Hartman 65112149 User manual

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Bali Gas Fire Pit Table
(65112149 )
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is a soft metal and over tightening may strip the thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the table over and into position when
fully assembled
ASSEMBLY STEPS:
1. Turn table top over and put onto a soft clean surface
2. LOOSELY attach Side panel 1 (B) and Side panel 2 (C) to table top (A) with bolts (K) and big flat washers (N) using Spanner (O) DO
NOT TIGHTEN THE BOLTS AT THIS STAGE
3. LOOSELY attach rear panel (D) to Side panel 1 & 2 with bolts (M) and big flat washers (N) using Spanner (O)
4. LOOSELY attach bottom frame (E) to connecting bar (F) with bolts (K) and big flat washers (N) using Spanner (O)
5. LOOSELY attached assembled bottom frame to Side panel with bolts (L) and big flat washers (N) using Spanner (O)
6. Tighten all bolts one by one using spanner, being careful not to over tighten any as this will cause the thread to become damaged
7. Turn table top over and place in desired position
8. Open the door, connect the gas pipe then put the gas tank on the fixed bottom frame and close the door
9. Pour the bag of glass beads (H) into fire pit
10. Put the centre glass (G) on top of the fire pit
11. Fire guard: fix 4pc glass (I) onto the glass clips (J). Note: When installing the glass clips, the direction of the clip on the same piece of
glass must be in reverse.
12. Put the assembled fire guard on the correct position on table top, the table is assembled completely.
Component’s
Fixings
Parts List
Parts Picture
Description
Q’ty
Part no
Parts list
Parts Picture
Description
Q’t
y
Part no.
A
Table Top
1
65112149A
H
Glass
beads
1
651124149H
B
Side panel
1 with door
1
65112149B
I
Fire Guard
Glass
4
651124149I
C
Side panel
2
1
65112149C
J
Glass clip
8
2100042
D
Rear panel
1
65112149D
K
M6*25mm
bolts
8
1231162
E
Bottom
frame
1
65112149E
L
M6*35mm
bolts
4
2100040
F
Connecting
bar
2
65112149F
M
M6*55mm
bolts
4
2002166
G
Centre
glass
1
65112149G
N
Flat
washers
16
1061162
O
Spanner
1
2100041

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
For more information regarding maintenance of your furniture please visit
https://www.hartmanuk.com/home
ASSEMBLY INSTRUCTIONS
Bali 115cm Square Gas Firepit with Ceramic Top
(65112149 )
1
2
3
4

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
5
6
7
8
9
