Harman MIB GLOBAL ENTRY User manual

MIB Global
ENTRY / STANDARD / STANDARD PLUS
Composition Audio (PQ):
Radio
Status: September 20, 2013
German: April 2015
Partno.:SGB012901CA
SGB012901CA





Explanation of symbols
Identifies a reference to a section with
important information and safety notes 
in a chapter, which should always be
observed.
This arrow shows that the section
continues on the next page.
This arrow shows the section end.
This symbol identifies situations, in which
the vehicle has to be stopped as quickly
as possible.
® ™ This symbol identifies a trademark. If this
symbol is missing, this does not
guarantee that the terms may be used
freely.
·Symbols of this kind refer to
warningswithin the same sectionor on
the given page to point out possible
accident and injury dangers and how
they can be avoided.
·Cross-reference to possible material
damage within the same section or on
the given page.
WARNING
Texts with this symbol refer to dangerous situations,
which could result in death or severe injuries if not
noted.
CAUTION
Texts with this symbol refer to dangerous situations,
which could result in slight or severe injuries if not
noted.
NOTE
Texts with this symbol refer to situations, which could
result in vehicle damage if not noted.
Textswiththissymbolcontainnotesaboutenvironmental
protection.
Textswiththissymbolcontainadditionalinformation.
DANGER
Texts with this symbol refer to dangerous situations,
which will result in death or severe injuries if not
noted.
Volkswagen AG is continually working on further
development of all types and models. We thank
you for your understanding that changes in the
scope of supply, equipment and technology are
possible at any time as a result. The information
concerning scope of supply, appearance,
performance, dimensions, weight, fuel
consumption, standards and functions of the
vehicle correspond to the information state at the
time of going to press. It might only be possible to
deliver some of the equipment later (your local
Volkswagen Partner can provide information about
this) or it might only be offered in specific markets.
No claims can be derived from the information,
illustrations or descriptions in these instructions.
Copying, reproduction or translation, even of
excerpts, is not permitted without written consent
of Volkswagen AG.
Volkswagen AG expressly reserves all rights
pursuant to the copyright law. Subject to change
without notice.
Produced in Germany.
© 2014 Volkswagen AG
Printed on paper made of chlorine-free
bleached cellulose.

User Instructions
USER Instructions - MIB GLOBAL – certification texts 2015-03-10
page 1 of 3
1 Homologation- and Certification texts
1.1 Material compliance
The MIB GLOBAL Headunit
(infotainment headunit for vehicular use only) is compliant with the ELV directive (2000/53/EC).
1.2 Declaration of Conformity to EC directive “R&TTE” (1999/5/EC)
Česky [Czech]: HARMAN tímto prohlašuje, že tento MIB GLOBAL Headunit je ve shoděse základními požadavky a
dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk [Danish]: Undertegnede HARMAN erklærer herved, at følgende udstyr MIB GLOBAL Headunit overholder de
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch [German]: Hiermit erklärt HARMAN, dass sich das Gerät MIB GLOBAL Headunit in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti [Estonian]: Käesolevaga kinnitab HARMAN seadme MIB GLOBAL Headunit vastavust direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
English: Hereby, HARMAN, declares that this MIB GLOBAL Headunit is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Español [Spanish]: Por medio de la presente HARMAN declara que el MIB GLOBAL Headunit cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική [Greek]: ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ HARMAN ∆ΗΛΩΝΕΙ ΟΤΙ MIB GLOBAL Headunit ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ.
Français [French]: Par la présente HARMAN déclare que l'appareil MIB GLOBAL Headunit est conforme aux exigences
essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Italiano [Italian]: Con la presente HARMAN dichiara che questo MIB GLOBAL Headunit è conforme ai requisiti essenziali
ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski [Latvian]: Ar šo HARMAN deklarē, ka MIB GLOBAL Headunit atbilst Direktīvas 1999/5/EK b tiskajām prasībām un
citiem ar to saistītajiem noteikumiem.
Lietuvių[Lithuanian]: Šiuo HARMAN deklaruoja, kad šis MIB GLOBAL Headunit atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
Nederlands [Dutch]: Hierbij verklaart HARMAN dat het toestel MIB GLOBAL Headunit in overeenstemming is met de
essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Malti [Maltese]: Hawnhekk, HARMAN, jiddikjara li dan MIB GLOBAL Headunit jikkonforma mal-ħtiġijiet essenzjali u ma
provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar [Hungarian]: Alulírott, HARMAN nyilatkozom, hogy a MIB GLOBAL Headunit megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski [Polish]: Niniejszym HARMAN oświadcza, że MIB GLOBAL Headunit jest zgodny z zasadniczymi wymogami oraz
pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC
Português
[Portuguese]: HARMAN declara que este MIB GLOBAL Headunit está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]: HARMAN izjavlja, da je ta MIB GLOBAL Headunit v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky [Slovak]: HARMAN týmto vyhlasuje, že MIB GLOBAL Headunit spĺňa základné požiadavky a všetky príslušné
ustanovenia Smernice 1999/5/ES.
Suomi [Finnish]: HARMAN vakuuttaa täten että MIB GLOBAL Headunit tyyppinen laite on direktiivin 1999/5/EY oleellisten
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska [Swedish]: Härmed intygar HARMAN att denna MIB GLOBAL Headunit står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Íslenska (Icelandic): Hér með lýsir HARMAN yfir því að MIB GLOBAL Headunit er í samræmi við grunnkröfur og aðrar kröfur,
sem gerðar eru í tilskipun 1999/5/EC
Norsk [Norwegian]: HARMAN erklærer herved at utstyret MIB GLOBAL Headunit er i samsvar med de grunnleggende krav
og øvrige relevante krav i direktiv 1999/5/EF.
„MIB GLOBAL Headunit“ stands for the variants:
MIB GLOBAL
ENTRY / STANDARD / STANDARD PLUS

