Heatmiser Dt-ts wifi rf User manual

1Model: DT-TS WiFi RF

Model: DT-TS WiFi RF

2Model: DT-TS WiFi RF

WiFi Series Model: DT-TS WiFi RF

Table Of Contents

2

1

2

3-4

5-6

7-8

9-11

11-12

13

14

15-16

17-18

18

Product Image

Table of Contents

What is a Room Thermostat?

Installation Procedure

LCD Display

WiFi Setup

Security Types and Compatibility

Remote Access Via App

Remote Access Via Web Browser

Temperature Display

Pairing with the RC1-W receiver

Pairing with the UH1-W

Testing Comms. with the UH1-W

19

20

21

22

23-24

25

26

27

28

29-31

32-34

Clean Screen

Locking the Keypad

Temperature Control

Frost Protection

Heating ON/OFF

Optional Features Explained

Adjusting the Optional Settings

Optional Settings - Features Table

Re-calibrating the Thermostat

Factory Reset

Wiring Diagrams

Notes

43 WiFi Series Model: DT-TS WiFi RF

What is a Room Thermostat?

If your heating system is a boiler with radiators, there will usually be only one room

thermostat to control the whole house. But you can have dierent temperatures

in individual rooms by installing thermostatic radiator valves (TRVs) on individual

radiators.

If you don’t have TRVs, you should choose a temperature that is reasonable for the

whole house. If you do have TRVs, you can choose a slightly higher setting to make

sure that even the coldest room is comfortable, then prevent any overheating in other

rooms by adjusting the TRVs.

Room thermostats need a free ow of air to sense the temperature, so they must not

be covered by curtains or blocked by furniture. Nearby electric res, televisions, wall

or table lamps may also prevent the thermostat from working properly.

A room thermostat simply switches the heating system on and o as necessary.

It works by sensing the air temperature, switching on the heating when the air

temperature falls below the thermostat setting, and switching it o once this set

temperature has been reached.

Setting a room thermostat to a higher temperature will not make the room heat up

any faster. How quickly the room heats up depends on the design & size of the heating

system.

Similarly reducing the temperature setting does not aect how quickly the room cools

down. Setting a room thermostat to a lower temperature will result in the room being

controlled at a lower temperature, and saves energy.

The way to set and use your room thermostat is to nd the lowest temperature settings

that you are comfortable with, and then leave it alone to do its job.

The best way to do this is to set the room thermostat to a low temperature

– say 18°C , and then turn it up by 1°C each day until you are comfortable with the

temperature. You won’t have to adjust the thermostat further. Any adjustment above

this setting will waste energy and cost you more money.

65 WiFi Series Model: DT-TS WiFi RF

1 2

3 4

Installation Procedure

This WiFi Series thermostat is designed to be ush mounted and requires a back

box of 35mm (minimum depth) to be sunk into the wall prior to installation.

Step 1

Carefully separate the front half of the thermostat from the back plate by placing a

small at head terminal driver into the slots on the bottom face of the thermostat.

Step 2

Place the thermostat front somewhere safe.

Terminate the thermostat as shown in the diagrams on pages 29-31 of this booklet.

Step 3

Screw the thermostat back plate securely into the back box.

Step 4

Clip the front of the thermostat back onto the thermostat back plate.

Do

Mount the thermostat at eye level.

Read the instructions fully so you get the best from our product.

Don’t

Do not install near to a direct heat source as this will aect functionality.

Do not push hard on the LCD screen as this may cause irreparable damage.

1 2

13

12

11

1. Frost Icon - Displayed when the thermostat is in frost protection mode.

2. OFF Key - Single press to enable/disable frost protection or press and hold to turn

o display.

3. Flame Icon - Displayed when the thermostat is calling for heat.

4. Keypad Lock Icon - Displayed when the keypad is locked.

5. WiFi Icon - Displayed when a WiFi connection is established

6. Room Temp - Indicates the current temperature sensor mode.

7. Set - Displayed when the target temperature is adjusted.

8. Clean Screen - Freezes screen temporarily to enable cleaning.

9. Cancel - Used to exit setup/program operations.

10. Setup/Programming Keys - Used to navigate setup options.

11. Up/Down Keys - Increase or decrease values shown on bottom digit group.

12. Current Temp - Indicates the current sensor temperature.

13. Units of Temperature - Degrees Celsius or Fahrenheit.

LCD Display

5

7

9

10

34

6

8

87 WiFi Series Model: DT-TS WiFi RF

109 WiFi Series Model: DT-TS WiFi RF

Setting Up Your WiFi Thermostat

Step 1:

Download and install the WiFi thermostat setup utility from our web site:

www.heatmiser.co.uk/wi

Step 2:

Connect the thermostat to your PC with the USB cable provided. This will power the

thermostat through the USB port and will allow you to test the WiFi connection.

