Heartland Classic 6200 User manual

Installation and Operating Instructions For
Models:
Save these instructions
for future use
Note: Please read these instructions thoroughly before attempting to install this unit.
6200 48" Electric Convection w/smooth top Range
6210 48" Electric Convection w/smooth top Self Clean Range
8200 30" Electric Convection w/smooth top Range
8210 30" Electric Convection w/smooth top Self Clean Range
Model
6200/6210
NOTE: Clock must be
set or your main oven
will not function!
Model
8200/8210
ATTENTIONINSTALLER:Leavethismanualwithappliance
The oven door thermometer does not sense
temperature. It is for aesthestics only and is
nonfunctional.
© 2004HEARTLANDAPPLIANCESINC.
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage. Refer to this manual.
Forassistanceoradditionalinformation,
consult a qualified installer, service
agency, manufacturer (dealer). Please
read these instructions thoroughly
before attempting to install this unit.
Failuretofollowinstallationinstructions
will result in costly service calls.
C
®
US
Manual#67402
0060204.013106
1050FountainStreetNorthCambridge,Ontario,Canada N3H4R7
Bus.[phone] Fax[phone] TollFreePhone1-800-361-1517 TollFreeFax1-800-327-5609

1
TABLE OF CONTENTS
Description ............................... Page
1. Assembly and Installation ...................................... 2
2.PositioningtheRange ............................................ 3
3.InstallationClearances ........................................... 3
4. Exhaust Hood ........................................................ 4
5. Ventless Installation ............................................... 4
6.VentedInstallation.................................................. 5
7.ImportantSafetyInstructions.................................. 6
8.Radiant Heat Element Safety…………………..........6
9.OvenSafety............................................................ 8
10.SelfCleanOvenSafety......................................... 8
11.CooktopFeaturesandLayout .............................. 9
12. How to Set Smooth Cooktop Burners ..................10
13.Radiant Heat Elements .......................................11
14.CookwareSelection............................................ 12
15.Care & Cleaning of the Smooth Cooktop ............ 13
16.ToOrderCooktopCleaningSupplies .................. 14
17.OvenandWarmingDrawerFeatures ...................15
18.ControlPanel.......................................................16
19.WarmingDrawerControl&Operation ..................17
20.OvenBake/BroilControl ......................................18
21.OvenOperation....................................................19
22. How to Select Cooking Methods .........................20
23. Clock / Timer Function ........................................21
24.Time of Day Setting .............................................21
25. Minute Minder.....................................................21
26. Time Bake..........................................................22
27. GeneralCookingGuidelines ...............................23
28. Meat & Poultry Cooking Guide & Tips .................24
Description .......................................... Page
29. Broiling & BakingCooking Guide & Tips ..............25
30.GeneralCareandCleaning..................................26
31.Porcelain .............................................................26
32.StandardOven&WarmingDrawerCleaning........26
33.SelfCleanOvenCleaning ....................................26
34.HowtoSelf Clean ................................................28
35.TimeDelay SelfClean .........................................29
36.Cancel TimeDelay SelfClean .............................30
37. Nickel Trim ..........................................................31
38. Exhaust Hood......................................................31
39.ConvectionFanFilter...........................................31
40.OvenandCabinetLightReplacement ..................31
41.InteriorOvenRackRemoval.................................32
42.RackSupportsRemoval ..................................... 32
43.OvenDoorRemoval .............................................33
44.WarmingDrawerRemoval ...................................34
45.TheBroilerPan....................................................34
46.RangeProblemSolver .........................................35
47.OvenThermostat .................................................35
48. If you still require help—......................................35
49.OtherProducts ....................................................36
50.PartsDiagram .....................................................37
51. Parts List.............................................................38

2
Assembly and Installation
To fully enjoy your new range, it is important that you read this booklet thoroughly.
Note:
Pleasecheckforanydamagethatmayhaveoccurredduringshipping.Intheunlikelyeventthatyoufindanyshipping
damage,informyourdealerimmediately!
Caution when unpacking:
Lift the range by the bottom skirt, do not lift by nickel trim.
Unpacking:
Note:toavoid injury, pleasewearsafetyequipement, glasses andgloves,whileyou are unpackingyournewrange.
1) Unscrew the 12 screws that hold the crate onto the skid. There are 12 along the bottom and 4 along the top.
2)After the screws have been removed, carefully lift thecrate over the stove and set it aside.
3)Nextwithapairoftinsipscutthemetalbandingthatholdsthestoveintoplace.Cautionmetalbandingisundertension!
4)Carefullyremovethemetalbanding,the2 boardsthat whereunder thebandingandthecardbordcapandstyrofoam.
5)Youarenowreadytoremovetherangefromtheskid
For30"unitshaveonepersonateachendstandbesidetheskidandcarefullylifttherangebythebottomskirt,andathird
person pull the skid out from underneath the range. Slowly set the range down on the floor, bending you knee's not your
back!
For48"unitsunitshaveonepersonateachendandoneside,standbesidetheskidandcarefullylifttherangebythebottom
skirt,andafourthpersonpulltheskidoutfromunderneaththerange.Slowlysettherangedownonthefloor,bendingyour
knee'snot your back!
6)Finishunpackingtherangeremovingpackingtapearoundthe doorsand inthe oven.
Both 30" and 48" Ranges consist of two main parts:TheRangeBody,and
TheCabinet/ExhaustHood
Tools required for assembly: -Phillips/RobertsonScrewdriver
- 5/16" ( 8 mm) wrench or crescent wrench
Gliders:
The teflon glider should extend beyond the bottom of the leg by approximately
1/8"-1/4". Adjusting levelling bolts in too far will cause the leg to drag on the
floorpotentially causing damage to flooring. (see figure1). Check that gliders
and floor are free of any debris, this will ensure you do not scratch your floor. TeflonGlider
1/8"- 1/4"
Assembly of Exhaust Hood to Range
Seethemanualentitled"CabinetInstallationInstructions
for Gas, Electric, Combination and Wood Stoves"which
is included with the cabinet .
(DONOTRESTCLOSETCORNERBRACKETSON
SMOOTHSURFACE,DAMAGETOSURFACEMAY
OCCUR)
Figure 1
Figure 2
You must have a qualified electrician connect the new range to be sure all electrical codes and rules are
observed except when range is equipped with a cord and plug

