HDC Kurzweil KP300X User manual

C
M
Y
CM
MY
CY
CMY
K
KP300X_1.pdf 1 2018-06-28 오전 11:03:33

02
INFORMATION FOR YOUR SAFETY!
THE FCC REGULATION WARNING (for USA)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Unauthorized changes or modification to this system can
void the user's authority to operate this equipment.
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
Power Supply
Please connect the designated DC adaptor to an AC outlet
of the correct voltage.
Do not connect it to an AC outlet of voltage other than that
for which your instrument is intended.
Unplug the DC power adaptor when not using the instru-
ment, or during electrical storms.
Connections
Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.
Location
Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields
Interference with other electrical devices
Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.
Cleaning
Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into the instru-
ment. If this happens, remove the electric plug from the
outlet. Then have the instrument inspected by qualified
service personnel.
Disconnect all cables before moving the instrument.
CAUTION
The normal function of the product may be disturbed
by Strong Electro Magnetic Interference. If so, simply
reset the product to resume normal operation by
following the owner's manual. In case the function
could not resume, please use the product in other
location.
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 2 17/12/12 17:59

03
Contents
Panel & Display Description
Front Panel............................................................................4
Rear Panel............................................................................6
LCD Display...........................................................................6
Setup
Power Supply........................................................................7
Setting a Music Stand...........................................................7
Connecting a Sustain Pedal..................................................7
Connecting a Volume Pedal..................................................7
Connections
Connecting a pair of Headphones.........................................8
Connecting an Audio Equipment...........................................8
Connecting an MP3/CD Player.............................................8
Connecting a Computer........................................................8
Connecting a USB Flash Drive.............................................8
Playing the Demos..............................................................9
Playing Voices
Playing Voices.......................................................................9
Playing Two Voices Simultaneously.....................................10
Playing Different Voices with Both Hands.............................10
Touch...................................................................................10
Sustain.................................................................................11
Portamento..........................................................................11
Pitch Bend...........................................................................11
Modulation...........................................................................11
Transpose............................................................................11
Octave.................................................................................11
Piano Mode.........................................................................12
Metronome..........................................................................12
Freesolo..............................................................................12
Auto Accompaniment
Playing Auto Accompaniment (rhythm track only)...............13
Playing Auto Accompaniment (all tracks)............................13
Accompaniment Sections....................................................13
Playing Different Accompaniment Sections.........................14
Fade In/Out.........................................................................14
Accompaniment Volume......................................................15
Chord Basics.......................................................................15
Tempo.................................................................................16
One Touch Setting...............................................................16
Harmony.............................................................................17
Performance Assistant
Enter the Performance Assistant.........................................18
Guitar Mode........................................................................18
Playing in Guitar Mode........................................................18
Piano Mode.........................................................................19
Playing in Piano Mode.........................................................19
Exit the Performance Assistant...........................................19
Synth
Enter the Synth....................................................................20
Create User Voice...............................................................20
Exit the Synth......................................................................20
DSP Effect..........................................................................21
Mixer...................................................................................21
Pedal Function
Volume Pedal......................................................................22
Sustain Pedal (Assignable).................................................22
Album.................................................................................23
Other Functions
Tune....................................................................................24
Beat.....................................................................................24
Split Point............................................................................25
Pedal Assign.......................................................................25
Harmony..............................................................................25
Fade In................................................................................26
Fade Out.............................................................................26
Portamento Time.................................................................26
Reverb Type........................................................................26
Reverb Level.......................................................................26
Chorus Type........................................................................27
Chorus Level.......................................................................27
MIDI In.................................................................................27
MIDI Out..............................................................................27
Auto Power Off....................................................................27
Registration Memory
Registering the Panel Settings............................................28
Recalling the Registered Panel Settings.............................28
Selecting a Registration Bank.............................................28
Freezing the Accompaniment Parameter............................28
Song Recording
Start Recording...................................................................29
Stop Recording....................................................................30
Play back Recording...........................................................30
Delete Recording.................................................................30
Song
Listening to the Songs.........................................................31
Song Control.......................................................................31
Lesson Mode.......................................................................31
Chord Dictionary
DICT1 (Chord Learning Mode)............................................33
DICT2 (Chord Testing Mode)..............................................33
Connecting USB Flash Drive
Common Operation.............................................................34
Play.....................................................................................34
Load....................................................................................35
Save....................................................................................36
Delete..................................................................................36
Format.................................................................................36
Keyboard and ASCII Character Relative Table...................36
MIDI
What's MIDI?.......................................................................37
Downloading Data from the Computer................................37
Troubleshooting................................................................38
Specifications....................................................................39
Appendices
Voice List.............................................................................40
Style List..............................................................................47
Song List ............................................................................50
Demo List............................................................................52
Album List...........................................................................53
MIDI Implementation Chart.................................................54
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 3 17/12/12 17:59