User Instructions
USER Instructions
-
MIB GLOBAL
–
certification texts
2015
-
03
-
10
1.3 FCC statements (North America)
(§15.19)
"This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation”
and (§15.21)
“CAUTION TO USERS” / “FCC WARNING”
“Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment “
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guidelines.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
1.4 Industry Canada (IC) statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
1.5 Brasil
“Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência
prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em
caráter primário.”

User Instructions
USER Instructions
-
MIB GLOBAL
–
certification texts
2015
-
03
-
10
1.6 Mexico
For equipment subject to the NOM-121 (spread spectrum devices) it is necessary to follow the next
indications:
'Para cumplimiento de la Cofetel:
La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y
(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su
operación no deseada”
1.7 Taiwan
本產品符合低功率電波輻射性電機管理辦法 第十二條、第十四條等條文規定
1.
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更
原設計之特性及功能。
2.
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無
干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
本模組於取得認證後將依規定於模組本體標示審驗合格標籤，並要
求最終產品平台廠商(OEM Integrator)於最終產品平台
(End Product)上標示” 本產品內含射頻模組，其NCC 型式認證號碼
為:CCXXxxYYyyyZzW
1.8 Thailand
This telecommunication equipment conforms to NBTC technical requirement!
1.9 United Arabian Emirates
TRA
REGISTERED No.:
XXXXXX/XX
DEALER No.:
0028019/10

Table of contents 1
SGB012901CA
Contents
About these instructions .................2
Function description.........................3
Introduction
–Before initial use ..................................... 3
–Safety notes ...........................................3
–Overview of control elements....................5
–Basic operating principles.........................7
Audio and media mode
–Radio mode.......................................... 10
–Media mode ......................................... 14
Phone control (PHONE)
–Introduction to phone control................... 23
–Description of phone control ................... 27
Settings
–Menu and system settings
(SETUP).............................................. 31
Abbreviations used ......................... 34
Index.................................................... 35

SGB012901CA

About these Instructions
●You can find an alphabetical index at the end of
the instructions.
●An abbreviation index explains technical
abbreviations and designations.
●Direction information normally refer to the
travel direction.
●Illustrations serve for orientation and are to be
understood as depictions of principles.
They describe all equipment and models without
identifying them as special equipment or model
variants. As a result, equipment can be described,
which your vehicle might not have. Your local
Volkswagen partner can provide more detailed
information about this.
All information in these instructions correspond to
the information state at the time of going to press
and only apply to devices built-in ex-works. Due to
the on-going further development of devices and
possible upgrades in device software, deviations
between device displays and function and the
information in these instructions are possible. No
claims can be derived from information, illustrations
or descriptions differing in these instructions.
If you want to sell or lend the vehicle, please ensure
that these instructions are in the vehicle and that the
data and files saved in the device are deleted.
2 About these Instructions

