Harbor Freight Tools 90787 User manual

LATHE DUST
COLLECTION HOOD
ASSEMBLY AND OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
Copyright © 2003 by Harbor Freight Tools®. All rights reserved. No portion of
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353
90787
90787.p65 10/21/03, 3:03 PM1

Page 2
SKU 90787
Specifications
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using Product, basic safety precautions should always be followed
to reduce the risk of personal injury and damage to equipment.
Read all instructions before using this Product!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use the Dust Hood in damp or wet locations.
Don’t expose to rain. Keep work area well lighted.
3. Keep children away. Children must never be allowed in the work area. Do not let
them handle or play with the Dust Hood.
4. Store idle equipment. Always keep out of reach of children.
5. Use the right product for the job. Do not attempt to force a small product or
attachment to do the work of a larger industrial Product. There are certain applications
for which this product was designed. It will do the job better and more safely at the
rate for which it was intended. Do not modify this product and do not use this product
for a purpose for which it was not intended.
6. Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid footwear
are recommended when working. Wear restrictive hair covering to contain long hair.
7. Use eye protection. Always wear ANSI approved impact safety goggles during set-
up.
8. Do not overreach. Keep proper footing and balance at all times. Do not reach over
or across running machines.
9. Maintain products with care. Keep the Dust Hood clean for better and safer
performance.
Hood Overall Dimensions 8-3/4” L x 8-1/2” W X 7-1/2” H
Shield Dimensions 9-1/2” L x 5-1/4” W x 1/8” Thick
Hose Flange Diameter 3-7/8” OD.
Fasteners Included: Two Dome Headbolts, Two Wing Nuts with Washers.
90787.p65 10/21/03, 3:03 PM2

Page 3
SKU 90787
10. Stay alert. Watch what you are doing, use common sense. Do not operate any tool
when you are tired.
11. Check for damaged parts. Before using any product, any part that appears
damaged should be carefully checked to determine that it will operate properly and
perform its intended function. Check for alignment and binding of moving parts; any
broken parts or mounting fixtures; and any other condition that may affect proper
operation. Any part that is damaged should be properly repaired or replaced by a
qualified technician.
12. Guard against electric shock. Prevent body contact with grounded surfaces such
as pipes, radiators, ranges, and refrigerator enclosures.
13. Replacement parts and accessories. When servicing, use only identical
replacement parts. Use of any other parts will void the warranty. Only use accessories
intended for use with this product. Approved accessories are available from Harbor
Freight Tools.
14. Do not use the product if under the influence of alcohol or drugs. Read warning
labels if taking prescription medicine to determine if your judgment or reflexes are
impaired while taking drugs. If there is any doubt, do not operate the product.
15. Maintenance. For your safety, service and maintenance should be performed
regularly by a qualified technician.
Warning: The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which cannot be
built into this product, but must be supplied by the operator.
Unpacking
When unpacking, check to make sure the parts listed on page 5 are included. If any parts
are missing or broken, please call Harbor Freight Tools at the number on the cover of this
manual as soon as possible.
Warning! Exposure to crystalline silica may cause silicosis (a serious lung disease), cancer
and death. Exposure to aluminum oxide (a dust generated from material removing processes)
can result in eye, skin and breathing irritation. Always use a NIOSH (National Institute for
Occupational Safety and Health) approved respirator and safety goggles. Avoid skin expo-
sure. Proper ventilation in the work area is required.
90787.p65 10/21/03, 3:03 PM3

Page 4
SKU 90787
Assembly and Operation
Note: Before assembling or operating the Dust Hood Cover, read and follow all of the safety
warnings and instructions that came with the lathe.
Note: This Dust Hood Cover is designed to be used with a vacuum or dust extraction system
(both not included). The hose and hose clamp to connect the vacuum or dust extraction
system to the Dust Hood Cover is not included with the Dust Hood Cover. The outside
diameter of the Hose Flange is 3/8”.
Note: This Dust Hood Cover is to be used with lathe beds having pre-drilled holes specifically
designed for attaching Dust Hood Covers.
Warning! When assembling, adjusting, or cleaning the Dust Hood Cover, make sure
the lathe is unplugged from its power source.
1. Attach the Shield (1) to the Hood (3) using the two Pins (2). See FIGURE 1.
2. Find an acceptable place to mount the Dust Hood Cover on the lathe bed. Position the
Bracket (4) on the top, back of the lathe, in a positon between the live centers. The shorter
end of the “L” shaped Bracket (4) should fit snug against the back side (vertical side) of the
lathe.
3. Center the holes on the bottom of the Hood (3) over the slots on the longer “L” section
of the Bracket (4). Put the Bolts (Screw set (5)) through the holes, the Bracket slots, and
through the holes on the horizontal flat surface of the lathe bed. Secure them with the
Washers and Wing Nuts (Screw set (5)).
4. Attach the vacuum hose (not included) to the
Hose Flange with a hose clamp (not included).
When you are ready to operate the lathe,
first turn on the vacuum or dust extraction
system.
Note: The Shield (1) swings up and down.
We recommend keeping the Shield (1) in the
down position during operation to assist with
dust collection airflow.
5. Follow the instructions and warnings
that came with your lathe to resume operation.
FIGURE 1
Bracket (4)
Holes on the
bottom of the Hood (3)
Hose Flange
Shield (1)
Maintenance
1. After making sure the lathe is unplugged, gently wipe the Dust Cover Hood clean with a lint
free cloth.
2. Make sure the Hose Flange is clear of any dirt, dust, or debris.
Pin (2)
Pin (2)
90787.p65 10/21/03, 3:03 PM4

Page 5
SKU 90787
NOTE: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS
MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBU-
TOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER
AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER
REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Assembly Drawing and Parts List
Part No. Description Qty.
1 Shield 1
2 Pin 2
3 Hood 1
4 Bracket 1
5 Screw Set 1
1
2
3
4Part No. 5, the Screw Set is not shown.
It includes: Two Dome Headbolts, Two
Wing Nuts with Washers.
