MACH®GAS-FIRED BOILER
C750 - C900 - C1050 OUTDOOR
BOILER GUIDE
This manual is to be used in conjunction with the
MACH®C750-C1050 Installation & Owner’s Manual.
Model #:_______ Serial #:_____________________
Installation Date: ___________________________________
Harsco Industrial, Patterson-Kelley
100 Burson Street, East Stroudsburg, PA 18301
Telephone: [phone]
Toll Free: 877.728.5351
Facsimile: 570.476.7247
www.harscopk.com
MACH
®
C750-C1050 Outdoor Boilers
Rev. 1.0 (11/17/2008)
C.S.A Design-Certified
Complies with ANSI Z21.13/CSA 4.9
Gas-Fired Low Pressure Steam and Hot Water Boilers
ASME Code, Section IV
Certified by Harsco Industrial, Patterson-Kelley
C.S.A Design-Certified
Complies with ANSI Z21.13/CSA 4.9
Gas-Fired Low Pressure Steam and Hot Water Boilers

MACH®C750-C1050 Outdoor Boilers
The information contained in this document is subject to change
without notice from Harsco Industrial, Patterson Kelley.
Harsco Industrial, Patterson-Kelley makes no warranty, of any
kind, with respect to this material, including, but not limited to
implied warranties of merchantability and fitness for a particular
application. Harsco Industrial, Patterson-
Kelley is not liable for errors appearing in
this guide or for incidental or consequential
damages occurring in connection with the
furnishing, performance or use of this
material.
TABLE OF CONTENTS
MACH®C750-C1050 Outdoor Boilers.................1
Table of Contents....................................................2
1BOILER MODIFICATIONS ...................... 3
1.1Completed Outdoor Boiler................................3
1.2Required Tools & Parts.....................................4
2FIELD INSTALLED COMPONENTS ....... 5
2.1Install Power Cord Seal....................................5
2.2Gas Inlet Assembly...........................................5
2.3PVC Air Inlet Pipe Assembly ............................6
2.4Exhaust Vent Installation..................................7
2.4.1Exhaust Vent System Installation...............7
2.4.2Stainless Steel Exhaust System ................7
2.4.3Stainless Steel Adapter..............................7
2.5CPVC Exhaust Vent System ............................7
2.5.1Stainless Steel Adapter for CPVC..............7
2.6Hood Assembly.................................................8
2.7Hood Support....................................................9
3MAINTENANCE..................................... 10
4ASSEMBLY DRAWING......................... 11
4.1Assembly Drawing..........................................11

MACH®C750-C1050 Outdoor Boilers
3
1 Boiler Modifications
1.1 COMPLETED OUTDOOR BOILER
FRONT VIEW REAR VIEW
This boiler has been modified by the factory and shipped as an outdoor boiler; additional assembly is
required to complete the outdoor boiler. These additional assemblies are listed in this manual and the
MACH®C750-C1050 Installation & Owner’s Manual.
Be sure to identify your boiler and its specific installation requirements. It is essential to read, understand,
and follow the recommendations of this manual before installing, operating, or servicing this equipment.
Failure to do so could result in serious injury, death, and/or property damage.

