hamiltonbeach.com
for a list of parts, accessories,
and replacement parts that are
available for your coffeemaker.
Place carafe, with carafe lid
attached, on warming plate.
AUTOMATIC SHUTOFF: The coffeemaker will
automatically shut off 2 hours after brew cycle is
complete.
NOTE: The unit will only brew on one side at a time.
840219701 ENv04.indd 9 1/29/14 4:49 PM

10
9
How to Use Carafe Side (cont.)
PAUSE AND SERVE:
To serve coffee during the brewing cycle, remove carafe and pour a
cup. By removing the carafe, the flow of coffee from the bottom of
the filter basket will stop.
WARNING! Burn Hazard: The carafe must be replaced within
20 seconds of being removed to prevent overflow.
NOTES:
• If the coffeemaker is not turned off manually, it will automatically
shut off in 2 hours.
• BOLD mode will require additional time to complete a brewing
cycle. Coffeemaker remembers last brew option selected. If
unplugged, coffeemaker defaults to REGULAR.
Tips for Best-Tasting Coffee
• All coffees are made from either arabica beans or robusta beans,
or some combination of both. Arabica beans are slightly more
expensive, but tend to produce better-tasting coffee.
• Ground coffee will become stale much faster than whole beans. If
buying preground coffee, choose a package with the latest expiration
date or a smaller quantity.
• If grinding whole beans, set your coffee grinder on a fine/medium
grind. This will yield the best-tasting grounds. Try to use freshly
ground coffee within about a week of grinding.
• Using a water filter, filtered water, or bottled water will yield better-
tasting coffee than tap water.
• Use approximately 1 Tablespoon (15 ml) of grounds for each cup of
coffee being made. To avoid overflow, use slightly less grounds
(3/4 tablespoon [11.2 ml]) when brewing decaf or flavored coffees.
Also, be aware that using coffee that is ground too finely may also
cause the filter basket to overflow.
• Make sure your coffeemaker is clean. See “Care and Cleaning”
sections.
8
For enhanced full/strong-flavored
coffee, press BREW OPTIONS
button until BOLD is displayed.
Press I/O (ON/OFF) button to
start. Press I/O (ON/OFF) button
again to turn off.
840219701 ENv04.indd 10 1/29/14 4:50 PM

11
3
5
Programming – For Carafe Side Only
21 4
Press HOUR and then MINUTE to
set clock.
Rotate dial to the left to select
carafe ( ). Continue holding PROGRAM
button, press HOUR and MINUTE
until the desired brewing start
time is reached, and then release
PROGRAM button.
Hold PROGRAM until clock flashes.
Press PROGRAM to activate
automatic brewing. Green
program light will illuminate to
indicate the unit is programmed
and will begin brewing at the
selected start time.
NOTE: The unit will only brew on one side at a time. Single-Serve side cannot be used while Carafe side is programmed.
840219701 ENv04.indd 11 1/29/14 4:51 PM

12
Care and Cleaning
All coffeemakers should be cleaned at least once a month (once a week for areas with hard water).
Pour 1/2 cup (118 ml) of plain white vinegar and 1/2 cup (118 ml) of
cold water into water reservoir. Press I(ON) button. Press O(OFF) button after 30 seconds and wait 30
minutes. Press I(ON) button. Press O(OFF) button when finished.
Run 2–3 more brew cycles with CLEAN WATER only. Allow to cool
between cycles.
DO NOT use the “SANI” setting when washing in the dishwasher.
“SANI” cycle temperatures could damage your product.
2 3
4 6
TOP-RACK
DISHWASHER-SAFE
1
CARAFE-SIDE ONLY 5
Shock Hazard.
Do not immerse cord, plug, or coffeemaker in any liquid.
wWARNING
OR
840219701 ENv04.indd 12 1/29/14 4:52 PM

