OWNER’S MANUAL
Model 890A
Scale Interface Kit & GPS Attachment Kit for
AGCO
balers

2
HARVEST TEC 890A TABLE OF CONTENTS
PAGE
INTRODUCTION
3
OVERVIEW
3
INSTALLATION OF
PIP INTERFACE CONTROL
BOX
4
-
5
Installation of PIP Interface Control Box & Harness 4
Wiring Diagra 5
Setup Instructions 5
INSTALLATION OF GPS RECEIVER HA
RNESS
6
-
7
GPS Receiver Installation 6
GPS Harness Installation 6
Wiring Diagra 7
SETUP INSTRUCTIONS
8
OPERATING
INSTRUCTIONS
9
CONVERTING YIELD DATA FILE
10
-
11
PC Installation of Yield Data File Converter Progra 10
Converting Yield Data File 11
COMMON QUESTIONS ABOUT THE 890A
12
TROUBLE SHOOTING
12
WIRING DIAGRAMS
13
-
14
PARTS BREAKDOWN FOR MODEL 890A
15
NOTES 16
WARRANTY STATEMENT
BACK PAGE
***NOTE: Need to Purchase Garmin 16X HVS***
AGCO Part no. 1425350

3
INTRODUCTION
Congratulations on purchasing a Harvest Tec Model 890A Scale Interface & GPS Attach ent
Kit. This kit provides you with the ability to record yield apping files onto a USB flash drive
along with writing the exact bale weight into your job records. The kit will also write the rolling
average fro the last three bales weighed by the AGCO scale kit on the baler to the tag if
your baler is equipped with a Harvest Tec Model 850 Tagger (U.S. Patent 7,621,111B2 & U.S.
Patent 7,415,924B2). The 890A will only work with AGCO balers with the AGCO scale kit
installed. The yield apping portion of the kit will only work if you plug a Gar in 16X HVS into
the Interface box. For this kit to function at all your baler ust have the Harvest Tec Model
500 Moisture Monitor or Harvest Tec odel 565 Preservative Application Syste installed on
it.
OVERVIEW
There are two parts to the Harvest Tec Model 890A Precision Infor ation Processor (PIP)
Interface Control & GPS Attach ent Kit. The PIP Interface portion is designed to onitor the
bale scale CAN co unication and intercept the signal when it is trans itted. As this weight
is captured it is i ediately stored into the job records for that specific bale. If your baler is
equipped with a Tagger, as the signal is intercepted the 890A will use the data collected fro
the last three bales and write rolling averages to the tags. The data will then be readable
using a Harvest Tec Model 860 Scanner. The GPS attach ent portion is designed to interface
the Gar in 16X HVS into the 565/500 syste and have it collect GPS points to be processed.
With this processed data the PIP will create and store a yield files, save in a CSV for at, onto
the USB flash drive.

4
INSTALLATION OF PIP INTERFACE CONTROL BOX
Installation of PIP Interface Control Harness
The PIP Interface Controller (PIC) (006-5676) will ount next to the AGCO Bale Weighing
Controller. The AGCO Bale Weighing Controller will be located inside the right fender. Mark and
drill four 5/16 holes next to the bale scale and attach with four 1/4 x 1 “bolts and flange nuts.
Disconnect the harness plug shown above (figure 1). Connect the AGCO interface cable (006-
0890A) in the open port. Connect the AGCO scale harness plug into the other connection on the
AGCO interface cable. Connect the last connection into the PIC.
Locate a green ter inating resistor (006-5650Z) on the Harvest Tec Precision Infor ation Processor
(006-5671LS), Pu p Controller (006-5672), or Tagger Control (006-5673). The ter inating resistor
will be at different locations depending on the options installed. Re ove the resistor. Connect one
end of the co unication harness, found in the 890A kit (006-5650F) to the PIP Interface Control
box and the other connect to the open port were the ter inating resistor was re oved fro .
Figure 1

