Hawksmoor TOOLSTATION 18783 User manual

SKU: 18783
2600W Electric Blower Vacuum
WHAT'S IN THE BOX
If you do not have all these items, please contact:
www.coreservice.co.uk
Hotline: [phone]
Email [email protected]
Original User’s Instructions
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE
Housing x 1Lower tube x 1 Upper tube x 1 Collection bag
and bracket x 1
Bracket
wheel x 1 Screw x 4 Belt x 1

2
TOOLS REQUIRED
SPECIFICATION
Technical Data
Model No. DT2260F
Voltage / Frequency 220V-240V~ , 50Hz
Input Power 2600W
No Load Speed 9000~15,000/min
Air Speed 160-270km/h
Max. air volume 13.2m³/min
Collection bag 35L
Mulching rate 10 : 1
Net Weight 2.65kg
Measured Sound Pressure Level 90.2dB(A) K=3dB
Measures Sound Power Level 102.4dB(A) K=3dB
- Guaranteed sound power level 105dB(A)
4.27m/s2K=1.5m/s2
Cable PVC 2 x 0.75mm2, 10m, BS plug
The sound values have been determined according to noise test code given in EN 786, using the
basic standards EN ISO 11201 and EN ISO 3744.
The sound intensity level for the operator may exceed 80 dB(A) and ear protection measures are
necessary.
The declared vibration value has been measured in accordance with a standard test method (according
to EN 786) and may be used for comparing one product with another. The declared vibration value
may also be used in a preliminary assessment of exposure.
The declared vibration value has been measured in accordance with a standard test method (according
to EN 786) and may be used for comparing one product with another. The declared vibration value
may also be used in a preliminary assessment of exposure.

3
WARNING!
Depending on the actual use of the product the vibration values can differ from the declared
total! Adopt proper measures to protect yourself against vibration exposures! Take the whole
work process including times the product is running under no load or switched off into
consideration!
Proper measures include among others regular maintenance and care of the product and
cutting attachments, keeping hands warm, periodical breaks and proper planning of work
processes!
EXPLANATIONS AND SYMBOLS, CAUTIONS AND WARNINGS
Caution / Warning.
Read the instruction manual.
Wear hearing protection.
Wear eye protection.
Wear dust protection.
Wear protective gloves.
Wear protective, slip-resistant footwear.
Switch the product off and disconnect it from the power supply before assembly,
cleaning, adjustments, maintenance, storage and transportation.

4
Remove plug from the mains immediately if the cable is damaged or cut.
Do not expose the product to rain or wet conditions.
Warning: The fan is still rotating when open or close the cover,be careful, specially the
inlet cover.
360
o
Be aware of people around you and do not direct towards them.
Objects thrown by the product could hit the user or other bystanders. Always ensure
that other people and pets remain at a safe distance from the product when it is in
operation. In general, children must not come near the area where the product is.
105
Guaranteed sound power level value in 105dB.
This product is of protection class II. That means it is equipped with enhanced or
double insulation.
The product complies with the applicable European directives and an evaluation
method of conformity for these directives was done.
A product placed on the United Kingdom market meets the UKCA Marking
requirements
WEEE symbol. Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local Authority or local
store for recycling advice.

5
HEALTH AND SAFETY
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR YOUR REFERENCE
WARNING! When using the product the safety rules
must be followed. For your own safety and that of
bystanders, please read these instructions before
operating the product. Please keep the instructions
safe for later use.
Training
• Read the instructions carefully. Be familiar with the controls and
the proper use of the product.
• Never allow people unfamiliar with these instructions or children
to use the product. Local regulations can restrict the age of the
operator.
• Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their property.
• This product is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the product
by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the product.
Preparation
• The personal protective equipment protects your own health
and the health of others and ensures the smooth operation of
the device.
• Wear suitable work clothing,such as sturdy shoes with nonslip

6
soles, long, robust trousers,gloves, safety goggles andear
protection. Wear these at all times while operating themachine.
Never use the device barefooted or wearing open sandals. Wear
respiratory protection to protect against dust.
• Do not wear clothing or jewellery that could be sucked intothe
air intake. Wear protective headwear to contain long hair.Keep
long hair away from the suction apertures.
• Pay attention to people, especially children, pets, open windows,
etc. The blown material can be thrown in their direction.
• Stop working if they are in close proximity. Keep a safety
distance of 5 m around you.
• Be familiar with your surroundings and pay attention to potential
dangers that may be overlooked when working.
• Carefully inspect the surface to be cleaned and remove all wires,
stones, cans and other foreign bodies.
• Use a rake or broom to remove foreign bodies before beginning
the blowing/suction process.
• Use both parts of the blowpipe so that the airflow can work
close to the ground.
• In very dry conditions, lightly moisten the surface or use a
sprayer to reduce the build-up of dust.
• Do not work with a damaged or incomplete device or one which
has been converted without the permission of the manufacturer.
• Before use, check the safety status of the device, in particular
the mains cable and the switch.
• Only use the device when fully assembled.
• Only use the device in suction mode if the collection bag is
attached.Check the collection bag regularly for wear or damage.
• Never operate the device with defective protection equipment or
faulty protection covers or without any protection equipment.
• Please be aware that the operator or user is responsible for
accidents or injuries to other people or their property.
• Avoid wearing loose clothing,clothing with hanging laces or ties.
• Operate the machine in a recommended position and only when

