hanshow Nebular-T01-N User manual
Hanshow Nebular-T01-N Product Manual
IHanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
STATEMENT
This document and all its contents contained remain the proprietary material of
Hanshow Technology Co., Ltd. (Hanshow) and are protected by Chinese laws and
applicable international conventions on copyrights. Any reproduction, transmission,
disclosure, revision, modification or use otherwise of this document or the whole or part
of its contents, in whatever form and by whatever means, is not permitted without prior
express written authorization from Hanshow. Offenders will be liable for any and all
damages caused by their offence hereof and will be subject to all remedies that
Hanshow is entitled to seek under applicable laws.
Hanshow Nebular-T01-N Product Manual
II Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
ABOUT THE MANUAL
This document describes features, specification, package, and precautions of Nebular-
T01-N.
Please read this manual carefully before using the device in first, retain the manual for
subsequent use or for the next owner. If the instructions contained in this manual are
insufficient to resolve issues that occur during device operation or maintenance, please
contact Hanshow Technical Customer Service Center (China: 400-0365-305;
Netherlands: 0800-022-5037; Belgium: 0800-71-335; France: 0800-91-7602; Thailand:
1800-011-185) directly, we will provide you with multi-channel technical services.
TARGET USERS
This document provides engineers with necessary data and related guidelines of
Nebular-T01-N. Users have to master the basic knowledge on communication and
network and so on. This manual is applicable for the below engineers:
⚫Testing Engineer
⚫Technical Support Engineer
⚫After Sales Engineer
⚫Installation Engineer
Hanshow Nebular-T01-N Product Manual
III Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
SYMBOL DESCRIPTION
Icon
Description
Information indicated with this icon should be paid special attention and attached
great importance by the reader.
Information indicated with this icon is the explanation on the formal text for the
readers to comprehend the text better.
[X-X]
It means special noun definition is provided here.
EXPLANATION OF TERMS
Acronym
Expanded form
Description
PriSmart
PriSmart Smart Retail System
Manage all store product data and issue
price update command, as well as support
multi-store management.
ESL-Working
ESL-Working System
Manage all the APs and ESLs in store, and
ESL-Working 3.0 and above supports multi-
store management.
ESL Controller
ESL Controller
Also called AP that is used for data
interaction between ESL-Working and ESL
Controller.
ESL
Electronic Shelf Label
Used for displaying product information like
promotion information, price, and grade.
Table of Contents
IV Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
Table of Contents
1 Overview .................................................................................................................................................1
1.1 System architecture..........................................................................................................................1
1.2 Features ...........................................................................................................................................2
2 Product view............................................................................................................................................3
2.1 Product appearance.........................................................................................................................3
2.2 Dimensions.......................................................................................................................................4
3 Hardware performance ...........................................................................................................................5
3.1 Specifications ...................................................................................................................................5
3.2 Naming rule ......................................................................................................................................6
3.3 Product nameplate ...........................................................................................................................6
4 Packaging and accessories ....................................................................................................................7
4.1 Packaging.........................................................................................................................................7
4.2 Product accessories.........................................................................................................................8
5 Application scenarios..............................................................................................................................9
6 Precautions ...........................................................................................................................................10
6.1 Transportation considerations........................................................................................................10
6.2 Precautions for use.........................................................................................................................10
Hanshow Nebular-T01-N Product Manual
1 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
1 Overview
Nebular-T01-N is Hanshow’s newest generation temperature sensor label. Based on
2.4GHz private wireless protocol, Nebular-T01-N can communicate with ESL controllers
to report temperature in real time or flash light. With extended life, Nebular-T01-N serves
traditional retail, new retail, department stores and fashion, pharmacies, culture, and
entertainment.
1.1 System architecture
Hanshow ESL system includes ESLs, ESL Controller, ESL-Working,All-Star, Database,
Integration server, CloudMonitor and Handheld Terminal (PDA), as shown in Figure 1-1.
Specifically, the ESLs are used for electronically displaying product information such as
name and price, and services available for customers.