3
Positioning the Range
1. Whentherangeisfullyassembled,recheckallelectricalconnectionsespeciallybetweentheexhausthoodandthe
back of the range. As well, check that all nuts and bolts have been tightened.
2. Ensureteflon gliders andflooringareclean,(as described on page2under"Gliders").
3. Caution:Onflooringwithveryroughsurfacesordeep,largegroovestheappliancemayhavetobeliftedandslowly
slid into position.
4. Putbothhandsonthetrimandcarefullypushtherangeintoplace,makesurefloorisclearofalldebris.Don'tforget
to plug in the main power cord and the exhaust hood power cable and test the operation of the appliance,
before the range is in it's final position. See cabinet installation instructions.
5. Toleveltherange,simplyadjustthelevellingscrewswithteflonpadslocatedatthebottomofeachleg(theonesyou
assembledonpage2under"Gliders").Usinga5/16(8mm)openendwrenchturntheadjustingscrewclockwiseto
raiseupthecorner,andcounter-clockwisetolowerthecorner.(Don'tforgettheteflonglidershould extend beyond
the bottom of the leg by approximately 1/8"-1/4") Ensure the unit is perfectly level, or utensils may fall of during
cooking.
6. Note: Onsoftkitchenflooring,theweightofthestovemaycauseslightdepressionsintheflooring.Whentherange
is in position and levelled, you may want to place coasters under the teflon gliders of each leg, to protect the floor.
Removethecoasterswhenmovingtherangeforcleaningorservicing.
Figure 3
Installation Clearances
Iftherangemuststandbesidearefrigerator,itisimportant
forproperair circulation, that therebeatleastfive inches
(125mm)ofspacebetweenthetwoappliances.
Donotinstallrangecloserthan1/2"(13mm)fromadjacent
surfaces.
Toeliminatetheriskofburnsorfirebyreachingoverheated
surfaceunits,installationofcabinetstoragespace above
the surface units should be avoided. If there is existing
cabinet storage space have at least 30 1/4" (768 mm) of
clearance.(seefig3)
Forbest cooking results,your range should be level.
Thiscanbecheckedwithacarpenter’slevelontopofthe
cooking surface and across the oven rack. If levelling is
required,adjustthelevellingscrewsunderoneormoreof
the legs (see "Positioning the Range" step 5).
Caution: Ensure the unit is per-
fectly level, or utensils may fall
off surface during cooking.
Minimum
30 1/4”
768 mm

4
Exhaust Hood
Yourrangeisequipped with a two speed range hood thatmaybeeitherventeddirectlyto the outside, or may be
installedventless.Asetofexhaustfiltersareincludedwithyourhood.Thefiltersshouldbecleanedperiodicallyin
soapywater.ExtrasareavailablefromyourdealerordirectlyfromHeartlandAppliancesInc.Pleaseorder4ormore
filtersat one time to save freight and handling charges.
VentlessInstallation
Your unit is already set up for ventless operation. Cooking fumes are drawn through the filters and exhausted
throughtherear of the hood, back into the room. Install theexhaust filters in their location under the cabinet by
firstremovingthelightlens.Thenononeside,insertoneofthefiltersintothegrooves(frontandrearofthecabinet)
and slide into place. Repeat these steps for the second filter
Installation of Ducting
Installation through an outside wall
Remove air deflector (used for ventless operation only). Cut a 3 1/2 x 10 1/2 ( 88.9mm x 266.7 mm) hole through
the wall directly behind the range hood outlet (See Figure 4.), making sure no wall studs are cut. Push range into
position.Fromoutsideofthehouse,measuredistancefromthesidingtotherangeoutlet.Cutductpipethatlength,
plus1”(25.4mm)foroverlapintooutlet.Attachventhoodtopipe.Caulkthebackofventhoodandaroundpipewhere
it goes through wall and into range hood outlet so caulking seals against outside siding.
Completeinstallation byfollowingdirectionsunderVentless Installation.
Installation through an attic to an outside wall
Ifthevent elbows are embedded in thewall,therangemay be positioned as showninFigure4.Continue the duct
through the ceiling into the attic. Terminate duct either on an outside wall just below the sofit using a vent hood or
throughtheroofwith a roof cap. Seal with caulking around and under cap or hood.
Completeyour installationbyfollowing directionsunderVentless Installation.
Figure 4
Exhaust venting
options