5
Wiring Diagram
Setup Instructions
1. Turn the 500/565 control syste on. After a few seconds the Main Menu screen should
appear. Press Setup Mode, the Setup Mode screen will then appear.
2. Press Baling Rate. The Bale Rate Settings screen will then appear.
3. Press the underline 0 next to bale scale. The keypad will then appear. Press 1 followed by
enter.
4. The scale is now active in the syste .
5. The AVG Bale Weight will now adjust for every bale being ade. If no signal co es fro the
scale it will default to your inputted value.
AGCO
Bale
Weighing
Controller
AGCO interface
cable
006
-
0890A
PIP Interface
Control Box
006
-
5676
Co unication
harness
006
-
5650F
3
5
Connection
at baler
Fig. 1

6
INSTALLATION OF GPS RECEIVER HARNESS
GPS Receiver Installation
Locate your Gar in 16X HVS. This should have been purchased through your AGCO dealer.
The GPS receiver will be hard ounted on top of your baler in the area of the isstie flag
indicators. If the isstie flag indicators are not present find a flat surface near the knotter
cover/door. This location should give the GPS receiver the best chance at receiving the strongest
satellite signal.
GPS Harness Installation
Once the Gar in GPS receiver has been installed, route the harness to the right side of the
baler. The harness needs to be plugged into the PIP Interface Control (PIC) box that was
included in the 890A kit, so using the zip ties provided, fasten the harness securely to the baler
routing it safely towards the PIC box ounting location. (***Note: ake sure wiring harnesses are
not in any pinch points and will not co e in contact with oving parts on the baler.) Once the
harness as been routed and secure, locate the GPS adapter harness (006-5650GPS2) included
in the 890A kit. This is the adapter harness that the GPS harness plugs into so that it can be
interfaced into PIC. Plug the GPS adapter harness into the port labeled “Port 4” on the PIC.
*****Wiring directions for balers without AGCO bale weighing scale installed:
Locate a green ter inating resistor (006-5650Z) on the Harvest Tec Precision Infor ation
Processor (006-5671LS), Pu p Controller (006-5672), or Tagger Control (006-5673). The
ter inating resistor will be at different locations depending on the syste installed on the baler.
Re ove the resistor. Connect one end of the co unication harness (found in the 890A kit 006-
5650F) to the PIC, and the other connect to the open port were the ter inating resistor was
re oved fro .

7
Wiring Diagram
Gar in GPS 16X HVS
GPS adapter harness
006-5650GPS2
3 4 2
1
PIP Interface Control Box
006-5676
006-5650F
Connection
at baler
Fig. 1 (look
at pg 4 &5
AGCO
Bale
Weighing
Controller

8
SETUP INSTRUCTIONS
1. Turn the 565 control syste on. After a few seconds the Main Menu screen should appear.
Press Setup Mode, the Setup Mode screen will then appear.
2. Press Yield Mapping setup.
a. Yield Mapping Setup should now be displayed.
3. Press the underlined value next to Swath Width (Ft). Enter in the swath width that will be
baled, press Enter to confir .
4. Press the underlined value next to GPS. Enabling/Disabling will require entering the
appropriate value. 0 to Disable, 1 to Enable. Press Enter to confir .
5. Make sure the USB flash drive is inserted into the PIP’s Data Transfer port before
baling. Without the USB flash drive a yield file will not be created. (USB flash drive
provided in the 880 kit)
.
2
4
3
USB flash
drive