SGB012901CA
Description of functions
Introduction
Before initial use
Checklist
Before initial use, you should carry out the following steps to operate the device safely and be able to usethe complete
scope of the provided functions:

Observe basic safety notes ⇒Page 3.
Become familiar with the overview of control elements⇒Page 5.
Reset the device system and function settings to the ex-works state⇒Page 31.
Only use appropriate data carriers for media mode
⇒Page 14.
Safety notes
WARNING
If the driver is distracted, this can cause
accidents and injuries. Operating the radio
system, a cellphone or phoning can distract
from traffic conditions.
●Always drive attentively and
responsibly.
●Only connect, insert or withdraw data
carriers in a standing vehicle at a safe
distance from traffic.
●Select loudspeaker levels so that acoustic
signals from outside can be heard well at any
time, e. g., the siren of rescue services.
Comply with legal regulations.
●A too-high volume can damage hearing.
This also applies in the case of high
volumes of brief duration.
WARNING
At operation of a cellphone or radio device
without connection to an external antenna,
the limiting value for electromagnetic
radiation can be exceeded in the vehicle and
consequently endanger the health of driver
and passengers. This also applies if an
exterior antenna is not installed properly.
WARNING (continuation)
●Keep a minimum distance of 20
centimeters between antenna of a cellphone
and an active medical implant, e.g., a cardiac
pacemaker, because cellphones can
negatively influence the function of active
medical implants.
●Do not keep a cellphone directly adjacent
to an active medical implant or directly above
it, e.g., in your chest pocket.
●If you suspect that a cellphone is interring
with an active medical implant or other
medical device, switch it off immediately.
WARNING
Unattached or incorrectly secured external
devices, e. g., cellphones, can be thrown
about the vehicle interior at a sudden
braking maneuver or accident and cause
injuries. Never arrange or attach external
devices on the doors, the front windshield,
above or near the area marked "AIRBAG"
on the steering wheel, the dashboard, seat
backs or between these areas and
passengers. External devices can result in
severe injuries in the case of accidents,
especially when the airbags open.
Introduction 3

WARNING
Connection lines of external devices can
hinder the driver.
●Lay connection lines, so that the driver is
not hindered.
WARNING
A too-high volume can damage hearing.
This also applies in the case of high
volumes of brief duration.
WARNING
Sudden loudness changes can occur at
change or connection of an audio source.
●Reduce the volume level before you
change or connect an audio source.
WARNING
An armrest can hinder the freedom of
movement of a driver and consequently
cause accidents and severe injuries.
●Always keep armrests closed during
rides.
WARNING
When the housing of a CD player is opened,
injuries can be caused due to invisible laser
beams.
●Only have CD players repaired by a
specialist company.
NOTE
In areas of no or deficient cellphone network
supply and possibly in tunnels, garages and
undergrounds passageways, a phone call
might be interrupted and it might be impossible
to reestablish connection – including any
emergency calls!
NOTE
●A cellphone must always be switched off
in environments with special regulations and
if the use of cellphones is prohibited.
NOTE (continuation)
NOTE (continuation)
The radiation emitted from a switched-
oncellphone can interfere with sensitive
technical and medical devices, which can
result in malfunction or damage to the device.
●High speeds, poor weather and road
conditions as well as network quality can
hinder or interrupt a phone call in a vehicle.
NOTE
Incorrect insertion of a data carrier or an
unsuitable data carrier can damage the
device.
●Pay attention to the correct insertion
position ⇒Page 14.
●Strong pressing can destroy the lock in
the SD card slot.
●Only use suitable SD cards.
●Always insert or withdraw CDs edgewise at
a right angle to the device front without
bending them and consequently scratching
them. ⇒Page 14.
●Inserting a second CD when there is
already one inserted or is being ejected can
destroy the CD drive. Always wait until the
data carrier has been ejected completely!
NOTE
Foreign particles sticking to a data carrier and
data carriers that are not round can damage the
CD drive.
●Only use clean 12 cm standard CDs!
–Do not glue any stickers or similar
things onto a data carrier. Stickers can
detach from and damage the drive.
–Do not use any imprinted data carriers.
Layers and imprints can detach and
damage the CD drive.
–Do not insert any 8 cm single CDs or
non-circular CDs (shape CDs).
–Do not insert any DVD plus, dual disc or
flip disc, because these are thicker than
normal CDs.
NOTE
The vehicle loudspeakers can be damaged by too
loud or distorted playback.
4 Function description