Panel & Display Description
Front Panel
04
1. POWER Button
Turn the power on and off.
2. VOLUME Knob
Adjust the master volume.
3. STYLE SELECT Button
Directly set a preset style.
4. ACCOMP +/- Buttons
Press to adjust the Accompaniment
volume.
5. TEMPO+/- Buttons
Press to edit the tempo value.
6. FADE IN/OUT Button
Press it to turn the Fade In or Fade
Out on.
7. SYNC STOP Button
Press it to turn the Sync Stop
function on and off.
8. SYNC START Button
Press it to turn the Sync Start
function on and off.
9. CHORD MODE Button
Press it to enter Chord mode.
10. INTRO1/ENDING1 Button
Play the Intro or Ending pattern 1.
11. INTRO2/ENDING2 Button
Play the Intro or Ending pattern 2.
STYLE MODE：
12. FILL A Button
Play the Fill-in pattern A.
13. FILL B Button
Play the Fill-in pattern B.
14. FILL C Button
Play the Fill-in pattern C.
15. FILL D Button
Play the Fill-in pattern D.
16. START/STOP Button
Start or stop playing a style.
SONG MODE：
12. PAUSE Button
Pause or continue song playback.
13. REW Button
Rewind the song playback.
14. FF Button
Fast forward the song playback.
15. REPEAT A/B Button
Set the beginning and the end for
a loop section of a selected song.
16. START/STOP Button
Start or stop playing a song.
17. LCD Display
Show all the important settings
for the current operation.
18. L Button
Choose to practice the left hand
part in Lesson Mode.
19. R Button
Choose to practice the right hand
part in Lesson Mode.
CHORD DICT. Button
Hold the button to enter the Chord
Dictionary.
20. LESSON Button
Press it to enter Lesson mode.
21. RECORD Button
Press it to enter Recording mode.
22. FREEZE Button
Press it to turn the Freeze function
on or off.
23. PERFORM. Button
Press it to turn the Performance
Assistant function on and off.
24. SYNTH Button
Press it to enter the Synth menu.
25. FREESOLO Button
Press it to turn the FreeSolo
function on and off.
26. MIXER+/- Buttons
Press to enter the Mixer menu.
27. FUNCTION+/- Buttons
Press to enter the Function menu.
1
11
2
20
12 13 14 15 16
17
18 19
5
6789
10
4
3
21 22 27
23 25 2624
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 4 17/12/12 17:59

Panel & Display Description
05
36 37 38 39
40
41 42 43 44 45
46 47 48 49
50 51 52 53
54
55
30
31
33 34 35
29
32
28. STYLE Button
Press to enter Style Mode.
29. VOICE Button
Press it to enter Voice Mode.
Press STYLE Button and VOICE
Button at the same time to enter
Demo Mode.
30. SONG Button
Press it to enter Song Mode.
ALBUM Button
Hold it to turn on the Album function.
31. BANK Button
Press it to select a bank.
32. STORE Button
Save current panel settings to one
of the memories.
Press [STORE] and [M1] together
to save the settings to M1.
ACCOMP Button
In Record mode, press it to select
the accompaniment track for
recording.
33~38. M1-M6 Buttons
In Memory mode, recall panel
settings from one of the memories.
M1-M4 Buttons
In O.T.S. mode, recall voice settings
that match the current style.
MELODY 1-MELODY 5 Buttons
In Record mode, select the melody
1-5 track for recording.
39. O.T.S. Button
Press it to turn the One Touch
Setting function on or off.
40. VOICE SELECT Buttons
Directly set a preset voice.
41. DUAL Button
Press it to turn the Dual function
on and off.
42. LOWER Button
Press it to turn the Lower function
on and off.
43. TOUCH Button
Press it to edit the Touch
Response setting.
44. SUSTAIN Button
Press it to turn the sustain function
on and off.
45. DSP Button
Press it to turn the DSP effect on
and off.
46. DATA DIAL
Adjust the parameters.
47. METRONOME Button
Press it to turn the metronome on
and off.
48. TRANSPOSE +/- Buttons
Press to edit the transpose value.
49. HARMONY Button
Press it to turn the harmony effect
on and off.
50. +/YES, -/NO Buttons
Adjust the parameters.
51. PIANO Button
Press it to turn the Piano Mode
on and off.
52. OCTAVE+/- Buttons
Press to edit the octave value.
53. USB DEVICE Button
Press it to enter USB Device mode.
54. PORTAMENTO Button
Press and hold it when playing the
keyboard to apply portamento effect
to the notes.
55. PITCH BEND/MODULATION
Bend notes left or right (pitch bend).
Apply a vibrato effect (modulation).
28
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 5 17/12/12 17:59

