HAMPTON BAY GFM00469A-CPY User manual

THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this replacement canopy. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item # 000000
Model # GFM00469A-CPY
USE AND CARE GUIDE
ARCHED GAZEBO REPLACEMENT CANOPY
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Warranty
1 YEAR FABRIC WARRANTY
WHAT IS COVERED
We warrant the fabric to be free of manufacturing defects to the original purchaser for one year.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
complete the assembly of this product.
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ......................................................................2
What is Not Covered ................................................................2
Pre-Assembly ................................................................2
Planning Assembly ..................................................................2
Package Contents.................................................................... 3
Assembly........................................................................4
Care and Cleaning................................
......................... 7

HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
I Protective cover 1
JFabric shade 1
3
I
J

4
1
l
Assembly
Insert the short shade rods (F) into the top slots of the fabric shade (J).
Inserting the short shade rods into the fabric shade
J
F
F

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
2
l
Assembly (continued)
Attaching the short shade rods
Attach the four ends of the short shade rods (F) to the front connector bars (A & B) using M6x35 bolts (CC) and washers (EE).
Pull out the elastic ribbons on the two fabric shade (J) slot ends, as shown in gure 2-4.
J
A & B without
magnet iron plate AB
2-4 A&B
JF
F
A
2-2
CC
EE
B
F
2-3
CC
EE
A
F
F
E
2-1
CC
EE
B
CC
EE

6
3
l
Assembly (continued)
Connecting the long shade rods
Insert the long shade rods (G) into the slot at the end of the fabric shades (J), through the plastic wheels (E1)
and rolling wheel (E2), into the remaining slots of the fabric shades (J).
Attach the long shade rods (G) to the plastic wheels (L1) on the other side top bar (D), and secure with
M6x18 countersunk bolts (BB).
J
3-1
G
J
E
GJ
3-2
E1
JG
3-3
A & B without
magnet iron plate
BB
D
3-5
G
G
L1
BB
BB
BB G
G
G
JBB BB BB BB
G G
L1
3-6
D
J
BB
G
3-4
NOTE: Fully tighten all thebolts using the hex wrench (GG).
NOTE :
bar (E) is the rolling wheel, other arethe plastic wheels.
E
E1 Plastic center
fabric wheel
E2 Steel Rolling Wheel

7 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
4
l
Assembly (continued)
Installing the protective cover
Attach the protective cover (I) to the side top bars (D) and the center lengthways bar (E) using M6x15 bolts (AA) and washers (EE).
I
E
D
D
AA
I
EE
E
AA EE
I
AA
EE
EE
D
AA
Care and Cleaning
Do not clean with abrasive materials, bleach, or solvents.
Store the canopy in a dry, sheltered place when not in use.
Keep the canopy away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
For best results, clean the canopy with a damp cloth, and dry the frames thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
A & B without
magnet iron plate

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
