SERVICE MANUAL
for
HEARTLAND
APPLIANCES
Metro & Legacy
Lines
Model 3520 - 30” Legacy
Model 3525 - 30” Metro
Model 3620 - 36” Legacy
Model 3625 - 36” Metro
Diagnosis Charts
Service Procedures
Component Data
Heartland Appliances Inc.
Manual No. MLSM010601
®

Part# 0910 MLSM2003-01-03
RepairManualforHeartlandAppliancesInc
Metro& Legacy Ranges
2001, April 1 HeartlandAppliancesInc.
1050FountainSt. N
Cambridge,Ontario;N3H 4R7
Allrights reserved. Nopart of thisbook may bereproduced in
anyformorbyanymeanswithoutwrittenpermissionfromHeartland
We have used all possible care to ensure the accuracy of
the information contained in this book. However, Heart-
land assumes no liability for any errors, omissions or any
defects whatsoever in the diagrams and/or repair proce-
dures or for any damage or injury resulting from utiliza-
tion of said diagrams and/or repair procedures.
Safety Information: Electric and Gas Ranges are complex
electromechanical devices. Any attempt to repair a range
may, if improperly performed, result in personal injury or
property damage. Heartland Appliances cannot be re-
sponsible for the interpretation of this manual, nor can it
assume any liability in connection with its use. For addi-
tional safety information, see page 5 of this manual.

3MLSM2003-01-03
Contents
Section 1: SafetyInformation.............................5
Section 2: Parts & Warranty Information............. 7
Section 3: Technical Specifications .................... 9
Section 4: Problem Diagnosis Charts ..........11-16
Section 5: Repair Procedures ..................... 17-56
Section 6: Wiring Diagrams
Models 3520/3525 ..................................................57
Models3620/3625...................................................58
Section 7: Exploded Views and Parts List ....59-60

4MLSM2003-01-03
PAGE LEFT BLANK

Section 1
5MLSM2003-01-03
Safety Information
Important Safety Notice
HeartlandAppliances’ Service
Manuals are intended for use by
individuals possessing
electrical, gas and mechanical
experience. Therefore,
Heartland Appliances cannot be
responsible for the interpretation
of its Service Manuals by those
not having a background of
electrical, gas and mechanical
experience, nor can it assume
any liability in connection with
their use.
Safe Servicing Practices
To preclude the possibility of
resultant personal injury and/or
property damage, it is imperative
that safe servicing practices be
observed. The following are
examples, but without limitation,
of such safe practices:
1. Before servicing, always
disconnect the product from
its source of electrical power
by removing the product’s
electrical plug from the wall
receptacle or tripping the
circuit breaker to OFF(or
removing the fuse) in the
branch circuit servicing the
product.
Note: If a specific diagnostic
check requires electrical
power to be applied such as
for voltage or amperage
measurements, reconnect
electrical power only for time
required for specific check,
and disconnect power
immediatelythereafter.
During any such check,
ensure no other conductive
parts, panels or yourself
come into contact with any
exposed current carrying
parts.
3. If a replacement part is
required ensure it meets
factory specifications.
4. Never by-pass or interfere
with the proper operation of
any feature, part or device
engineered into the product.
5. Prior to reconnecting
electrical power service to
the product, ensure that:
a) all electrical
connections
within the product
are correctly and
securely
connected,
b) all electrical
harness leads
areproperly
dressed and
secured away
from sharp
edges, high
temperature
components
(heaters, etc.)
and moving
parts,
c) anyun-insulated
current-carrying
metal parts are
secured and
spaced
adequately from
all non-current-
carrying metal
parts,
d) all electrical
grounds (internal
and external to
the product) are
correctly and
securely
connected, and
e) all access panels
and covers are
properlyand
securely
assembled
followingthe
servicing and
prior to operating
the product.
6. On gas appliances, do not
disturb gas-carrying
components or connections
until gas service to it is shut
off, and do not use a flame
to test for gas leaks.
Following repair work,
ensure all gas connections
are properly secured by
testing for gas leaks with a
bubble (soap) solution.
7. Do not attempt a repair if you
have any doubts as to your
ability to complete it in a safe
and satisfactory manner.