Panel & Display Description
06
Rear Panel
1. USB TO DEVICE
Connect a USB flash drive.
2. USB TO HOST
Connect to a computer.
3. SUSTAIN Jack
Connect a sustain pedal.
4. VOLUME Jack
Connect a volume pedal.
5. PHONES Jack
Connect a pair of stereo headphones.
6. AUX OUT Jack
Connect an audio equipment.
7. AUX IN Jack
Connect an external audio source,
such as an MP3 or CD player.
8. DC IN Jack
Connect the specified power adaptor.
1. SYNC STOP
2. TOUCH
3. SYNTH
4. ALBUM
5. PERFORM.H
6. FREE SOLO
7. SERIAL NUMBER
8. VOICE/STYLE/DEMO/SONG
9. DIR/FILE
10. RECORD
11. TREBLE CLEF
12. BASS CLEF
13. USB
14. USB DEVICE
15. STRING
16. MEASURE
17. BEAT
18. TEMPO
19. CHORD
20. MEMORY
21. FREEZE
22. ONE TOUCH SETTING
23. MEMORY BANK
24. A.B.C./FULL RANGE
25. FADE
26. SECTION A/B/C/D
27. NUMBERED NOTATION
28. LESSON
29. LEFT HAND
30. RIGHT HAND
31. DUAL
32. LOWER
33. HARMONY
34. DSP
35. SUSTAIN
36. ACCOMP
37-41. MELODY 1-5
LCD Display
1
2
3
4
5
89
10
11
12
13 14
15
17
19
20
21
23
24
25
26
27 28
29 30
31
33
35
36
37
38
39
40
41
6
16
7
22
32
34
18
12567 8
4
3
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 6 17/12/12 17:59

This section contains information about setting up your instrument
and preparing to play. Please go through this section
carefully before turning the power on.
Power Supply
1. Make sure that the piano is turned off. Before you switch your
piano on or off, turn down the volume of piano and any
connected audio equipments first.
2. Connect the AC adaptor to the DC IN jack on the rear panel.
3. Plug the AC adaptor into an AC outlet.
4. Press the [POWER] switch. The LCD will light up, indicating the
instrument is powered on.
5. When you are ready to turn off the instrument, press the [POWER]
switch again.
Notes:
1. In order to save energy, the instrument will automatically shut down
in 30 minutes when not in use. (Please refer to Auto Power Off).
2. For your safety, please unplug the instrument when it is not in use
or during a thunderstorm.
Setting a Music Stand
A music stand is supplied with the instrument. You can easily attach it
to the instrument by inserting it into the slots at the rear of the panel.
Connecting a Sustain Pedal
An optional footswitch can be plugged into the sustain jack and
be used to switch sustain on or off. Simply by pressing the pedal, you
will have a natural sustain as you play.
Connecting a Volume Pedal
An optional volume control can be plugged into the volume jack for
adjusting the volume of sound.
Setup
07
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 7 17/12/12 17:59

Connecting a pair of Headphones
Plug a pair of standard stereo headphones into the PHONES jack
for private practice or late-night playing. When headphones are
connected, the internal speakers will be muted, and the sound can
only be heard from the headphones.
Note:
Do not use headphones at high volume for long periods of time.
Doing so may cause hearing loss.
Connecting an Audio Equipment
The AUX OUT jack delivers the output of the instrument to external
audio equipment such as a keyboard amplifier, stereo sound
system, mixing console, or recording interface. Use an audio cable
to connect the AUX OUT jack of the instrument to the INPUT jack of
the external audio equipment.
Note:
To avoid damaging the speakers, please set the master volume
level to minimum before connecting the power and other devices.
Connecting an MP3/CD Player
The AUX IN jack receives audio signals from an external audio
source such as an MP3 or a CD player. Use an audio cable to
connect the AUX IN jack of the instrument to the OUTPUT jack of
an MP3/CD player. The instrument’s speakers will play the music
transmitted from the external player, and you can play along.
Connecting a Computer
Use a standard USB cable to connect the USB jack of the instru-
ment to the USB port of a computer. With USB, you can save a
keyboard performance to the computer or use the instrument to
play back music played on the computer.
Connecting a USB Flash Drive
Connect a USB flash drive to the instrument to save the data you’ve
created to the USB flash drive. You can also load files from a USB
flash drive to the instrument, or use the instrument to play back files
saved on USB flash drive.
Note:
To avoid errors or damaging the USB flash drive, do not remove it
when reading or writing is in progress
Connections
08
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 8 17/12/12 17:59

