Owner’s Manual
Distributed by HEININGER 1-888-722-5240 | [e-mail] | heininger.biz
Model number FMPPC2-2
Series number 5995 58,000 Btu/h
FMPPC2-2_5995.V3

1
Model number FMPPC2-2, Series 5995 - Tested by CSA International. ANSI Z21.97-2017/CSA 2.41-2017 Outdoor Decorative Gas Appliances
WARNING:
Don’t burn yourself! Do not touch or handle the firebowl when hot! To avoid injury always allow
the firebowl to cool down for at least 30 minutes before moving and handling the appliance.
DANGER:
If you smell gas:
1 Shut off gas to the appliance.
2 Extinguish any open flame.
3 If odor continues, leave the area immediately.
4 After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion, which could cause
property damage, personal injury, or death.
WARNING:
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
WARNING: For outdoor use only.
Installation and service must be performed by a qualified installer, service agency, or the gas
supplier.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which
has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such
as a camper, tent, car, or home.

2
LP SAFETY:
a. Do not store a spare LP-gas cylinder under or
near this appliance.
b. Never fill the cylinder beyond 80 percent full.
c. If the information in “(a)” and “(b)” is not followed exactly, a
fire causing death or serious injury may occur.
Do not use this appliance under overhead combustible surfaces.
MINIMUM CLEARANCES:
• Bottom: Non-Combustible Surface
• Top: 2 m / 80 in
• Sides: 0.9 m / 36 in
• For Installation on (or over) non-combustible floors only
Input: 58,000 Btu/h (17 kW) and manifold pressure:
11 in wc (2.74 kPa)
Min. gas supply for input adj. 11 in wc (2.74 kPa)
Max. gas supply: 11 in wc (2.74 kPa)
Injector Size* 2.32 mm
* Injector size marked clearly on the gas valve orifice.
Type of Gas: Propane (LP)
This appliance shall be used only outdoors in a well-ventilated
space and shall not be used in a building, garage or any other
enclosed area.
The gas supply must be turned off at the LP-gas supply cylinder
when this appliance is not in use.
Indoor storage of this appliance is permissible only if the cylinder
is disconnected and removed from the appliance.
Cylinders must be stored outdoors in a well-ventilated area out of
the reach of children.
Disconnected cylinders must have threaded valve plugs tightly
installed and must not be stored in a building, garage or any other
enclosed area.
The gas pressure regulator provided with this appliance must be
used and must be the same model as supplied with the unit.
The cylinder supply system must be arranged for vapor
withdrawal.
Cylinders used with this unit must have a collar to protect the
cylinder valve.
An approved LP-Cylinder stabilizer, such as the stabilizer ring
included, must be used when the appliance is in use.
Replacement parts and a list of such parts are available from
HEININGER through the contact information provided on the last
page of this Manual.
WARNING:
Please ensure that all adults and children which use or are
near a unit in use are aware of the hazard of high-surface
temperatures present on the unit during use and should use
caution and stay away to avoid burns or clothing ignition.
Carefully supervise young children in the area of this
appliance. Clothing or other flammable materials should
not be hung from the appliance or placed on or near the
appliance. Any guard or other protective device removed
for servicing the appliance must be replaced prior to
operating the appliance.
Installation and repair should be done by a qualified
service person. The appliance should be inspected before
use and at least annually by a qualified service person.
More frequent cleaning may be required as necessary.
It is imperative that control compartment, burners and
circulating air passageways of the appliance be kept clean.
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read
the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
WARNING:
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
NOTE TO INSTALLER:
Leave this manual with the appliance.
NOTE TO CONSUMER:
IMPORTANT. Retain this manual for future reference.
Read carefully.

3 2
All LP cylinders to be used with this appliance must be:
a. Constructed and marked in accordance with the U.S.
Department of Transportation (DOT) Specifications for LP-
Gas Cylinders, or the Standard for Cylinders, Spheres and
Tubes for Transportation of Dangerous Goods, CAN/CSA
B339, as applicable.
b. Provided with a listed overfilling prevention device.
c. Provided with a cylinder connection device compatible with
the connection for the appliance.
d. Only a 9 kg / 20 lb LP gas cylinder is to be used for this
appliance, approximately 46 cm / 18 in high & 30 cm / 12 in
diameter.
e. The use of an approved LP gas cylinder stabilizer, such as the
one included, must be used when using this appliance in order
to prevent the LP gas cylinder from tipping over.
CONNECTION:
1. Be sure the cylinder valve and appliance valves are “off”.
2. Place full LP gas cylinder on tank stabilizer ring.
3. Center the nipple in the cylinder valve and hold in place.
4. Using the other hand, turn the hand wheel clockwise until
there is a positive stop. Do not use tools.
5. Hand tighten only. When making the connection,
hold the regulator in a straight line with the cylinder valve, so
as not to cross thread the connection.
6. Leak test the connection. See section named “LEAK TEST”.
LEAK TEST:
1. DO NOT USE OR PERMIT SOURCES OF IGNITION
IN THE AREA WHILE DOING THE LEAK TEST.
THIS INCLUDES SMOKING.
2. Leak testing should be done once per year or whenever the
LP gas cylinder or any other gas system part is taken apart,
serviced or replaced, whichever is more frequent.
3. Ensure all gas system coupling joints are tight
and properly attached.
4. Prepare a leak testing solution of half liquid detergent
and half water.
5. Apply the solution to the LP gas delivery system at points as
shown in illustration indicated on page 3.
6. If parts of the fitting begin to produce bubbles, spray liquid, or
if you smell liquid propane gas, immediately close the valve on
the tank.
7. Wait 5 minutes for any gas to dissipate.
8. After waiting for 5 minutes, the leak(s) must be stopped by
tightening the loose joints, if possible, or by replacing the
faulty parts(s) with the part(s) recommended by the appliance
manufacturer.
WARNING:
Ensure that the appliance is kept at a minimum distance of
0.91 m / 36 in from the gas cylinder.
LP Cylinder
Appliance Tank Ring
Minimum
0.91 m / 36 in
LEAK TEST: Apply the solution to the LP gas delivery system at points.
Valve coupling regulator & Cylinder Coupling.
LEAK TEST: Apply the solution to the LP gas
delivery system at points:
1. Firebowl Valve Coupling
2. Gas Hose Regulator
3. Cylinder Valve Coupling
2. Gas Hose
Regulator
Heat Sensitive
Hand Wheel
Cylinder
Shut Off
Valve
Check Valve
Nipple with
Flow Limiting Device
3. Cylinder Valve
Coupling
!
Caution:
Trip Hazard!
Tank Ring