6MLSM2003-01-03
PAGE LEFT BLANK

Section 2
7MLSM2003-01-03
Parts & Warranty
How To Obtain Parts:
•Contact an authorized
Heartland dealer or Heartland
Appliances direct.
•When ordering replacement
parts (warranty or not) always
provide the following
information:
Serial Number
Model Number
Component Description
Part number
•Commonly replaced parts are
listed in Section 7 at the end of
this book and at the back of the
owner’s manual.
•To obtain replacement parts
directly from Heartland, contact
the following departments:
Heartland Appliances Inc.
1050 Fountain St. N.
Cambridge, Ontario
N3H 4R7
ph: 877-650-5775
fx: 800-327-5609
Non Warranty Replacement
Parts: Order Desk Ext. 2226 &
2227
Warranty Replacement Parts:
Service Dept. Ext. 2241, 2264 &
2244
Note: PleasecontactHeartland
AppliancesServiceDepartmentprior
toperforming service workinorder
to assist in the diagnosis of the
problem,thisshouldresult in having
to go to the customer’s home only
once.
How To Set Up Warranty Service:
•Contactoneof the manufactur-
er’s service technicians to
obtaina CSF referencenumber.
CSF numberwillserveas
authorizationtoproceed with
warranty work and will be
referenced for any future
warranty work. Contact
Heartland Appliances Service
Department at:
Heartland Appliances Inc.
1050 Fountain St. N.
Cambridge, Ontario
N3H 4R7
ph: 877-650-5775
fx: 800-327-5609
Service Department:
Extensions2241, 2264 &
2244
•CSF number to be referenced
in all warranty claims
•ContactingHeartland
Appliances prior to performing
service work, will assist in the
diagnosis of the problem, this
should result in having to go to
the customer’s home only
once.
How To Submit Warranty Claims:
•Forpromptwarranty claim
processing, submit your
standard service form (i.e.
Narda style) completely filled
out to:
Heartland Appliances Inc.
Service Department
1050 Fountain St. N.
Cambridge, Ontario
N3H 4R7
fx: 800-327-5609
•Warranty Claim forms to in-
clude, but not limited to, the
followinginformation:
•CustomerName,Address and
Phone Number
•Serial Number
•Model Number
•Date of Service
•Work Performed
••
••
•Full Description of Work
Performed
••
••
•CSF Reference number (see
“How To Set Up Warranty
Service” section above for
details).
How to Return Merchandise:
•Contact Heartland Appliances’
Service Department to obtain
authorization for any
merchandise returns at:
Heartland Appliances Inc.
1050 Fountain St. N.
Cambridge, Ontario; N3H
4R7
ph: 877-650-5775
fx: 800-327-5609
Service Department:
Extensions2241, 2264 &
2244
•Depending on the nature of the
merchandise to be returned, an
RGA number (Return Goods
Authorization) may be issued.
A comprehensive RGA Kit
package will be expedited with
instructions and back up
paperwork for the prompt and
safe return of the goods.

Section 2
8MLSM2003-01-03
Parts & Warranty
Serial Number Location in
Ranges:
•Metro & Legacy ranges have
the serial number located at the
back of the range and on the
kick plate.
To view serial number plate,
open door, and look at
kickplate’s right top corner.
(view shown with door removed)

Section 3
9MLSM2003-01-03
Technical Specifications
Dual Fuel Ranges (Electric Oven
& Gas Top)
•30” Models 3520/3525
240V, 60Hz, 4.1 Kw (3 prong or
4 prong)
Bake Element: 3400 W
Broil Ribbon Element: 4000 W
Conv. ring element: 2400 W
Natural Gas (6” w.c.)
Propane (11” w.c.)
½” NPT (5/8” flex line)
Surface Burners (4):15,500Btu
Note: Service Amperage to be
calculated by a qualified
electrician.
•36” Models 3620/3625
240V, 60Hz, 5.6 Kw (3 prong or
4 prong)
Bake Element: 5000 W
Broil Ribbon Element: 5000 W
Conv. ring element: 4800 W
Natural Gas (6” w.c.)
Propane (11” w.c.)
½” NPT (5/8” flex line)
Surface Burners (6):15,500Btu
Note: Service Amperage to be
calculated by a qualified
electrician.
•36” Models with Grill
3620B/3625B
240V, 60Hz, 5.6 Kw (3 prong or
4 prong)
Bake Element: 5000 W
Broil Ribbon Element: 5000 W
Conv. ring element: 4800 W
Natural Gas (6” w.c.)
Propane (11” w.c.)
½” NPT (5/8” flex line)
Surface Burners (4):15,500Btu
Grill Burners (2): 7,500 Btu
Note: Service Amperage to be
calculated by a qualified
electrician.
Electrical Requirements:
•Standard 240V; 60 Hz
receptacle,properlypolarized,
on its own dedicated line must
be used.
•Ranges are provided with a
molded plug cap power cord
rated at 120/240 Volts.
•Ranges must be electrically
grounded in compliance with
local codes. In absence of
local codes, the installation
must conform with the National
Electrical Code.
Gas Requirements:
•During any pressure testing of
the gas supply piping system at
test pressures equal to or less
than 2.5 kps, the appliance
must be isolated from the gas
supply system by closing its
individual manual shut off valve.
•The maximum propane/natural
gas supply inlet pressure must
not exceed 14” of water column
•Gas ranges must be installed in
compliance with local gas
codes. In absence of local
codes, the installation must
conform with the National Gas
Code.

