Saline CTM 6.0
Salt Chlorine Generator
Owner’s Manual

2019-2631
2019-10-10
TABLE OF CONTENTS
INTRODUCTION 4
WARRANTY INFORMATION 5
SAFETY INFORMATION 6-7
PREPARING YOUR WATER BEFORE INSTALLATION 8-9
SALT CHART FOR CORRECT MAINTENANCE 10
TOOLS AND PARTS REQUIRED FOR INSTALLATION 11
INSTALLING YOUR SYSTEM PLUMBING 12-13
ELECTRICAL 14
SPECIFICATIONS AND FUSE SIZING 15
STARTING THE SYSTEM 15
GENERAL OPERATION 16
MAINTENANCE AND CLEANING 17

2019-2631
2019-10-10
SalineCTM 6.0Salt Chlorine
Generator
CONTROLS BACTERIA AND ALGAE
in
Swimming Pool (and Spa) Waters
COMMERCIAL
A maximum of 283,000 L of water can be treated with
Saline CTM 6.0 Salt Chlorine Generator
Maximum output of hypochlorous acid equivalent to 2.268 kg
of free available chlorine per day
For swimming pools, a range of 1.0 - 3.0 ppm of free available chlorine must be maintained.
For spas, a range of 3.0 - 5.0 ppm of free available chlorine must be maintained.
KEEP OUT OF REACH OF CHILDREN
READ THE LABEL AND OPERATING MANUAL BEFORE USING
REGISTRATION NO. 30927 PEST CONTROL PRODUCTS ACT
WARNING: Operating the Saline CTM 6.0 Salt Chlorine Generator
without water flow through the cell can cause a buildup of flammable gases
which can result in FIRE OR EXPLOSION.
Do not use this device with bromide products.
NOTICE TO USER: This pest control product is to be used only in accordance with the
directions on the label. It is an offence under the Pest Control Products Act to use this
product in a way that is inconsistent with the directions on the label.
Hayward Commercial Pool
Pr oducts
10101Molecular Drive, Suite 200
Rockville, MD. 20850
Phone: [phone]
www.haywardcommercialpool.com

2019-2631
2019-10-10
Congratulations on purchasing your new Saline CTM 6.0 Salt Chlorine Generator. We
trust that this system will offer you the ultimate in swimming environments, and give
you years of trouble free operation.
This user’s manual will explain in detail the operation of your new system, as well as
water chemistry guides, warranty information, and much more.
If at any time you need additional information on your system, please feel free to
contact us.

2019-2631
2019-10-10
WARRANTY
The Hayward system carries a limited 3 year warranty
1. 3 year warranty on assembly of electrical components and cell
housing.
2. 1 year on all electrical items.
3. 2 years or 15,000 hours, whichever occurs first, pro-rated hourly,
on titanium electrodes. (Year 1 is warranted fully, thereafter pro-
rated warranty applies, applicable over the full 2 year period)
• Hayward advises that titanium electrodes will have to be replaced every
15,000 hours of operating time. Under no circumstances shall the
replacement titanium electrodes exceed the original 15,000 hour warranty.
• Hayward warranties will not be honored should it be shown that the
operating and maintenance procedures have not been followed,
particularly with regard to the correct maintenance of salt concentration
and water chemistry.
• Hayward warranties of the titanium electrodes will not be honored if the
system is operated in water temperatures lower than 15°C.
• Hayward warranties of the titanium electrodes will not be honored if the
system is operated in water where the salt concentration is lower than
3000 ppm.
• During the warranty period the customer shall return the defective
component, freight prepaid, accompanied by the original invoice or proof
of purchase, and Hayward shall at its sole discretion elect to repair or
replace the defective component and return it to the customer, freight pre-
paid.
Hayward accepts no responsibility other than to repair or replace a defective
component, and this warranty specifically excludes product failure due to accidental
damage, abuse, misuse, negligence, damage due to non-compliance of the operating
manual or unauthorized alterations or modifications to the system. Hayward accepts
no responsibility and is not liable for any extended warranties or variations to this
warranty offered by re-sellers of Hayward systems.

