Hamilton Beach 31230 Owner's manual

Toaster Oven
Four grille-pain
Horno de la tostadora
English ...................... 2
Français .................. 16
Español .................. 30
READ BEFORE USE
LIRE AVANT UTILISATION
LEA ANTES DE USAR
Questions?
Please call us – our friendly
associates are ready to help.
USA: 1.800.851.8900
¿Preguntas?
Por favor llámenos – nuestros
amables representantes están
listos para ayudar.
MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente
este instructivo antes de usar su
aparato.
Visit hamiltonbeach.com for delicious
recipes, tips, and to register your
product online!
Consultez hamiltonbeach.ca pour de
délicieuses recettes, des conseils pratiques
et pour enregistrer votre produit !
¡Visite hamiltonbeach.com.mx para
recetas deliciosas, consejos, y para
registrar su producto en línea!
Questions ?
N’hésitez pas à nous appeler –
nos associés s’empresseront
de vous aider.
CAN : 1.800.267.2826
840180401 ENv03.qxd:Layout 1 2/12/10 5:12 PM Page 1

2
IMPORTANT SAFEGUARDS
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plug,
or toaster oven in water or other liquid.
4. Close supervision is necessary when any appliance is used by or
near children.
5. Unplug from outlet when not in use and before cleaning. Allow to
cool before cleaning appliance and putting on or taking off parts.
6. Do not operate any appliance with a damaged cord or plug, or
after the appliance malfunctions or is dropped or damaged in
any manner. Call our toll-free customer service number for
information on examination, repair, or adjustment.
7. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter or touch
hot surfaces.
10. Do not place on or near a hot gas or electric burner or in a
heated oven.
11. Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
12. To disconnect, turn all controls off (STOP); then remove plug
from wall outlet.
13. Use extreme caution when removing pan or disposing of hot
grease.
14. Do not clean with metal scouring pads. Pieces can break off the
pad and touch electrical parts, creating a risk of electrical shock.
15. Oversize foods or metal utensils must not be inserted in a
toaster oven as they may create a fire or risk of electric shock.
16. A fire may occur if the toaster oven is covered, touching, or near
flammable material, including curtains, draperies, walls, and the
like, when in operation. Do not store any item on top of the
appliance when in operation or before the appliance cools down.
17. Extreme caution should be exercised when using containers
constructed of materials other than metal or glass.
18. Do not store any materials, other than manufacturer-recommended
accessories, in this oven when not in use.
When using electrical appliances, basic safety precautions should always be followed, including the following:
wWARNING
Fire Hazard.
• If contents ignite, do not open oven door. Unplug oven and allow contents to stop burning and cool before
opening door.
• Do not operate unattended while in Toast or Broil modes.
• Do not use with oven cooking bags.
• Always allow at least one inch between food and heating element.
• Always unplug toaster oven when not in use.
• Regular cleaning reduces risk of fire hazard.
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 2

3
SAVE THESE INSTRUCTIONS!
OTHER CONSUMER SAFETY INFORMATION
This appliance is intended for household use only.
WARNING! Shock Hazard: This appliance has a polarized plug (one
wide blade) that reduces the risk of electric shock. The plug fits only
one way into a polarized outlet. Do not defeat the safety purpose of
the plug by modifying the plug in any way or using an adapter. If the
plug does not fit, reverse the plug. If it still does not fit, have an elec-
trician replace the outlet.
The length of the cord used on this appliance was selected to reduce
the hazards of becoming tangled in or tripping over a longer cord.
If a longer cord is necessary, an approved extension cord may be
used. The electrical rating of the extension cord must be equal to
or greater than the rating of the appliance. Care must be taken to
arrange the extension cord so that it will not drape over the counter-
top or tabletop where it can be pulled on by children or accidentally
tripped over.
This appliance is equipped with a fully tempered safety glass door.
The tempered glass is four times stronger than ordinary glass and
more resistant to breakage. Tempered glass can break; however, it
breaks into pieces with no sharp edges. Care must be taken to avoid
scratching door surface or nicking edges. If the door has a scratch or
nick, call our toll-free customer service number.
Always unplug your toaster oven from the outlet when not in use.
19. Do not place any of the following materials in the oven: paper,
cardboard, plastic, and the like.
20. Do not cover crumb tray or any part of the oven with metal foil.
This will cause overheating of the oven.
21. To turn oven off, press the STOP button. See “Parts and Features”
section.
22. Do not place eyes or face in close proximity with tempered
safety glass door, in the event that the safety glass breaks.
23. Always use appliance with crumb tray securely in place.
24. Do not use appliance for other than intended use.
25. Clean oven interior carefully. Do not scratch or damage heating
element tube.
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 3