Section 3
10 MLSM2003-01-03
PAGE LEFT BLANK

Problem Possible Cause Repair/Test Procedure
Section 4
Problem Diagnosis Charts
Models 3520/3525; 3620/3625 & 3620B/3625B
11 MLSM20003-01-03
1. Range does not operate
(top and timer do not work) •No power to range – House
breaker tripped or fuse blown
•Open wire at terminal block
•Terminal block defective
•Power cord defective
üCheck power supply
(Procedure 1)
üCheck terminal block
(Procedure 2)
üCheck terminal block
(Procedure 2)
üCheck power cord
(Procedure 3)
2. Range does not heat (top works,
timer does not work) •Breaker tripped or fuse blown
•Open wire between terminal
block and relay board
•Defective Timer
•Coaxial power cable to timer
defective or inoperative
•Defective relay board
•Open 25 amp relay (36” models
only)
üCheck power supply
(Procedure 1)
üCheck terminal block
(Procedure 2)
üCheck terminal block
(Procedure 2)
üCheck power cord (Procedure
3)
üCheck relay board (Procedure
18)
üCheck 25 amp relay
(Procedure 21)
•Breaker tripped or fuse blown
•Timer blank – no power to
timer
•Timer not set to time of day
•Timer cannot be programmed
•Timer programmed to
“delayed time bake”
•Open wire or poor connection
at oven thermostat probe (F1
displayed in timer)
•Open bake/broil limit relay
•Timer programmed to “self
clean” (timer displays SC)
•Tripped or open safety limit
(red button popped)
3. Oven does not heat (top burners
operate) üCheck power supply
(Procedure 1)
üCheck timer (Procedure 4)
üCheck timer program
(Procedure 5)
üCheck timer program
(Procedure 5)
üCheck timer program
(Procedure 5)
üCheck oven thermostat probe
(Procedure 6)
ücheck timer (Procedure 5)
üCheck bake/broil limit
(Procedure 7)
üCheck timer program
(Procedure 5)
üCheck safety limit (Procedure
8)
4. Timer displays F1 •Wiring from Probe to Timer
disconnected or damaged
•Oven thermostat probe faulty or
disconnected
•Timer faulty
üCheck timer wiring (Procedure 4)
üCheck oven probe (Procedure 6)
üCheck wiring and connections
(Procedure 6)
üReplace timer (Procedure 4)

Problem Possible Cause Repair/Test Procedure
12 MLSM2003-01-03
Section 4
Problem Diagnosis Charts
Models 3520/3525; 3620/3625 & 3620B/3625B
5. Bake or convection bake
element does not heat (broil
operates)
•Open bake or convection bake
elements
•Open wire between bake
element and relay board
•Faulty timer or timer coaxial
power supply cable
•Open bake/broil limit
üCheck bake elements
(Procedure 9 and 10)
üCheck bake element
(Procedure 9 and 10)
üCheck wiring and connections
at relay board (Procedure 18)
üCheck timer (Procedure 4)
üCheck coaxial cable
(Procedure 19)
üCheck bake/broil limit
(Procedure 7)
6. Broil Element does not heat
(bake element operates) •Open broil element
•Open wire between broil
element and relay board
•Faulty timer or timer coaxial
power supply cable
•Open bake/broil limit
üCheck broil element (Procedure
11)
üCheck broil element (Procedure
11)
üCheck relay board (Procedure
18)
üCheck timer(Procedure 4)
üCheck coaxial cable
(Procedure 18)
üCheck bake/broil limit
(Procedure 7)
7. Oven temperature incorrect
(oven not baking properly) •Open thermostat probe
•Faulty bake/broil limit (cycling
on/off at lower temperatures)
•Faulty Timer
•Open timer coaxial power
supply cable
•Oven door gasket damaged
•Oven door hinge/spring broken
•Oven vent blocked
üCheck thermostat probe
(Procedure 6)
üCheck bake/broil limit
(Procedure 7)
üCheck timer (Procedure 4)
üCheck coaxial cable
(Procedure 19)
üCheck door gasket (Procedure
12)
üCheck oven door hinge
(Procedure 13)
üCheck oven vents (Procedure
14)
8. Oven will not shut off •Open oven thermostat probe
•Stuck relay on relay board
•Damaged timer coaxial power
supply
•Faulty timer
üCheck thermostat probe
(Procedure 6)
üCheck relay board (Procedure
18)
üCheck coaxial cable
(Procedure 19)
üCheck timer (Procedure 4)