2019-2631
2019-10-10
SAFETY INFORMATION
PLEASE READ THE FOLLOWING SAFETY INFORMATION CAREFULLY!
WARNING!
• Only a certified technician may install and service your Hayward system.
• Do not use this product with bromide products.
• Modifying your Hayward system in anyway may cause bodily injury
and will void your warranty.
• Warning: To reduce the risk of injury, do not allow children to operate this
device.
• Only replace components with those specified by manufacturer.
• When installing your system, ensure that power is linked to the main pump
power source for the pool to ensure that your Hayward system never
operates when the pumps are off.
• All boxes on your Hayward system contain high voltage components.
Never open any box while power is “on”.
• WARNING: Heavy pool (and/or spa) usage, and higher temperatures may
require higher chlorine output to maintain proper free available chlorine
residuals.
• If additional chlorine is required due to heavy bather loads, use granular or
liquid chlorine (sodium hypochlorite), to maintain appropriate chlorine
residual in the water.
• Maintaining high salt and chlorine levels above recommended range can
contribute to corrosion of pool (and/or spa) equipment.
• DO NOT add pool (and/or spa) chemicals directly to the skimmer. This
may damage the cell.
• Check the expiry date of the test kit as results may be inaccurate if used
after that date.

2019-2631
2019-10-10
• When replacing the cell, only use replacement cells having a label that
clearly states that it is a replacement cell for the chlorine generating
device Saline CTM 6.0 Salt Chlorine Generator, REGISTRATION
NUMBER 30927, PEST CONTROL PRODUCTS ACT.
• Follow all aspects of the local and National Electrical Code(s) when
installing Saline CTM 6.0 Salt Chlorine Generator.
• NOTE: For outdoor pools, chlorine residuals can be protected from
destruction by sunlight by addition of stabilizer (cyanuric acid).
• NOTE FOR USE ON SPAS: For proper sanitation, spas must be
completely drained periodically. The number of days between COMPLETE
DRAINAGE is equal to the volume of spa water in litres, divided by 10
times the maximum number of daily spa users. Refill spa with water and
repeat DIRECTIONS FOR USE of the device.
• HEALTH AND HYPERTHERMIA WARNINGS FOR SPA DEVICES:
People with a medical condition should consult a physician
before entering pool or spa water.
Maximum spa water usage temperature is 40°C. Bathing in spa
water at 40°C should not exceed 15 minutes.

8
2019-2631
2019-10-10
PREPARING YOUR WATER BEFORE INSTALLATION
Hayward saline chlorination systems operate by utilizing the sodium chloride
that has been added to the pool water, to produce sodium hypochlorite (liquid
chlorine), through the process of electrolysis.
In order for your Hayward system to operate correctly, sodium chloride (salt)
must be added directly to the pool at least 24 hours before the installation of the
equipment.
5 kg of sodium chloride must be added for every 1,000 litres of pool water (ie: a
200,000-litre pool will require 1,000 kg of salt for start-up).
It is best to add the salt around the pool, and not load all salt in one section.
Once the salt has been added, brush the surface of the pool continuously until
the salt has all dissolved. You must never leave large amounts of salt on the
surface of the pool, as this may cause damage to the pool surface.
When you add the initial load of salt, you will need to add additional chlorine, as
the salt will cause a chlorine demand.
Your pool water should be balanced in the following range before turning your
Hayward system on.
Water balance parameters
Swimming pool
Spa
Free available chlorine
1.0 – 3.0 ppm
3.0 – 5.0 ppm
pH
7.2 – 7.8
7.2 – 7.8
Total alkalinity
100 – 120 ppm
100 – 120 ppm
Calcium hardness
200 – 300 ppm
150 – 200 ppm
Cyanuric Acid (stabilizer)
30 – 100 ppm
30 – 100 ppm
Salt ranges
Swimming pool
Spa
Salt level
4,000 – 5,000 ppm
4,000 – 5,000 ppm
NOTE: Low salt levels will cause a reduction in chlorine production and will
damage the device. High salt levels will increase the possibility of corrosion on
pool equipment.
NOTE: If too much salt has been added, dilute with fresh water.