5
14.0"
355 mm
28”
711 mm
29 1/2”
787 mm
Range Hood Outlet
31/4"x
10"
83 mm
x 254mm
66 1/4"
1682 mm
62 3/8"
1585 mm
56"
1422 mm
36 1/8"
917 mm
29 3/4"
756 mm
14 7/8"
378 mm
20 "
508 mm
66 1/4"
1682 mm
56 "
1422 mm
36 1/8"
917 mm
9 1/4"
235 mm 47 1/2"
1207 mm
Ran
g
e Hood Outlet
3 1/4" x 10"
83 mm x 254 mm
39 3/4"
1010 mm
Power Cord
Exhaust Hood In
(female receptacle)
14.0"
355 mm
28”
711 mm
749 mm
Oven Exhaust
Installation must be done in
accordancewithalllocaland
nationalcodes.
Use only materials which
conform to local codes in
effect. Be sure power is
disconnected before doing
any electrical work. All duct
work must be metal.
Donotuseplasticduct.The
range hood should never
be exhausted into a wall
cavity or an attic where an
accumulation of grease
could become a fire
hazard.
When the installation is
completed, turn on the fan
andmakesurethatthereare
no obstructions in the duct.
30" Model
48" model
Venting Safety Guidelines
Vented Installation, Tools, Material, and Dimensions
Tools required to install vented hood: -Hammer -Slotscrewdriver
- Pliers - Electric drill
-Measuringtape - 3/32”(3 mm) Drill bit
- 1/2”(13 mm) Drill bit - Sabre saw OR Keyhole saw
Materials Required:
-31/4" x10" (82.55mmx254mm)metalduct—enoughtogothroughwallorattictooutside.Elbowsasrequired.
-Roofcaporwallventhood
- Caulking to seal around duct
- #6 x 1/2”(82.55 mm x 254 mm) sheet metal screws
Theabovearestandardpartsandareavailableatanyhardwarestoreorheatingcontractor.
NOTE : A 3 1/4" x 10" (82.55 mm x 254 mm) exhaust adaptor is included with the exhaust hood.

6
Important Safety Instructions
1. PROPERINSTALLATION—BESUREYOURAPPLIANCEISPROPERLYINSTALLEDANDGROUNDEDBYA
QUALIFIEDTECHNICIAN.Havetheinstallershowyouthelocationofthecircuitbreakerorfuse.Markitforfuture
reference.
2. Neveruseyourapplianceforwarmingorheatingtheroom.Useonlyforitsintendeduseasdescribedinthismanual.
3. Donotleavechildrenalone.Childrenshouldnotbeleftaloneorunattendedinareawhereapplianceisinuse.Children
should never be allowed to sit or stand on any part of the appliance.
4. Do not allow children to play with controls or any part of appliance.
5. Do not climb, stand or hang on the appliance.
6. Wearproperapparel—loose-fittingorhanginggarmentsshouldneverbewornwhileusingtheappliance.Flammable
material could ignite on contact with hot surface units and cause severe burns.
7. Userservicing—donotrepairorreplaceanypartoftheapplianceunlessspecificallyrecommendedinthemanual.
Allotherservicingshouldbereferredtoaqualifiedtechnician.Beforeperforminganyservice,switchoffcircuitbreaker
orremovefuse.
8. Storage in or on appliance—flammable materials should not be stored in an oven, near surface units or in range
cabinet.
9. Donotusewaterongreasefires–neverpickupaflamingpan-smotherfireorflamebycoveringpanwithawellfitting
lid, cookie sheet, metal tray or use dry chemical or foam type extinguisher.
10. Use only dry potholders—moist or damp potholders on hot surfaces may result in burns from steam. Do not let
potholdertouchhotheatingelements.Donotuseatowelorotherbulkyclothinplaceofpotholder.Suchmaterials
could catch fire on hot surface unit.
11. Do not let cooking grease or other flammable materials accumulate on the cooktop.
Exhaust Hood Safety
Caution: Do not store items of interest to children in cabinet above the range or on top of range cabinet.
Children climbing on range to reach items could be seriously injured.
1. Cleanexhausthoodfrequently—grease shouldnotbeallowedto accumulateonhood orfilter.
2. Iffoods catch fire under the hood,turnthefanoff.Thefan, if operating may spread the flame.
Radiant Top Burner Safety: Do not touch surface units or areas near units.
-Surfaceunitsmaybehoteventhoughtheyareconcealed. Duringandafteruse,donottouch,orletclothingorother
flammablematerialscontactsurfaceunitsorareasnearunitsuntiltheyhavehadsufficienttimetocool.Alwayskeep
dishtowels, cloths, potholders and other linens a safe distance away from cooktop.
-Cooktop surfaces nearthe elements increase intemperature, with thenumber of elements thatare on. Areasnear
surfaceunitsmaybecomehotenoughtocauseburns.Alwayskeepcombustiblewallcoverings,curtainsordrapes
asafe distanceawayfromappliance.
-Useproperpansize—thisapplianceisequippedwithoneormoresurfaceunitsofdifferentsizes.Selectutensilshaving
flatbottomslargeenoughtocoverthesurfaceunit-heatingelement.Theuseofundersizedutensilswillexposeaportion
oftheheating element todirectcontactandmay result inignitionofclothing. Proper relationship ofutensiltoburner
willalsoimproveefficiency.Neverleavesurfaceunitsunattendedathighheatsettings—boilovercausessmokingand
greasy spillovers may ignite. Avoid heating an empty pan as it may damage the cooktop and the pan.
-Glassandceramic cookwareisnotrecommended for usewithyourradiant smooth cooktopasthey may breakdue
tothesuddenchange intemperature.
-Utensilhandlesshouldbeturnedinwardandnotextendoveradjacentsurfaceunits—toreducetheriskofburns,ignition
of flammable materials, and spillage due to unintentional contact with the utensil.