Problem Possible Cause Repair/Test Procedure
Section 4
Problem Diagnosis Charts
Models 3520/3525; 3620/3625 & 3620B/3625B
13 MLSM20003-01-03
8. Oven will not work on timed
cooking or delayed time cooking
functions
•Timer not properly programmed
•Timer defective
üTimer programming steps
(Procedure 5)
üReplace timer (Procedure 4)
10.Oven light not working •Burned out oven bulb
•Timer defective
•Coaxial power supply cable
defective
•Open oven light housing or
wiring connections
•Open light’s transformer
üCheck oven bulb (Procedure
15)
üCheck timer (Procedure 4)
üCheck coaxial cable
(Procedure 19)
üCheck oven bulb (Procedure
15)
üCheck wiring to oven light
(Procedure 15)
üCheck transformer (Procedure
15)
11.Oven light trips house breaker
when light switched “on” •Electrical ground üCheck wiring to oven light housing (Procedure 15)
üCheck wiring to light
transformer (Procedure 15)
12.Convection fan not working •Timer defective
•Timer coaxial power cable
defective
•Open wire to fan motor
•Defective relay on relay board
•Baffle interference with
convection fan wheel
•Motor defective
üCheck timer (Procedure 4)
üCheck coaxial cable
(Procedure 19)
üCheck wiring to fan motor
(Procedure 16)
üCheck relay board (Procedure
18)
üCheck baffle plate (Procedure
16)
üReplace fan motor (Procedure
16)
13.Convection fan noisy •Back of stove panel vibrating
•Convection fan wheel loose or
warped
•Baffle interference with
convection fan wheel
üCheck stove’s back panel
(Procedure 32)
üCheck fan wheel (Procedure
16)
üCheck baffle plate (Procedure
16)
14.Oven door does not open after
completion of self clean cycle •Door latch mechanism inoperative
•Oven not cool
üCheck door latch mechanism
(Procedure 17)
üCheck self clean timer
programming (Procedure 5)
15. Timer making buzzing noises,
incorrect display, etc. •Timer defective •Timer coaxial power supply
cable defective
•Timer relay board defective
üCheck timer (Procedure 4)
üCheck coaxial cable
(Procedure 19)
üCheck relay board (Procedure
18)

Problem Possible Cause Repair/Test Procedure
14 MLSM2003-01-03
Section 4
Problem Diagnosis Charts
Models 3520/3525; 3620/3625 & 3620B/3625B
16.Bake & broil elements do not
heat after self clean cycle •Safety limit tripped or defective or wiring damaged
•Door latch mechanism
inoperative or wiring
•Timer programmed for a
delayed cooking function
•Bake/broil limit defective or
wiring damaged
•Relay board defective or wiring
damaged
•Timer coaxial power supply
cable defective
üCheck safety limit (Procedure
8)
üCheck wiring and connections
(Procedure 8)
üCheck door latch mechanism
(Procedure 17)
üCheck timer programming
(Procedure 5)
üCheck bake/broil limit
(Procedure 7)
üCheck relay board (Procedure
18)
üCheck coaxial cable
(Procedure 19)
17.Incomplete cleaning •Controls not properly set or self
clean programmed too short
•Bake element not heating
•Door latch mechanism
inoperative or stuck
•Bake/broil limit not bypassed or
defective
•Oven door not sealing
•Timer defective
•Safety limit not calibrated
properly or defective
•No signal from self clean
mechanism to timer
•House breaker tripped or fuse
blown
•Timer blank – no power
•Timer defective
•Timer coaxial power supply
cable defective
•Timer locked out (3 horizontal
red lines present in temperature
display
üCheck power supply
(Procedure 1)
üCheck timer (Procedure 4)
üCheck wiring and connections
at relay board (Procedure 18)
üCheck timer (Procedure 4)
üCheck coaxial cable
(Procedure 19)
üCheck timer programming
(Procedure 5)
18. Timer does not operate or
cannot be set
üCheck self clean timer
programming (Procedure 5)
üCheck bake element
(Procedure 9)
üCheck self clean mechanism
(Procedure17)
üCheck bake/broil limit
(Procedure 7)
üCheck oven door gasket
(Procedure 12)
üReplace timer (Procedure 4)
üCheck safety limit (Procedure
8)
üCheck wiring at timer
(Procedure 4)
üCheck wiring to self clean
mechanism (Procedure 17)