9
2019-2631
2019-10-10
Use standard test kits to check water chemistry, and use either a conductivity
tester or salt test strip to check saline levels.
(Note that most conductivity testers require frequent calibration to ensure
accurate readings, failure to calibrate the equipment will result in
inaccurate readings.)
How to Calculate volume of a pool
For a rectangular shaped pool
Length (m) x Width (m) x Average Depth (m) x 7.5 x 3.8 = Litres of water
For an oval or round shaped pool
Average length (m) x Average Width (m) x Average Depth (m) x 5.9 x 3.8 =
Litres of water

2019-2631
2019-10-10
The following is a chart to determine the amount of salt required to raise a pool or spa to 5000 ppm
SALT CHART FOR CORRECT MAINTENANCE
ppm Salt Levels
Number of KG of Salt to Be Added
ppm Salt
Pool and or spa Volume (litres)
1,000
100,000
200,000
300,000
400,000
500,000
600,000
700,000
800,000
900,000
1,000,000
5000
CORRECT
CORRECT
CORRECT
CORRECT
CORRECT
CORRECT
CORRECT
CORRECT
CORRECT
CORRECT
CORRECT
4800
2
20
40
60
80
100
120
140
160
180
200
4400
6
60
120
180
240
300
360
420
480
540
600
4000
10
100
200
300
400
500
600
700
800
900
1000
3800
12
120
240
360
480
600
720
840
960
1080
1200
3500
15
150
300
450
600
750
900
1050
1200
1350
1500
3200
18
180
360
540
720
900
1080
1260
1440
1620
1800
3000
20
200
400
600
800
1000
1200
1400
1600
1800
2000
2700
23
230
460
690
920
1150
1380
1610
1840
2070
2300
2500
25
250
500
750
1000
1250
1500
1750
2000
2250
2500
0-(Initial Salt Addition) 50 500 1000 1500 2000 2500 3000 3500 4000 4500 5000
Note:
There may already be some salt present in the pool or spa water.
Be sure to test the salt levels prior to adding more salt to the water.
10

2019-2631
2019-10-10
Strainer clear bowl with 20 mesh
1
PVC ball valve Sch. 40
2
PVC male adaptor Sch. 40
4
PVC nipple SCH 80
2
PVC bushing Threaded
1
PVC union S EPDM w/o
O-ring Sch. 80 threaded
2
Akenstrut clamps
2
Polypropylene valve, speed fit
2
Elbow street 90, SCH 80
2
Salt test strips
1
TOOLS AND PARTS REQUIRED FOR INSTALLATION
Your Hayward system will include an installation kit comprising of the
following items:
Description Qty
Additionally you will need the following items, not included, to complete
the installation:
• Polypropylene tubing
• Flex PVC tubing
• Wall anchors
• Disconnect box, fuse box, conduit, wiring and related material to supply 220v to systems
(220v systems only)
The following tools will be required to complete the installation:
Hand Tools Power Tools
Set of sockets Drill
Hammer Hammer Drill
Screw Drivers – Flat & Phillips
Wire Strippers Drill Bits
PVC Cutters Hole saw
60 cm (24”) Level Paddle bit
Slip joint pliers Steel bit drill set
Crescent wrench Mason bit
Tape Measure
Teflon Tape Taps
Allen Wrenches 2.5cm
True RMS Clamp Meter
0.9cm
Wire Cutters
11

