Description
The HLIOEXPAND is an expander board accessory for all OmniLogic pool controls. It offers four
additional temperature sensor inputs, pool/spa valve actuator outputs and low voltage (dry con-
tract) outputs to control various pool and backyard equipment. After installation, the OmniLogic
will detect the HLIOEXPAND and allow you to configure the additional input/outputs to control and/
or monitor your pool and backyard equipment.
SENSOR INPUT: Use only Hayward 10k ohm thermistor type temperature sensors (not
included). Hayward recommends the multipurpose "PC" sensor available at
local Hayward dealers.
VALVE ACTUATOR
OUTPUT: 24 VAC, 0.55 A, fuse protected
LOW VOLTAGE DRY
CONTACT RELAY: 24 VAC, 0.5 A max
Installation
DANGER of Death, Injury or Property Damage if procedure not followed. This accessory
connects to the OmniLogic panel beneath the dead front. Dead front removal is required for this
installation. Power to the OmniLogic panel MUST be shut off before the dead front is removed.
This means a complete shutdown of power to the entire OmniLogic panel.
Overview
The HLIOEXPAND is design to slide between guide rails and insert into a dedicated slot on the Om-
niLogic main board. Once inserted, the OmniLogic will discover the HLIOEXPAND and its inputs/
outputs can be configured within the OmniLogic's CONFIGURATION WIZARD.
There are two "locking" positions when sliding the HLIOEXPAND between the OmniLogic's guide
rails. The first position will hold the board in place to allow easy access to wire sensors, valves,
and low voltage equipment. Once all connections are made, slide the HLIOEXPAND further into the
second position. The HLIOEXPAND should insert firmly into the OmniLogic main board's slot and
lock in place.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2

Lock HLIOEXPAND into Position 1
1. Remove power to the entire OmniLogic panel.
2. Remove the OmniLogic deadfront to expose the main board and relays.
3. Slide the HLIOEXPAND between the guide rails until it locks as shown below. In this position,
the board will be sticking out from the enclosure allowing access to the wiring connections
on the HLIOEXPAND.
Position 1
Insert HLIOEXPAND board
until the guide rails clips into
the rst notch.
Guide Rail Notch
3
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Wiring
Refer to the diagram below for the location of the wiring connectors for temperature sensors, valve
actuators and low voltage pool/spa equipment. For detailed information about wiring these compo-
nents, Low Voltage Wiring section of the OmniLogic Installation manual.
When making these connections, be aware that wires should be routed to the low voltage side of
the OmniLogic. Taking care when routing wires will help prevent the possibility of pinching a wire
when re-mounting the panel.
After all connections have been made, use wire anchors and ties to secure the bundle of wires coming
from the HLIOEXPAND. Two anchors (with adhesive back) and two nylon ties straps are provided.
When determining a location to mount the anchors, be sure to position wiring below the deadfront
and above the OmniLogic's main board.
Note that the actuator outputs are protected by a 4 amp "automotive" type fuse. This fuse can be
replaced if necessary.
Sensor
2
Sensor
4
Sensor
3Sensor
1
LV
2
LV
4
LV
3LV
1
Valve1 Valve2 Valve3 Valve4
4A replaceable fuse
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
4
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
4

Lock HLIOEXPAND into Position 2
1. With all the wires attached, slide the HLIOEXPAND between the guide rails until it locks into
position 2 as shown below. If the board is difficult to slide, you may have to spread the guide
rails slightly to release the board from position 1.
2. Replace the OmniLogic deadfront and fasten.
3. Restore power to the OmniLogic.
Position 2
Slide the HLIOEXPAND board
all the way until it inserts rmly
into the OmniLogic main board's
slot. The guide rails will lock as shown.
5
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Configuration
The HLIOEXPAND will be automatically discovered at power up and can be found in the CON-
FIGURATION WIZARD. As you progress through the wizard, the four additional valve outputs, low
voltage outputs, and temperature sensor inputs will all be displayed in their corresponding tables.
They can be easily identified by looking for "IO Module" under "Device Type" in the tables (as
shown below). Refer to the OmniLogic Installation Manual for details on how to configure valve
outputs, low voltage outputs and temperature sensor inputs.
HLIOEXPAND
VALVES
HLIOEXPAND
Low Voltage Output
HLIOEXPAND
Temperature Sensors
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
6
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
6