7
-Alwaysturnthesurfaceunitsoffbeforeremovingcookware.
-Whenpreparingflamingfoodsunderthehood,turnthefanon.
-Usecarewhentouchingthecooktop.Thesmoothsurfaceofthecooktopwillretainheatandmaybehotenoughtoburn
eventhoughitmayappeardarkincolor afterthe controlshave beenturnedoff.
-Uselittlefatforeffectiveshallowordeepfatfrying.Fillingthepantoofulloffatcancausespilloverswhenfoodisadded.
Never try to move a pan of hot fat, especially a deep fat fryer. Wait until the fat is cool.
-If a combination of oils or fats will be used in frying, stir together before heating, or as fats melt slowly.
-Foodsforfryingshouldbeasdryaspossible.Frost,frozenfoodsormoistureonfreshfoodscancausehotfattobubble
upand over the sides of the pan.
-Always heat fat slowly, and watch as it heats.
-Useadeepfatthermometerwheneverpossibletopreventoverheatingfatbeyondthesmokingpoint.
-Avoid scratching the smooth cooktop. The cooktop can be scratched with items such as sharp instruments, rings or
other jewelry, and rivets on clothing. Do not stand on the smooth top.
-Donotoperatetheradiant surface units if the glass is broken. Spillovers or cleaningsolutionmaypenetrateabroken
cooktopandcreate a risk ofelectricalshock.Contacta qualified technician immediatelyshouldyoursmoothcooktop
becomebroken.
-Neverusethe smooth surface as a cutting board.
-Neverheatunopenedfood containers.Pressurebuildupmaymakecontainer burstand causeinjury.
-Neverleavejarsorcansoffatdrippings onor nearcooktop.
-Do not place or store items that can melt or catch fire on the smooth surface, even when it is not being used.
-Becarefulwhenplacingspoonsorotherstirringutensilsonthesmoothsurfacewhenitisinuse.Theymaybecomehot
andcouldcauseburns.
-Cleanthecooktopwith caution. If a wet spongeorclothisusedto wipe spills on a hotsurfaceunit,becarefulto avoid
steam burns. Some cleaners can produce noxious fumes if applied to a hot surface.
- NOTE : We recommend that you avoid wiping any surface unit areas until they have cooled and the indicator
light has turned off. Sugar spills are the exception to this. Please see the “Cleaning the Smooth Cooktop”
section for detailed instructions on keeping your cooktop clean.
-Whenthe cooktop is cool, use only Cerama BryteÒceramic cooktop cleaner and the Cerama BryteÒcleaningpadto
clean the cooktop.
-To avoid possible damage to the cooking surface, do not apply cleaning cream to the smooth surface when it is hot.
-After cleaning, use a dry cloth or paper towel to remove all cleaning cream residue.
-Readandfollowallinstructionsand warnings on the cleaning cream labels.
- Large scratches or impacts to cooktops can lead to broken or shattered glass.

8
Oven Safety
Do not touch heating elements or interior surfaces of oven—heating elements may be hot even though they are dark in
colour. Interior surfaces of an oven become hot enough to cause burns.
Duringandafteruse,donottouch,orletclothingorotherflammablematerialstocontactheatingelementsorinteriorsurfaces
of oven until they have had sufficient time to cool.
Othersurfacesoftheappliancemaybecomehotenoughtocauseburns—amongthesesurfacesare,forexample,ovenvent
openings and surfaces near these openings, oven doors.
1. Use care when opening door—let hot air or steam escape before removing or replacing food.
2. Do not heat unopened food containers—buildup of pressure may cause container to burst and result in injury.
3. Keepovenventductsunobstructed.
4. Placementofovenracks—alwaysplaceovenracksindesiredlocationwhileoveniscool.Ifrackmustbemovedwhileoven
is hot, do not let potholder contact hot heating element in oven.
5. Do not use aluminum foil to linethe bottom of the oven,it could result in a risk of electric shock or fire.
Self Clean Safety Instructions
Read the instructions below and the appropriate timer instructions before attempting to operate.
Do not touch heating elements or interior surfaces of oven—heating elements may be hot even though they are dark in
colour. Interior surfaces of an oven become hot enough to cause burns.
Duringandafteruse,donottouch,orletclothingorotherflammablematerialstocontactheatingelementsorinteriorsurfaces
of oven until they have had sufficient time to cool.
Othersurfacesoftheappliancemaybecomehotenoughtocauseburns—amongthesesurfacesare,forexample,ovenvent
openings and surfaces near these openings, oven doors.
1.Removeutensilsandcookwarefromtheoven. Ovenracksandracksupportsshouldberemovedfromtheoven.Racksand
supports left in the oven during self clean will become discoloured, but it will not affect the protective coating.
2. Remove all utensils and food from cooktop. Note: use of surface elements while range is self-cleaning is NOT
RECOMMENDED.Formodel 8210 30" range,thetworight and frontleftsurfaceelements will notbeoperationalduring self
cleanmodeaslongasthedoorlockisengaged.Formodel621048"range,thetwoleft andtworightsurfaceelementswillnot
be operational during self clean mode as long as the door lock is engaged.
3.Removeallcontentsfromthestoragedrawer. Thisincludesplasticoraluminiumutensilsandanyutensilswithplasticparts
thatcan become over heated and melt.
4. In 48" ranges remove all contents from the storage area behind the cast door. This includes plastic or aluminium utensils
and any utensils with plastic parts that can become over heated and melt.
5. DO NOT clean the gasket. The door gasket is essential for a good seal. Care should be taken not to rub, damage or move
thegasket.
6. Never use a commercial oven cleaner in a self cleaning oven. This will damage the finish.
7.Makesuretheconvectionfanisoff.Theconvectionfanswitchmustbeturnedoffatthecontrolpanelatthetimer.(The oven
light will automatically go off when the door is closed.)

