Harman Infiniy CLUBZ 150 User manual

CLUBZ 150
PORTABLE BLUETOOTH SPEAKER
User Manual
Warning!
Warranty Card

WELCOME TO HARMAN's FAMILY OF LEGENDARY BRANDS
01 EN

Input: 5V/0.5A
What’s in the box
Connections
Buttons
1
2
3
QSG
02 EN

2.0s
2.0s
2. Turn off the bluetooth speaker
1. Turn on the bluetooth speaker
This speaker comes with dual EQ to enter into various
personal preference, to swtich EQ, short press "+" and "－"
buttons to switch.
Power on / Power off
4
EQ switching
5
03 EN

Choose ”Infinity CLUBZ 150” to connect
2.0s
2.0s
2. Connect to bluetooth device
<
Settings Bluetooth
Bluetooth
Infinity CLUBZ 150
DEVICES
Connected
Now Discoverable
1. The speaker will automatically enter into pairing mode
when power on and wait for the device to connect.
Bluetooth connection
6
Music
7
3. When turn on, the speaker will automatically connect to
the last connected device if available. If not, short press
the " " button to re-enter the pairing.
4. Clean up the pairing information by long press the " "
and " " buttons in the same time.
04 EN

3.0s
x 1 x 1
x 2
Phone call
8
Voice assistant
9
Bluetooth mode, double press the " " button on the
speaker to activate Siri or Google Now on your phone. Please
make sure the Siri or Google Now is enabled on your phone.
05 EN

Speaker A Speaker B
3.0s
Speaker A Speaker B
True wireless stereo pairing
10
2. Enable bluetooth on your device and connect to
"Infinity CLUBZ 150", stereo sound will play from both speakers.
1. Long press the " " button to enter into the true wireless
stereo pairing mode as a master speaker. If one of them fails,
clean up the pairing information.
06 EN

Specifications
Bluetooth version: 4.2
Support: A2DP V1.2; GAVDP V1.3; AVRCP V1.6; HFP V1.7
Transducer: 43mm
Output power: 4.5W
Frequency response:100Hz - 20KHz
Signal-to-noise ratio: >70dB
Battery type: Lithium-ion polymer (3.7V, 750mAh)
Battery charge time: 3.5 hour @ 5V0.5A
Music playing time: up to 8 hours (50% volume level )
Bluetooth transmitter power: -6 ~ 4dBm
Bluetooth transmitter frequency range: 2.402 — 2.480GHz
Bluetooth transmitter modulation: GFSK, 1/4-DQPSK, 8DPSK
Dimensions：Φ70*82.3 (mm)
Weight: 195g
LED Behavior
11
12
White
Fast flash
White
Slow flash
White
Flash
White
On
White
Fast flash
White
Fast flash
White
On
True wireless
stereo pairing
mode
True wireless
stereo
connected B
A
A
On
Stand by
Bluetooth
pairing mode
Bluetooth
connected
Dual speaker connect
07 EN

Warning
13
IMPORTANT: To ensure that the CLUBZ 150 is waterproof,
please remove all cable connections and tightly close the
cap; exposing the CLUBZ 150 to liquids without doing so
may result in permanent damage to the speaker. And do
not expose CLUBZ 150 to water while charging, as doing so
may result in permanent damage to the speaker or power
source,IPX7 waterproof is dened as the speaker can be
immersed in water up to 1m for up to 30 minutes.
CLUBZ 150 is IPX7 waterproof.
INFORMATION ON DISPOSAL FOR USERS OF
WASTE ELECTRICAL &ELECTRONIC EQUIPMENT
(PRIVATE HOUSHOLD)
This symbol on the products and/or accompanying documents
means that used electrical and electronic products should not
be mixed with general household waste. For proper treatment,
recovery and recycling, please take these products to
designated collection points, where they will be accepted on a
free of charge basis. Alternatively, in some countries you may be
able to return your products to your local retailer upon the
purchase of an equivalent new product. Disposing of this
product correctly will help to save valuable resources and
prevent any potential negative eects on human health and
the environment which could otherwise arise from inappropriate
waste handling. Please contact your local authority for further
details of your nearest designated collection point. Penalties
may be applicable for incorrect disposal of this waste, in
accordance with national legislation.
08 EN

Congratulations with the purchase of your new Product. We
have done our utmost to make your experience the best one
possible. If you have any questions when setting up your
Product and would like some helpful hints, we recommend
that you visit the relevant country specic support website for
your Product There you will also nd relevant contact
information. If you cannot nd the information you are looking
for, please contact the vendor that sold the Product to you
or contact the relevant HARMAN customer support center by
electronic mail or phone.
We recommend that you register your Product via the relevant
country specic website for your Product. Your registration will
allow us to inform you about updates for certain products,
possible new oers and new Products and/or applications.
Registering is easy; just follow the instructions on the relevant
country specic website for your Product.
This symbol is only valid in the European Union. If you wish to
discard this product, please contact your local authorities or
dealer and ask for the correct method of disposal.
SET UP INFORMATION & PRODUCT REGISTRATION
INFORMATION ON DISPOSAL IN OTHER COUNTRIES
OUTSIDE THE EUROPEAN UNION
IF YOU PURCHASED PRODUCTS IN INDIA, PLEASE
VISIT WWW.HARMANWARRANTY.IN TO REGISTER
FOR WARRANTY
09 EN

