Harlequin AF330 Manual

HARLEQUIN SET UP
MODELS: AF330,AF345,AF360
www.lptentcanada.com/www.lptentusa.com

VISIT THE SUPPORT PAGE AT LPTENTUSA.COM / LPTENT.CA FOR MORE INFORMATION ON LP TENT PRODUCTS.
POP UP TENT |Harlequin
Thank you for choosing the Harlequin.
The Harlequin pop up canopy tents are intended for
frequent use. This aluminum frame is lighter and
stronger than its steel counterpart and still compara-
ble in price. With a polyester canopy and walls this
canopy tent is well suited for markets, trade shows,
sporting events or any other type of event.
For an optimal use of this product we invite you to
follow our setup guide.
Reinforced
Aluminum
Scissors
Ø40mm Octagonal
Aluminum Profile
Stainless Steel Screws
Fiberglass Injected
Connections and Handles
Height Adjustment
Reinforced Fabric
on Corners, Peaks
and Connections
Steel Foot Plates

VISIT THE SUPPORT PAGE AT LPTENTUSA.COM / LPTENT.CA FOR MORE INFORMATION ON LP TENT PRODUCTS.
Open the structure 60% of the way then position 2 people face to face, grab the scissors and pull while backing up.
Do not tighten the Velcro on the roof
during the assembly of the canvas.
Deploying the structure
With two people, open the roof and grab at each corner.
Correctly position the peak and the corners of your top.
Open the frame 40% of the way
Position the frame
Once each corner of the top is correctly placed on the corners of the structure (A) attach the Velcro
straps in the corners like as shown above (B), finally open the tent all the way and attach the
Velcro straps in the center of the valences to the scissors like as shown above (C)
Position the top Secure the top to the frame
SET UP INSTRUCTIONS |Harlequin
FRAME DEPLOYMENT
TOP INSTALLATION
1 2 3
1 2
Place the tent on a flat surface,
standing upright on its 4 feet. Then
loosen the roof strap.
Position the frame Do not grab or pull at feet.
A B C

VISIT THE SUPPORT PAGE AT LPTENTUSA.COM / LPTENT.CA FOR MORE INFORMATION ON LP TENT PRODUCTS.
SET UP INSTRUCTIONS |Harlequin
Push point A) towards point (B) until you hear a click. Once you hear the click the locking system will
be locked into place and your tent will be secure (C). Repeat on all legs.
Adjust the height of the tent using the extendable legs. To do this, press the button (A) and lift the
upper part of the leg (B). The lower part must slide by itself (C).
You can choose between 3 height settings.The walls are provided for the maximum height. (When
extending the legs do not stand on the foot plate)
Corner lock with button Height adjustment
Position the wall so that the Velcro strip on the top of the face the
outside of the tent. Attach the Velcro to the roof strip (Inner side).
Wall installation
Attach the Velcro strips on both sides
around the legs of the tent.
If you mount several walls the vertical
Velcro attaches to the next wall.
Unzip the two vertical zippers (door only), roll the door/curtain and
hang it with the Velcro strips on the top of the wall.
Opening the door/window wall curtain
Do not force the frame. Close the
frame and check for blockage
WALL INSTALLATION
FRAME DEPLOYMENT
3 4
1 2 3
A
B
C
A
B
C

VISIT THE SUPPORT PAGE AT LPTENTUSA.COM / LPTENT.CA FOR MORE INFORMATION ON LP TENT PRODUCTS.
Attach the carabiners to the scissors points on each corner of the tent (A). Place the stakes at a
minimum distance of 3ft.
Place the weight on the foot plate of your tent (A). Stack any extra weights if necessary.
Weighting Anchoring
• Wash with a damp cloth and soapy water (no abrasive sponge or
detergent).
• Rinsing possible with a hose (high pressure not recommended).
• Air dry before storing.
• To remove dirt, grass, clean the frame with a damp cloth (No
detergent).
Cleaning the roof, walls and frame: Storing: Transportation:
• Wash and dry before storing.
• Store the tent upright in its carrying case.
• Store the material in a dry place not subject to high humidity.
• Transport the tent preferably upright.
• In case of horizontal transport, do not put weight on the structure.
CLEANING & MAINTENANCE
WEIGHTING & ANCHORING
1 2
1 2 3
A
SET UP INSTRUCTIONS |Harlequin
A