Problem Possible Cause Repair/Test Procedure
Section 4
Problem Diagnosis Charts
Models 3520/3525; 3620/3625 & 3620B/3625B
15 MLSM20003-01-03
19. Timer blank or flashing during
cooking or after completion of
cooking cycle
•House breaker tripped or fuse
blown
•No power to timer - defective
coaxial power supply cable
•Defective timer
•Cooling fan inoperative or
blocked - timer’s temperature
safety limit tripped
•Defective relay board
•36” models only. Defective 25
amp relay or wiring between
relay to terminal block or relay
board.
20. Cooling Fan not working
üCheck Power supply
(Procedure 1)
üCheck coaxial cable
(Procedure19)
üCheck timer (Procedure 4)
üCheck cooling fan limit
(Procedure 20)
üCheck relay board (Procedure
18)
üCheck 25 amp relay (Procedure
21)
•No power to cooling fan
•Cooling fan stuck with foreign
material
üCheck cooling fan (Procedure
20)
üCheck cooling fan (Procedure
20)
21. Cooling Fan stays in on position
for several hours
•Faulty fan limit
•Self Clean Latch not fully
retracted
üCheck cooling fan (Proc 20)
üCheck door latch mechanism
(Procedure 17)
22. Top burner does not ignite •No gas to burner
•Faulty ignition switch
•Open wire to ignition switch
•Burner valve stem cannot be
turned
•Open wire from ignition switch
to spark module
•Spark module defective
•Electrode dirty or defective
üCheck gas supply (Procedure
24)
üCheck burner valve (Procedure
29)
üCheck ignition switch
(Procedure 23)
üCheck wiring and connections
(Procedure 23)
üCheck burner valve (Procedure
29)
üCheck ignition switch
(Procedure 23)
üCheck spark module
(Procedure 22)
üCheck wiring and connections
(Procedure 22)
üCheck spark module
(Procedure 22)
üCheck burner electrode
(Procedure 28)
23. Top burner on high at any
setting •Burner valve defective
•Too much gas pressure
•Regulator defective
üReplace burner valve
(Procedure 29)
üCheck gas supply (Procedure
24)
üCheck regulator (Procedure 25)

Problem Possible Cause Repair/Test Procedure
16 MLSM2003-01-03
Section 4
Problem Diagnosis Charts
Models 3520/3525; 3620/3625 & 3620B/3625B
24. Burner electrode continues to
spark after burner has lit •Burner components incorrectly positioned
•Cooking utensils too large or
contents spilled over
•Spark module faulty
•Burner electrode dirty or
defective
üCheck burner caps (Procedure
27)
üCheck cookware
üCheck spark module
(Procedure 22)
üCheck burner electrode
(Procedure 28)
üCheck ignition switches
(Procedure 23)
üCheck ignition switches
(Procedure 23)
üCheck spark module
(Procedure 22)
üCheck power cord and wiring
(Procedure 3)
üCheck burner valve (Procedure
29)
üCheck power supply
(Procedure 1)
üCheck wiring and connections
(Procedure 1)
üCheck air shutters (Procedure
26)
25. Electrodes spark when ignition
switches are in “off” position •Ignition switch faulty
•Ignition switch wet
•Spark module faulty
•Loose ground in range or
defective power cord
•Valve stem not level - keeping
switch from turning “off”
•Loose ground in house wiring
or receptacle
•Air shutter adjustment needed
(too much air)
26.Grill electrodes continue to
spark after burner has lit üCheck air shutters (Procedure 26)
üCheck cookware
üCheck spark module
(Procedure 22)
üCheck burner electrode
(Procedure 28)
•Air shutter adjustment needed
(too much air)
•Cooking utensils too large or
contents spilled over
•Spark module faulty
•Burner electrode dirty or
defective

