Hanover HVNB48 User manual

HanoverOutdoorFurniture
IMPORTANT
Ifyouhaveanyproblemswiththisproduct(missingordamagedparts,assemblyissues,etc.),
PLEASEDONOTRETURNTOTHERETAILER/STORE
fromwhereyoupurchasedtheproduct.
PleasecallourToll‐FreeCustomerServiceHotlineat:1‐877-976-4402
Between9:00AMand5:00PMEasternTime,MondaythroughFriday
Orvisitourwebsiteat:www.hanover‐products.com
Toexpediteanyfuturewarrantyclaims,pleaseretaintheInstructionSheet,Warranty
Cardandreceiptforfutureuse.
For additionalon‐linesupportonassembly,troubleshootingandcare&maintenanceofyouroutdoor
furniture,pleasevisitourwebsiteat:www.hanover‐products.com.
6/1/2015(b)

FIGURE 1
B
B
Back
Sideframe
FIGURE:2
B
B
Seat
B - 1/4-20 X 2-1/4 WAFER SHCS
8
2
A - 5/16 PLASTIC PINS
Qty. Description
MODELS: HVNB48 & HVNB60
Step 1
Lay back assembly on the floor
Attach the side frames with (4) 2 1/4" bolts
Do not tighten bolts yet fig.1
Step 2
Insert (2) pins into pre-drilled holes
on the back assembly. fig.1
Step 3
Set bench upright. First, attach the front
part of the seat using (2) 2 1/4" bolts. fig.2
TOOLS NEEDED
4mm HEX KEY, ALLEN, T-HANDLE
(INCLUDED)
Step 4
Push the rear part of the seat up into
the pins located on the back assembly.
Attach the rear of the seat using
(2) 2 1/4" bolts. fig. 2
Tighten all bolts at this time
A
__(2) Sideframe
__(1) Seat
__(1) Back
__(1) Hardware pack
ALL HARDWARE IS COATED STAINLESS STEEL
6/25/2015
ASSEMBLY INSTRUCTIONS