12
2019-2631
2019-10-10
PLUMBINGYOUR SYSTEM
Your Hayward system can be plumbed using two different methods. Both will
work fine, however, the following must be taken into account before making the
decision of what method to use.
1. Your Hayward system requires a minimum of 75 Lpm of flow through the cell
to produce the rated amount of chlorine. Be sure that if you use the pressure
drop plumbing method [1] you have sufficient pressure drop across your
filter to adequately flow 75 Lpm through the cell.
2.When using the pressure drop plumbing method [1], you are sending
un-filtered water through the cell, so you need to ensure that you clean the
included strainer at least 1 time per week to remove any debris. Failure to
clean the strainer will result in a lack of flow, reducing chlorine production, and
ultimately reducing flow to the point that the flow switch de-activates the
system.
3. If you elect to use the bypass plumbing method [2], you will need to purchase
a butterfly valve based on the size of the pipe you are using. This can
sometimes be cost prohibitive, but the upside of this plumbing method is that
you are sending filtered water through the cell, which reduces the frequency of
needing to clean the strainer. Bypass plumbing method [2] also generally
allows for more flow through the cell, which is recommended.
4. Remember, always ensure that the return line from the Hayward cell is
plumbed after the heater. Never plumb the return line before the heater, as
you will be sending a high ppm of chlorine through heater, which may cause
damage.
5. No matter which plumbing method you use, you will always have to plumb the
cooling line into box 3 (rectifier) using filtered water. This cooling line allows
the heat sink in box 3 to cool the critical components.

13
2019-2631
2019-10-10
PRESSURE-DROP PLUMBING METHOD [1]
Saline CTM 6.0 Salt Chlorine Saline CTM 6.0 Salt Chlorine
Generator power supply Generator cell
NOTES:
THE RECTIFIER COOLING LINES MUST BE CONNECTED
FROM THE SUCTION SIDE OF THE PUMP AND AFTER THE
FILTER. ALWAYS USE FILTERED WATER.
IF THERE IS A CONTROLLER PRESENT, THE OUTLET LINE
THAT FEEDS THE CONTROLLER PROBES COULD BE
CONNECTED TO THE RECTIFIER.
BYPASS MANIFOLD PLUMBING METHOD [2]
NOTES:
THE RECTIFIER COOLING LINES MUST BE CONNECTED
FROM THE SUCTION SIDE OF THE PUMP AND AFTER THE
FILTER. ALWAYS USE FILTERED WATER.
ALTERNATIVELY, IF THERE IS A CONTROLLER PRESENT, THE
OUTLET LINE THAT FEEDS THE CONTROLLER PROBES COULD
BE CONNECTED TO THE RECTIFIER.
Saline CTM 6.0 Salt Chlorine Saline CTM 6.0 Salt Chlorine
Generator power supply Generator cell

14
2019-2631
2019-10-10
ELECTRICAL SPECIFICATIONS
Each Hayward model has very specific wiring requirements based on its line
voltage and amperage draw.
• The Saline CTM 6.0 Salt Chlorine Generator operates at 110 – 120v. A
power cord will be supplied out of the power box. Plug this into any
standard 110 – 120v outlet. As above, the cord labeled ORP must be
plugged into a controller, or a 120v outlet.
• Your Hayward system must be wired to the main pump power supply, so
that if the pump is shut down, the power to your Hayward system is lost.
ELECTRICAL SPECIFICATIONS AND FUSE SIZING
MODEL:
MAX PRIMARY AC
AMPS
SYSTEM INPUT
VOLTAGE
BREAKER
REQUIRED
TM
Saline C 6.0 Salt Chlorine
Generator
9.9 110 – 120v 20amp
Fuse sizing:
TM
Saline C Model Fuse size and type
6.0 Salt Chlorine Generator 20amp dual element, slow blow, RK5 fuse