Section 5-3
17 MLSM2003-01-03
Procedure 1 - Breakers & Fuses
Step 1: Be sure all range controls
are turned off.
Step 2: To restore power, turn the
breaker switch to “OFF” position,
then back to “ON” (when a breaker
trips, the switch moves to an
intermediate position between the
“ON” and “OFF” positions)
Step 3: If breaker trips again, the
circuit is still overloaded.
Step 4: Fuse blocks utilize a
double pole fuse block with two
cartridge type fuses joined together
at the handle.
Step 5: Pull block out of panel
Step 6: Fuses can be checked
with ohnmmeter set at the lowest
resistance scale. Touch probes to
brass caps at each end. If no
continuity then replace with fuse
that meets local electrical codes
and is not larger than specified for
the range.
Step 7: Clip fuses firmly back on
panel (“ON” notation should appear
at the top of the block). Loose
connections can cause the fuse to
overheat.
Step 8: Proper power readings on
receptacle can be tested with a
multimeter set to AC volts.
Step 9: With range unplugged,
place test probes as per diagrams.

Section 5-3
18 MLSM2003-01-03
Procedure 2 - Terminal Block
Step 1: Disconnect power supply
to range. Pull range away from wall.
Step 2: Remove back panel. Refer
to Procedure 32 for details.
Step 3: Inspect terminal block for
burnt terminal connections. If
damaged, replace.
Step 4: To replace terminal block,
remove power cord by unscrewing
the three screws that retain the
ends of the cord to the terminal
block.
Step 5: Mark and disconnect all
wires attached to the terminal block
(including wire to ground stud for 4
prong power cords)
Step 6: Terminal block can be
removed from range by removing
the two center screws.
Step 7: Install new terminal block,
attach all red, white and black wires
as originally marked
Step 8: Attach power cord back on
terminal block. Be sure all wires are
secure. 3 prong power cords have
jumper cable from center (neutral)
side of terminal block to stud. 4
prong power cords have copper
wire from cord directly attached to
ground stud.

Section 5-3
19 MLSM2003-01-03
Procedure 3 - Power Cord
Step 1: Disconnect power supply
to range.
Step 2: Pull range away from wall.
Step 3: Pull plug from receptacle
with a quick firm tug (do not pull by
the cord). Power cord
configurations are as follows:
3 prong 240V; 60 Hz (electric)
4 prong 240V; 60 Hz (electric)
Step 4: Inspect plug for damaged,
corroded or burnt terminals. Look
around molded portion for signs of
over heating. If damaged replace
cord.
Step 5: Remove back panel (Refer
to Procedure 32 for details.
Step 6: Inspect power cord
connection at terminal block.
Inspect wires and strain relief clamp
for signs of damage. If damaged,
replace. See Procedure 2 for
details.
Step 7: If no visible damage
detected, check individual wires in
the power cord with a multimeter.
Step 8: Place one test probe on
the wire end and the other test
probe on the plug end. If no
continuity, replace power cord.
Step 9: For 3 prong cords, outer
terminal wire end (black side)
should indicate continuity to one
(not both) outer terminals of plug.
For 4 prong wires, black and red
wires at terminal end correspond to
specific terminal ends at plug.
Twist cord to ensure no internal
break occurs - replace if needle
drops.
Step 10: To remove power cord,
unscrew the three screws that
retain the ends of the cord to the
terminal block.
Step 11: Attach new power cord to
terminal block securely.

Section 5-3
20 MLSM2003-01-03
Procedure 4 - Timer Replacement
Step 1: For oven to operate, time
of day must be set in timer. See
Timer Programming (Procedure 5)
for details.
Step 2: Disconnect power supply
to range.
Step 3: Legacy Models. With
edge of fingers, pry on timer’s
edges to dislodge from control
panel.
Step 4: Metro models. Remove
control panel (see Procedure 34).
Step 5: Disconnect coaxial power
supply cable by lifting both locking
tabs.
Step 6: Disconnect two molex
plugs from clock. Double black
wire molex plug is positioned on the
connector closest to the bottom of
the timer.
Molex plug with white/black wires is
positioned on the connector closest
to the top of the clock.
Note: Black/white wire molex plug
is the oven thermostat probe wiring.
Double black molex plug is the self
clean microswitch wiring.
Step 7: To replace timer, push on
four tabs (two per side) and push
timer through front of control panel.
Step 8: Transfer all wires to the
new timer in the exact same
location (mark wires prior to
removing from old timer to ensure
proper transfer).
