Havis C-CSR-2 Configuration guide
C-CSR-2 INSTALL
INSTRUCTIONS
CONSOLES
ATTACH CARD READER TO BRACKET USING
1.
SUPPLIED HARDWARE IF APPLICABLE.
EXTEND 3090 ASSEMBLY MOVING THE TWO
2.
HOLD DOWN TABS IF NECESSARY.
INSERT TWO CARRIAGE BOLTS THROUGH
3.
3090 ASSEMBLY & CARD READER BRACKET
IF NECESSARY.
FASTEN USING 1/4-20 SERRATED NUTS.
4.
C-3090
ATTACH CARD READER TO
1.
BRACKET USING SUPPLIED
HARDWARE IF APPLICABLE
ATTACH CARD READER TO
2.
ASSEMBLY USING 2X, 1/4-20
X 1/2" PPHMS, 1/4-" FLAT
WASHERS
EXTEND UT-101 ASSEMBLY MOVING THE
1.
TWO HOLD DOWN TABS IF NECESSARY.
LOOSEN SIDE TAB AND REMOVE SCREW.
2.
INSERT CARD READER BRACKET BETWEEN
3.
THE HOLD DOWN TAB AND SIDE SLOT,
REATTACH THE SCREW .
ATTACH CHOSEN CARD READER TO
4.
BRACKET USING SUPPLIED HARDWARE IF
APPLICABLE.
ATTACH CARD READER TO
1.
BRACKET USING SUPPLIED
HARDWARE IF APPLICABLE
ATTACH SECONDARY BRACKET TO
2.
TRAK OR OTHER FLAT SURFACE.
USING 2X, 1/4-20 X 1/2" HHCS & 1/4-
20 SERRATED NUTS. NOTE IF A
HAVIS TRAK IS NOT BEING USED,
OTHER HARDWARE MAY BE
REQUIRED (SUPPLIED BY
INSTALLER) .
ATTACH CARD READER TO
3.
ASSEMBLY USING 2X, 1/4-20 X 1/2"
HHCS, 1/4" FLAT WASHERS & 1/4-20
SERRATED NUTS
C-CSR-2 INSTALL
INSTRUCTIONS
UT-101
FLAT SURFACE & TRAK