Parts and Features
Baking Pan
LED Display
Mode Buttons
Temperature
Probe
Slide-Out
Crumb Tray Oven Rack
Function
Buttons
Broil Rack*
(optional accessory
on select models)
Broil Rack* in Baking Pan
(*optional accessory
on select models)
BROIL/TOAST POSITION
(Use this position also for pizza)
BAKE POSITION
4
Before First Use
Most heating appliances produce an odor and/or smoke when used the first
time. Plug unit into outlet. Press BAKE button. Use UP and DOWN arrows to set
temperature to 450°F; then press TIMER button and set for 5 minutes. Let oven
preheat for approximately 5 minutes. The odor should not be present after this
initial preheating. Wash baking pan, broil rack*, and oven rack before using.
NOTE: *Broil rack is an optional accessory on select models.
Probe Jack
and Storage
Compartment
Rear Bumper
(allows airflow between
back of oven and wall)
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 4

How to Toast
2
TEMP TIMER
ENTER
START STOP
4
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
TEMP TIMER
ENTER
1
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
TEMP TIMER
ENTER STOP
3
Press TOAST button. The LED display will
read “CNTR RACK”—this is a prompt to
center the rack in the oven for best toasting
results.
Place food into oven. NOTE: MED is the
default toast shade. After first use, the last
shade selected
will be the default.
Once a shade is selected, press
ENTER/START. A beep will sound when
toasting cycle is complete. The desired
shade may be changed at any point
during the toasting cycle by pressing
the up/down buttons.
• To toast frozen pastry or waffles,
select a light color and toast directly
on oven rack. If pastry has a glaze or
frosting, use baking pan to prevent
dripping.
• The number of slices of bread, the
bread freshness, and the starting tem-
perature of the oven will affect toast
color. Adjust the toast shade to
achieve the desired color.
• When toasting, condensation may
form on oven door. A toaster is open
and allows moisture to escape. A
toaster oven is a closed space and
so moisture is slow to escape. This
is normal.
• At the end of the toast cycle, remove
toast immediately or the heat remain-
ing in the toaster oven will continue to
cook and dry out your toast.
Fire Hazard.
• If contents ignite, do not open oven door. Unplug oven and allow
contents to stop burning and cool before opening door.
• Do not leave appliance unattended when in operation.
• Always unplug toaster oven when not in use.
wWARNING
Press the up/down buttons if a different
toast shade is desired. Choose from LITE,
LT+, MED, MED+, and DARK.
BEFORE FIRST USE: Wash all removable parts in
warm, soapy water and dry thoroughly.
5
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 5

How to Bake
BAKE CONV.
TEMP
ENTER
START
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
2
TOAST BROIL PROBE
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
5
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
1
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV WARM
3
Press BAKE button. The LED display will
read “350F” or the last temperature
selected in Bake mode.
Press the up/down buttons if a different
temperature is desired (between 200°F
and 450°F). Once a temperature is
selected, press ENTER/START.
NOTE: 350°F is the default bake tempera-
ture. After first use, the last temperature
selected will be the default.
The oven will turn on and begin to heat.
This will be evident as the LED display
will flash “PRE” and then “HEAT.” A beep
will sound when preheated, and the LED
display will flash “LOAD” and then “FOOD.”
4
Place food into oven.
Fire Hazard.
• If contents ignite, do not open oven door. Unplug
oven and allow contents to stop burning and cool
before opening door.
• Do not use oven cooking bags.
• Always allow at least 1 inch between food
and heating element.
• Always unplug toaster oven when not in use.
wWARNING
6
If desired, press TIMER button to set
bake time. The LED will default to 30
minutes and display “0:30.” Press the
up/down buttons to set the desired
baking time in 1-minute increments, or
simply hold the button down longer to
scroll in 10-minute increments.
Once a bake time has been selected,
press ENTER/START.
The timer will begin to count down and
beep when baking is complete. Remove
food using oven mitts. Unplug from
outlet when finished.
NOTE: The oven is equipped with a
2-hour auto shutoff timer. If no bake time
is selected, the unit will begin to count
down from 2 hours, including preheat
time, and then shut off.
6
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 6

