Compact, integrated music system
Key Features
■65-Watts-per-Channel Output – Distortion-free sound
at any listening level
■Digital-Audio Connections – Two coaxial and two optical
digital inputs and one coaxial digital output maximize
connection flexibility and eliminate D/A conversions for
maximum sound quality
■Analog-Audio Connections – Two stereo RCA inputs for
full-size audio components and one stereo 3.5mm (1/8")
input for computers and portable media players maximize
connection flexibility
■Phono Input – Connects to turntables with MM (moving-
magnet) phono cartridges
■Headphone Jack
■Clock with Sleep Timer and Dual Alarms
■VFD Display
■Gold-Plated Binding Posts
■Striking Industrial Design
Specifications
Audio Specifications
■Power output: 65 watts per channel (both channels driven),
20Hz – 20kHz, <0.07% THD, 6 ohms
■Bandwidth: 20Hz – 35kHz (–3dB)
■System frequency response: 20Hz – 20kHz, ±0.5dB
■Signal-to-noise ratio (IHF-A): 90dB (analog inputs);
96dB (digital inputs)
■Channel separation: >–65dB
■Crosstalk between sources: >–70dB
■Input sensitivity (1kHz): 250mV RMS, ±1dB (RCA inputs);
7.5mV (phono input)
FM Specifications
■Frequency Frequency range: 87MHz – 108MHz
■Usable sensitivity (IHF): 1.3μV/13.2dBf
■Signal-to-noise ratio: 68dB (mono); 65dB (stereo)
■Distortion: 0.15% (mono); 0.3% (stereo)
■Stereo separation @ 1kHz: 35dB (100% deviation @ 65dBf)
■Selectivity ±300kHz: 65dBf
■Image rejection: 80dB
■IF rejection: 90dB
■Station presets: 30
■RDS capability: PS (program service); RT (dynamic radio text)
CD Specifications
■Disc compatibility: CD, CD-R, CD-RW, MP3, WMA
■THD+N (20Hz – 20kHz): <0.025%
■Frequency response: 20Hz – 20kHz, ±0.5dB
■Channel separation: >–65dB
■Signal-to-noise ratio (A WTG): >96dBr; >94dBr (22kHz filter)
Speaker Specifications
■Low-frequency transducer: 130mm (5-1/8") honeycomb
composite, shielded
■High-frequency transducer: 25mm (1") MMD dome, shielded
■Frequency response: 60Hz – 25kHz (–3dB)
■Nominal impedance: 8 ohms
■Crossover frequency: 2.2kHz
General Specifications
■Power requirement: AC 120V/60Hz
■Power consumption: <1W full standby (clock not activated);
<2W standby (clock activated);
150W maximum (both channels driven)
■Operating temperature: 0°C – 40°C (32° – 104°F)
■Controller dimensions (W x H x D): 90mm x 240mm x 240mm
(3-9/16"x 9-7/16"x 9-7/16")
■Amplifier dimensions (W x H x D): 90mm x 240mm x 240mm
(3-9/16"x 9-7/16"x 9-7/16")
■Speaker dimensions (W x H x D): 272mm x 181mm x 196mm
(10-23/32"x 7-1/8"x 7-3/4"), with grilles
■Weight: System: 13.9kg (30.5 lb);
Controller: 2.0kg (4.4 lb);
Amplifier: 2.8kg (6.3 lb)
Speakers (each): 4.4kg (9.8 lb)
MAS 102