SGB012901CA
Overview of control elements
Fig. 1 Overview of control elements.
The device is supplied in different models, which can have different labeling and functions of device
buttons.
1 Rotary and push button:
–To switch on or off, press ⇒Page 7.
–To change the volume, rotate ⇒Page 7.
2 Device buttons: To call a function area, press.
–PHONE : Open phone function ⇒Page 23.
–LIST : Open station list in radio mode ⇒Page 10. Open song list in media mode
⇒Page 14.
–and : Arrow keys also affect the currently active audio source.
–: Switch sub-menus step-by-step back to the main menu or undo entries made.
–FM : Switch to FM radio mode. Switch to display of the station keys in FM radio modes
⇒Page 10.
–AM : Switch to AM radio mode. Switch to display of the station keys in AM radio modes
⇒Page 10
–MEDIA : Switch to media mode. In media mode, switch to another media source
⇒Page 14.
–MUTE : The current audio source is muted ⇒Page 8.
–SETUP : Open system and function settings ⇒Page 31.
3 Function keys: The function depends on the respective operating state. To execute the respective
function, press ⇒Page 7.
4 CD drive: For inserting and ejecting CDs ⇒Page 14.
5 Screen: You can adjust the brightness ⇒Page 31.
6 : Eject CD ⇒Page 14. 
Introduction 5

7 Adjustment knob: The function depends on the respective operating state.
–In all radio operating types for manual station or channel setting, rotate and press for starting
and stopping the intro check (SCAN).⇒Page 10.
–In media mode for opening the song list, rotate ⇒Page 14.
–To mark menu items in long lists, rotate and press to call the marked item, e. g., station selection
from station list.
–To change your own settings, rotate, e. g., volume adjustment (GALA).
8 USB connection: For connecting external data carriers ⇒Page 14.
9 AUXIN multimedia jack: For connecting external audio sources ⇒Page 14.
10 SD card slot: To insert SD cards ⇒Page 14. Insert SD card with the cut-off corner first and with the
label face up (contact area face down) carefully into the slot. 
6 Function description



SGB012901CA
Basic operating principles
Topic introduction
You can find information about the following
specific topics in this chapter:
Rotary and push buttons, device and
function keys ...................................................... 7
Switch on or off ................................................... 7
Change the basic volume ................................... 8
Additional displays and display options ................. 9
Screen displays can vary due to setting changes,
and the device can behave in part differently
from the description in these instructions.
Station, song change and volume settings can
also be made via the multifunction steering
wheel dependent on the vehicle ⇒Manual
Operating instructions.
Supplementary information and warnings:
●Safety notes ⇒Page 3
●Overview of control elements ⇒Page 5
Due to market-specific device software,
possibly not alllisted displays and functions
are available. The lack of a function is not a
device defect.
Due to national legal requirements, a few
functions can no longer be selected starting
from a specific speed.
Using a cellphone in the vehicle can cause
noise in loudspeakers.
In a few vehicles with ParkPilot, the volume
of the current audio source is reduced
automatically when the reverse gear is
engaged. 
Rotary and push buttons, device and function keys
First read and observe the safety
notes on page 3 and the introductory
information on page 7.
Rotary and push buttons
The left rotary and push button
⇒Fig. 1 1 is designated a volume control or
on and off switch.
The right rotary and push button
⇒Fig. 1 7 is designated as setting button.
Device buttons
The labeled buttons on the device are designated
as "device buttons" and displayed by a button
symbol with blue contents, e. g., device button
MEDIA ⇒Fig. 1 2 .
You operate device buttons by pressing or
holding down.
Function keys
There are six keys not labeled next to the screen.
⇒Fig. 1 3 . These keys are called "function
keys", because their function changes the
current operating state correspondingly.
Which function is assigned to a function key
is displayed on the screen directly next to
the respective key. 
On/off switching
First read and observe the safety
noteson page 3 and the introductory
information on page 7.
To switch the device on or off manually,
⇒Fig. 1 1 press the rotary or push
button for short time. 
Introduction 7

