Hartman 13102164 User manual

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE.
For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product.
ASSEMBLY INSTRUCTIONS
MEDITERRANEAN PARASOL
(13102164 – DOVE)
(13102154 – GREY)
ATTENTION:
1. Please read these instructions carefully before assembly
2. Please allow 15 minutes for assembly.
3. Although assembly only requires 1 person it is advised that a second person be present to help place into position when fully assembled.
Care for the canopy:
• Simply clean the umbrella canopy with a soft brush and mild detergent.
• Do not machine wash or machine dry.
• Do not iron.
Component’s
Component’s
Parts List
Parts Picture
Description
Q’
ty
Component
no.
Parts List
Parts Picture
Description
Q’
ty
Component
no.
A
Cross Base A
1
13102164A
13102154A
E
Washers
4
1061162
(φ16/φ
8.2*1.2
)
B
Cross Base B
1
13102164B
13102154B
F
Wrench
(M8)
1
2100046

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE.
For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product.
• Air-dry the canopy thoroughly in an open position before storing for extended periods of time.
IMPORTANT! Always close/put down the parasol when not in use. Do not use or assemble the parasol in wind, rain, thunderstorms or if it’s
snowing. In these weather conditions, we recommend to fold down or disassemble the parasol. Disassemble by following the setup steps in this
manual.
IMPORTANT! The parasol must be secured in place using a parasol base. Make sure the ground is level and firm.
IMPORTANT! If the crank gets too hard to turn, check if the rope has come off the pulley. If you continue to turn the crank, the rope or crank
handle could break.
IMPORTANT! Placing the parasol over or near a swimming pool can cause premature fading of the canopy.
WARNING: Do not assemble the parasol on sandy, muddy or loose soil.
Keep children and pets away while setting up the parasol.
Children must be supervised around the parasol.
This parasol is for outdoor use only.
Do not light any fires under or near the parasol!
This parasol is primarily intended to be used as a sunshade and not as wind protection.
D
Bolts
(φ8*20)
4
2100045
H
Cover
1
13102164E
13102154E
For more information regarding maintenance of your furniture please visit
http://www.hartmanuk.co.uk/after_care_videos.html
Step 1
Place Cross Base (A) on a soft surface, line up not and
place Cross Base (B) over Cross Base (A).
ches
Step 2
Attach Support Pole(C) to Cross Base by using
Bolts(D) and Washers(E), hand tighten only.
Adjust the Support Pole (C) to be sure it is
positioned correctly on the Cross Base and
finally tighten all Bolts with Wrench(F).
Be careful not to over tighten.
Step 3
Insert the Parasol (G) into Support Pole (C).
Step 4
Unlock the clip to raise the canopy
arm
C
Support Pole
1
13102164C
13102154C
G
Parasol
1
13102164D
13102154D

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE.
For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product.
Step 5
Step 6
Turn the crank handle in clockwise direction to
open the parasol canopy.
Ensure the clip is locked into place to secure the
canopy arm in place
Step 7
Turn the crank handle counter clockwise to close the
parasol.
Step 8
DO NOT JUST FOLD DOWN SUDDENLY, OR THE
PLASTIC PART (L) WILL BE EASILY BROKEN.

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE.
For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product.
Step 9
Step 10
Step 10
Use Cover (H) when your parasol is not in use.