9
FEATURES - USING THE SURFACE ELEMENTS
Cooking Controls (Surface Units)
A - 1200 watt radiant 5 1/2" dia.
B - 2000 watt radiant 7 1/2" dia.
C - 2500 watt dual radiant 9" dia.- 1000 watt
inner ring
E -1500 watt radiant 6 1/2" dia
(30" Model only)
G - Element Controls (allows an infinite range
of cooking termperatures)
Control Panel Layout:
Thecontrolpanel is laid
outinastraightline and
eachcontrolisidentified
by a graphic on the left
side of the knob
corresponding to the
radiantsurfaceelement
on the cooktop.
Model 8200/8210 Control Panel
Model 6200/6210 Control Panel
Top Elements Indicator Light
Left Rear Element Control
Left Front Element Control
Center Dual Element
Control
Right Rear and Bridge Ele-
ment Control
Right Front Element Control
OvenControl
Oven Indicator
Light
Top Elements Indicator Light
Left Rear Element Control
LeftFrontDualElement
Control
Right Rear Element Control
OvenControl
Oven Indicator
Light
Right Front Element Control
30" Model
A
C
B
E
G
48" Model
A
B
C
F
D
A - 1200 watt radiant 5 1/2" dia.
B - 2000 watt radiant 7 1/2" dia.
C - 2500 watt dual radiant 9" dia. - 1000 watt inner ring
D - 1800 +800 watt radiant 7" dia (48" model only)
F - 1800 watt radiant 7" dia. (48" model only)
D & F -Total area of bridge element 16 1/2"x7"
G-ElementControls(allowsaninfiniterangeof cooking
temperatures)
G
Warming Drawer
Indicator Light Warming Drawer
Indicator Light

10
Burners A,B, E & F:
- Push the knobs in and turn in either direction to the setting desired.
-Thehighernumber selected represents the higher temperature.
- At both the low (1) and high(7) settings, the control will "click" into position.
Control will also "click" and pop back up, in the off (0) position.
- Please be sure control knob is turned off (0) when your finished cooking.
How to Set Smooth Cooktop Burners
Note: You may hear slight "clicking" sounds during cooking. These sounds are normal and indicate the control is maintaining the
power level set on the knob.
Dual Surface Unit Control Knob - Burner C:
Dual element has two cooking sizes available to select from in order to offer
the versatility to match the size of the heating element, to the size of the
cookwarebeingused.
To use the inner surface heating element (5-6"):
- Push the knob in and turn counterclockwise to settings 1 through 3.
Controlpanel screening matches correspondingheatingelementselected.
To use the entire heating element (8-9"):
- Push the knob in and then to settings 1 through 5.
Controlpanel screening shows both inner and outer surface units heating
-Thehigher number selectedrepresentshighertemperature.
Bridge Burner operation - Burner D (48" models only):
BridgeBurnerofferstheversatilityofusingtherearelementonlyortherear
element and the bridge (Fig. A), the front element only (Fig. B) or all three
settings simultaneously, thanks to the two separate controls.
To use the rear element only:
- Push the knob in and turn counterclockwise to settings 1 through 3.
To use the rear and bridge sections:
- Push the knob in and turn to settings 1 through 5.
Controlpanel screening matches corresponding heating elements selected.
Thehighernumberselected represent high temperature.
To use front element in bridge burner:
- Push knob in and turn in either direction to the desired setting.
Thehighernumberselectedrepresents the higher temperature.
To use all three elements simultaneously:
- Operate both controls and turn to desired settings.
Indicator lights (allBurners):
Ageneralburnerindicatorlight will glow red when one or more radiant heating
elements are turned on, and will remain "on" until the last heating element is
turnedoff.
Each burner also has a dedicated light which will glow when the radiant
element is hot, and will remain "on", even after the control has been turned
off,untilthesurfaceiscooledtoapproximately150degreesFarenheit.
Fig. A
Fig. B