After start-up, the system starts with the most
recently set volume if this does not exceed the
default maximum volume when it is switched on.
⇒Page 31.
Dependent on the country and device, the device
is switched off automatically when the engine is
turned off or the vehicle key is removed from the
ignition lock. When the device is switched on
again, it is switched off again automatically after
approx. 30 minutes (timeout).
Energy management
If battery voltage decreases below the minimum
on-board voltage supply with ignition switched
off, an alarm sounds and LOW BATTERY is
displayed. The device should be switched off.
If the battery voltage decreases further, RADIO OFF
is displayed for a short time, and the device
switches off automatically.
Anti-theft encoding
Dependent on the country and device, the device
is protected against theft and unauthorized use
by a security code.
The security code of anti-theft encoding remains
saved in the vehicle after initial entry (comfort
radio encoding). If the anti-theft encoding must be
canceled manually, e.g., when the device is
installed in a different vehicle, please contact a
Volkswagen Partner.
If the vehicle battery is disconnected, switch on the
ignition before you switch the device on again.

Change the basic volume 
First read and observe the safety notes
on page 3 and the introductory
information on page 7.
Volume changes are displayed on the screen by a
"bar". The device is blocked against operation
during that time.
A few volume settings and adjustments can be set
as default values Page 31.
⇒
Increase, reduce or mute the volume
Volume control ⇒Fig. 1 Rotate clockwise.
Increase the volume
Decrease the volume
Mute
OR: Press the button on the multifunction steering wheel
⇒Manual Operating instructions.
Volume control ⇒Fig. 1 Rotate counterclockwise. OR: Press the
button on the multifunction steering wheel ⇒Manual Operating
instructions.
Volume control 
⇒Fig. 1 Rotate counterclockwise until  is displayed.
OR: Press the MUTE device button.
When the device is muted, the currently played media source is
paused.  is displayed on the screen.
If the basic volume was increased greatly for
an audio source, reduce the volume before
you switch to another audio source. 
8 Function description

SGB012901CA
Additional displays and display options
First read and observe the safety notes
on page 3 and the introductory information
on page 7.
All displays can only be shown after the
complete system start of the radio.
Vehicle-dependent, changes to climate settings or
displays of driver assistance systems built-in ex-
works are shown on the screen temporarily. The
displays are closed automatically when they are no
longer required for support.
With a few devices, the current time can also be
displayed in the status line of the screen. The
station or song display is then displayed above
or below it. 
Introduction 9


Audio and media mode
Radio mode
Topic introduction
You can find information about the following
topics in this chapter:
Radio main menu...............................................10
Station list 11 ..................................................... 11
Select, set and store station ...............................11
Intro check (SCAN)13 ........................................ 13
The radio system is supplied in various models
dependent on the country and equipment. All
possible device models are listed in the overview
of control elements ⇒Fig. 1.
The retrieval of radio mode and control are
dependent on the device in part.
Supplementary information
and warnings:
●Safety notes
●⇒Page 3
●Overview of control elements
●⇒Page 5
●Basic operating principles
●⇒Page 7
Parking garages, tunnels, high buildings
or mountains can interfere with reception
of a radio signal.
Foil or metal-coated stickers on windows can
hinder reception in vehicles with glass-mount
antennas. 
Radio main menu
Fig. 2 RADIO main menu.
First read and observe the safety
noteson page 3 and the introductory
information on page 10.
Press FM or AM device button to start radio mode
in the respective frequency range.
The currently set station is displayed in the
middle of the screen. ⇒Fig. 2.
The screen area on the side shows the station
frequency, with which the respective station
button next to it is assigned. Cf. ⇒Page 11,
Select, set and store station.
If RDS is available, the station name can be
displayed in addition to the station frequency 1 .
Switch the frequency range and memory level
The currently selected frequency range with memory
level is displayed below the station display 2 (FM 1).
The respective frequency range is called when
you press the device button FM or AM .
You switch the memory levels of the respective
frequency range when you repeatedly press the
device button FM or AM .
Frequency range: Memory levels
FM: FM 1, FM 2.
AM: AM 1, AM 2. 
10 Function description

Function Handling
Select station via arrow keys
/ 
Press the

or

device button for
short time.
Corresponding to the setting for the arrow keys, there is a switch
between saved stations and receivable stations. Setting for the arrow

SGB012901CA
Station list
Fig. 3 Radio mode: Station list (FM).