The instrument features several professional demos. Please refer to
DEMO LIST.
1. Press the [STYLE] and [VOICE] buttons at the same time to start
playing the demo.
2. Select a demo song.
Use the data dial, the [+/YES] button or the [-/NO] button to select a
demo.
3. Rotate the [VOLUME] knob to set the desired volume level.
4. Press the [STYLE] and [VOICE] buttons simultaneously again or
press the [START/STOP] button to stop playing and exit Demo mode.
Note:
In the DEMO mode, only the following buttons will work: START/STOP,
TEMPO+, TEMPO-, +/YES, -/NO, VOLUME, POWER ON/OFF.
Playing the Demos
09
The keyboard has a variety of remarkably realistic built-in voices.
Please refer to Voice List.
Playing Voices
1. Press the [VOICE] buttons.
Enter the VOICE mode, LCD shows VOICE R1 and the current voice
number and name.
2. Select a voice.
Use the data dial, the [+/YES] button, the [-/NO] button to select the
voice you want to play. You can also use the Voice Select buttons to
select a preset voice.
3. Play the voice.
Play the keyboard to use the selected voice for performance.
Note:
Each Voice Select button has two preset voices. Press it repeatedly to
shift between the upper and lower preset voice.
In voice selection, if you have selected the upper voice of a Voice
button, pressing another button will directly select its upper voice. In the
same way, if you have selected a lower voice, pressing another button
will select its lower voice.
Playing Voices
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 9 17/12/12 17:59

Playing Two Voices Simultaneously
1. Press the [DUAL] button.
It turns on the Dual function. “VOICE R2” and “DUAL” light up on
display. LCD shows the current dual voice number and name.
2. Selecting a voice for VOICE R2.
Use the data dial, [+/YES] and [-/NO] button, or Voice Select
buttons to select a dual voice.
3. Play the voices.
Play the keyboard, and you will hear two different voices playing
together, just like two different instruments being played at the
same time.
Note:
When the keyboard is split, only the right hand area will have the Dual
voice function.
Playing Different Voices with Both Hands
1. Press the [LOWER] button.
It turns on the Lower function. The keyboard is split into the left and
right areas, each with a different voice. “VOICE L” and “LOWER”
light up on display. LCD shows the current lower voice number and
name.
2. Selecting a voice for VOICE L.
Use the data dial, the [+/YES] button or the [-/NO] Button to select a
lower voice.
3. Play the voices.
Play the keyboard with both hands, and you will hear two different
voices from the left and right hand areas.
Split Point
The key that splits the keyboard into the left and right hand areas is
called “Split Point”. The default lower split is F#3, however, you can
assign it to any other key. Please refer to the Other Function for
details.
Touch
The touch response feature allows you to expressively control the
voice level based on your playing dynamics, just as on an acoustic
instrument.
1. Press the [TOUCH] button. The LCD shows the current touch level.
2. Use the data dial, the [+/YES] button, the [-/NO] button or the
[TOUCH] button to change the touch response level.
If the value is set to OFF, that means no touch response to
keyboard.
10
Playing Voices
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 10 17/12/12 17:59

Sustain
1. When the sustain is turned on, “SUSTAIN” lights up on display, and all
notes you play will have a longer sustain.
2. Press the [SUSTAIN] button to turn the SUSTAIN effect ON or OFF.
Note:
When using a sustain pedal, you can produce a more strong and natural
sustain effect than by using the [SUSTAIN] button.
Portamento
Press and hold the [PORTAMENTO] button, then play the keyboard to
apply a portamento effect to the notes you play.
Release the [PORTAMENTO] button to exit portamento mode.
Pitch Bend
Use the pitch bend wheel to bend the pitch of notes left or right while
playing the keyboard. The pitch bend wheel will automatically return to
normal pitch when released.
Roll the wheel toward left or right to add pitch bending effect to your
performance. It will increase the pitch when rolling right, and decrease the
pitch when rolling left. The range of pitch change is 2 semitones.
Note:
Use the pitch bend wheel to imitate the pitch bend effect of guitar, violin,
saxophone, and so on. It makes the performance more vivid.
Modulation
Roll the wheel up and down to apply a vibrato effect to the notes you play.
It will enhance the effect when rolling up or down, and have no effect
when the wheel is in center place.
Note:
The modulation effect is important when playing string instrument like
guitar and violin. The modulation effect makes the voice more realistic.
Transpose
Transpose function allows the overall pitch of the instrument to be
transposed up or down by a maximum of one octave in semitone steps.
1. Press [TRANSPOSE +] or [TRANSPOSE -] to edit the transpose value
from -12 to +12 semitones.
2. Press [TRANSPOSE +] and [TRANSPOSE -] or press [+/YES] and
[-/NO] at the same time to reset the value to default.
Octave
The Octave function will shift the pitch up or down by 2 octaves for voice
R1, R2 and L respectively.
1. Press [OCTAVE +] or [OCTAVE -] to change the octave value over the
range of -2 to +2.
2. Press [OCTAVE +] and [OCTAVE -] or press [+/YES] and[-/NO] at the
same time to reset the value to default.
Note:
After adjusting the octave, notes in the highest and lowest keyboard range
may not sound normally. This is normal.
Playing Voices
11
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 11 17/12/12 17:59