HARMAN International Industries, Incorporated (“HARMAN”) is
the manufacturer and through its local subsidiary, warrants to
you that the Product (including components provided in/with
the Product) will be free from defects in workmanship and
materials for a period of ONE year from the date of retail
purchase by you (the “Warranty Period”). During the Warranty
Period, the Product (including components), will be repaired or
replaced at HARMAN’s option, without charge for either parts or
labor OR at HARMAN’s sole option, the price of the Product may
be refunded, subject to depreciation based on your purchase
price for the Product pro-rated over the remaining balance of
the Warranty Period. Any warranty service or replacement of
parts will not extend the Warranty Period.
This Limited Warranty does not cover defects which are a result
of: (1) damage caused by accident, unreasonable use or
neglect (including the lack of reasonable and necessary
maintenance); (2) damage during shipment (claims must be
presented to the carrier); (3) damage to, or deterioration of,
any accessory or decorative surface; (4) damage resulting from
failure to follow instructions contained in your owner’s manual;
(5) damage resulting from the performance of repairs by
This limited warranty (the “Limited Warranty”) protects only the
original end-user (“you” or “your”), and is not transferable and
is applicable only in the country (excluding EEA member states
and the Russian Federation) in which you originally purchased
your INFINITY Product (the “Product”). Any attempt to transfer
this warranty shall immediately make this warranty void.
WHO IS PROTECTED BY THE WARRANTY
LIMITED WARRANTY
10 EN

Furthermore, this Limited Warranty covers only actual defects
within the Product itself, and does not cover the cost of
installation or removal from a xed installation, setup or
adjustments, claims based on misrepresentation by the seller,
performance variations resulting from installation-related
circumstances such as source quality or AC power or Product
modications, any unit on which the serial number has been
eaced, modied or removed, or units used for other than
home use. This Limited Warranty is valid only for INFINITY products
purchased from an authorized dealer.
someone other than HARMAN authorized service center; (6)
deterioration of component parts, the nature of which is to
become worn or depleted with use, such as batteries.
Except to the extent expressly prohibited in your jurisdiction by
applicable law, all implied warranties, including tness for a
particular purpose and merchantability are hereby excluded
and in no event shall HARMAN or any HARMAN subsidiary be
liable for any indirect, direct, incidental, special or consequential
loss or damages whatsoever (including, without limitation, other
pecuniary loss) arising out of the use of or inability to use the
Product, even if HARMAN and/or a HARMAN subsidiary have
been advised of the possibility of such damages. To any extent
that HARMAN cannot lawfully disclaim implied warranties under
this Limited Warranty, all such implied warranties are limited in
duration to the duration of this warranty. Some jurisdictions do
not allow the exclusion or limitation of incidental or consequential
damages or exclusions or limitations on the duration of implied
warranties or conditions, so the above limitations or exclusions
may not apply to you. This warranty gives you specic legal rights,
and you may also have other rights that vary by jurisdiction.
11 EN

This Limited Warranty covers all expenses for labor and materials
required for the repair OR replacement of the Product that is
found to be defective, and a reasonable return shipping
charge within the country of repair. Please be sure to save the
original shipping carton(s), because a charge will be made for
additional cartons/packaging. You will be charged for the cost
of examining a unit that is not in need of repair (including
resulting shipping costs), or for necessary repairs not covered by
this Limited Warranty. We sincerely thank you for your
expression of condence in INFINITY. We wish you many
years of listening pleasure.
For a seamless experience please register your product at
www.HarmanWarranty.in. (if you purchased products in India)
Information on service centers can be found on the registration
page. Contact the dealer who sold you this Product, or
contact HARMAN customer support using the contact
information on the relevant country specic support website
for your Product to request warranty service. To validate your
right to this Limited Warranty, you must provide the original sales
invoice or other proof of ownership and date of purchase. Do not
return your Product without prior authorization from the
corresponding dealer or HARMAN. Warranty repair of the
HARMAN Product must be carried out by Harman authorized
service center. Unauthorized warranty repair will void the
warranty and is performed at your sole risk.
You are also welcome to consult the relevant country specic
HARMAN support website for your Product for helpful hints.
HOW TO OBTAIN WARRANTY SERVICE
WHO PAYS FOR WHAT
12 EN

The Bluetooth word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by HARMAN International
Industries, Incorporated is under license. Other trademarks and trade names
are those of their respective owners.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.harman.com
HARMAN International Industries, Incorporated. All rights reserved.
Infinity is a trademark of HARMAN International Industries, Incorporated,
registered in the United States and/or other countries.
Features, specifications and appearance are subject to change without notice.
To register for warranty in India, scan QR
www.HarmanWarranty.in
13EN

CLUBZ 150
可攜式藍牙喇叭
使用者手冊
警告！
保固卡

歡迎使用 HARMAN 傳奇品牌系列
15 TW

輸入：5V/0.5A
包裝盒內物品
連接
按鈕
1
2
3
QSG
16 TW

2.0S
2.0S
2. 關閉藍牙喇叭
1. 開啟藍牙喇叭
本喇叭帶有雙 EQ，以迎合不同的個人喜好；如欲開關 EQ，
請短按「+」及「-」按鈕以進行切換。
開機/關機
4
EQ 開關
5
17 TW

2.0S
2.0S
2. 連接至藍牙裝置
<
Settings Bluetooth
Bluetooth
Infinity CLUBZ 150
DEVICES
Connected
Now Discoverable
1.開啟電源後，喇叭將自動進入配對模式，然後等待裝置連接。
藍牙連接
6
音樂
7
選擇「Infinity CLUBZ 150」以進行連接
3. 開啟時，喇叭將自動連接到最後連接的裝置（如有）。
否則，短按「 」按鈕以重新進入配對模式。
4. 同時長按「 」和「 」按鈕，清除配對資訊。
18 TW
