For operation, location and safety information,
please refer to the Installation & Operating Manual.
PMG Spec sheet only (Je D) May 2015
Form No. FTBR, FTBX Spec Sheet Page 1 of 3 May 2019
The Hatco Remote Drop-In Frost Top keeps pre-chilled
beverages, snacks, hors d’oeuvres and side dishes cool
and ready to serve, but in remote congurations that offer
exibility for your particular kitchen design needs. Also
available in a Slim Line Series, providing wider access to
your customer, regardless of the sneeze guards.
Standard features
• R-513A refrigerant available for California only. Please
contact Hatco for more information
• Available in 1-, 2 and 3-pan models as well, as 2- and 3-pan
slim congurations
• Accommodates full-size and half-size sheet pans
• NSF 7 approved cold wall construction utilizes a refrigerant that
keeps food product cold without drying it out
• Auto-defrost is activated through an advanced electronic
controller programmed at the customer location
• 1" NPT brass drain simplies cleaning (excluding FTBR-1
a nd F TBX-1)
• Matches the Hatco line of Heated Wells for an integrated look
• FTBR models only:
– Include a condensing unit (shipped loose, can be eld
mounted up to 50 feet [15.24 meters] of tubing from unit) and
a control panel (shipped loose - probe wires are 9 feet
[2.7 meters]) for installing in more convenient or
desirable locations
• FTBX models only:
– Include a control panel (shipped loose - probe wires are
9 feet [2.7 meters mm]) but shipped without a condensing
unit for the increased exibility of multiple
Frost Top congurations
(FTBR only)
Options (available at time of purchase only)
c
Additional Four-Year Parts Only Warranty on Compressor (FTBR only)
(not available for export voltages)
Accessories
c
Half-Size Pan (18"W x 13"D [457 x 330 mm])
c
Full-Size Pan (18"W x 26"D [457 x 660 mm])
Remote Drop-In Frost Tops
Models: FTBR-1, -2, -3, -S2, -S3
FTBX-1, -2, -3, -S2, -S3
Control Panel
Model FTBR-S2 with
accessory sheet pans
Condensing unit
(FTBR only)
Remote models consist of these
components shipped loose

HATCO CORPORATION
l
P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
[phone]
l
(414) 671- 6350
l
www.hatcocorp.com
l
[e-mail]
FRONT VIEW
SIDE VIEW
FRONT VIEW SIDE VIEW
No drain on
FTBR-1 or FTBX-1
.5"
(13 mm)
3.06"
(77 mm)
FTBR-1 FTBX-1: 21.06” (535 mm)
FTB-2,-3 FTBX-2,-3: 28.94" (735 mm)
FTBR-1, FTBX-1: 28.94" (735 mm)
FTBR-2, FTBX-2: 39" (991 mm)
FTBR-3, FTBX-3: 57" (1448 mm)
5.05"
(128 mm)
(FTBX only)
FTBR-S2, FTBX-S2: 54.94" (1395 mm)
FTBR-S3, FTBX-S3: 80.81" (2053 mm)
FTBR-S2,-S3, FTBX-S2,-S3:
21.06" (535 mm)
5.05"
(128 mm)
(FTBX only)
Solenoid Valve
(FTBX only)
Solenoid Valve
(FTBX only)
.84"
(21 mm)
.84"
(21 mm)
.84"
(21 mm)
.84"
(21 mm)
.5"
(13 mm)
3.06"
(77 mm)
FRONT VIEW
SIDE VIEW
FRONT VIEW SIDE VIEW
No drain on
FTBR-1 or FTBX-1
.5"
(13 mm)
3.06"
(77 mm)
FTBR-1 FTBX-1: 21.06” (535 mm)
FTB-2,-3 FTBX-2,-3: 28.94" (735 mm)
FTBR-1, FTBX-1: 28.94" (735 mm)
FTBR-2, FTBX-2: 39" (991 mm)
FTBR-3, FTBX-3: 57" (1448 mm)
5.05"
(128 mm)
(FTBX only)
FTBR-S2, FTBX-S2: 54.94" (1395 mm)
FTBR-S3, FTBX-S3: 80.81" (2053 mm)
FTBR-S2,-S3, FTBX-S2,-S3:
21.06" (535 mm)
5.05"
(128 mm)
(FTBX only)
Solenoid Valve
(FTBX only)
Solenoid Valve
(FTBX only)
.84"
(21 mm)
.84"
(21 mm)
.84"
(21 mm)
.84"
(21 mm)
.5"
(13 mm)
3.06"
(77 mm)
Minimum: 13.64" (347 mm)
Maximum:17.38" (442 mm)
Minimum: 10.75" (273 mm)
Maximum: 12.09" (307 mm)
Minimum:
11.36" (289 mm)
Maximum:
11.81" (300 mm)
4.87"
(124 mm)
Field
Connection
Location
9.125"
(232 mm)
6.75"
(171 mm)
6.5"
(165 mm)
8.188"
(208 mm)
4.523"
(115 mm)
13.64" (347 mm) 10.75" (273 mm)
11.36" (289 mm)
4.87"
(124 mm)
Field
Connection
Location
9.125"
(232 mm)
6.75"
(171 mm)
Please specify the following with
each order:
1. Desired Voltage:
120 or 220-240V
2. Number of Full-Size
Sheet Pans Accommodated:
1-, 2-, 3-pan as rectangular,
sheet pan with Slim or
Standard conguration
3. Remote Refrigeration:
Note: Shipped loose: Frost Top, Control
Panel (Probe wires are 9 feet [2.7 meters])
and a TXV valve