Piano Mode
Piano Mode is specially designed for piano players. It recreates the voice
and touch of a real acoustic piano. By pressing the [PIANO] button, the
instrument replicates a concert grand voice. All parameters become
optimized for concert piano performance
1. Press [PIANO] button to enter or exit Piano Mode.
2. In the Piano mode, if you start a style, it only plays the rhythm part.
Metronome
The metronome provides a steady beat to help you practice at a preset
tempo.
1. Press the [METRONOME] button to turn the metronome on.
2. Press the [METRONOME] button again to turn the metronome off.
3. To set the metronome beat, please refer to Other Functions for details.
Notes:
1. If you turn on the metronome during style playback, the metronome
sound will start from the next beat and its time signature will match
the current style.
2. In Recording, you can turn on the metronome, but the metronome
sound will not be recorded.
Freesolo
The FreeSolo function allows you to switch voice in an exceptionally
fast, accurate and seamless way, faithfully reproducing the special effects
of an acoustic instrument, and making your performance more real and
exciting.
1. Turn on the FreeSolo function.
Press the [FreeSolo] button to turn on the function, “FREESOLO”
lights up on display.
It will automatically disable the A.B.C. function, the Dual and Lower
function.
2. Select a voice to play.
Use the data dial or the [+/Yes]/[-/No] buttons to select a voice for
FreeSolo.
3. Play in the FreeSolo mode.
In FreeSolo mode, please use the right hand area to play and use
the left hand area to switch voice.
● Press and hold a white key in the left hand area to activate the first
special voice pattern. Release the key to restore the basic voice.
● Press and hold a black key in the left hand area to activate the
second special voice pattern. Release the key to restore the basic
voice.
● Press simultaneously two or more white keys in the left hand area to
activate the first special voice pattern. It will keep using the special
voice even after releasing the keys.
● Press simultaneously two or more black keys in the left hand area to
activate the second special voice pattern. It will keep using the special
voice even after releasing the keys.
4. Turn off the FreeSolo function.
Press one of the Voice select buttons or the [FreeSolo] button to exit
the mode. The “FREESOLO” indicator lights off.
Playing Voices
12
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 12 17/12/12 17:59

The auto accompaniment feature puts a full backing band at your
fingertips. All you have to do is play the chords with your left hand , and
the accompaniment will automatically play along, instantly following the
chords you play. With auto accompaniment, even a solo performer can
enjoy playing with the backing of entire band or orchestra. The instru-
ment features a variety of styles. Please refer to the Style List for details.
Playing Auto Accompaniment (rhythm track
only)
1. Press the [STYLE] button.
Enter the STYLE mode. “STYLE” lights up on display. LCD shows the
current style number and name.
2. Select a style.
Use the data dial, the [+/YES] button, the [-/NO] button to select a
style. You can also use the Style Select buttons to select a style.
3. Press the [START/STOP] button to start playing the rhythm tracks.
Note:
Each Style select button has two preset styles. Press it repeatedly to shift
between the upper and lower preset style.
In style selection, if you have selected the upper style of a Style button,
pressing another button will directly select its upper style. In the same
way, if you have selected a lower style, pressing another button will
select its lower style.
Playing Auto Accompaniment (all tracks)
1. Press the [STYLE] button.
2. Select a style.
3. Press the [CHORD MODE] button to turn on the A.B.C. function. The
keyboard will be split into two areas. Play the chords in the left hand
area.
Press [CHORD MODE] button again to enter “full range” mode.
The “FULL RANGE” indicator appears. You can play Multi Finger
chords over the entire keyboard range.
4. Turn the Sync Start function on.
Press the [SYNC START] button, then play a chord in the left hand
area to start the auto accompaniment. When you play a different
chord, the accompaniment will change along.
Alternatively, press the [START/STOP] button to start rhythm
playback. Then play a chord in the left hand area, the chord part will
start as well.
5. Press the [START/STOP] button to stop the accompaniment.
Accompaniment Sections
Specially created variation patterns can be added into the accompani-
ment, making your performance more professional and personalized.
Auto Accompaniment
13
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 13 17/12/12 17:59

