Heatilator SC60 User guide

SC60
Woodburning Fireplace
2 in min. air
space clearance
from chimney
43-1/8 in
25 in
41-1/4 in
8 in

a brand of Hearth & Home Technologies Inc.
1915 West Saunders Street • Mt. Pleasant, Iowa 52641
800-927-6841 • heatilator.com
The information provided in this literature is for planning purposes only and subject to change.
Please consult the installation manual for actual installation. The ame and ember appearance
may vary based on the type of fuel burned and venting conguration used. For full warranty
details, go to heatilator.com.
*Please consult the MSRP book for a complete list of optional accessories.
Photo on cover shown with optional air gasketed door.
AVAILABLE FROM
HTL-1024U-1008
Options
DM Doors
Fireside Gas Logs
• Exceptional heating capacity of 70,000 Btu/hr.
• Large viewing area with 36" wide and 19-1/8" tall opening
• Firebox assembly is fully insulated and comes standard with rebrick lining and
outside air kit
• Standard 160 CFM fan with blower control connects directly to stainless steel
heat tubes for added heat output
• Ability to control combustion rate and heat output via the air kit and ue
damper assemblies
• A hearth extension is required
• SL300 Series venting
• Tested and listed to UL safety standards
• Heatilator Warranty
SC60
Incredible Heating Capacity
Options*
Product Dimensions
Framing
Dimensions
Gasketed Air Control Door
40-3/4 in.
19-1/8 in.
7-3/4 in.
35 in.
36 in.
42-1/8 in.
Damper
Handle
25 in.
10-1/4 in.
9 in.
Gas Knockout
10-1/2 in.
Dia.
10-1/2 in.
Dia.
25 in.
3-7/8 in.
9-7/8 in.
1-1/8 in.
18-3/4 in.
10-1/4 in.
9 in.
40 in.
(effective height)
3-1/2 in.
Gas Knockout
Outside
Air
21-1/8 in.
12-1/2 in.
25 in.
2 in min. air
space clearance
from chimney
43-1/8 in
25 in
41-1/4 in
8 in