Close station list
●Press the LIST device button to close the
station list.
If not operated, the station list is closed
automatically after some time.
Displays and symbols in the station list
⇒Fig. 3 Display: Meaning
1 Display of the selected frequency range
(e. g., FM station list).
2 Currently broadcasted station.
First read and observe the safety
notes on page 3 and the introductory
information on page 10.
All stations are displayed, which can currently be
received in the selected frequency range.
Open station list.
●Press the LIST device button to open the
station list ⇒Fig. 3.
3 Update display: Update the station list.
4 FM2M4: Display of a saved station.
The displayed station is saved on
the memory level FM2 on function key 4.
5 Scroll bars are only displayed if more than
three stations are received. 
Select, set and save station
Fig. 4 Radio mode: Frequency range FM1. Fig. 5 Radio mode: Station list (FM).
First read and observe the safety
noteson page 3 and the
introductory information on page 10.
Select the desired frequency range ⇒Page 10.
Select station
A saved station can only be played if it can be
received at the current location.

Audio and media mode 11

Function Handling
Press the LIST device button to open the station list ⇒Fig. 5. Rotate the
adjustment knob to search through the list and press to select the desired
station.
Select a station from the station
list.
Select a saved station on the
station buttons.
Press the device button to close the station list. If not operated, the station list is closed
automatically after some time.
Press the function key next to the saved station frequency for short time.
Set station frequency manually
Function Handling
Change frequency incrementally. Rotate adjustment knob.
Go through the frequency
range quickly. Keep the device button or pressed down. After you release it, the
next receivable station is set automatically.
Store a station manually
Function Handling
Select a frequency range and memory level ⇒Page 10. Select a
station.
Keep the desired function key pressed down until a signal sounds.
Store a station manually on
station buttons.
Store a station from the
station list on a station button.
The currently heard station is saved on this function key. A station
saved on a function key is shown by a white frame ⇒Fig. 4 1 .
Storing a station on an already assigned function key deletes the
station saved previously on it.
Press the LIST device button for a short time to open the
station list.
Stations already saved on a station button are identified in the station
list (e. g., ⇒Fig. 5FM1M1). The displayed station is saved on the
memory level FM1 on function key 1.
Rotate the adjustment knob to search through the list and press to
select the desired station.
Press the device button to close the station list. Keep the desired
function key pressed down until a signal sounds. The currently heard
station is saved on this function key.
Store a station automatically (AUTOSAVE)
Using the Autosave function, the strongest received stations are automatically saved on the station
buttons on memory level FM 1/FM 2 or AM 1/AM 2.
Function Handling
Select desired frequency range ⇒Page 10.
Keep device button FM or AM pressed down for approx. five seconds and then release it.
Store a station automatically
on station buttons. Storing automatically is displayed on the screen during the
storing process. This process can take a few seconds.
If no receivable station is found, the message No Stations available appears in the
middle of the screen. 
12 Function description


SGB012901CA
Intro check (SCAN)
Fig. 6 Radio mode: Intro check (SCAN).
Firstread and observe the safety
notes on page 3 and the
introductory information on page 10.
If the Intro check is running, all receivable stations in
the current frequency range are played for approx.
five seconds.
Select the desired frequency range
⇒Page 10.
Function Handling
Start the Intro check. Press the adjustment knob briefly. Scana) is displayed on the screen
⇒Fig. 6 1 .
Press the adjustment knob again.
End the Intro check. The Intro check is also stopped if a station is selected manually
via the station buttons.
a)
The Scan display blinks device-independent while the Intro check is active. 
Audio and media mode 13


