HBeZon BA-0013MC-L User manual

INSTALLATION MANUAL

This product must be connected to a grounded metal permanent wiring system
or an equipment-grounding conductor must be run with the circuit conductors and connected
to the equipment grounding terminal or lead on the product.
CAUTION:
An Electrical option mirror must be wired to a 20 Amp GFI(Ground Fault
Interrupter) protected circuit when used in bathrooms and all other locations required by the
National Electric Code.
WARNING:
WARNING:
ALL WIRING SHOULD BE DONE BY A QUALIFIED LICENCED ELECTRICIAN.
WARNING:
WARNING:
HOW TO CONNECTIONS
When using an electrical furnishing, basic precautions should always be followed ,including the
following:
To reduce the risk of burns,fire,electric shock or injury to persons.
Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the manufacturer.
Never drop or insert any object into any opening.Do not use outdoors.
Risk of electric shock.Connect this furnishing to a properly grounded circuit
only. See grounding instructions.
ELECTRIC CONNECTIONS
IMPORTANT SAFETYINSTRUCTIONS
Shut off power before wiring.
Requires 120 VAC 20 Amp GFI protected Circuit.
GROUNDING INSTRUCTIONS:
1
Neutral to ribbed.
Live to smooth.
Ground to green. Neutral / ribbed. Live / smooth

HARDWARE AND TOOLS ( Tools not included)
1/4”& 1/8” Drill Bits Pencil Level
Power DrillMallet Tape Measure Safety Goggles
ITEM IMAGE NAME
HARDWARE LISTS
Mounting Screw
Wall Anchor
2
Please read carefully and save these instructions
Don't discard any of the packaging until you are sure that you have all of the parts and the fitings
Make sure power to the junction box is off before commencing installation.
IMPORTANT
1. Unpack LED cabinet. DO NOT lay cabinet on tiled or concrete surface prior to installation
Cabinet must be on protected surface to prevent chipping of the corners
2. Care must be taken before drilling pilot holes to avoid any existing wiring or pipe work that may
be concealed.
3. A certified electrician must perform all work.The mirror must be connected to a GFI
INSTALLATION
Please refer to below surface mount or recess mount method.
MAINTENANCE
Wipe clean with a soft damp cloth. Apply glass cleaner to cloth and do not apply directly to mirror
Never use abrasive cleaners as these could damage the finish or exposed LEDstrip 2
INSTALLATIONINSTRUCTIONS
1
2

3
Step 1 Step 2
Step 3
Measure and mark the back mounting holes on
the wall.
Unpack the LED medicine mirror and prepare
tools needed.
Draw horizontal line connecting the marked location.
The line should be level.
Adjust to level if necessary.
Drill holes,and put in the plastic expansion bolt.
SURFACE MOUNT INSTRUCTION
Use a 1/4”(6mm) bolt

Step 4
Step 5 Attach the cabinet to the wall with mountin screws from the hardware pack.
4
Connect hardwire to power line.
Make sure the power off(Voltage:AC110-12V,50/60Hz)
Neutral / ribbed. Live / smooth

Step 1
5
20 in.(W) x 28 in.(H) x 4.8 in.(D) 17-1/2 in.(W) x 22-1/4 in.(H) x 3-1/2 in.(D)

Step 3
Step 2
6
Connect hardwire to power line.
Make sure the power off(Voltage:AC110-12V,50/60Hz)
Neutral / ribbed. Live / smooth

7
INTRODUCTIONOF TOUCH FUNCTION
After power on, the button shows white and it is in waiting stagte,
click to turn on the light function and the button turn on yellow.
Click again to turn off the light function and the button to turn to white.
Long click the button to make the light gradually dims
Click the button again and the light gradually brightens
After power on, the button shows white and it is in waiting state,
click to turn on the defogging function and the button turn on yellow.
Click again to turn off the defogging function and the button to turn to white.
After power on, the button shows white and it is in waiting state,
click to turn on the light function and the white turn on yellow.
Long press to switch the color temperature of light by 3k-yellow, 4k-natural or 6k-cold white

A
C
B
SKU# A B C
BA-0013MC-L 20 28 4.8
BA-0014MC-R 20 48 4.8
A - Width
B - Height
C - Depth
Unit: Inch
Note: All dimensions & specifications are approximate
and subject to change without notice.
8
For any questions or queries regarding our products, please contact our support team：
Email ：[email protected]
Website：www.hbezon.com
Customer Service:
