HCL HCM9LWAN21 User manual

19"W LCD Color Monitor HCLHCM9LWAN21
1
Service
Service
Service
HorizontalFrequency
30-83kHz
TABLE OF CONTENTS
Description Page Description Page
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
Table Of Contents…………………………………………...1
Revision List………………………………………………....2
Important Safety Notice.…….........................……...... 3
1. Monitor Specification..............................…………........4
2. LCD Monitor Description…………………………….......5
3. Operation Instructions....................................…...........6
3.1. General Instructions...........................…....................6
3.2. Control Button…………………………….…...............6
3.3 Adjusting the Picture.................................…..............7
4. Input/Output Specification............……………...............9
4.1. Input Signal Connector............…………....................9
4.2. Factory Preset Display Modes......….........................9
4.3. Panel Specification.....………………........................10
5. Block Diagram….........................................................13
5.1 Software Flow Chart……………………….……….13
5.2.Electrical Block Diagram……………………….......15
6. Schematic……………..............................................17
6.1 Main Board....……….............................................17
6.2 Power Board………………………………………....22
7. PCB Layout..………….............................................25
7.1. Main Board………................................................25
7.2. Power Board….....................................................26
8. Maintainability………...............................................29
8.1.Equipments and Tools Requirement......................29
8.2.Trouble Shooting………........................................30
9. White-Balance, Luminance adjustment………..…...35
10. Monitor Exploded View…………………….…........37
11. BOM List…............................................................38
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

19"W LCD Color Monitor HCLHCM9LWAN21
2
Revision List
Version Date Revision History TPV Model Name
A00 Nov.-12-08 Initial release T973RDNCWCKLNN

19"W LCD Color Monitor HCLHCM9LWAN21
3
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performing service
operations. Some of these service operations require the use of tools specially designed for the purpose. The
special tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics may create shock,
fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from AOC.
AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)

19"W LCD Color Monitor HCLHCM9LWAN21
4
1. Monitor Specification
Driving system TFT Color LCD
Viewable Image Size 481mm diagonal
Pixel pitch 0.2835mm( H ) × 0.2835mm( V )
LCD Panel
Video R,G,B Analog Interface
Separate Sync. H/V TTL
H-Frequency 30kHz – 83kHz
Input
V-Frequency 55-75Hz
Display Colors 16.7M Colors
Dot Clock 135MHz
Max. Resolution 1440 × 900 @60Hz
Plug & Play VESA DDC 2BTM
EPA ENERGY STAR®ON Mode ≤36W
OFF Mode ≤2W
Input Connector 15-pin D-Sub
Input Video Signal Analog:0.7Vp-p(standard), 75 OHM, Positive
Horizontal : 410mm
Maximum Screen Size
Vertical : 256mm
Power Source 100~240VAC,47~63Hz
Operating Temp: 5° to 50°C
Storage Temp.: -20° to 60°C
Environmental Considerations
Operating Humidity: 10% to 85%
Dimension 440×356×215 (W ×H×D)mm
Weight (N. W.) 4kg Unit (net)
Power Consumption ( Maximum ) 36 Watts
Regulatory Compliance UL, CE, FCC

19"W LCD Color Monitor HCLHCM9LWAN21
5
2. LCD Monitor Description
The LCD Monitor will contain a main board, an adapter board and an inverter board which house the flat panel
controllogic,brightnesscontrollogicandDDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Video signal, DDC
Power Board
(
Include ada
p
ter and inverter
)
Flat Panel and
CCFL backlight
Main Board RS232 Connector
For white balance
adjustment in
factory mode
HOST Computer
CCFT Drive.
AC-IN
100V~240V
Monitor Block Diagram

19"W LCD Color Monitor HCLHCM9LWAN21
6
3. Operation Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the
monitor. By changing these settings, the picture can be adjusted to your personal preferences.
•The power cord should be connected.
•Connect the video cable from the monitor to the video card.
•Press the power button to turn on the monitor position. The power indicator will light up.
3.2 Control Buttons
External Control Button
1. Power Key
2. LED
3. MENU/ENTER
4. Contrast
5. Brightness
6. Auto Adjust Key/Exit
Front Panel Control
•Power Button:
Press this button to switch ON/OFF of monitor’s power.
•MENU / ENTER:
Activate OSD menu when OSD is OFF or activate/de-activate adjustment function when OSD is ON or Exit OSD
menu when in Brightness/ Contrast Adjust OSD status.
•Contrast:
Adjust contrast or function adjust.
•Brightness:
Adjust brightness or function adjust.
•Auto Adjust button / Exit:
1. When OSD menu is in active status, this button will act as EXIT-KEY (EXIT OSD menu).
2. When OSD menu is in off status, press this button over 2 seconds to activate the Auto Adjustment function.
The Auto Adjustment function is used to set the HPos, VPos, Clock and Focus.
•Power Indicator:
Green — Power On mode.
Red — Off mode.
OSD Lock Function: To lock the OSD, press and hold the MENU button while the monitor is off and then press

19"W LCD Color Monitor HCLHCM9LWAN21
7
power button to turn the monitor on. To un-lock the OSD - press and hold the MENU button while the monitor is off
and then press power button to turn the monitor on.
3.3 Adjusting the Picture
•OSD Settings
1. Press the MENU-button to activate the OSD window.
2. Press or to navigate through the functions. Once the desired function is highlighted, press the
MENU-button to activate it. If the function selected has a sub-menu, press or again to navigate through the
sub-menu functions. Once the desired function is highlighted, press MENU-button to activate it.
3. Press or to change the settings of the selected function.
4. To exit and save, select the exit function. If you want to adjust any other function, repeat steps 2-3.
The OSD Message
•OSD functions
Main Menu
Item
Main
Menu
Icon
Sub Menu Item Sub Menu
Icon Description
Contrast
Contrast from Digital-register.
Luminance
Brightness
Backlight Adjustment.
Focus
Adjust Picture Phase to reduce Horizontal-Line
noise.
Image Setup
Clock
Adjust picture Clock to reduce Vertical-Line noise.
H. Position
Adjust the horizontal position of the picture.
Image Position
V. Position
Adjust the vertical position of the picture.

19"W LCD Color Monitor HCLHCM9LWAN21
8
Main Menu
Item
Main
Menu
Icon
Sub Menu Item Sub Menu
Icon Description
Warm N/A Recall Warm Color Temperature from EEPROM.
Cool N/A Recall Cool Color Temperature from EEPROM.
sRGB N/A Recall sRGB Temperature from EEPROM.
User / Red
Red Gain from Digital-register.
User / Green
Green Gain from Digital-register.
Color Temp.
User / Blue
Blue Gain from Digital-register.
Yes N/A
Auto Adjust the H/V Position, Focus and Clock of
picture.
Auto Config
No N/A
Do not execute Auto Config, return to main menu.
H. Position
Adjust the horizontal position of the OSD.
V. Position
Adjust the vertical position of the OSD.
OSD Setup
OSD Timeout
Adjust the OSD timeout.
Language
Language N/A Select the language you like.
Information
Information N/A
Show the resolution, H/V frequency and input port
of current input timing.
Yes N/A Clear each old status of Auto-configuration.
Reset
No N/A Do not execute reset, return to main menu.
Exit
N/A N/A Exit OSD.

19"W LCD Color Monitor HCLHCM9LWAN21
9
4. Input/Output Specification
4.1 Input Signal Connector
Pin No. Description Pi N No. Description
1. Red 9. +5V
2. Green 10. Detect Cable
3. Blue 11. Ground
4. Ground 12. DDC-Serial Data
5. Ground 13. H-Sync
6. R- Ground 14. V-Sync
7. G- Ground 15. DDC-Serial Clock
8. B- Ground
15 - Pin Color Display Signal Cable
15
610
11 15
4.2 Factory Preset Display Modes
Stand Resolution
Horizontal
Frequency(KHz)
Vertical
Frequency(Hz)
Dos-mode 720×400 31.47kHz 70.0Hz
640×480 31.47kHz 60.0Hz
VGA
640×480 37.50kHz 75.0Hz
800×600 37.879kHz 60.0Hz
SVGA
800×600 46.875kHz 75.0Hz
1024×768 48.363kHz 60.0Hz
1024×768 56.476kHz 70.0Hz
XGA
1024×768 60.021kHz 75.0Hz
1280 × 1024 64.000kHz 60.0Hz
SXGA
1280 × 1024 80.000kHz 75.0Hz
WXGA+ 1440×900 55.935kHz 59.8Hz

19"W LCD Color Monitor HCLHCM9LWAN21
10
4.3. Panel Specification
4.3.1 General Feature

19"W LCD Color Monitor HCLHCM9LWAN21
11
4.3.2 Optical Characteristics

19"W LCD Color Monitor HCLHCM9LWAN21
12
4.3.3 Electrical Characteristics
TFT LCD Module
Backlight Unit

19"W LCD Color Monitor HCLHCM9LWAN21
13
5. Block Diagram
5.1 Software Flow Chart
1
2
N
Y
5
Y
N
10
Y
N
12
Y
N
7
Y
N
6
4
3
8
9
14
11
13
Y
N
15
Y
N
16
17
19
Y
N
18

19"W LCD Color Monitor HCLHCM9LWAN21
14
Remark:
1) MCU initialize.
2) Is the EEprom blank?
3) Program the EEprom by default values.
4) Get the PWM value of brightness from EEprom.
5) Is the power key pressed?
6) Clear all global flags.
7) Are the AUTO and SELECT keys pressed?
8) Enter factory mode.
9) Save the power key status into EEprom.
Turn on the LED and set it to green color.
Scalar initializes.
10) In standby mode?
11) Update the lifetime of back light.
12) Check the analog port, are they’re any signals coming?
13) Does the scalar send out an interrupt request?
14) Wake up the scalar.
15) Are there any signals coming from analog port?
16) Display "No connection Check Signal Cable" message. And go into standby mode after the message
disappears.
17) Program the scalar to be able to show the coming mode.
18) Process the OSD display.
19) Read the keyboard. Is the power key pressed?

19"W LCD Color Monitor HCLHCM9LWAN21
15
5.2 Electrical Block Diagram
Main Board
Panel Interface
(CN601)
Crystal
24MHZ
(X401)
MCU RTD2120L
(U401)
Scalar RTD2025L
(Include ADC, OSD)
(U501)
D-Sub Connector
(CN301)
H sync
V sync
RGB

19"W LCD Color Monitor HCLHCM9LWAN21
16
Power Board
AC input
100V~240V
VEMI filter Rectifier Transformer Output
Rectifier
12V Inverter
Circuit
Power Switching
Sense Resistor
PWM Control IC
IC Power Supply
Photo Couple Sampling
12V DC Switching MOS Transformer Resonance NET High Voltage Output
IC Power Supply
Converter PWM Control IC Open Lamp Protection
Current Sampling

19"W LCD Color Monitor HCLHCM9LWAN21
17
6. Schematic
6.1 Main Board
715G2507 1 2
1 2
ZD201
UDZSNP5.6B
R203 10K 1/16W 5%
FB201
120OHM
FB202
NC
G2507-B-2-X-3-070922
R204 3.9K OHM 1/16W
1
2
3
4
5
6
7
8
CN202
CONN
C209
0.1uF/16V
1 2
ZD202
UDZSNP5.6B
KEY0 {4}
MVC C
LED_R
KEY1 {4}
* BKLT-EN High ON(3.3V)
Q204
PMBS3906
Auto
Bright
+
C203
100uF 16V
TPV （ Top Victory ） Electronics Co.,Ltd
Contrast
Menu
1
2
3
4
5
6
CN201
CONN
BKLT-EN
VCC3
R205 3.9K OHM 1/16W
DIM# {4}
VCC3
R206 10K 1/16W 5%
BKLT-VBRI
C201
0.1uF/16V
+
C202 C204
0.1uF/16V
1 2
ZD203
UDZSNP5.6B
Q205
PMBS3906
CMVCC
CMVCC
LED_R# {4}
LED_G# {4}
LED_G
CMVCC
F
Back light
Dimming(0.5V~3V)
C205
0.1uF/16V
C206
0.1uF/16V
VSS
1
VOUT 2 VIN
3
U201
AP1117E33LA
LED_R
C210
0.1uF/16V
LED_G
BKLT-EN
POWER_KEY # POWER_KEY # {4}
VCC3
R210 10K 1/16W 5%
R213 10K 1/16W 5%
Title
Size Document Number Rev
Date: Sheet of
02.POWER
A
26Saturday , September 22, 2007
R207
120R 1/16W 5%
R208
120R 1/16W 5%
R201
200 OHM 1/16W
INV_ON# {4}
R202
4K7 1/16W 5%
Q202
PMBS3904