11
About the smooth cooktop surface units…
Thecooktopfeaturesheating unitsbeneath asmoothEurokera Ceramic surface.
Note:Aslightodorisnormalwhenanewcooktopisusedforthefirsttime.Itiscausedbytheheatingofnewpartsandinsulating
materials and will disappear in a short time.
The surface unit will cycle on and off to maintain your selected control setting.
It is safe to place hot cookware on the smooth surface even when the cooktop is cool.
Evenafterthesurfaceunitsareturnedoff,theradiantcooktopretainsenoughheattocontinuecooking.Toavoidovercooking,
remove pans from the surface units when the food is cooked. Avoid placing anything on the surface unit until it has cooled
completely.
•Waterstains(mineraldeposits)areremovableusingthecleaningcreamorfullstrengthwhitevinegar.
•Useofwindowcleanermayleaveaniridescentfilmonthecooktop.Thecleaningcreamwillremovethisdiscoloration.
•Do not store heavy items above the cooktop. If they drop onto the cooktop, they can cause damage.
•Do not use the surface as a cutting board.
TemperatureLimiter
Everysurface unithasatemperaturelimiter.
Thetemperaturelimiterprotectsthesmooth surface from getting too hot.
The temperature limiter may cycle the units off for a time if:
•The pan broils dry
•The pan bottom is not flat
•The pan is off center
•There is no pan on the unit
OFF CENTER
DRAGGING
Never cook directly on the
smooth surface, always
use appropriate cookware
Always place pan in the
centerofthesurfaceunit
you are cooking on
Do not slide cookware
acrossthecooktopasitcan
scratch the surface-the
smooth cooktop is scratch
resistant not scratch proof.

12
Selecting types of Cookware:
Thefollowinginformationwill help you choose cookware, which will givegoodperformanceonglasscooktops
Stainless Steel: Recommended.
Aluminum: HeavyWeightrecommended .
Good conductivity. Aluminum residues sometimes appear as scratches on the cooktop, but can be
removedif cleaned immediately.Because of its low melting point, thin weight aluminum should not
beused.
Copper Bottom: Recommended.
Coppermayleaveresidues,whichcanappearasscratches.Theresiduescanberemoved,as long
as the cooktop is cleaned immediately. However, do not let these pots boil dry. Overheated metal
can bond to glass cooktops. An overheated copper bottom pot will leave a residue that will
permanentlystainthecooktopifnotremovedimmediately.
Porcelain Enamel Recommended.
Covered Cast Iron: As long as the cookware is covered completely with porcelain enamel, this cookware is recom-
mended.Cautionisrecommendedforcastiron cookware that is not completely covered with
smooth porcelain enamel as it may scratch the glass ceramic cooktop.
Glass-ceramic: Usable, but not recommended
Poorperformance.Mayscratchthesurface
Stoneware: Usable, but not recommended
Poorperformance.Mayscratchthesurface
Home Canning Tips:
LBe sure the canner is centered over the surface unit.
LMake sure the canner is flat on the bottom
LUserecipesandprocedures from reputable sources. These areavailablefrommanufacturerssuch as BallÒand KerrÒ
andtheDepartmentof Agriculture Extension Service.
LTo prevent burns from steamorheat,usecautionwhencanning.
LFlat-bottomedcannersarerecommended.Useofwaterbathcannerswithrippledbottomsmayextendthetimerequired
to bring water to a boil.
Wok Cooking:
LWe recommend that you use only a flat-bottomed wok. They are
availableatyourlocalretailstore.
LDo not use woks that have support rings
LDo not use round bottom woks. You could be seriously
burned if the wok tipped over.
Pots and Pans:
Check pans for flat
bottoms by using a
straight edge
Pans with rounded, curved, ridged or warped bottoms are not recommended

13
Cleaning the Glass Cooktop:
(fororderinginformation of any of thefollowingcleaningproductsplease see page 14)
Clean your cooktop after each spill
Make sure all control knobs are in the “0”(off) position
Normal Daily Use Cleaning:
Only use the recommended cleaning cream, Cerama Bryte™, on the glass cooktop. Other creams may not be as effective.
To maintain and protect the surface of your glass cooktop, follow these steps:
1. Before using the cooktop for the first time, clean it with the cooktop cleaning cream. This helps protect the top and
makes clean up easier.
2. Daily use of the cooktop cleaning cream will help keep the cooktop looking new and easy to clean.
3. Shake well. Then apply a few drops of the cream directly to cooktop surface on soiled area.
4. Use a paper towel or sponge to clean the entire cooktop surface.
Note : It is very important that you DO NOT use the soiled area until it has been cleaned thoroughly.
Cleaning Pad for Burned-On Soil:
1. Allow the cooktop to cool.
2. Apply a few drops of cooktop cleaning cream to the soiled area. Spread the cream across the entire soiled area.
3. Using the cleaning pad, rub the soiled area. Apply pressure, as needed, while rubbing with the pad.
4. Ifanysoilremains, repeat the above steps.
5. Foradditionalprotection,afterallsoilhasbeenremoved, polish the entire surface with the cooktop cleaning cream.
Warning: Damage to your cooktop surface may occur if you use pads other than Blue Scotch-Brite™ Multi-Purpose No
Scratch by 3M
Razor Scraper for Heavy, Burned-On Soil:
1.Allow the cooktop to cool.
2. Apply a few drops of cooktop cleaning cream to the soiled area. Spread the cream across the entire soiled area.
3. Hold the scraper at approximately a 45°angle against the ceramic glass surface and scrape the soil. It will be
necessary to press down on the razor scraper while scraping the soiled area.
4. Keep small amount of cream on the soil as you scrape.
5. Afterscrapingwith razor scraper, use the cleaning pad with cleaning creamto remove any residual soil.
6. Ifanysoilremains,repeat the above steps as needed.
7. Foradditionalprotection,afterallsoilshavebeenremoved,polishtheentiresurface with the cooktop cleaning
cream.
Note: Razor blade is packed inverted for safety reasons. Prior to use, the blade must be rotated and reinserted into slot.
Do not use a dull or nicked blade