Convection Bake
(on select models)
Fire Hazard.
• If contents ignite, do not open oven door.
Unplug oven and allow contents to stop
burning and cool before opening door.
• Do not use oven cooking bags.
• Always allow at least 1 inch between food
and heating element.
• Always unplug toaster oven when not in use.
wWARNING
BAKE CONV.
TEMP
ENTER
START
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
2
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
5
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
TEMP TIMER
ENTER
1
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV WARM
3
Press CONV button. Both the BAKE and
CONV lights will illuminate. Press the up/down buttons if a different
temperature is desired (between 200°F
and 450°F). Once a temperature is
selected, press ENTER/START.
The oven will turn on and begin to heat.
This will be evident as the LED display
will flash “PRE” and then “HEAT.” A beep
will sound when preheated, and the LED
display will flash “LOAD” and then “FOOD.”
4
Place food into oven.
6
Press TIMER button to set bake time.
The LED will default to 30 minutes and
display “0:30.” Press the up/down but-
tons to set the desired baking time in
1-minute increments, or simply hold the
button down longer to scroll in 10-minute
increments.
Once a bake time has been selected,
press ENTER/START.
The timer will begin to count down and
beep when baking is complete. Remove
food using oven mitts. Unplug from
outlet when finished.
NOTE: The oven is equipped with a
2-hour auto shutoff timer. If no bake time
is selected, the unit will begin to count
down from 2 hours, including preheat
time, and then shut off.
7
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 7

wWARNING
How to Broil
TEMP TIMER
ENTER
START STOP
2
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
13
Press BROIL button. The LED display will
read “BRL.” Press ENTER/START. The oven will begin
heating at highest temperature setting. Place food into oven using broil rack.
TOAST BROIL PROBE
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
4
If desired, press TIMER button to set
broil time. The LED will default to 20
minutes in Broil mode and display
“0:20.” Press the up/down buttons to
set the desired broil time in 1-minute
increments, or simply hold the button
down longer to scroll in 10-minute
increments.
Fire Hazard.
• If contents ignite, do not open oven door. Unplug
oven and allow contents to stop burning and cool
before opening door.
• Do not leave oven unattended during operation.
• Keep 1 inch between food and heating element.
• Do not use oven cooking bags.
• Do not heat foods in plastic containers.
• Follow food manufacturer’s instructions.
8
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 8

APPROX. BROIL TIME
30 minutes
15 minutes
15 to 20 minutes
15 minutes
NOTES:
• Cook beef and pork to at least 160
° F (71 ° C).
• Cook chicken to at least 165
° F (74 ° C).
• Cook fish until at least 145
° F (63 ° C) or until opaque or flakes with a fork.
• Visit foodsafety.gov for more safe cooking temperature information.
• In broil mode, the probe can be used to measure temperature by pressing the PROBE
button. The temperature will display for 5 seconds.
These cooking times are an average and should be adjusted to individual
preferences. Turn foods halfway through cooking time.
NOTE: Turn sausage links or patties after 3/4 of cooking time.
TEMP TIMER
ENTER
START STOP
56
Once a broil time has been selected,
press ENTER/START. The timer will begin
to count down and beep when finished.
Remove food using oven mitts. Unplug
from outlet when finished.
NOTE: The oven is equipped with a
2-hour auto shutoff timer. The unit will
begin to count down from 2 hours,
including preheat time, and then shut off.
How to Broil (cont.)
9
FOOD
1/4-lb. Hamburgers
Hot Dogs
Sausage Links or Patties
(pierce casings before cooking)
Fish
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 9

How to Warm
TEMP TIMER
ENTER
START STOP
2
TEMP TIMER
ENTER
START STOP
5
OVEN TIME OVEN TEMP DESIRED TEMP ACTUAL TEMP
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
13
Press WARM button. The LED display will read “WARM.” NOTE: If you would like the oven
to keep your food warm after cooking/baking using the Bake, Convection, or Probe modes,
simply press the WARM button at any time during the cooking/baking cycle. Once the set
cooking time has elapsed, the unit will switch to Warm mode for the auto default time of
2 hours. Press ENTER/START. The oven will turn on and begin to heat.
CHOOSE MODE TO START
TOAST BROIL PROBE
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
BAKE CONV. WARM
TEMP TIMER
ENTER
START STOP
4
Place food into oven. Press TIMER button to set keep warm time. The LED will default
to 1 hour in Warm mode and display “1:00.” Press the up/down buttons to set the
desired keep warm time in 1-minute increments or simply hold the button down
longer to scroll in 10-minute increments.
Fire Hazard.
• If contents ignite, do not open oven door. Unplug
oven and allow contents to stop burning and cool
before opening door.
• Do not use oven cooking bags.
• Always allow at least 1 inch between food
and heating element.
• Always unplug toaster oven when not in use.
6
Once a time has been selected, press
ENTER/START. The timer will begin to
count down and beep when the keep-
warm cycle is completed.
Remove food using oven mitts. Unplug
from outlet when finished.
NOTE: The oven is equipped with a
2-hour auto shutoff timer. The unit will
begin to count down from 2 hours,
including preheat time, and then shut off.
wWARNING
10
840180401 ENv03.qxd:Layout 1 2/12/10 5:11 PM Page 10