9
OPERATION INSTRUCTIONS
1. Once installation and setup is co plete the syste is ready for baling. There is a GPS
indicator icon that will appear in either of the Auto atic or Manual ode screens. The GPS
icon shows the user that the GPS is trans itting data to the PIP to be processed. The GPS
icon, if getting a good satellite signal, will continually increase/decrease in size. While all this
is going on a Yield file is being created and saved to the USB flash drive. Additionally as you
enter the Auto atic/Manual ode work screens an alert essage will appear above the
Override key. This the alert essage will display “Opening USB flash” and if the PIP locates
the USB flash drive successfully the alert essage will disappear and the yield data will be
written too the flash drive. If a different alert essage is being displayed see pg. 12 for
troubleshooting.
2. Once baling is co plete, create a New Job and the yield data file that was written to the USB
flash drive will be co plete and ready to be converted. See CONVERTING YIELD DATA
FILE for the next step.
****NOTE: If you’re a first ti e user, begin with the INSTALLATION OF YIELD DATA FILE
CONVERTER PROGRAM before atte pting to convert the yield data file.
GPS
ICON

10
CONVERTING YIELD DATA FILE
PC Installation of Yield Data File Converter Program
1. Plug the USB flash provided in the 880 kit into the USB port on the co puter.
2. The USB flash will have a zipped file on it and will be labeled ydConverterSetup-V1_0_0_0.
a. Double click on that folder to open it and there will be two files inside labeled setup &
ydConverterSetup. Double click on ydConverterSetup.
b. A setup screen will appear, click Next.
c. The next screen will ask you what folder you would like to save the File Converter
Progra in. Use the default option and click Next to accept. Next a confir ation screen
will appear, press Next to confir . The co puter will then let the Yield File Converter
Progra install itself (Co puter will take up to a 1 in to save the yield file converter
progra to its desktop).
d. Once the progra has been installed you will see and Icon on the co puters desktop
as pictured above.

11
Converting Yield Data File
1. The yield data file that was created on the USB flash while baling will need to be converted
before it can be utilized in a yield apping progra . Start by double clicking on the yield
apping file converter Icon located on the co puters desktop.
2. The progra should open. Click on Select Files and navigate to the USB flash where the data
files are located. Selected the file labeled as the users created job na e .YDT
3. Once the .YDT file has been selected, click open to start the conversion. This process will
take up to a few seconds. The converted file will read; the users created job na e –ym. It will
be located on the USB flash that the yield data file was created on.
NOTE: Once converted, the file is in the appropriate for at and it can be used by any yield
apping software/progra .

12
COMMON QUESTIONS ABOUT THE 890A
1. Will the 890A input the bale weights on my Job Records?
Yes. It will input the bale weight in the Job Records.
2. Why do my Job Records only show the default weight?
The default weight will always be the first weight displayed in the Job Records. After the first
bale they should change with the baling conditions. The bale scale option needs to be turned
on in the PIP. See Setup Instructions. If this is on check all connections and verify the
scale is working.
3. What happens if the scale misses a bale weight?
If no signal is seen fro the scale the syste will record 0’s into your bale records.
4. What weight is written to the tags?
The weight on the tags is a rolling average of the prior three bales.
TROUBLE SHOOTING:
890A Bale Scale
PROBLEM
POSSIBLE
CAUSE
SOLUTION
Bale weight not correct on Job
Records
1. Scale not turned on in
Harvest Tec onitor
2. Bad connections
1. Turn scale on in the Bale Rate
Settings enu
2. Check all connections and verify
scale is functional
Bale weight not correct on tags 1. The first three tagged
bales will have the default
weight. All re aining bales
will have a rolling average of
the prior three bales
1. Check other bales. If proble
persists check scale and tagging
syste .
890A GPS Yield Mapping
PROBLEM
P
OSSIBLE CAUSE
SOLUTION
Alert Message ‘USB Flash not
found’ appears in Auto or
Manual odes.
1. USB flash drive not in
USB port on PIP.
1. Check to see if USB flash has
fallen out or if one needs to be
installed.
‘Opening USB Flash File’ is not
appearing when entering
Manual or Auto atic ode.
1. GPS disabled. 1. Check Yield Mapping Setup to
ake sure that the GPS is enabled.
Yield Map not showing up on
USB flash drive
1. GPS is disabled.
2. GPS did not connect to
GPS satellites prior to
baling.
3. Harness is da aged or the
connection is
dirty/da aged.
1. Check Yield Mapping Setup to
ake sure that the GPS is enabled.
2. Verify that the GPS icon is beign
displayed in Auto atic/Manual
odes
3. Inspect GPS wiring harness and
connections.