Open the setup utility and press Read to view the current thermostat conguration.

Step 3:

Enter the SSID, Security Type and Security Code of your wireless network.

These settings can usually be found on the underside of your wireless router.

For more information please consult your router manual.

See page 11 for additional information on security types and compatibility.

Step 4:

Enter a xed IP address for your WiFi thermostat outside of the router DHCP range.

It is likely that your network will be congured to operate on a DHCP basis.

This means your router automatically issues an IP address to a device that

successfully connects to the network.

Your WiFi thermostat needs a xed IP address in order for local and remote access

to operate and you must set this up manually.

Log into your wireless router and navigate to the LAN settings page.

Find and select the DHCP setup details.

This should dene the IP range that can be assigned to devices connecting to

the network.

As an example, you may have an IP starting range 192.168.1.1 and ending

192.168.1.99. This means you can safely provide your WiFi thermostat the IP

address 192.168.1.100 as no other devices will be assigned this address by the

router.

If your DHCP range is from 192.168.1.1 to 192.168.1.253 you cannot use 254 or

above.

You need to change the DHCP range, taking care not to change any of the rst

3 numbers.

Tip! When setting up an IP address, the rst three sets of numbers must be the

same as the router IP address and the fourth set must not be used elsewhere on the

network.

Step 5:

Enter the Subnet mask for the network.

This information can usually be found on the underside of your wireless router.

Step 6:

Enter the IP address of your gateway and DNS. In most cases, this is the IP

address of your wireless router.

If you have a multi-zone system and are using the Multi-Link, the Gateway of

the thermostat will need to be congured as the IP address of the Multi-Link.

1211 WiFi Series Model: DT-TS WiFi RF

Step 7:

Create a unique username and password that will be used to access your thermostat

from a web browser.

Default Username: admin Default Password: admin

Change these settings to your personal preference and record for future use.

A 4 digit access PIN is required to use the smartphone/tablet app and also helps to

secure your system.

Step 8:

When you have entered the details of your WiFi network press Apply and disconnect

the USB cable, (the thermostat LCD should go blank).

Reconnect the USB cable to the WiFi thermostat, when the thermostat has rebooted it

will attempt to connect to your network. This process takes approximately one minute

and is complete when the WiFi symbol is displayed on screen.

Security Types and Compatibility

The WiFi Thermostats operate on the 802.11b standard.

If your router is a G model, you must ensure it is setup to work in B&G mode.

You will not be able to connect to your thermostat without changing this setting on

G model routers.

There are currently 4 common methods of securing your wireless connection:

OPEN/DISABLED (not recommended)

W.E.P. (lowest security level)

Your choice of security settings in the thermostat must match the setting in your

router. Often you will nd WPA and WPA2 are a single option in the router.

This is perfectly normal as the router automatically selects the correct security level

and you can set the thermostat up using either one of these settings.

Passwords can be up to 63 characters in length including spaces _. / \ characters.

The W.E.P. option is not so simple. Some routers generate a hidden password from

a pass phrase whilst others require a 10 or 26 digit hex password and won’t accept

anything else. Your thermostat utility can deal with both options but the following

restrictions may apply:

A hex password can only be made up of the numbers 0 to 9 and the letters a to f

(lower case only).

Hex passwords can only be 10 characters or 26 characters in length.

If a passphrase is used it must be either 5 or 13 characters in length but can be any

letter or number.

Your thermostat will automatically calculate the same hidden password your router

creates from the same phrase.

These restrictions are common to most routers but you should refer to the router

manual for specic restrictions that apply to your model.

W.P.A. (medium security)

W.P.A.2. (highest security)

Room Temperature SET Temperature

Temperature Display

The temperature display information is driven by two dierent inputs; the sensor

measurement and the target temperature you have set.

