HC Stage Lighting HC-B04 User manual

4*12w 6in1 battery wireless par
User manual
P le ase rea d t he ins t r u ction s ca refu ll y before use

2
TABLE OF CONTENTS
1. S af ety I nst r uctions
...................................................................................2
2. Technical Specifications
........................................................................ 6
3. How To Control The Unit
....................................................................... 7
4. Remind
...................................................................................................10
5.QR Code.........................................................................................10
statement
The product has well capability and intact packing when leave
factory. All of the user should comply with warning item and manual,
any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction &
problem owing to ignore the manual.
1. Safety Instructions
Please keep this User Guide for future consultation. If you sell the
unit to another user, be sure that they also receive this instruction
booklet.

3
Unpack and check carefully there is no transportation damage before
using the unit.
Before operating, ensure that the voltage and frequency of power
supply match the power requirements of the unit.
It’s important to ground the yellow/green conductor to earth in
order to avoid electric shock.
The unit is for indoor use only. Use only in a dry location.
The unit must be installed in a location with adequate ventilation, at
least 50cm from adjacent surfaces. Be sure that no ventilation slots
are blocked.
Disconnect main power before replacement or servicing.
Make sure there are no flammable materials close to the unit while
operating as it is fire hazard.
Use safety cable when fixes this unit. DO NOT handle the unit by

4
taking its head only, but always by taking its base.
Maximum ambient temperature is Ta: 40℃. DO NOT operate it
where the temperature is higher than this Unit surface temperature
may reach up to 85℃. DO NOT touch the housing bare-hand during
its operation. Turn off the power and allow about 15 minutes for the
unit to cool down before replacing or serving.
In the event of serious operating problem, stop using the unit
immediately.Never try to repair the unit by yourself. Repairs carried
out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always
use the same type spare parts.
DO NOT touch any wire during operation as high voltage might be
causing electric shock.
Warning:
Please set one light only as master when used Master-slave model
in the same channel.

5
DO NOT set any light as master when used DMX hold model.
To prevent or reduce the risk of electrical shock or fire, do not expose
the unit to rain or moisture.
DO NOT open the unit within five minutes after switching off.
The housing, the lenses, or the ultraviolet filter must
be replaced if they are visibly damaged.
Caution:
There are no user serviceable parts inside the unit. DO NOT open
the housing or attempt any repairs yourself. In the unlikely event your
unit may require service, please contact your nearest dealer.
Installation:
The unit should be mounted via its screw holes on the bracket.
Always ensure that the unit is firmly fixed to avoid vibration
and slipping while operating. And make sure that the

6
structure to which you are attaching the unit is secure and is able to
support a weight of 10 times of the unit’s weight. Also always use a
safety cable that can hold 12 times of the weight of the unit when
installing the fixture.
The equipment must be fixed by professionals. And it must be fixed
at a place where is out of the touch of people.
2. Technical Specifications
Light Sources: 4pcs 6in1 RGBWA+UV LED
Beam Angle: 15°
Power Voltage: AC 100-240V, 50/60Hz
Net Weight: 2.5Kgs
Control
DMX Channel: 6/10 Channel
Control Modes: DMX ,wireless ,IR Remote and smart phone
Construction
Display: LCD Display
Data In/Out socket: 3-pin XLR sockets

7
Power Socket: Powercon in/out
Protection Rating: IP22
3. How To Control The Unit
The DMX512 is widely used in intelligent lighting control,with a DMX
512 controller.connect several lights together,dmx in and dmx out,
3 pin XLR connectors: Pin 1: GND, Pin 2: Negative signal (-), Pin 3:
Positive signal (+)
Display:
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions
Turn on operation: when in charging or turn off, press "MENU" for m
ore than 4s,then screen will display clients' logo and model of produ
cts,
there are "MENU","UP"."DOWN" for your selection to choose the fun

8
ction,press" ENTER" to confirmed and enter the next menu,press "M
ENU" could back to the last menu.
When turn on,press “Menu” for more than 4s,the screen will display”
Power Off”,and will close LED output by then.
If charger connect with electricity,the screen will display charging
icon and percentage of battery power.Or will be turn off directly,and
the battery powered will be totally cut off.
When using Master-Slave model,apart from the first one as Master
without setting,the others need to set as Slave.
When using DMX512 controller,all the lights need to set as DMX
model.

9
MENU
Choose Pattern
Static Color
Macro Color
Show Mode
Sound model
RGBWAP (0-255) Strobe( 0-20)
001-032
AUTO / FADE / SNAP /
STRO(RGBA)
Sound ( 1-3) outdoor no the
function
User setting
Channel
DMX512 Address
Slave Mode
WiFi Mode
6CH / 10CH
001-512
System setting
White balance
Show Battery
Display sleep
Auto lock
Infrared Setting
Wireless Setting
Factory Reset
RGBWAP ( 127-255)
Yes / No?
Open/5Sec/10Sec/15Sec
On / Off
On / Off
On / Off
Password

10
Information
Work Hours:
Software Version
Level Percent
000H-999H
002
10-100
Some tips for the lights:
1. Please be fully charged for first use,it will take 4 hours,but would
be good for Battery.
2. About " Emergency Lamp " function,when set Emergency Lamp
on,also light works with power cable connection. If power cable is
interrupted,leds will turn on white light. This feature suit to special
scenes
3. How to turn on the light?
A-when set "Auto power no", press "menu button" 3-5 seconds,will
turn on the display.
B-when set "Auto power yes", it will turn on automatically when
power cable plugged, disconnect the power cable will turn off.
4. How to check power information, please set "battery show " to yes,
then two ways.
A-when light on, you can see the info on the upper right corner of the
display.

11
B-when light off, press the menu button lightly,will show it in display
DMX channel’s functions and values (6/10 DMX channels):
6CH
No.
DMX512
Value
Function
1
0~255
Red dimmer
2
0~255
Green dimmer
3
0~255
Blue dimmer
4
0~255
White dimmer
5
0~255
Amber dimmer
6
0~255
UV dimmer
10CH
No.
DMX512
Value
Function
1
0~255
Total dimmer , CH9 (0~9)
2
0~9
Strobe off
10~255
Strobe：10 lowest，255 fastest
3
0~255
Red，the max depend on total dimmer
4
0~255
Green，the max depend on total dimmer

12
5
0~255
Blue，the max depend on total dimmer
6
0~255
White, the max depend on total dimmer
7
0~255
Amber, the max depend on total dimmer
8
0~255
UV, the max depend on total dimmer
9
0~9
Dimmer model
10~29
Color choose : CH10 choose color
30~49
Jump variable effect:CH10 control the
speed
50~69
gradual variable effect :CH10 control the
speed
70~89
mutation effect: CH10 control the speed
90~109
Red + strobe:CH10 control the speed
110~129
Green + strobe:CH10 control the speed
130~149
Blue + strobe:CH10 control the speed
150~169
Amber + strobe:CH10 control the speed
170~189
Purple + strobe:CH10 control the speed
190~209
Sounds control the jump variable effect
210~229
Sounds control the jump variable effect +
gradual variable effect
230~255
Sounds strobe

13
230~255
Sounds control the strobe
10
0~255
This channel’s function are depending on
the value of CH9：
When CH9 is 10~29 ，then the function is
colors choose.
When CH9 is 30~189，then the function is
speed control: 0 is the lowest,255 is the
fastest.
4.Remind
It need to charge a times for each two months,and 50% battery
power at least, if for a long time without using.
5.QR Code
Scan the QR code below to download the APP (LED WiFi ) to
your smart phone.