INTRO Section
The intro is an opening section of the song.
When the intro pattern finished, the system will automatically shift to
the main section.
MAIN Section
The Main is the principal section of a song. It will play and repeat the
Main pattern until another section's button is pressed.
FILL IN Section
Auto fill in function automatically adds a fill to your performance. When
the fill-in is finished,accompaniment shifts to the Main section.
ENDING Section
Ending is used for the ending of the song. When the ending is finished,
accompaniment automatically stops.The length of the ending differs
depending on the selected style.
Playing Different Accompaniment Sections
1. Press the [STYLE] button.
2. Select a style.
3. Turn the A.B.C. on.
4. Turn SYNC START on.
5. Press the [FILL A] button.
6. Press the [INTRO/ENDING] button.Now the A flashes on LCD, the
style is ready to play.
7. It will start the accompaniment as soon as you start playing in Chord
section.When the playback of the Intro 1 is finished, it automatically
leads into Main A section.
8. Press the [FILL B]/[FILL C]/[FILL D] button. A fill-in plays,
automatically followed by the Main B/C/D section.
9. Press the [INTRO/ENDING] again to play an Ending Section. When
the ending is finished, the auto accompaniment automatically stops.
Note:
During style playback, if you press and hold one of the FILL [A]-[D]
buttons, the fill-in pattern will repeat until the button is released.
When style stops, press one of the FILL [A]-[D] buttons to select a MAIN
section. The “A, B, C or D” indicator will appear on LCD.
Fade In/Out
Fade In
Starting the style with fade in produces a smooth beginning, the volume
increases from low to high. When style stops, press the [FADE IN/OUT]
button to turn on the fade-in function.
Fade Out
Stopping the style with fade out produces a smooth ending, the volume
decreases from high to low. When style is playing, press the [FADE
IN/OUT] button to turn on the fade-out function.
Fade In/Out Time
The default fade-in/fade-out time setting is 10 seconds. You can set the
time in Other Functions.
Auto Accompaniment
14
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 14 17/12/12 17:59

Accompaniment Volume
1. Press [ACCOMP+] or [ACCOMP-] button to adjust the accompaniment
volume over the range of 0 to 127.
2. Press [ACCOMP +] and [ACCOMP-] button simultaneously to turn off
ACCOMP volume.
3. Press [ACCOMP +] and [ACCOMP-] button simultaneously again to
turn on ACCOMP volume.
Auto Accompaniment
15
Chord Basics
A chord, in music, is a harmonic set of three or more notes that are
heard simultaneously. The most common type of chord is a triad. A
triad is a set of three notes that can be stacked in thirds. When
arranged this way, the triad's notes, from lowest pitched to highest, are
called: the Root, the Third, and the Fifth.
Triad Type
The basic triad types are as follows:
Chord Inversion
When a chord’s root is not the lowest note in the triad, it is called an
inversion chord. When the root note is the lowest note, it is called a
root-position chord. If we put the Third and Fifth in the root position, it
forms an “Inversion”, so it is called an “Inverted Chord”. A major triad
and its inversion are illustrated on the right.
Chord Name
The chord name consists of two parts: Chord root and Chord type.
Single Finger
Single-finger makes it easy to produce major, seventh, minor and minor
seventh chords by pressing a minimum number of keys on the auto
accompaniment section.
Major Triad
Minor Triad
Augmented
Triad
Diminished
Triad
A root with a major third added above and a perfect fifth
constitutes a “Major Triad”.
A root with a minor third added above and a perfect fifth
constitutes a “Minor Triad”.
A root with a major third added above and an
augmented fifth constitutes an “Augmented Triad”.
A root with a minor third added above and a diminished
fifth constitutes a “Diminished Triad”.
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 15 17/12/12 17:59