19"W LCD Color Monitor HCLHCM9LWAN21
18
03.input
VGA_G-
C315
0.1uF /16V
C305
5pF/50V
C304
0.047uF
C309
0.047uF
C307
0.047uF
C306
0.047uF
C301
0.047uF
C311
0.047uF
VGA_R-
DDC1_SDA{4}
DDC1_SCL{4}
G2507-B-2-X-3-070922
DSUB_V
1 2
ZD302
UDZS5. 6B
R326
NC/100K 1/ 16W 5%
1 2
ZD303
UDZS5. 6B
Q301
NC/PMBS3904
DSUB_V {4}
R327
NC/4K7 1/16W 5%
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
17 16
CN301
DB15
VGA_CON
DVI _5V
R311
100R 1/16W 5%
GND POWER DGND
RTD_B- {5}
RTD_B+ {5}
RTD_R+ {5}
RTD_R- {5}
RTD_G- {5}
RTD_G+ {5}
R307
75R 1/16W 5%
3
1 2
D302
BAV99
RTD_V {5}
RTD_H {5}
D312
NC/UDZS5.6B
C316
NC/0. 1uF/16V
R306 360R OHM 1/16W 5%
R313
360R OHM 1/16W 5%
R309 360R OH M 1/16W 5%
R310
75R 1/16W 5%
DAT2- 1
DAT2+ 2
2/4s hield 3
DAT4- 4
DAT4+ 5
DDC SCL 6
DDC SDA 7
VSYNC 8
R25
HSYNC 28
DAT1- 9
DAT1+ 10
1/3s hield 11
DAT3- 12
DAT3+ 13
+5V 14
SYNC GND 15
HPD 16
G26
RGB GND 29
DAT0- 17
DAT0+ 18
0/5s hield 19
DAT5- 20
DAT5+ 21
clk shield 22
clk+ 23
clk- 24
B27
GND
32
GND
31
CN302
NC/JACK
R301 100R 1/16W 5%
C303
33pF
R317 NC/100R 1/16W 5%
D313
NC/UDZS5.6B
1 2
ZD305
UDZS5.6B
R303 100R 1/16W 5%
3
1 2
D301
BAV99
DDC2_SCL
R305
2K2 1/16W 5%
C302
33pF
R304
2K2 1/16W 5%
1 2
ZD304
UDZS5.6B
R314
75R 1/16W 5%
R312 360R OH M 1/16W 5%
DSUB_5V
3
1 2
D303
BAV99
R302 0R 05 1/16W
R315
360R OHM 1/16W 5%
1 2
FB 302
BEAD
R308 360R OH M 1/16W 5%
C308
5pF/50V
C310
5pF/ 50V
F
1 2
FB 301
BEAD
1 2
FB 303
BEAD
TPV （ Top Victory ） Electronics Co.,Ltd
RX0P {5}
RX0N {5}
RX2P {5}
RX1N {5}
RX1P {5}
RXCP {5}
RX2N {5}
RXCN {5}
R318 NC/10R 1/16W 5%
RX0P
RX0N
RX1P
RX1N
RX2P
RX2N
R319 NC/10R 1/16W 5%
R320 NC/10R 1/16W 5%
R321 NC/10R 1/16W 5%
R322 NC/10R 1/16W 5%
R323 NC/10R 1/16W 5%
R324 NC/10R 1/16W 5%
RXCP
RXCN
R325 NC/10R 1/16W 5%
C317
NC/0. 1uF/16V
D315
NC/UDZS5.6B
3
1 2
D304
NC/BAV99
DDC2_SCL {4}
R316 N C/10K 1/16W 5%
D310
NC/UDZS5.6B
3
1 2
D305
NC /BAV99
DVII_DETECT {4}
DDC2_SDA {4}
HOT_PLUG
HPD_CTL
DDC2_SDA
FB304
NC/150 OH M
3
1 2
D306
NC/BAV99
3
1 2
D307
NC/BAV99
3
1 2
D308
NC /BAV99
3
1 2
D309
NC/BAV99
DDC1_SDA
DSUB_H
DSUB_5V
VGA_B+
3
1 2
D311
NC/BAV99
RTD_B-
RTD_B+
RTD_R-
RTD_R+
RTD_G+
RTD_G-
DDC1_SCL
CMVCC
CMVCC
FB305
NC/150 OH M
1 2
ZD 307
UDZS5.6B
1 2
ZD 301
UDZS5.6B
3
1 2
D314
NC/BAV99
DSUB_CONNECT {4}
VGA_R-
VGA_G-
VGA_G+
VGA_R+
VGA_G+ VGA_R+
VGA_B+
VGA_B-
VGA_G+
VGA_B+
VGA_B-
VGA_R+
Tit le
Size Document Number Rev
Date: Sheet of
B
36Saturday , Sept ember 22, 2007