14
Cleaning The Glass Cooktop:
Special Care for Sugary Spills:
Our testing shows that if you are cooking high sugar mixtures such as jelly or fudge and have a spillover, permanent damage
to the cooktop surface may occur unless the spillover is immediately removed.
1. Turnoffallsurfaceunits.Remove all hot pans.
2. Wearing an oven mitt, hold the razor scraper at approximately a 45°angle and move the spill to a cool area on the
cooktop(awayfromthehot surface unit).
3. Removethespillwithapapertowel.
4. Any remaining spillover should be left until the surface of the cooktop has cooled.
5. Cleantheaffected area thoroughly as described underDailyUsecleaning(see previous page).
Note: if pitting has already occurred, the cooktop glass will have to be replaced. In this case, service will be necessary.
Milky Looking Lines on Cooktop:
LThese lines come from the process of gluing the cooktop into the metal frame.
LUse the cooktop cleaning cream to remove these lines.
LYou have to put a lot of “elbow grease”behind it to remove the lines, but it is possible to take them off.
Metal Marks and Scratches:
1. Be careful not to slide pots and pans across your cooktop. It will leave metal markings on the cooktop surface.
Thesemarksareremovable using the cleaning cream with cleaning padand/orrazorscraper.
2. Ifpotswitha thin overlay of aluminum or copper are allowedto boil dry,theoverlaymayleave a black discoloration
onthecooktop.Thisshouldberemoved immediately before heating again or the discoloration may be permanent.
Warning: Carefully check the bottoms of the pans for nicks and gouges that would scratch the cooktop.
MeltedPlastic or Porcelain from Cookware:
1. If porcelain from cookware melts/hardens onto the glass it usually cannot be removed because it bonds to the glass.
2. If any plastic melts onto the glass and has not already hardened, you may try to remove it following the general
instructionsdescribedabove under SugarySpillovers.
Note: If you have melted porcelain or plastic that will not come off the glass, the cooktop will have to be replaced and service
willbenecessary - however, neither parts nor labourwillbecovered under warranty (pleasereviewTermsandConditions for
fulldetails).
Cooktop Seal:
To clean the cooktop seal around the edge of the glass, let a wet cloth rest on it for a few minutes, then wipe clean. Use a
mild detergent if needed. Do not use metal scraper on the seal as it may damage it and compromise the seal.
To Order Parts:
To order more cleaning cream, cleaning pad and razor scraper for cleaning yourglasscooktop,please call our toll free
number:1-800-361-1517 and ask for the order desk.
GLASS/CERAMICCOOKTOPCREAMCLEANER …………………..……..Part # 01732
GLASS/CERAMICSCRAPERand PAD …………………….............…………...Part # 01733
GLASS/CERAMIC COOK TOP CLEANING KIT ...................................…Part # 01734
(includes scraper, pad and cream) .

15
Cooking Controls
The cooking controls are located on the right
handsideofthecooktop;thesecontrolsofferan
infinite number of heat settings for ease and
accuracy in cooking and baking.
Solid Element Features
(seefigure5)
A) 6" (152mm) Ultra Temp Solid Element
Burners-heatup 25%fasterthanconventional
solidelements.Twoon30"modelsand2on48"
models
B)7"(177mm)UltraTempSolidElementBurners
forbiggercookingjobs-alsoheatup 25%faster
than conventional solid elements. Two per 48"
models and one per 30" models
C9"(228mm)AutomaticElementSolidElement
Burner - heat sensing, thermostat controlled
element,accuratelymaintainstemperatures.
D) Solid Element Controls - allow an infinite
selectionofcookingtemperatures
E)AutomaticElementControl-allowsaccurate
selectionofcookingtemperatures.
Oven Features
F)Oventemperature control - With bake control, broil control
G) Self Clean latching handle - slides to the right to lock the oven door during the self clean cycle. (self clean models only). Latch
must not be used to lock door during regular cooking functions or damage to latch may occur. Activating the latch will
prevent the use of the left front and two right burners on model #8210 - 30" self clean and the two left and two right burners
onmodel#6210 self clean.
H)Convectionoven: - baking,broiling
- timedbaking,broiling
- convectionbaking,broiling
- timedconvectionbaking,broiling
- 4positionracking
- 4cubicfeetofenergyefficientbakingarea(.11cubicmeters)
- lowmaintenancehightemperatureselfcleanoven(selfcleanmodelsonly)
Warming Drawer Features
I) Located under the main oven, glides open for easy access
J)Thermostatictemperaturecontrol, locatedjustrightandbehind thewarmingdrawer
- sliding humidity control
-large1cubic foot warming area
Storage Features (48" models only)
- Rack storage area: ideal for oven racks and baking trays.
- Utensil drawer: Unique storage space, keeping necessities within easy access
H
eartlan
d
H
eartlan
d
H
eartland
Features
B
Control Panel
Figure 5
(48" Model shown)
ACD
Rack
Storage
Utensil
Drawer
E
F
G
H
IIJ

16
ClockControl Panel-Thetimerandcontrolpanelisconcealedbehindthecabinetdoorfor
standard and self clean models. Note: Warming Oven is not timer controlled
K) Digital Timer - With minute minder and automatic start and stop cooking features.
L)RockerSwitchcontrols the overhead light under the exhausthood.
M)RockerSwitchcontrolsconvectionfanforconvectionbaking/broiling.
N) Three position switch controls the high / low for the exhaust fan. Center position is “OFF”.
Control Panel
A
U
T
O
2
K
LM
Please Note: Warming oven is not affected by timer settings
N

