Handy Dryers Sterillo Uno User manual
USER MANUAL
www.sterillo.com
Sterillo Ltd
Unit 9 •Stort Valley Ind Estate •Stansted Road
Bishop’s Stortford •Herts •CM23 2TU •UK
+44 1279 466500
2
•Do not open the front panel – electric shock risk.
•Never look directly at the UV bulb when in operation.
•Do not allow children or adults to pull or hang on the machine.
•Place the unit away from direct water supplies.
•A suitably rated fused power supply is required.
•Ensure the correct power supply is used, if more than +/-10%
the unit may malfunction.
•The power must be turned off during installation and maintenance.
•Ensure the unit has a reliable earth connection.
•This unit must be installed by a qualied electrician.
•If the power cord is damaged it must be replaced by the manufacturer,
its service agent or a qualied person.
•A residual current device (RCD) with a rated residual operating current,
not exceeding 30mA is recommended.
•Please use dedicated spur.
•In case of malfunction, switch off power immediately.
Environmental Protection
•Do not dispose of electrical waste with household waste, please recycle
in appropriate facilities. Check with your Local Authority or retailer for
recycling advice.
WARNING: INJURY MAY OCCUR IF MISUSED
Prohibited
Do not allow
unit to get
excessively wet
Do not
dismantle
Follow
instructions
carefully
3
UV LAMP SPECIFICATION
Size
Lamp Total Length L1 (mm) 145±1.5
Lamp Diameter D1 (mm) 12±0.2
Lamp width max 27
Component and
materials
Quart 3 glass tube
Electrode hot cathode
Lead wire molybdenum rod
Lamp base 2G7
Performance
Power 9W
Ultraviolet radiation
intensity(μW/cm2) >4500
Stabilisation time 5 minutes
Average life (h) 8000
4
•Ensure there is at least 500mm clear space above the machine.
•It is recommended that a minimum distance of 100mm should
be left clear to either side of the unit.
•Avoid locations where people or doors might damage the unit.
•Choose a completely at wall surface to mount the unit with
the power cable above.
LOCATION
DO NOT install in the following places
•Where the temperature can be below -10°C or above 40°C.
•Where the unit may come into direct contact with excessive water.
•If the unit will be in direct or strong sunlight.
•If there is a lot of condensation in the environment.
•If there are corrosive, neutral or reductive gases present.
•20m or more below, or 2000m or higher than, sea level.
PRE-INSTALLATION PRECAUTIONS
5
CLEANING & MAINTENANCE
External maintenance
Clean with a soft cloth. If the unit is very dirty use a soft, dampened
cloth with a neutral cleaning agent, then polish with a soft, dry cloth.
•Only use neutral cleaning agents.
•Do not use thinners, acidic or alkaline toilet cleaners or nylon brushes
(they may damage the surface).
•If using chemical cloths, read instructions rst.
•Unplug the unit before maintenance.
•Incorrect repair may result in danger for the user.
•The guarantee does not cover damage which is caused by modications,
accident, misuse, abuse, neglect, commercial use or improper use.
We reserve the right to change the product and the instructions without
notice in accordance with the policy of continuous improvement.
WARNING: This appliance contains a UV emitter.
Do not stare at the light source.
NEVER look directly at the bulbs when in operation.
•Ensure unit and power are switched off and
remove the outer shell to access the lamp unit.
•Remove lamp unit cover to reveal the dual bulb.
Carefully clear the unit of any dust using a soft brush.
•Gently loosen the old lamp by holding the lamp
holder in one hand and pulling the lamp upwards
and away from the lamp holder.
•Replace the dual lamp with a new one by
inserting it into the lamp holder and pushing
it downwards until it clicks into position.
Do not touch the new lamp with your bare hands.
•Replace the cover.
1
2
3
6
PACKING LIST
A. Rawplug ........................................................x 4
B. 30mm Wall Screws ................................................x 4
C. Instruction Manual ................................................x 1
D. Allen Key ........................................................x 1
E. Sterillo UNO Unit ..................................................x 1
7
8
www.sterillo.com
Sterillo Ltd
Unit 9 •Stort Valley Ind Estate •Stansted Road
Bishop’s Stortford •Herts •CM23 2TU •UK
+44 1279 466500