13
WIRING – PIN OUT DIAGRAMS
Com
munication harness
-
006
-
5672
Pin 1 Red Can 12 volt
Pin 2 Red Battery 12 volt
Pin 3 Green Co channel OH
Pin 4 Silver Shield
Pin 5 Yellow Co channel OL
Pin 6 Not used
Pin 7 Not used
Pin 8 Black Can ground
Pin 9 Black Battery ground
Pin 10 Not used
AGCO interface cable
-
006-0890A
A Not used
B Yellow or Orange Can channel OH/IH
C Black Ground
D Not used
E Not used
F Red 12 volt positive
G Green or Blue Can channel OL/IL
PIC
-
006
-
5676
Pin 1 Yellow Can channel IH
Pin 2 Green Can channel IL
Pin 3 Not used
Pin 4 Not used
Pin 5 Not used
Pin 6 Orange Can channel OH
Pin 7 Blue Can channel OL

14
WIRING – PIN OUT DIAGRAMS CONT.
AGCO GPS Adapter Harness
–
006
-
5650GPS2
Pin 1 Red Power 12V
Pin 2 Black Ground
Pin 3 Blue RS232 Signal Receive
Pin 4 Yellow RS232 Ground
Pin 5 Not used
Pin 6 Not used
Pin 7 White RS232 Signal Trans it

15
PARTS BREAKDOWN FOR MODEL 890A
Ref
Description
Part#
Qty
1 PIP Interface Control 006-5676 1
2 AGCO interface cable 006-0890A 1
3 Co unication harness 006-5650F 1
4 AGCO GPS Adapter
Harness
006-5650GPS2 1
5 PIP Re ovable Storage
Cover
006-5650RSC 1
6 Re ovable Storage 006-5650USB 1
1
3
2
5
6
4

16
NOTES:

17
WARRANTY AND LIABILITY AGREEMENT
Harvest Tec, Inc. will repair or replace co ponents that are found to be defective within 12 onths
fro the date of anufacture. Under no circu stances does this warranty cover any co ponents
which in the opinion of Harvest Tec, Inc. have been subjected to negligent use, isuse, alteration,
accident, or if repairs have been ade with parts other than those anufactured and obtainable fro
Harvest Tec, Inc.
Our obligation under this warranty is li ited to repairing or replacing free of charge to the original
purchaser any part that in our judg ent shows evidence of defective or i proper work anship,
provided the part is returned to Harvest Tec, Inc. within 30 days of the failure. Parts ust be
returned through the selling dealer and distributor, transportation charges prepaid.
This warranty shall not be interpreted to render Harvest Tec, Inc. liable for injury or da ages of any
kind, direct, consequential, or contingent, to persons or property. Further ore, this warranty does
not extend to loss of crop, losses caused by delays or any expense prospective profits or for any
other reason. Harvest Tec, Inc. shall not be liable for any recovery greater in a ount than the cost
or repair of defects in work anship.
There are no warranties, either expressed or i plied, of erchantability or fitness for particular
purpose intended or fitness for any other reason.
This warranty cannot guarantee that existing conditions beyond the control of Harvest Tec, Inc. will
not affect our ability to obtain aterials or anufacture necessary replace ent parts.
Harvest Tec, Inc. reserves the right to ake design changes, i prove design, or change
specifications, at any ti e without any contingent obligation to purchasers of achines and parts
previously sold.
Revised 01/03/06

18
HARVEST TEC, INC.
P.O. BOX 63
2821 HARVEY STREET
HUDSON, WI 54016
PHONE: [phone]
1-800-635-7468
FAX: [phone]
E ail: [e-mail]