15
2019-2631
2019-10-10
STARTINGTHE SYSTEM
Once your Hayward system has been successfully wired and plumbed, it is ready
for use.
• Make sure that the valves to and from the cell are in the open position.
• Make sure that you have water flowing through the water-cooled heat sink
in box 3.
• Ensure that the cord labeled ORP is either plugged into a controller or
directly into a 110v outlet
1. Move the safety switch to the “on” position.
2. Wait 10 seconds for the system to respond.
3. Turn the black knob on the side of box 1 clockwise, and watch the
amp or voltmeter on box 3 slowly increase.
(If your system is linked to an automatic ORP controller, we suggest you
turn the system to maximum, which will allow for full production every time
the controller calls for it. If you are running your system manually you will
need to find the point at which you keep a satisfactory level of chlorine in
the water. It may take several days to find this point.)
• If your Hayward system is linked to an automatic controller, remember that
it will only work when the controller is in feed mode. It is also a good idea
to make sure that your controller is not set in proportional band mode,
instead try using double set point control (if your controller supports this
function). An example of this is if you want to maintain a 700 ORP, have
the controller set to turn on at 695 ORP and turn off at 705 ORP, that way
your Hayward system is not switching on and off all the time.
(Call the manufacturer of your controller if you are having difficulties in
comprehending the saline chlorination system set up instructions. Most
controllers also require a “gold tip” ORP probe when working with a saline
chlorination system.)

16
2019-2631
2019-10-10
GENERAL OPERATION
Your Hayward system operates when power is activated by the main pumps,
and from your ORP controller, and will continue to operate for as long as power
is applied from those two sources.
• The system has an output range of 5-100% of the rated chlorine
production, and can be adjusted by turning the black knob of the side of
box 1 in a clockwise or anti-clockwise motion. When adjusting the control
knob on the side of box 1, you will notice the amperage needle of the
gauge on box 3 increases or decreases.
Higher amperage = higher chlorine production.
Normal operating amps and volts for this model device are:
Saline CTM 6.0 Salt Chlorine Generator - 25 amps @ 15v
• Water flow through the Hayward cell is critical. Whether you plumbed
your system in using the pressure drop or bypass method, please ensure
that you have at least 75 Lpm through the cell to achieve the rated
chlorine production.
** Remember, your Hayward system is a chlorine generator, and
will only operate as well as you maintain it. Careful attention must
always be paid to proper chemical balancing, and regular service.

2019-2631
2019-10-10
MAINTENANCE AND CLEANING
Your Hayward system is designed to operate 24/7 at max power, and will give
you years of trouble free use if you follow these basic maintenance and cleaning
instructions.
• Remember, this system produces sodium hypochlorite “liquid chlorine” from
the salt that you have added to the water. It will only continue to operate
correctly if salt is maintained at the correct 5000ppm level. Low salt will lower
the amount of chlorine produced, and cause damage to the electrolytic cell.
(Warranties will not be honored if it is determined that salt has been run low.)
• There is a strainer mounted at the bottom of your Hayward cell, which will
trap debris and stop it from entering the cell, this strainer needs to be
cleaned regularly.
• The plates that are inside the PVC cell housing are the most critical part of the
system. You will notice that over time a white substance (calcium minerals)
will build up on the plates, especially at the top of the cell. This buildup needs
to be cleaned by removing the cell from the housing and soaking it in a dilute
muriatic solution (1:5) for about 10 – 15 minutes. Reverse polarity systems will
need to be cleaned every 3 – 6 months. (Warranties will not be honored if it is
determined that the cell has not been
cleaned regularly.)
1. Muriatic acid is corrosive, please follow safety instructions and wear
protective clothing.
2. To avoid splash, always ADD MURIATIC ACID TO WATER rather than
water to muriatic acid.
• Remember, the titanium plates that make up the cell are the most
expensive part of the Hayward system and are going to need to be
replaced roughly every 15,000 hours of operating time. By ensuring that
salt is always at the correct level, and plates are cleaned regularly, you
will increase their “life”, thus saving you money…
Hayward offers a wide range of other products that can help you maintain salt levels
in your pool, including conductivity controllers and saturated salt feeders for those
pools that lose large amounts of water.
17
