Use and Care Guide
6-Tier Shelving Unit
Item # 1000026321
Model # E60120180B6RTHD
PACKAGE CONTENTS HARDWARE INCLUDED
A – Shelf x 6 B – Tapered
sleeve x 48
+ 2 extra
C – Bottom pole with
pre-installed leveler x 4
D – Top pole x 4 AA –
Washer x 2
BB –
Anchor x 2
CC –
Screw x2
Safety Information
Read and understand this manual before assembly.
Before you begin, inspect each part and compare to the Package Contents list.
If any part appears missing or damaged, do not assemble and use this product.
Contact Customer Service at 1-800-514-6729.
1. Two adults are recommended for ease of assembly. Use care when handling.
2. Assemble on a soft surface, such as carpet, to avoid scratching the finish.
CAUTION: Do not allow children to play or
climb on the product.
CAUTION: Place the unit on a level surface to
avoid a tipping hazard.
CAUTION: Each shelf holds up to 850 lbs,
evenly distributed. Do not overload.
Assembl
y
1 Assembling the posts 2 Installing the bottom shelf
□Before you begin, discard the black circular
pieces found when unpacking this product.
They are for shipping purposes only.
□Screw the bottom pole (C) to the top pole (D).
Repeat for the remaining poles.
□Determine the desired position of the
shelf (A). Ensure that it is no more than 6
in. from the floor.
□Place two tapered sleeves (B) into the
appropriate groove on each pole
assembly. Ensure the “UP” arrow faces
up. Ensure each sleeve is the same height
to ensure the shelf is level when installed.
□Place the shelf (A) on its side and slide
each pole assembly through the bottom of
the shelf (A) until snug. After all pole
assemblies are in place, position the unit
in the upright position.
□Push down on each corner of the shelf (A),
ensuring the corners of the shelf (A) slip
fully in the locked position over the
sleeves (B).
3 Adding shelves 4 Adjusting the levelers 5 Mounting to the wall
□Determine the position of the second shelf.
Place the tapered sleeves (B) onto the pole
assemblies and ensure that the sleeves are
level with each other.
□Slide the shelf (A) down from the top of the
pole assemblies and onto the tapered
sleeves (B).
□Push each corner of the shelf (A) down until
it locks into position over the sleeves (B).
Repeat for the remaining shelves (A).
□Move the assembly to the desired
location.
□If needed, adjust the levelers on the
bottom of the poles (C) to ensure the
shelving unit is level. Rotate the
levelers counterclockwise to raise
the poles, and clockwise to lower
the poles.
WARNING: This step is required to ensure the
stability of the shelves.
□Mark the locations of the mounting holes with a
pencil using the top shelf (A) as a guide. Drill pilot
holes at the marked locations using a 1/4 in. bit, and
insert the wall anchors (BB) into the holes.
□Secure the top of the shelf (A) to the wall by inserting
screws (CC) with washers (AA) through the shelf (A)
and into the wall anchors (BB).
D
C
C
NSF
®
A
B
B
6
in.
B
A
A
CC BB
AA

HOMEDEPOT.COM
Please contact 1-800-514-6729 for further assistance.
Optional Caster Assembly
HDX offers optional rolling casters that you can purchase either online or at
your local The Home Depot if you wish to convert this shelving unit into a
rolling shelving unit. Unscrew and remove the leveling feet on the bottom of
the shelving unit and replace with casters. Ensure the casters you purchase
are 3 in. or 4 in. in size and have a 3/8 in. thread diameter.
CAUTION: Tipping Hazard: Failure to follow these caster
guidelines can result in damage or personal injury.
□Push mobile units in a long direction.
□Use caution when moving heavily loaded carts as they are
more difficult to control.
□Place heavy objects on the lowest shelf.
□Inspect casters before use and replace those that are worn
immediately.
CAUTION: Total load capacity for 3 in. casters is 350 lbs and
450 lbs for 4 in. casters, evenly distributed.
3/8"