This is the current room temperature. This is the temperature you are trying to

achieve in your home.

1413 WiFi Series Model: DT-TS WiFi RF

To remotely connect to your WiFi Thermostat you must forward a port within your

router to your WiFi Thermostat.

As all routers are setup dierently, you should consult your user manual or the

manufacturer’s website for more information.

Generally you should create a new service within your router. Within this service

you must open TCP port 8068.

Use the port forwarding function to forward the new service to the IP address of

your WiFi thermostat.

Remote Access via App

To remotely access your WiFi Thermostat via a web browser you must rst open

port 80 and forward this to the IP address of your WiFi Thermostat.

Remote Access via Web Browser

To connect to your thermostat, open your preferred browser and enter the IP

address that you gave the thermostat during setup and press enter.

You will be asked to enter a password and username.

These are both set to“admin” as default.

We recommend you change these settings to ensure the security of your system.

For further information, click the help link within the browser.

1615 WiFi Series Model: DT-TS WiFi RF

• To pair the thermostat with the receiver, press and hold the

SCREEN button for 10 seconds .......................................................................

Pair Successful

The address of the receiver will ash on the thermostat display and the

Comms LED on the receiver will ash and then go out to indicate the

pair is successful.

• Press DONE to conrm the pairing ................................................................

Pair Fail

If the Comms LED does not ash there is a problem with the RF signal and

you should reduce the distance between the thermostat and receiver.

Where possible ensure there are no metal objects blocking the signal.

Check features 06 - 08 have been congured correctly.

Comms LED

To pair the thermostat with the RC1-W receiver, follow these steps.

On the receiver;

Press and hold the pairing button until the communication LED lights up.

On the thermostat;

• Press PROG and then SETUP .................................................................................

• The small number 01 in the top right corner of the LCD is the feature number.

• Use the Up key to select 06 (Receiver Type) .................................................................

The options within feature 06 are: 00 = UH1-W or 01 = RC1-W receiver.

• Use the Up/Down keys to set feature 06 to 01 (RC1-W) ................................

• Use the Up key to select 07 (Receiver Address) ..........................................................

• You can now select a Receiver Address from 01-32.

Use the Up/Down keys to set the RC1-W Receiver address .........................

(You must set a unique receiver address for each receiver installed).

• Use the Up key to select 08 (Zone Number) ................................................................

• You are able to connect two WiFi RF thermostats to one RC1-W receiver.

Use the Up/Down keys to select the zone this thermostat

controls (01 or 02) ........................................................................................................

• Press DONE to conrm and exit .......................................................................................

Pairing with the RC1-W Receiver

If using with the UH1-W wiring centre, turn to page 17.

1817 WiFi Series Model: DT-TS WiFi RF

• On the thermostat use the Up key to adjust the set temperature

above the room temperature ............................................................................

• Press DONE ...............................................................................................................

Testing Communications with the UH1-W

On the UH1-W:

Set the board address number, choose from 01-09 on the rotary switch.

Note: Each UH1-W will need a dierent address.

On the thermostat:

• Press PROG and then SETUP .................................................................................

• The small number 01 in the top right corner of the LCD is the feature number.

• Use the Up key to select 06 (Receiver Type) .................................................................

The options within feature 06 are: 00 = UH1-W or 01 = RC1-W receiver.

• Use the Up/Down keys to set feature 06 to 00 (UH1-W) ................................

• Use the Up key to select 07 (Receiver Address) ..........................................................

• You can now select a board address from 01-09.

Use the Up/Down keys to set the UH1-W board address ................................

• Use the Up key to select 08 (Zone Number) ...................................................................

• You are able to connect eight WiFi RF thermostats to one UH1-W.

Use the Up/Down keys to select the zone this thermostat

• controls (01 - 08) ..............................................................................................................

• Press the Up key at the top of the screen to select feature 09 ..................................

You will now see the ame icon and after a few seconds the RF symbol

will appear. The assigned zone on the UH1-W should now be active.

If the output on the UH1-W is not activated, reduce the distance between

the thermostat and the UH1-W and check features 06-09 have been setup

correctly, then repeat the above process.

Pairing with the UH1-W • Use the Up/Down keys in the centre of the screen to select if the

thermostat will bring on the pump & boiler outputs ............................