MACH®C750-C1050 Outdoor Boilers
4
1.2 REQUIRED TOOLS &PARTS
The following tools are required for the installation of the MACH®Outdoor Boiler loose parts on a new
MACH®Outdoor Boiler.
Pipe wrench (for 1” pipe elbow).
Tape measure.
Cordless drill / screw driver..
Phillipshead driver / screwdiver
¼” socket driver for #6 self tapping screws.
Approved gas pipe sealant.(See section 2.2)
Small tube of 100% silicone.
Approved exhaust vent sealer. (See Section 2.3 / 2.4)
Approved PVC cleaner & solvent.
Customer Supplied Parts
Exhaust Adapter
Exhaust pipe
Seal tight connector
Waterproof conduit
The boiler and these instructions is for outdoor use only. Do not install in any
enclosure. All exhaust venting and air intake must be outdoors. All installations of venting systems should be
done only by qualified venting systems personnel. Venting must be installed in accordance with vent system
manufacturer’s installation instructions and this manual. Installing a boiler or vent system using improper
installation methods or materials can result in serious injury or death due to fire or asphyxiation from carbon
monoxide or other poisonous gases. Breathing exhaust fumes may cause serious personal injury or death.
Reorder No. 6020-V2WHPK
Improper use may
result in fire or injury.
Read instructions/safety
manual before installing,
operating or servicing boiler.
c
!
WARNING
1998 HCS, Inc. 800-748-0241
See MACH®C750-C1050 Installation & Owner’s
Manual for specific safety requirements, warnings, installation requirements
and diagrams. These instructions are a supplemental document which should
be used in conjunction with the MACH®C750-C1050 Installation & Owner’s
Manual for your specific MACH®Boiler. The boiler and these instructions is for
outdoor use only. Incorrect installation may result in injury or death.
Shut off and disconnect electric and gas before installing the MACH®Outdoor Boiler.
See this MACH®C750-C1050 Outdoor Boiler Manual & MACH®C750-C1050 Installation & Owner’s Manual for
additional information. Incorrect installation may result in severe injury or death.

MACH®C750-C1050 Outdoor Boilers
5
2 Field Installed Components
2.1 INSTALL POWER CORD SEAL
(Customer Supplied)
For this OUTDOOR boiler use water proof conduit and sealtight connectors to the boiler. Before starting the
boiler, check to ensure that the proper electrical service is connected to the boiler.
2.2 GAS INLET ASSEMBLY
See Drawing # BP00000218
1. Remove gas shut-off valve.
2. Assemble one (1) 1” street 90º elbow (item #1) to
outlet of boiler and assemble gas shut-off valve to the
elbow. This allows clearance for the air inlet stack.
Use approved pipe sealer that resists the action of
Fuel Gases such as Natural Gas or LPG. DO NOT
USE Teflon™ tape.
See MACH®C750-C1050 Installation & Owner’s Manual for specific
electrical requirements and diagrams. Incorrect electrical connections may result in severe injury or
death.
Use water-
proof
conduit &
seal tight
connector
90º street elbow
See MACH®C750-C1050
Installation & Owner’s Manual for specific gas connection
requirements and diagrams. Incorrect gas connections may

MACH®C750-C1050 Outdoor Boilers
6
2.3 PVC AIR INLET PIPE ASSEMBLY
See Drawing # BP00000218
1. Assemble 6” PVC “SD type” air inlet piping assembly. Assemble 4” long straight pipe (ITEM
#7), to 90 degree elbow (ITEM #6) to 27” long straight pipe (ITEM #5), using approved PVC
cleaner and solvent.
2. Place the assembled inlet pipe over the inlet collar, position pipe to be straight and parallel to
the back of the boiler and secure using (3) #6 x ½” self tapping screws (ITEM#8) evenly
spaced around the pipe. Silicone (customer supplied) around the seam of the PVC pipe and
collar.
3. Install screen (ITEM #4) in top of inlet vent.
Silicone seal
seam between
collar and pipe.
Check that pipe is
square & parallel to
the back of the boiler.
Secure pipe to
collar with (3) #6
x ½” self tapping
screws, evenly
spaced.