Multi-finger
Multi-finger allows you to play chords in normal fingering. Try playing
the 32 types of C chords listed on the right.
Full Range
In Full Range mode, it detects chords played in normal fingering
(Multi-finger) over the entire keyboard range.
Tempo
Each style is preset with a default or standard tempo, but you can
change it as needed.
1. Change the tempo.
Press the [TEMPO+]/[TEMPO-] buttons to edit the tempo setting.
When the tempo value is flashing on LCD, use the data dial to
make a quick change in the value.
2. To restore the default tempo setting, press the [TEMPO+] and
[TEMPO-] buttons simultaneously.
One Touch Setting
When One Touch Setting is switched on, you can instantly recall all
auto accompaniment related settings including voices selection and
digital effects, all with the single touch of a button.
1. Press the [O.T.S.] button to turns on the function. The “O.T.S.”
indicator lights up and the A.B.C. function will be turned on.
2. Press one of the [M1] - [M4] buttons. Various panel settings
(including voice and effects) that match the current style will be
recalled instantly.
3. Play the keyboard.
One Touch Setting parameter list:
Part ON/OFF (VOICER1,R2,L)
Voice Number (VOICER1,R2,L)
Voice Volume (VOICER1,R2,L)
Voice Reverb Level (VOICER1,R2,L)
Voice Chorus Level (VOICER1,R2,L)
Note:
In O.T.S. mode, the Registration Memory is not available.
Auto Accompaniment
16
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 16 17/12/12 17:59

Harmony
17
The Harmony function will automatically add harmony effect to the notes
you play in the right hand area, enriching your performance with a more
harmonic expression.
1. Turn on the harmony function.
Press the [HARMONY] button to turn on the harmony function.
“HARMONY” lights up on display. The LCD shows the current
harmony type.
2. Play with harmony effect.
Turn on the A.B.C. function, then play a chord in the left hand area.
When you play in the right hand area, it will add harmony effect to the
notes you play.
3. Turn the harmony off.
Press the [HARMONY] button again to turn off the function. LCD will
show “OFF” and the “HARMONY” lights off.
4. Set the harmony type.
You can set the harmony type in Other Functions.
Note:
The harmony types of 1+5, Octave 1~2, Echo 1~4, Tremolo 1~4 and Trill
1~4 are always available, but the rest will not respond until you turn on
the A.B.C. function and then play a chord in the chord section.
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 17 17/12/12 17:59

Performance assistant is an easy-to-use function. It provides a variety
of beautiful phrases to help you play your familiar instrument voice on
the keyboard with ease.
There are 2 voices you can select to play in Performance Assistant:
Guitar and Piano.
Enter the Performance Assistant
1. Press the [PERFROM.] button to turn on the function. It enters the
Guitar Mode and LCD shows the Guitar voice name and number.
2. Use the data dial to switch between the Guitar voice and the Piano
voice.
3. The default time signature is “4-4”. You can use the [+/YES] or
[-/NO] button to change the time signature over the range: 2-4, 3-4,
4-4 and 6-8.
4. Use the [TEMPO+] / [TEMPO-] to adjust the tempo value.
Guitar Mode
Guitar key map
The Guitar Mode allows you to perform a guitar voice with keyboard
just like you're playing a real guitar. In this mode you can use ssuch
guitar phrases as strum (5), broken chord (5), echoism (5) and also
2 endings.
Chord part
E1 to B3 is the chord part area. Play a chord in this area.
Sub Area 1
C4 to B4 (only white keys) is the sub area 1. Up to 5 types of broken
chord are provided in this area.
Sub Area 2
C5 to A5 (only white keys) simulate the 6 strings of a real guitar.
Play a free solo in this area.
Rhythm Area
C6 to G6 (only white keys) is the rhythm area. Wonderful styles and
strums are provided in this area. Use A6 to B6 to play an ending.
Position Change
Press C7, the guitar position will be changed.
Playing in Guitar Mode
Play a chord in the chord part.
LCD will show its chord name and the guitar’s root note will sound.
Play a broken chord in the sub area 1.
When the chord type is on display, press a white key in the sub area 1,
a wonderful broken chord phrase will start. Press other white keys to
play different phrases. Try playing a different chord with your left hand
and enjoy the subtle change in the phrases.
18
Performance Assistant
Guitar Key map
Chord Part Sub Area 1 Sub Area 2 Rhythm
Area
Position Change
Chord Part Sub Area 1 Sub Area 2 Rhythm
Area
Position Change
Chord Part Sub Area 1 Sub Area 2 Rhythm
Area
Position Change
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 18 17/12/12 17:59