A. FTBR with a condensing unit - may be
eld mounted up to 50' (15.24 meters) of
tubing from the unit - that is
shipped loose
B. FTBX without a condensing unit
(Solenoid Valve attached to Frost Top)
Ordering Instructions:
Remote Drop-In Frost Tops
Models: FTBR-1, -2, -3, -S2, -S3, FTBX-1, -2, -3, -S2, -S3
Form No. FTBR, FTBX Spec Sheet Page 2 of 3 May 2019
Model FTBR only
Condensing Unit
May be field mounted up to
50' (15.24 meters) from unit
All Models
Control Panel
May be field mounted
up to 9' (2.7 meters)
from unit
Model FTBR-S2, -S3
FTBX-S2, -S3
Model FTBR-1, -2, -3
FTBX-1, -2, -3
Well Opening
(B)
(A)
Model Minimum Width (A) Maximum Width (A) Minimum Depth (B) Maximum Depth (B)
FTBR-1, FTBX-1 27.44" (697 mm) 28" (711 mm) 19.44"(494 mm) 20.125" (511 mm)
FTBR-2, FTBX-2 37.375" (949 mm) 38"(965 mm) 27.31"(694 mm) 28"(711 mm)
FTBR-3, FTBX-3 55.375" (1407 mm) 56"(1422 mm) 27.31"(694 mm) 28"(711 mm)
FTBR-S2, FTBX-S2 53.31" (1354 mm) 54"(1372 mm) 19.44"(494 mm) 20.125" (511 mm)
FTBR-S3, FTBX-S3 79.19" (2011 mm) 79.875"(2029 mm) 19.44"(494 mm) 20.125" (511 mm)
Cutout Dimensions for Remote Frost Tops

HATCO CORPORATION
l
P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
[phone]
l
(414) 671- 6350
l
www.hatcocorp.com
l
[e-mail]
PRODUCT SPECS
Remote Drop-In Frost Tops
The Drop-In Frost Top shall be a Model ... as manufactured
by the Hatco Corporation, Milwaukee, WI 53234 U.S.A.
The Frost Top shall be rated at ... watts, ... volts and be ... inches (millimeters) in
overall width. It shall utilize R-404A or R-513A refrigerant and consist of aluminized
steel housing, electronic temperature control, and with or without a
condensing unit (compressor, sight glass, service valves, receiver, and dryer).
Accessories may include sheet pans.
Warranty consists of 24/7 parts and service assistance (U.S. and Canada only).
Remote Drop-In Frost Tops
Models: FTBR-1, -2, -3, -S2, -S3, FTBX-1, -2, -3, -S2, -S3
Form No. FTBR, FTBX Spec Sheet Page 3 of 3 May 2019
Model†
Dimensions ∆
(Width x Depth x Height) Voltage
Load/
BTU/H Ship Weight
FTBX-1 28.94" x 21.06" x 3.56" (735 x 535 x 90 mm) 120 330 85 lbs. (39 kg)
220/230/240
FTBX-2 39" x 28.94" x 3.56" (991 x 735 x 90 mm) 120 630 138 lbs. (63 kg)
220/230/240
FTBX-3 57" x 28.94" x 3.56" (1448 x 735 x 90 mm) 120 930 220 lbs. (100 kg)
220/230/240
FTBX-S2 54.94" x 21.06" x 3.56" (1395 x 535 x 90 mm) 120 630 130 lbs. (59 kg)
220/230/240
FTBX-S3 80.81" x 21.06" x 3.56" (2053 x 535 x 90 mm) 120 930 182 lbs. (83 kg)
220/230/240
∆For FTBX models only, add 5.05" (128 mm) to the height for the attached solenoid valve.
Model†
Dimensions
(Width x Depth x Height) Voltage HZ
HP Compressor
Size Watts Amps Phase Ship Weight
FTBR-1 28.94" x 21.06" x 3.56" (735 x 535 x 90 mm)
120 60 1/4 804 6.7
Single
125 lbs. (57 kg)
220/230/240 50 1/3 616/667/744 2.8/2.9/3.1
60 686/749/816 3.1/3.3/3.4
220 60 686 3.1
FTBR-2 39" x 28.94" x 3.56" (991 x 735 x 90 mm)
120 60 1/4 804 6.7
171 lbs. (78 kg)
220/230/240 50
1/3
616/667/744 2.8/2.9/3.1
60 686/749/816 3.1/3.3/3.4
220 60 686 3.1
FTBR-3 57" x 28.94" x 3.56" (1448 x 735 x 90 mm)
120 60 1/4 804 6.7
213 lbs. (97 kg)
220/230/240 50
1/3
616/667/744 2.8/2.9/3.1
60 686/749/816 3.1/3.3/3.4
220 60 686 3.1
FTBR-S2 54.94" x 21.06" x 3.56" (1395 x 535 x 90 mm)
120 60 1/4 804 6.7
179 lbs. (81 kg)
220/230/240 50
1/3
616/667/744 2.8/2.9/3.1
60 686/749/816 3.1/3.3/3.4
220 60 686 3.1
FTBR-S3 80.81" x 21.06" x 3.56" (2053 x 535 x 90 mm)
120 60 1/4 804 6.7
230 lbs. (104 kg)
220/230/240 50 1/3 616/667/744 2.8/2.9/3.1
60 686/749/816 3.1/3.3/3.4
220 60 686 3.1
†Models shipped with electronic temperature control and TXV valve (all shipped loose). Exception: FTBR units include a condensing unit and the FTBX units include
a solenoid valve attached to well.
T
Contact Hatco for R-513A refrigerant specications.
SPECIFICATIONS
Remote Drop-In Frost Tops – with Condensing Unit
T
and Remote Control Panel
The shaded areas contain electrical
information for International models
SPECIFICATIONS
Remote Drop-In Frost Tops – with Remote Control Panell (without a Condensing Unit)
