hayneedle PACA012-3 User manual

For assistance with assembly, please contact
Customer Care Center
1-888-880-4884
ITEM NAME: Belham Living Steel Outdoor Pergola Gazebo with Retractable Canopy Shades -
Green Canopy with Textured Brown Frame
SKU: PACA012-3
1/10

PRE-ASSEMBLY PREPARATION:
2/10
!THISPACKAGE MAY CONTAIN SMALL ITEMS WHICH SHOULD BE KEPT AWAY FROM CHILDREN
•Please check that all parts and hardware are included before beginning assembly.
•Save all packing materials until assembly is complete to avoid accidentally discarding smaller
parts or hardware.
•Read through the preparation and assembly instructions in full before beginning assembly
•Please use CAUTION AND CARE WHEN LIFTING the product to avoid personal injury and
(or) damage to the product.
to reduce the risk of personal injury and damage to product or surroundings.
Always install on level ground utilizing ground stakes. This garden
permanently staked or attached to concrete floor or platform.
house cannot be
Keep all children and pets away from assembly area.
Begin assembly no less than 6 feet from any obstruction such as fence, garage, house,
overhanging branches, clothes line or electrical wires.
Some parts may contain sharp edges, wear protective gloves if necessary. At least two or
more people are recommended for safe assembly.
Please have a ladder and a rubber mallet ready before assembly.
Note:
It is very important to read and follow these Safety Precautions before assembly and during the use of this
product.
•
•
•
•
•

Notice:
This gazebo / pergola is intended as a temporary shade structure, not a permanent structure.
As a result the canopy / top must be removed during heavy rain, winds, or inclement weather
including but not limited to thunderstorms, hurricanes, snow , and sleet.
Failure to do so will risk damage to the canopy / top and the structure of the unit itself.
Damage occurred to the unit from not removing the top is not covered by the manufacturer.
1) Keep all flame and heat sources away from this tent fabric. This tent is made with fabric
that meets CPAI-84 specifications for the flame resistance. It is not fire proof. The fabric
will burn if left in continuous contact with any flame source. The application of any
foreign substance to the tent fabric may render the flame-resistance properties ineffective.
2) When assembling and using this product, basic safety precautions must always be followed
to reduce the risk of personal injury and damage to product or surroundings. Do not cook
3)
4) Garden house fabrics are water resistant but not waterproof and may leak during
precipitation. Fabrics will fade from direct exposure to sunlight.
or barbeque under the canopy.
3/10
MAINTENANCE AND CARE TIPS ALOGREPROF
Please properly tighten all hardware and perform periodic inspections during usage for
cracked welds or loose nuts or bolts.
5)

M 4pcs
Q2pcs
K 2pcs
I 5pcs
G4pcs
E2pcs
O P 1pc2pcsN 4pcs
S8pcsR 1pc
S4
S6
L 2pcs
J 6pcs
H 1pc
F 2pcs
C 2pcs
2pcsA
Part list
D 2pcs
B 2pcs
Corner Post Corner Post
Long Side Beam Long Side Beam
Short Side Beam Short Side Beam
Short Beam
Guide Pole
Guide Pole
Post Base
Canopy Stake Hex Wrench
T
Hex Wrench
Bracket Bracket
1pc
1 10pcs67pcs 2
M6x16
6pcs3
M6x55 M6x65
416pcs
M6x15
2-M6 M6
M6
M6
5 83pcs
Bolt Cap
Bolt ( ) Bolt ( ) Bolt （) Bolt ( )
To best protect
frame finish,
do not put parts
directly on ground.
Guide Pole
Short Beam Short Beam
Post Top Cover
1/104/10

S4
T
M6x16
1 8pcs
M4pcs
M
1
2pcs
B
A2pcs
1
A B
or
M
orA B
Step 1: Attaching post bases
Attach one post base (M) to the bottom of each corner post (A)
with bolts (1) using hex wrench (T).
Attach one post base (M) to the bottom of each corner post (B)
with bolts (1) using hex wrench (T).
5 /10

E
1
M6x15
S
8pcs
4
S6
S4
A
B
A
B
N
M6x16
124pcs
O 2pcs
F
4
1
4pcsN
NE
E
N
F
E
2pcsF
E 2pcs
1
F
Step 2: Attaching long side beams
Note：
Please pay attention to the hole
positions of corner posts A &B
when assembling the E - F
side beams.
Corner Post A with eight holes
facing front. Corner Post B with
six holes facing front.
AB
2.1
2.2
2.3
2.1 Insert beam (F) into beam (E), secure the bracket (O) to beam (E) with bolts (1).
2.2 Inset the post top cover (N) into the top of post (A,B), make sure holes line up.
2.3 Attach one post (A) to each beam (F) with bolts (4) and bolts (1).
2.4 Attach one post (B) to each beam (E) with bolts (4) and bolts (1).
T
2.4
O
6 /10

D
M6x15
S
4 8pcs
S4
S6
24pcs1 M6x16
C
1
C
C
D
1
4
D
D 2pcs
2pcsC
1
C
D
Step 3: Attaching short side beams
T
3.1
3.2
3.3
3.1 Insert one beam (D) into each beam (C) and secure them with bolts (1).
3.2 Attach the beam (C) to the top of post (A) with bolts (4) and (1).
3.3 Attach the beam (D) to the top of post (B) with bolts (4) and (1).
B
A
B
A
1/107/10

G
S4
T
10x
2M6x55
II
G
H
2
G
11x1 M6x16
1pcP
H
I 5pcs G H
I
P
1
M6
1pcH
G
G 4pcs 1
I
H
P
2-M6
P
I
I
I
Step 4: Attaching short beams
4.1 4.2
4.4
4.1 Insert each beam (G) into one beam (I) and secure them with bolts (1).
4.2
4.3
Insert beam (H) into beam (I) and attach bracket (P) to them with bolts (1).
Attach the beams (H-I ) onto the center of the beams (E-F) with bolts (2).
Note the bracket (P) shall stay underneath the beams (H-I).
4.3
4.4 Attach the beams (G-I) evenly onto the top of the beams (E-F) with bolts (2).
E
E
F
F
1/10/108

J
P
JJ
J
J
T
S4 J
O
J
J
J
5
J
3 6pcs
M6x65
6pcsJ 3
Step 5: Attaching guide poles
583pcs
3
5
5.1 5.2
5.3
5.4
5.5
5
5.1 Snap guide poles (J) onto each bracket (O).
5.2 Attach the other end of the guide poles (J) to the beams (C-D) with bolts (3).
5.3 Snap guide poles (J) onto bracket (P).
5.4 Attach the other end of the guide poles (J) to the beams (C-D) with bolts (3).
5.5 Fully tighten all the bolts (1,2,3,4). Cover bolts (1,2,3) with bolt caps (5).
C
D
D
C
1/10/109

K
8pcsR
2pcs
Q
M
R R
L
K
QQL
L 2pcs
K 2pcs
Q
L
Q
Step 6: Attaching canopies
6.1 Pull canopies onto the guide poles under the short side beams. Be sure each canopy
lines up with the other at each long side of the frame.
6.1
6.2
6.3
6.2 Insert one guide pole (K) into both ends of one canop y. Insert one guide pole (L) into
both ends of the other canopy. Snap each guide pole (L) into each guide pole (K).
6.3 Adjust the position of each post (A/B) to make sure they stand upright. Hammer
ground stakes into soft ground through the holes on each post base to stabilize the
pergola.