13
Troubleshooting – Single-Serve Side
PROBLEM PROBABLE CAUSE/SOLUTION
Err message on display. • Too much water in the water reservoir. Turn brew selector dial to carafe ( ) and push BREW NOW button
to remove water. Wait for 3 beeps and blue power light to turn off. Restart the Single-Serve process.
Weak coffee. • Not enough ground coffee used. If using pods, make sure the pod(s) are centered in the pod basket and/or
brew basket and use two pods for stronger coffee. See “How to Use Single-Serve Side.”
Coffee overflows from brew
basket, travel mug, or regular
mug.
• Excessive amount of water in reservoir. Use travel mug or mug into which coffee will be brewed to fill
reservoir. Use slightly less grounds when brewing decaffeinated, flavored, or finely ground coffee. Or use
medium ground coffee.
Coffee tastes bad. • Coffeemaker needs cleaning.
• Coffee ground too coarsely or too finely. Set coffee grinder to automatic drip grind.
• Poor coffee quality and freshness.
• Poor water quality (use filtered or bottled water).
Water exits carafe side. • Make sure selector dial is set to Single-Serve side.
Auto-start feature does not
work with Single-Serve side. • Auto-start feature is not designed to work with Single-Serve side. Program mode is for Carafe side only.
Clear water when brewing
with single-serve pack. • Forgot to lock handle down, which pierces top foil of single-serve packs.
Steam flows up across
control panel. • When brewing ground coffee with single-serve pack holder assembly removed, steam will travel up across the control panel if the basket handle is pressed down. Leave the handle up for ground coffee or soft pods.
• Do not exceed MAX water level for single-serve pack brewing.
840219701 ENv04.indd 13 1/29/14 4:52 PM

14
Troubleshooting – Carafe Side
PROBLEM PROBABLE CAUSE/SOLUTION
Brew basket overflows or
coffee brews slowly. • Excessive amounts of ground coffee.
• Decaffeinated and/or coffee ground too finely can cause overflow. Use slightly less grounds when brewing
decafeinated, flavored, or finely ground coffee. Or use medium ground coffee.
• Coffeemaker needs cleaning.
If using a paper filter:
• Coffee grounds between paper filter and brew basket.
• Paper filter not open and in proper position.
• Rinse brew basket before inserting paper filter so the edges will remain pressed against the sides of the
basket.
• Poor-quality paper filter.
Coffee leaks onto base. • Carafe removed from warming plate for more than 20 seconds during the brewing cycle.
Coffee tastes bad. • Coffeemaker needs cleaning.
• Coffee ground too coarsely or too finely. Use medium ground coffee.
• Coffee-to-water ratio unbalanced. Adjust for personal preference.
• Poor coffee quality and freshness.
• Poor water quality (use filtered or bottled water).
840219701 ENv04.indd 14 1/29/14 4:52 PM

15
Troubleshooting – Carafe Side
PROBLEM PROBABLE CAUSE/SOLUTION
Coffee sediment in cup. • For Carafe side, use a high-quality, basket-style paper filter instead of optional permanent coffee filter.
• For Single-Serve side, try a more coarsely ground coffee.
Coffee not brewing or unit
will not turn on. • Carafe not positioned on warming plate.
• Water reservoir is empty.
• Unit is unplugged.
• Power outage.
• Power surge. Unplug; then plug the unit back in.
• Clock requires reset after power outage.
Longer than normal brew
time. • Mineral deposits can build up in the pump of your coffeemaker. Periodic cleaning of the inside of the unit is recommended. More frequent cleaning may be necessary, depending on the hardness of your water. See
“Care and Cleaning” section. NOTE: Do not disassemble the unit.
Water exits the Single-Serve
side when brewing with the
carafe.
• Make sure selector dial is set to Carafe side.
840219701 ENv04.indd 15 1/29/14 4:52 PM

16
Limited Warranty
This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and
is in lieu of any other warranty or condition.
This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original
purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective,
at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or
component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal
or greater value.
This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to
the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or
gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the
product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the
rating label (e.g., 120V ~ 60 Hz).
We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All
liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition
of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such
warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have
other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or
special, incidental, or consequential damages, so the foregoing limitations may not apply to you.
To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada
or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers
on your appliance.
840219701 ENv04.indd 16 1/29/14 4:52 PM