MACH®C750-C1050 Outdoor Boilers
7
2.4 EXHAUST VENT INSTALLATION
This MACH®Outdoor Boiler is designed for outdoor use only.
See MACH®C750-C1050 Installation & Owner’s Manual for additional venting requirements.
2.4.1 Exhaust Vent System Installation
(Customer Supplied)
The exhaust vent should extend a minimum of 12 inches above the hood or at least two (2) feet above
the highest part of any independent structure within ten (10) feet of the vent.
Boiler clearance for combustibles / non-combustibles should be maintained per MACH®C750-C1050
Installation & Owner’s Manual.
2.4.2 Stainless Steel Exhaust System
Install manufactured exhaust vent systems in accordance with the manufacturer’s listing and instructions.
2.4.3 Stainless Steel Adapter
An adapter is required to be installed between the boiler and the stainless venting. Below is a
table containing the available adapter for each MACH®boiler size. Installer should use Adapters
listed below or equivalent.
MACH®Boiler Size Nominal Stack
Size Stainless Adapter for Stainless Vent Supplier / Part Number
C-750,C-900,C-1050 8" Heat-Fab / 9801MACH
Stainless Steel Adapter for Stainless Steel Vent
2.5 CPVC EXHAUST VENT SYSTEM
This MACH®Outdoor Boiler is designed for outdoor use only.
See MACH®C750-C1050 Installation & Owner’s Manual for additional venting requirements.
2.5.1 Stainless Steel Adapter for CPVC
An adapter is required to be installed between the boiler and the CPVC venting. Below is a table
containing the available adapter for each MACH®boiler size. Installer should use Adapters listed
below or equivalent.
The boiler vent should be installed per this manuals instruction. The
information contained herein should be used as a guide only and is not intended to be used in lieu of
qualified technical expertise. Failure to comply may result in injury or death.

MACH®C750-C1050 Outdoor Boilers
8
MACH®Boiler Size Nominal Stack Size Stainless Adapter for CPVC Vent Supplier / Part Number
C-750,C-900,C-1050 8" Heat-Fab / 9801PKCPVC
Stainless Steel Adapter for CPVC Vent
Use approved high temperature silicone between the adapter and exhaust connections.
See MACH®C750-C1050 Installation & Owner’s Manual for additional information.
2.6 HOOD ASSEMBLY
See Drawing # BP00000218
1. Place hood assembly (ITEM #3) on boiler with
the stack hole facing the back of the boiler.
2. The hood will rest on the 4 angle brackets (inside the hood).
3. The 4 rectangular spacers will be on the sides of the cabinet.
4. Assemble the exhaust vent and place it through the hood
then into the exhaust outlet on the boiler.
5. There are 4 holes located on the sides of the hood. Insert (4)
¼” quick release pins (ITEM #2), through the hood into the
cabinet until the pin is locked in place.
6. Secure & seal exhaust venting. See section 2.4
When constructing a venting system from CPVC, use only CPVC ASTM
F441 Schedule 40 pipe & ASTM F439 Schedule 80 fittings. Cement and primer must conform to
ASTM F493.
Failure to comply may result in failure of venting system. This may cause severe injury or death.
Position exhaust
pipe in center of
hood gasket.

MACH®C750-C1050 Outdoor Boilers
9
2.7 HOOD SUPPORT
1. When working on the back section of the boiler the hood can be raised and supported by the
hinged top section of the boiler. This is similar to the hood of a car and prop-rod support.
2. Remove the 2 rear quick release pins only.
3. Remove the screws holding the rear top hinged section of the boiler.
4. Raise the hood until the top section can be raised and placed behind the angle supports, slowly
lower the hood until it is supported by the top section.
For further instructions on installation see MACH®C750-C1050 Installation
& Owner’s Manual.
Be sure to correctly support the hood using the hinged boiler cover as a
prop engaging the angle supports inside the hood. Failure to do this could result in the hood falling and
may cause severe injury or death.
Remove the 2 rear quick release
pins only! Set hinged top section
behind “L” brackets on the hood
and slowly lower hood until it is
supported by the top section.

MACH®C750-C1050 Outdoor Boilers
10
3 Maintenance
The MACH®outdoor boiler requires maintenance as described in MACH®Installation & Owner’s Manual
(latest edition) as well as the additional maintenance listed below.
General Warning
These additional maintenance items should be performed monthly.
1. Check for flue gas recirculation into the air inlet. Flue gas recirculation indicates that the vent is
not installed properly for local conditions.
2. Check for freezing of the condensate lines. Frozen lines will result in boiler malfunction. Operation
of the boiler in cold temperatures may require the use of heat trace lines for the boiler condensate
trap and drain.
3. Check for inlet air box, vent and safety relief valve obstructions due to outdoor debris such as but
not limited to, leaves, insects, snow, branches and other blockages.

MACH®C750-C1050 Outdoor Boilers
11
4 Assembly Drawing
4.1 ASSEMBLY DRAWING