7
standing on a solid, flat surface.
• Do not operate the machine on a paved surface or a gravel
surface where the ejected material could cause injury.
• Always perform a visual inspection prior to use to make sure that
the shredding machine(including its bolts) and other fastening
equipment are secured, and that the housing is undamaged and
the protective equipment and shields are present.
• Replace worn or damaged components in sets to ensure
balance. Replace damaged or illegible markings.
Operation
• Do not switch on the device if it is held upside down or is not in
operating position. Avoid starting the device unintentionally.
• Make sure that the device is switched off before you pick it up
or carry it.
Having your finger on the switch off the device while carrying ,it
can cause accidents.
• Never point the device at others,and in particular, do not point
the air jet at the eyes and ears during operation.
• Always ensure secure positioning, particularly on slopes,when
working. Always hold the device tightly with both hands and only
work with a correctly adjusted carrying strap.Do not stretch too
far and do not lose your balance.
• Keep fingers and feet away from the suction pipe aperture and
impeller. There is a risk of injury.
• If you are tired or lacking in concentration or have consumed
alcohol or tablets, do not work with the device. Always have a
break on time.
• Work using common sense.
• Move slowly, do not run.
• Prolonged use of the device can lead to blood circulation
disorders in the hands caused by vibration. You can however
extend your machine use time by wearing appropriate gloves or
by taking regular breaks.

8
• Avoid operating the machine in poor weather conditions,
especially when there is a lightning hazard. Only work in daylight
or where there is good artifcial illumination.
• Do not vacuum burning, glowing or smoking materials (e.g.
cigarettes, embers etc.), vapours or highly flammable, toxic or
explosive substances.
• Stop the machine and disconnect the plug from device .Ensure
the moving parts are at a full standstill.
- when you are not using the device or when you are
transporting or leaving it unattended;
- before removing any obstruction or blocked channels,
- before checking, cleaning or carrying out other work on the
machine.
- after contact with foreign bodies or if abnormal vibration
occurs.
• Do not use the device in a closed or poorly ventilated area.
• Do not use the device near flammable liquids or gases. There is
a risk of fire or explosion if this advice is not heeded.
• In the case of an accident or malfunction during operation, the
device must be switched off immediately and disconnect the
plug from power source. Read the “Troubleshooting” section to
correct any malfunctions.
• Ensure that the in-feed is empty prior to starting the machine.
• Keep your face and body away from the in-feed aperture.
• Do not allow hands or other body parts or clothing to enter the
in-feed or discharge chute, or to be in the vicinity of moving
parts.
• Ensure you are standing securely and do not lose your balance.
Avoid an abnormal work posture. When material is being taken
in by the machine, never stand on a higher level than the base of
the machine.
• Do not stand within the ejection zone while operating the
machine.
• Take extreme care when feeding material into the machine to

9
ensure no metallic objects, stones, bottles, canisters or other
foreign objects are taken in.
• Do not allow processed material to accumulate in the ejection
zone since this can prevent proper ejection and cause the
material to be brought back into the machine via the in-feed
aperture.
• If the machine becomes clogged, turn off the power source and
disconnect the machine from the mains supply or remove the
batteries before freeing any refuse.
• Never operate the machine with defective protective equipment,
or shields, or without safety equipment, e.g. without the
collection bag being connected.
• Keep the power source free of refuse or other accumulated
material to prevent it from becoming damaged and to avoid a
potential fire.
• If the cutting mechanism comes into contact with a foreign
object or the machine starts to emit unusual noises or vibrate,
immediately turn off the power source and wait for the machine
to come to a standstill. Disconnect the machine from the mains
supply or remove the batteries and perform the following steps
before re-starting and operating the machine:
- investigate for damage;
- replace or repair damaged parts;
- check for loose parts and tighten as necessary.
• Ensure that you do not touch any of the dangerous moving
parts before you have unplugged the machine from the mains
supply or removed the batteries from the machine, and that the
dangerous moving parts have come to a complete standstill.
• In the case of an accident or malfunction during operation,
the device must be switched off immediately. Injuries must
be properly treated or medical assistance sought. Read the
“Troubleshooting” section to correct any malfunctions.

10
Maintenance and storage
• Regularly check the functionality and integrity of the device to
avoid danger to the operator.
• Replace worn or damaged parts in the interests of safety. Only
use original replacement parts and accessories.
• Do not try to repair the device yourself, unless you have
professional training. All work not mentioned in these
instructions may only be performed by authorised service
representatives commissioned by us.
• Store the device in a dry place and out of reach of children.
• Treat your device with care. Clean the ventilation slits regularly
and follow the maintenance instructions.
• Keep all inlets for the cooling air free of debris.
• Do not use the device if the switch cannot be turned on and
off. Damaged switches must be replaced at a customer service
workshop. Do not overload your device. Only work within the
power range indicated. Do not use low-performance machines
for heavy work. Do not use the device for purposes for which it
is not intended.
• If you stop the machine for maintenance, inspection, storage or
to change accessories, switch off the power source,disconnect
the achine from the mains supply or remove the batteries and
ensure that all moving parts have come to standstill.Allow
the machine to cool down before the inspection ,changing
accessories,etc.,
• Maintain the machine with care and keep it clean.
• Always allow the machine to cool down before storage .
• Be aware that the shredding machine can always still move even
if the power source is switched off by the locking function of
the rotective equipment. Be awareof this when maintaining the
shredding machine .
• Never try to circumvent the locking function of the protective
equipment.