19"W LCD Color Monitor HCLHCM9LWAN21
19
Tit l e
Size Document Number Rev
Dat e: Sheet of
04.MCU/RTD2120L
B
46Saturday , September 22, 2007
D403
LL4148
CMVCC
R407
NC/10K 1/16W 5%
DDC2_SCL
DDC2_SDA R440 100R 1/16W 5%
C404
NC/0.1uF/16V
DDC2_SDA{3}
R441 100R 1/ 16W 5%
DDC2_SCL{3}
R410 NC/100R 1/16W 5%
DDC1_SCL{3} DDC1_SDA
DDC1_SCL
R411
4K7 1/16W 5%
R412
4K7 1/16W 5%
R4134K7 1/16W 5% R4144K7 1/16W 5%
R426 22R 1/16W 5%
R428 22R 1/16W 5%
KEY0 {2}
KEY1 {2}
MCU_VCC_S
MC U _V C C _S
MC U _V C C
R445 4K7 1/16W 5%
KEY1
R429 0R05 1/ 16W
G2507-B-2-X-3-070922
CRYSTAR_OUT
R438
3.9K OHM 1/16W
POWER_KEY #
DDC1_SDA{3}
R430 100R 1/ 16W 5%
DIM#
INV_ON#
DVII_DETECT{3}
1 2
X401
24mhz
MC U _V C C
INV_ON#{2}
R442 100R 1/ 16W 5%
R444 4K7 1/16W 5% R443 4K7 1/16W 5%
A0
1
A1
2
A2
3
GND
4SDA 5
SCL 6
WP 7
VCC 8
U403
NC/24LC16B/SN G
R419
NC
MC U _V C C
C406
0.1uF/16V
LED_G#
IICSCL
IICSDA
RTD_SD3/SDI
RTD_SCLK
DSUB_CONNECT
R415
6K8 1/16W 5%
R416
10K 1/16W 5%
C403
0.1uF/16V
DSUB_CONNECT {3}
PPWR_ON#
DIM#{2}
R439
6K8 1/16W 5%
LED_R#
VCC3
R432 100R 1/ 16W 5%
1
3
2
D401
NC
PPWR_ON#{6}
Closed to X'tal
DSUB_V {3}
MC U _V C C
+
C408
NC
R421
NC
FB401
150 OHM
MCU_RESET
F
R436
10K 1/16W 5%
HPD_CTL
{5}
R409 NC/100R 1/16W 5%
R408 NC/100R 1/16W 5%
R406
NC/10K 1/16W 5%
+
C405
10uF/50V
R405
NC/10K 1/16W 5%
R427 NC DSUB_VDSUB_V1
MC U _V C C
R451
4K7 1/16W 5%
WP
R453
1K 1/16W 5%
KEY0
POWER_KEY # {2}
PANEL_VCC
MC U _V C C
R424 1K 1/16W 5%
IICSDA
IICSCL
MCU_RESET
MVC C
C410
0.1uF/16V
TPV （ Top Victory ） Electronics Co.,Ltd
LED_G#{2}
LED_R#{2}
BAT54C
RTD_SCLK {5}
RTD_SD3/SDI {5}
1
Closed to MCU
2
P5.5/PWM5
1
DSCL2/P5.6
2
DSDA2/P5.7
3
RST 4
ASCL1/P3.0/RXD
5
NC
6
NC
7
ASDA1/P3.1/ TXD
8
VSS
17
XO
15
VCC 41
P1.0/T2 40
P1.1 39 P1.2 38 P1.3 37 P1.4 36 P1.5 35 P1.6 34 P1.7 33
NC
19
VSYNC 28
NC 29
P6.0/ADC0 20
P6.1/ADC1 21
P6.2/ADC2 22
P6.3/ADC3 23
P6.4 24
P6.5 25
P6.6/CLKO1 26
P6.7 27
XI
16
P3.2/INT0
9
P3.3/INT1
10
P3.4/T0
11
P3.5/T1
12
P7.6/CLKO2
13
P7.7
14
NC
18
NC 30
NC 31
NC 32
NC
43 NC 42
P5.0/PWM0
44
P5.1/PWM1
45
P5.2/PWM2
46
P5.3/PWM3
47
P5.4/PWM4
48
RTD2120L
U401
RTD2120L-LF
C401
10pF
C402
1uF 10V
C412
1uF 10V
Q401
PMBS3904
3
DSUB_5V
MCU_VCC_S
R425
10K 1/16W 5%
MC U _V C C _S
C411
10pF
R437
3.9K OHM 1/16W
MCU_VC C
U402
AZ431AN-AE1
R401
3.9K OHM 1/16W
DVI_5V
R431
6K8 1/16W 5%
WP
R404
10K 1/16W 5%
R403
3.9K OHM 1/16W
R402
1K 1/16W 5%
C409
NC
D402
BAV70
CRY STAR_OUT {5}
MCU_VCC_S
R433 100R 1/16W 5%
CMVCC