00 = UFH Zone (Outputs enabled)

01 = Radiator Zone (Outputs not enabled)

• Press DONE to conrm and exit ...............................................................................

2019 WiFi Series Model: DT-TS WiFi RF

Locking the Keypad

The thermostat has a keypad lock facility.

• To activate the lock press the bottom right corner of the display and hold for 10s.

• When activated, you will see the Keypad Lock symbol.

• To cancel, press the bottom right corner of the display again for 10 secs.

Clean Screen

Pressing will disable all keys, providing you 15 seconds to wipe the screen

clean before the keys are re-activated.

Keypad Lock Indicator

The keys under the temperature display allow you to adjust the

set temperature.

When you press either of these keys, you will see the temperature and

the word SET appear on screen.

Select the desired temperature and press to conrm and exit.

Temperature Control

Set Temperature

Set Icon

2221 WiFi Series Model: DT-TS WiFi RF

Pressing the key once will place the thermostat in frost protect mode.

In this mode, the thermostat will display the frost icon and will only turn the heating on

should the room temperature drop below the set frost temperature (see page 23).

Should the heating be turned on whilst in frost mode, the ame symbol will be

displayed.

To cancel the frost protect mode, press the key once.

Frost Mode

The heating is indicated ON when the ame icon is displayed.

When the ame icon is absent, there is no requirement for heating to achieve the set

temperature but the thermostat remains active.

To turn the thermostat OFF completely, press and hold the OFF key .......................

The display and heating output will be turned o completely.*

To turn the thermostat back ON, press the ON key once ...............................................

Heating On/O

Thermostat completely OFF Thermostat powered ON

*See Feature 3 on page 23

Frost Protection Mode Enabled

2423 WiFi Series Model: DT-TS WiFi RF

THE FOLLOWING SETTINGS ARE OPTIONAL AND IN MOST CASES

NEED NOT BE ADJUSTED

Feature 01 – Temperature Format: This function allows you to select between °C or °F.

Feature 02 - Switching Dierential: This function allows you to increase the switching

dierential of the thermostat. The default is 1°C which means the thermostat will

switch the heating on 1°C below the set temperature and will turn it o when the set

temperature is achieved. With a 2°C dierential, the heating will switch on 2°C below the

set temperature and will switch o when the set temperature is achieved.

Feature 03 - Frost Protect: You can set whether the thermostat will maintain the frost

temperature when the thermostat display is turned o. As a default, this is enabled.

Feature 04 – Frost Protect Temperature: This is the temperature maintained when the

thermostat is in frost mode. The range is 07-17°C. The default is 12°C and is suitable for

most applications.

Feature 05 – Output Delay: To prevent rapid switching, an output delay can be entered.

This can be set from 00 - 15 minutes. The default is 00 which means there is no delay.

Feature 06 – UH1-W or RC1-W Receiver: The thermostat can work with our UH1-W 8

zone wiring centre or RC1-W 2 channel receiver. This setting determines which is being

used.

Optional Features Explained

Feature 07 – Receiver Address: Within one building, up to 9 UH1-W’s or 32 RC1-W’s

can be used. Each receiver must have a unique receiver address.

Feature 08 – Zone Number: This is the zone number you are assigning the

thermostat to on either the UH1-W or the RC1-W receiver. 01 - 08 - UH1-W, 01 - 02 –

RC1-W.

Feature 09 – Underoor Heating or Radiator Zone (UH1-W Only): This setting

determines whether the thermostat will activate the pump & boiler output on the

UH1-W. If set to 00 the outputs will be activated. 00 = UFH, 01 = Radiators.

Feature 10 – Fail Safe: If enabled, the thermostat will send a signal to the receiver

every 20 minutes. Should the receiver fail to receive two signals, the receiver will

activate the output for 20% of the time. This is to protect the system against a loss of

wireless signal and in case the thermostat battery fails whilst you are away.

Feature 11 – Temperature Up/Down Limit: This function allows you to limit the use

of the up and down keys. This limit is also applicable when the thermostat is locked

and so allows you to give others limited control over the heating system.

Feature 12 – Air Sensor Selection: On this thermostat, you can select which sensor

should be used. Built in sensor or remote air sensor.

2625 WiFi Series Model: DT-TS WiFi RF

To adjust the optional settings, follow these steps.

• Press SETUP ..................................................................................................................