Media mode
Topic introduction
You can find information about the following
specific topics in this chapter:
Requirements of media sources and audio files ...14
Playback sequence of audio data carriers ...........16
MEDIA main menu ............................................16
Switch media source .........................................17
Manual song switch ...........................................17
Folder and song selection from list .....................18
Switch display mode...........................................18
Switch playback mode (MIX, REPEAT) 19
Insert or eject CD...............................................19
Insert or withdraw SD card ................................20
External audio source on multimedia jack
AUXIN ...............................................................20
Connect external audio source, data carrier or
iPod™ to USB....................................................21
Connect external audio source via Bluetooth®
..........................................................................21
The following audio sources are called "media
sources" in the following; they are found on
different data carriers, e. g., CD, or external MP3
player, which contain audio files. These audio
files can be played via the corresponding drives
or audio inputs of the radio system (internal CD
drive, USB port, Bluetooth®interface or
multimedia jack AUXIN).
Copyright
Audio and video files saved on data carriers are
normally subject to copyright protection pursuant
to the respectively applicable international and
national regulations. Comply with legal
regulations!
Supplementary information and warnings:
●Safety notes ⇒Page 3
●Overview of control elements ⇒Page 5
●Basic operating principles ⇒Page 7
This product is protected by specific
industrial property rights and copyright of
Microsoft Corporation. The use or distribution
of such technology external to this product
and without a license from Microsoft or an
authorized Microsoft branch is prohibited. 
Requirements of media sources and audio files
First read and observe the safety
notes on page 3 and the
introductory information on page 14.
Ex-works built-in CD players correspond to safety
class 1 according to DIN IEC 76 (CO) 6/ VDE 0837.
Only 12 cm standard CDs may be inserted into
the device.
The listed, playable file formats are hereafter
collectively called "audio files". A CD with such an
audio file is called an "audio data CD".
14 Function description

SGB012901CA
Media source Requirements for playing
Audio CD (up to 80 min). – CD digital audio specification.
CDROM, CDR, CDRW audio data
CD to max. 700 MB (megabyte)
according to ISO 9660, UDF or in Joliet
file system.
USB storage media in file system
FAT32.
SD memory cards in file system
FAT12, FAT16, FAT32 or VFAT to
max. 2 GB (gigabyte) and SDHC
memory cars to max. 32 GB (SD®
and SDHC®)a).
 Playback of audio files via
Bluetooth®b).
Playback of external audio sources via
AUXIN multimedia jack.
Playback of external audio sources via
USB connection.
–MP3 files (.mp3) with bit rates of 48 to 320 kbit/s or
variable bit rates.
–WMA files (.wma) to 9.2 mono/stereo to 192 kbit/s without
copy protection.
–Playlists in PLS and M3U formats.
–Playlists not bigger than 20 kB and with no more than 250
links.
–Max. 32 playlists on one data carrier.
–Max. 256 folders and max. 512 files on one data carrier.
–Folder trees with maximum eight levels.
–MP3 files (.mp3) with bit rates of 48 to 320 kbit/s or
variable bit rates.
–WMA files (.wma) to 9.2 mono/stereo to 192 kbit/s without
copy protection.
–Playlists in PLS and M3U formats.
–Playlists not bigger than 20 kB and with no more than 250
links.
–Max. 32 playlists on one data carrier.
–Max. 1024 folders and max. 65,535 files on one data
carrier.
–Folder trees with max. eight levels.
–Max. size of a single file in FAT32 file system 4 GB.
–The external audio source must support the A2DP or
AVRCP Bluetooth®profile V 1.3 and be coupled with the
radio ⇒Page 21.
–3.5 mm jack plug connectible for audio output ⇒Page 20.
–USB media source connectible for audio output ⇒Page 21.
a)
SD®, SDHC® and SDXC® are brands or registered trademarks of SD 3C, LLC in the USA and/or other countries.
b)
Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
Restrictions and notes
Soiling, high temperatures and mechanical
damages can make a data carrier unusable.
Pay attention to the notes of the data carrier
manufacturer.
Quality differences between data carriers from
different manufacturers can result in malfunctions
during playback.
Observe legal regulations concerning copyrights!
Ds are not played when they are recorded in
DirectCD format. Pay attention to the format
under Windows®.
The configuration of a data carrier or devices and
programs used for recording can result in the
impossibility to read individual songs or the data
carrier.
You can find information about how audio files
and data carriers are best created (compressions
rate, ID3 tag, etc.) in the Internet, for example.
Reading a data carrier with compressed audio
files (MP3, WMA, etc.) takes longer due to the
larger data volume than the reading of a "normal"
audio CD. Complex folder trees can delay reading
additionally.
Playlists only set one specific playback sequence.
No files are saved in playlists. Playlists are not
played if the files are not saved there on the data
carrier where the playlist references (relative path
information). 
Audio and media mode 15