19"W LCD Color Monitor HCLHCM9LWAN21
20
Tit le
Size Document Number Rev
Dat e: Sheet of
05.RTD2525L
B
56Saturday , Septem ber 22, 2007
FB502
120OHM
CRYSTAR _OUT
DGND
RXE2+
RXE1+
RTD_R-
RXE0+
RX2N {3}
C507
0.1uF /16V
C501
0.1uF /16V
C506
0.1uF /16V
R1.8DVCC
RTD_G+
Q501
KN2907AS
Q502
KN2907AS
DGND
R1.8DVCC
DGND
G2507-B-2-X-3-070922
R507 3.3 OHM 2W
RXE3+
V1/REXT
1
V2/RX1P
2
V3/RX1N
3
V4/RX0P
4
V5/RX0N
5
V6/RXCP
6
V7/RXCN
7
AVS
8
AHS
9
ADC_GND
10
B-
11
B+
12
G-
13
G+
14
R-
15
R+
16
ADC_VDD
17
BJT_B
18
VCCK
19
PGND
20
TXE3+
21
TXE3-
22
TXE2+
23
TXE2-
24
TXO1- 36
TXO1+ 35
TXO2- 34
TXO2+ 33
TXOC- 32
TXOC+ 31
TXO3- 30
TXO3+ 29
TXE0- 28
TXE0+ 27
TXE1- 26
TXE1+ 25
V0/RX2N 48
VCLK/RX2P 47
TMDS_VDD 46
XIN 45
DDCSCL/PWM0 44
DDCSD A/PWM 1/IRQ 43
SCL 42
SDA 41
VCCK 40
PGND 39 TXO0- 38
TXO0+ 37
U501
RTD2025L QFN-48
RXO1+
RXO1- LVDS_O[0. .9] {6}
LVDS_E[0..9] {6}
RTD_SD 3/SDI
VCC3
RTD_SCLK
RXO0-
VCC3
VCC3
RTD_V{3}
RTD_H{3}
RTD_B+{3}
RTD_B-{3}
RTD_G-{3}
RTD_R-{3}
RTD_G+{3}
RTD_R+{3}
CRYSTAR_OUT {4}
RTD_DDCSCL RTD_DDCSDA
RTD_SCLK {4}
DDC2_SCL{4}
RTD_SD 3/SDI {4}
DDC2_SDA{4}
TMDS_ VDD
TMDS_VDD
RX1P{3}
RX0P{3}
F
RX2P {3}
R1.8DVCC
C503
0.1uF /16V
RTD_G-
RTD_R+
BJT_B
RTD_H
RXO3-
RXOC+
RXO2-
RTD_B-
RXO3+
RXO0+
RXE1-
RXE0-
R1.8DVCC
RXOC-
RXE2-
RTD_B+
RXE3-
RTD_V
R1.8DVCC
R508 100R 1/16W 5%
R509 100R 1/16W 5%
RTD_DDCSDA
RTD_DDCSCL
RXO2+
RXOC-
RXOC+
TPV （ Top Victory ） Electronics Co.,Ltd
BJT_B
FB501
150 OHM
RX0N
RXCP
RX1P
RXCN
RX1N
RX0P
RX2N RX2P
RX0N{3}
RX1N{3}
LVDS_O2 RXO1-
LVDS_E4 R XE2-
LVDS_E8 R XE3-
RXEC+LVDS_E7
RXEC-LVDS_E6
LVDS_O0 RXO0-
RXO3+LVDS_O9
RXCN{3}
RXCP{3}
LVDS_O7 RXOC+
RXO2+LVDS_O5
LVDS_E0 R XE0-
LVDS_O6 RXOC-
RXO2-LVDS_O4
LVDS_O1 RXO0+
LVDS_O8 RXO3-
RXE1+LVDS_E3
RXE1-LVDS_E2
LVDS_E1 R XE0+
LVDS_O3 RXO1+
LVDS_E9 R XE3+
LVDS_E5 R XE2+
1.8AVCC
DGND
TMDS_VDD
C502
0.1uF /16V
R503
1K 1/16W 5%
FB503
120OHM
+
C505
22uF50V