• Use the Up/Down keys at the top of the screen to select the feature

number (shown on page 26) and then use the Up/Down keys in the

center to adjust the setting ....................................................................................

• Press DONE to conrm and exit ............................................................................

Adjusting the Optional Settings

Feature Number

Setting Value

01

02

03

04

05

06

07

08

09

10

11

12

FEATURE

Temperature Format

Switching Dierential

Frost Protect

Frost Protection Temperature

Output Delay

Receiver Type

Receiver Address

Zone Number

UFH or Radiators (UH1-W only)

Fail Safe

Up/Down Temperature Limit

Sensor Selection

DESCRIPTION

00 = oC

01 = oF

(°C = Default)

0.5o- 3.0oC (1.0oC = Default)

00 = Disabled

01 = Enabled

(01 = Default)

07o- 17oC (12oC = Default)

00 - 15 Minutes (00 = Default)

00 = UH1-W, 01 = RC1-W

UH1-W = 01-09, RC1-W = 01-32

UH1-W = 01-08, RC1-W = 01-02

00 = UFH, 01 = Radiators

00 = Disabled, 01 = Enabled

00o- 10oC (00oC = Default)

00 = Built in sensor, 01 = Remote air sensor

SETTING

Optional Settings - Feature Table

2827 WiFi Series Model: DT-TS WiFi RF

All icons displayed simultaneously. Factory reset is complete.

Calibration Temperature Setting

Set Icon

If you need to re-calibrate the thermostat, follow these steps.

• Press and hold the OFF key to turn the thermostat o .................................................

• Press and hold the ON key until the temperature appears on the screen .............

• Use the Up/Down keys to congure the new temperature ...............................

• Press DONE to conrm the new temperature ..................................................................

• Press the ON key once to turn the thermostat back on ...............................................

Re-calibrating the Thermostat

The thermostat has a reset function to restore all settings to their factory defaults.

To perform a factory reset, follow these steps.

• Press & hold the OFF key to turn the thermostat display o ..................................

• Press and hold the bottom left corner of the LCD for 10 seconds.

• All of the screen icons will appear for 2 seconds and then disappear.

• Press the ON key once to turn the thermostat display back on ............................

Factory Reset

3029 WiFi Series Model: DT-TS WiFi RF

DT-TS WiFi RF with RC1-W Receiver

Combination Boiler System

Wiring Diagram - DT-TS WiFi RF

To Boiler

N

S/L P/L

L

Mains Supply In

S/L = Switched Live

P/L = Permanent Live

P/L and S/L connections

will vary depending on the

boiler model but will normally

be connected to the

thermostat connections.

230VAC

RC1-W

B1 A2 A1

B2 N L

Recommendations

Max Cable Size - 1.5mm

Back Box Depth - 35mm

N.B. The DT-TS WiFi RF is designed to work

with the RC1-W and the UH1-W. Please refer to

the appropriate diagram for connections

to your heating system.

Neutral

Live

Remote Air Probe

If Fitted

Mains Supply

From Fused Spur

DT-TS WiFi RF

NLRT2 -

230VAC

Room

Sensor

3231 WiFi Series Model: DT-TS WiFi RF

Wiring Diagram - 2x DT-TS WiFi RF

with RC1-W Receiver

230VAC

RC1-W

B1 A2 A1

B2 N L

P/L and S/L connections will vary

depending on the boiler model but

will normally be connected to the

thermostat connections.

N.B Valves must have end switches

Two Zone Heating System

N

L

N

L

Mains Supply In

Heating Zone 2 Valve

Heating Zone 1 Valve

P/L

To Boiler

S/L

N

L

Neutral

*

= Neutral

*

Notes

.........................................................................................................................................................................

3433 WiFi Series Model: DT-TS WiFi RF

Notes

.........................................................................................................................................................................

Notes

.........................................................................................................................................................................

35 WiFi Series

Twitter: heatmiseruk

Facebook: facebook.com/thermostats

Want More Information?

Call our support team on: +44 (0)1254 669090

Or view technical specications directly on our website:

www.heatmiser.com

PDF FAQ

Heating Professionals:

Request a copy of our product

installation guide containing

detailed technical specications

for our complete product range:

www.heatmiser.com/guide

Heatmiser DT-TS WiFi RF User manual

Popular Thermostat manuals by other brands