Playing in Piano Mode
1. Select Piano Mode.
In performance assistant mode, use data dial to select Piano Mode.
2. Play a chord in chord part.
3. Play different phrases and rhythms in the Sub Area and the Rhythm
Area.
4. Press A6, B6 or C7 to end your piano performance. When the
ending is finished, the phrase stops automatically.
Exit the Performance Assistant
When the phrase stops, press the [VOICE], [STYLE], [SONG], [DEMO],
[PERFORM.] to exit the Performance Assistant mode.
Play a free solo in the sub area 2.
When the chord type is on display, press the white keys in the sub
area 2 you can play guitar free solo, like you're playing a real one.
Try playing different chords with your left hand, and play your free solo.
The last white key B5 is invalid.
Play a strum rhythm in the rhythm area.
When the chord type is on display, press a white key in the rhythm
area you can play the magic strum rhythm. Try playing different chords
with your left hand, and play your strums.
End the guitar performing.
Press the A6 or B6 to end your guitar performance. When the ending is
finished, the phrase stops automatically.
Play the echoism.
All of black keys on Sub area 1, Sub area 2 and Rhythm area are
echoism keys. There are 5 kinds of echoism patterns preset to the C#,
D#, F#, G#, A# circularly.
Change the position
Press the C7, the PERFORM.H icon will be lit on the LCD. It means
that the guitar position has been changed to the High position.
Try playing the white keys in sub area 1, Sub area 2 and Rhythm area,
listen to the phrase you are performing now.
Piano Mode
Piano Key Map
The Piano Mode allows you to perform the piano voice just like playing
an acoustic instrument. In this mode you can use such piano phrases
as piano rhythm (5), broken chord (5) and also 3 endings.
The piano key map is similar to the guitar key map. Press A6 to C7
to play the ending. All the black keys above C4 are invalid.
19
Performance Assistant
Piano Key map
Sub AreaChord Part Rhythm
Area
Sub AreaChord Part Rhythm
Area
Chord Part Sub Area 1 Sub Area 2 Rhythm
Area
Position Change
Chord Part Sub Area 1 Sub Area 2 Rhythm
Area
Position Change
Chord Part Sub Area 1 Sub Area 2 Rhythm
Area
Position Change
Chord Part Sub Area 1 Sub Area 2 Rhythm
Area
Position Change
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 19 17/12/12 17:59

You can use the synth function to create your own voice on the basis of
the built-in voice samples.
Enter the Synth
Press [SYNTH] button to turn on the Synth function. The "SYNTH"
indicator lights up.
In Synth mode, the following functions will be disabled: Lower, Dual,
Auto Accompaniment and the Piano Mode.
Create User Voice
1. Press [SYNTH] button to enter the user voice selection interface.
LCD displays “UserV.01” and the user voice number.
Use the data dial to select a voice number you want.
2. Press [+/YES] button to enter the next menu. Then use the data dial
to select “Voc_Edit” or “Delete”. Press [+/YES] to go forward or
press [-/NO] to return to the previous menu.
3. If you select “Voc_Edit” and press [+/YES], the LCD will display
“PcmVoice” and sample voice number. Use data dial to select voice
parameter, the voice parameter will display on the LCD as follows
“PcmVoice”, “Vib Rate”, “VibDepth”, “VibDelay”, “EnvAttac”,
“EnvRelea”, “EnvDecay”.
If you select the “Delete” menu and press [+/YES] button, LCD
displays “Sure?”. Press [+/YES] button to delete the user voice, and
then return to previous menu; or press [-/NO] to cancel the operation,
and then return to previous menu. You can also press [SYNTH] or
[-/NO] button to return to previous menu.
4. After selecting a voice parameter, press [+/YES] button to enter the
parameter value setting mode. At this mode, the parameter value
will flash on LCD. Use the data dial to adjust the value, you can play
the keyboard to listen to the voice effect.
5. Press [SYNTH] button and LCD displays “Sure?”. Press [+/YES]
button to save the user voice , and then return to previous menu, If
you press [-/NO] button, it will cancel the operation, and then return
to previous menu.
6. At any time, press [-/NO] button to return to the previous menu.
Exit the Synth
In the user voice selection interface, press one of the buttons to exit the
function: [SYNTH], [STYLE], [SONG], [DEMO].
NOTE:
The Synth function is not available during song playback, demo
playback, recording or in USB Device mode.
Synth
20
Parameter name
PcmVoice
VibRate
VibDepth
VibDelay
EnvAttac
EnvRelea
EnvDecay
Range Default
000 - 722 001
000 - 127 064
000 - 127 064
000 - 127 064
000 - 127 064
000 - 127 064
000 - 127 064
C
M
Y
CM
MY
CY
CMY
K
AW_AW830_Manual_G03_171207.pdf 20 17/12/12 17:59