Figure 1-1 Hanshow ESL system architecture
Hanshow Nebular-T01-N Product Manual
2 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
1.2 Features
The features of Nebular-T01-N are as follows:
⚫Measurement accuracy: ±0.1℃
⚫Temperature measurement range: -30℃～60℃
⚫Size: 2.9”
⚫Operating frequency band: 2402MHz ~ 2480MHz, 2473.3MHz-2493.5MHz (only for
Japan)
⚫Maximum transmit power: 1dBm
⚫Built-in LED indicator: 7-color display assists in product geolocation.
⚫Embedded NFC chip: Supports NFC function. NFC response distance is 10mm.
⚫Supports AES-128 encryption.
⚫Supports OTA (Over-The-Air) upgrade.
Hanshow Nebular-T01-N Product Manual
4 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
2.2 Dimensions
This section covers the dimensions of Nebular-T01-N.
Figure 2-2 Nebular-T01-N dimension
Hanshow Nebular-T01-N Product Manual
5 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
3 Hardware performance
This chapter consists of:
⚫Specifications
⚫Naming rule
⚫Product nameplate
3.1 Specifications
Table 3-1 lists the Nebular specifications.
Table 3-1 Nebular-T01-N specifications
Name
Description
Dimensions (mm*mm*mm)
89.4*40.0*7.8
Weight (g)
28.5
Size (inch)
2.9
Battery life [3-1]
3 years
Battery capacity
1030mAh
Battery type
CF302752F
Protection level
IP68
Operating temperature (℃)
-30 ~ 60
Storage temperature (℃)
0 ~ 40
Humidity (%RH)
30 ~ 70
Note:
➢[3-1]: The battery life is calculated based on the following scenario: the battery
life is 3 years if Nebular-T01-N reports temperature every 3 minutes.
Hanshow Nebular-T01-N Product Manual
6 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
3.2 Naming rule
You can identify Nebular-T01-N from the following naming rule:
Figure 3-1 Naming rule of Nebular-T01-N
3.3 Product nameplate
Figure 3-2 shows the nameplate of Nebular-T01-N.
Figure 3-2 Nameplate of Nebular-T01-N
Note: The above is for reference only, actual label information might vary.
Hanshow Nebular-T01-N Product Manual
7 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
4 Packaging and accessories
This chapter describes packaging and required accessories of Nebular-T01-N.
4.1 Packaging
Nebular-T01-N packaging and the specific label quantity is shown in Figure 4-1.
Figure 4-1 Nebular-T01-N family packaging
Hanshow Nebular-T01-N Product Manual
9 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
5 Application scenarios
Nebular-T01-N is applicable to hypermarket, supermarket and retail stores, mainly for
refrigeration areas.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement.
Hanshow Nebular-T01-N Product Manual
10 Hanshow Copyright Reserved ©
Hanshow Technology Co., Ltd.
6 Precautions
During transportation and usage of Nebular-T01-N, note the following precautions.
6.1 Transportation considerations
Avoid the following considerations during transport:
⚫Water leakage or heavy moisture
⚫Heavy stacking
⚫High heat conditions above 40℃
6.2 Precautions for use
Follow the precautions:
⚫Operating environment, -30℃~ 60℃, 30% ~ 70%RH
⚫Storage environment, 0℃~ 40℃, 30% ~ 70%RH.
⚫Keep Nebular-T01-N within the specified temperature range, otherwise the battery
life might be shortened.
⚫The output capacity will degrade at low temperature.
⚫Frequent communications or flashing might shorten battery life during the use.
⚫Avoid dropping or tossing Nebular-T01-N.
⚫Do not disassemble Nebular-T01-N without permission.
⚫The mineral substances in rainwater, moisture or liquids might corrode the
electronic circuit. Avoid water on the product as much as possible.
⚫Regularly clean Nebular-T01-N.
⚫Promptly remove cosmetics, perfume and other dirty from Nebular-T01-N to avoid
damages.
⚫Do not use Nebular-T01-N in water. Otherwise, no warranty is provided.
⚫Avoid direct contact with chemical detergent.
⚫Do not install Nebular-T01-N in a strong magnetic environment.
⚫Communications might be limited or affected by wireless communication systems
that share the 2.4GHz frequency-band, such as Wi-Fi, Bluetooth, and Zigbee.
⚫Do not place Nebular-T01-N near kitchen appliances such as stove or microwave
oven.