17
Heartlan
d
H
e
artla
n
He
ar
tlan
Closed
Open
Warming Drawer Control and Operation
To activatethe warming drawer,first find thetemperature controllocated
besidethe warmingdrawer behindthe drawerdoor.
Select a temperature level from "0 - 3" where "0" is off and "3" is high. The
temperatureis infinitely variable and ragesfrom 130°F to 220°F. (54°Cto
104°C)
Whenthecontrol isinuse the indicatorwillglow untilthetemperature level
hasbeenreached, thenit will cycleon andoffto maintaintemperature.
Warmrolls,breads, vegetables, meatsetc.
aswellas plates onHIGH.
Thewarmingdrawer alsofeaturesa humidity
controllocated along thetop ofthe drawer
door. When the control ispositioned tothe
leftstop,the humidityis retainedinthe warm-
ingdrawer. Ifpositioned tothe rightstop,
thenair is ableto circulateallowing humidity
to escape.
Too keepmoisture in,close humidity control.Tokeep things crisp,open humiditycontrol. Proof( rise)
breador pizza doughon LOWwithhumidify controlclosed
Pleasenote: Do notuse thedrawer as storage. Items storedthere maybe damagedif the temperature
controlis activated.Warmingdrawer may beremoved foreasier cleaning(see "Warming Drawer
Removal" page 34")
warmingovenidicator light located
rightandbelow main oven control
temperaturecontrol
humidity control
slidingwarmingdrawer
0
2
3
1

18
Bake - Broil Control
Baking
To bake, push down and turn the oven control counter clockwise to any desired temperature.
When baking is selected, the indicator light under the bake symbol lights up, and the bake
elementwillactivate.Theelementwillthencycleonandofftomaintainanaveragetemperature
intheoven
Pleasenote: thatwhenovenisturnedontopreheat,thefirstcyclemayexceedsettemperature
-pleaseallowovento cycleon/offbeforeplacingfoodinoven.
Thetemperatureisinfinitelyvariablebetweentemperatures 150°Fand 550°F(65°Cand290°C.)
Broiling (do not broil with door open)
Toactivatebroil(topelement),turnovencontroltobroil.Whenbroilingisselected,theindicator
light, lightsup.Tode-selectbroiling,turntheovencontrolknobtoatemperaturesetting,which
resetsthe control tobakingmode. Ifknobis turned pastthe"BROIL" position-elementwill not
operate.Turnback to broil position.
Oven Bake/ Broil Control
Main oven
indicator light
Warming drawer
indicator light

19
Oven Operation
BeforeYoustart:
1. Remove the oven racks and oven rack supports and clean with soap and water. (see
interior oven rack and rack support removal pg. 32 ).
2. Unwrapbroilerpanandcleanwithsoapandwater.
3. Cleanovenwithsoapand water,makingsurethatalladhesiveshave beenremoved.
4. Settimeontheclock,clockmustbesetorovenwillnotfunction!(seetimersection
pg.21).
5.Turn ovenonto500°F(260°C)for30minutestoburnoffbondingagentsintheinsulation.
Therewill beanunpleasant odourandsome smoke,whichisunavoidable.
Getting to Know Your Oven
Theovenlightwillautomaticallyactivatewhentheovenisopenedanddeactivatewhenthe
ovendoorisclosed.
Alsoiftheovenissetforconvectionmode,thentheconvectionfanwilldeactivatewhenthe
ovendoorisopened, andactivate whentheovendoorisclosed.
Theovenfeaturesmultilevelregularbaking/broilingintimedorun-timedmodes. Forenergy
efficientbatchbaking,chooseconvectionbaking,whichallowsyoutobakeonmultilevels
simultaneously. Fortraditionalbakingtheconvectionfeatureshould be OFF.
Yourovenhasatemperaturerangeof150°Fto550°F(65°Cto290°C).TheovenCycling
Lightglowsuntilovenreachesthehighendofheatingcycle,thencyclesoffandonduring
cooking.Theaverageofthehighandlowlevelsoftheheatingcycleswillbeapproximately
within30°Fofselectedtemperature.Thistemperaturefluctuationisnormalandstandard
intheapplianceindustry.Seepages24and25 forrecommendedbakingandroastingtimes
andtemperatures.
Note:
1)SelfCleanModelsOnly-Donotengagetheselfcleanovendoorlatchwhennotin
selfclean mode, as itis possible the ovendoor safety interlock willactivate at high
oventemperaturesanddamage couldoccurtothe lockingmechanism.Also,while
thelatchisengaged,thefrontleftandtworightburnersaredeactivatedonModel8210
30" self clean, as well the two left and two right burners on the model 6210 48" are
deactivated.
2)See pages 23 through 25 for recommended broil times and settings.
3)Temperaturesinovensmayshiftovertimeanditisnaturalfortheusertograduallyadapt
cookingtimesaccordingly.Then,whenbakinginanewovenwithpropercalibration,results
maynotbeasexpectedbasedonpreviousbakinghabits.Ovencavitysizesalsovaryfrom
manufacturer to manufacturer and could affect cooking results slightly. Therefore, it may
takesometimetofamiliarizeyourselfwithyournewovenandsomeadjustmentincooking
times may be necessary.