43
THE APPLIANCE IS NOT TO BE USED UNTIL
ANY LEAK IS CORRECTED.
A gas appliance repairman or LP gas dealer should be called if
attempts to stop the leak(s) are unsuccessful and, in such case, the
LP gas supply must be shut off at the cylinder valve or the cylinder
must be removed from the appliance until the leak(s) is corrected.
Should any part of this appliance (including the burner) become
soiled or dirty, wipe lightly with a damp cloth.
Do not use flammable or corrosive cleaning products on or near
this unit.
Ensure that gas hose is placed in an area where it is unlikely to
be tripped over (such as pathways or trails) or subject to other
accidental damage.
Keep the appliance area clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
Solid fuels shall not be burned in this appliance.
Installation must conform with local codes or, in the absence of
local codes, with either the National Fuel Gas Code, ANSI Z223.1/
NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1
or Propane Storage and Handling Code, B149.2, or the Standard for
Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV
Series, Recreational Vehicle Code, as applicable.
PRE-IGNITION INSPECTIONS
GAS HOSE INSPECTION
Clean and inspect the hose before each use of the appliance.
Attention: If there is evidence of abrasion, wear, cuts, or leaks,
the hose must be replaced prior to the appliance being put into
operation.
REPLACEMENT PARTS
Replacement parts such as gas hose and regulators, burner tubes,
rocks, etc. are available by FMI Brands Inc. 1888-514-1663
BURNER & ORIFICE INSPECTION
Inspect the burner prior to each use. Ensure the orifice holes are
not plugged and the burner tube is not damaged, or compromised.
The burner must be replaced prior to the appliance being put into
operation if there is evidence of damage. Replacement burners are
available from FMI Brands Inc.
BURNER TUBE INSPECTION
Inspect the burner tube under the appliance and ensure the mesh
screen is in place, prior to each use.
ATTENTION: If the screen is dislodged perform an insect nest
inspection, prior to ignition. See section ‘REMOVING INSECT
NESTS’.

5
SECTION 2: IGNITION
STEP 1
Ensure that the appliance valve
dial is in the “OFF” position by
pushing and turning clockwise
until the dial stops.
STEP 2
Securely attach regulator (large
end of hose) to your propane
cylinder.
STEP 3
Extend hose to full length and ensure that the propane tank is as
far as safely possible from the Firebowl and place the tank in the
included stabilizer ring.
!
Caution:
Trip Hazard!
LP Cylinder
Tank Ring
WARNING:
TRIP HAZARD! Ensure the gas hose is placed in an area where
it is unlikely to be tripped over (such as pathways or trails) or
subject to other accidental damage.
WARNING:
The hose should not be twisted or kinked when attached to
the gas cylinder. The hose should never touch the appliance.
Ensure that the appliance is kept at a minimum distance of
0.91m (36 in) from the gas cylinder.
SECTION 1: ASSEMBLY
STEP 1 Enclosed are four bags of rocks, one factory installed 10'
propane-rated hose with attached regulator, and one propane tank
stabilizer ring.
STEP 2 Remove the plastic bags containing the rocks, and set
aside the propane stabilizer ring.
STEP 3 Open the two bags containing mid-sized rocks, labelled
conveniently for you “M” and arrange in burner area.
STEP 4 Open the single bag containing larger sized rocks, labelled
conveniently for you “ L” and arrange on top of the medium sized
rocks.
Our preferred configuration is
pictured here.
Never handle rocks which
have not been allowed to
cool from exposure to flame.
Never attempt to rearrange
rocks while unit is ignited.
STEP 5 The fourth bag of rocks are included as spares and labelled
“Spare Rocks”. These can be stored and used as replacements.
Note:
• Rocks are not to exceed a maximum weight of 2 kgs or 4.4 lbs.
NOTE TO USER:
Before igniting the unit for the first time, follow steps one
through 5 in the below Ignition section.

6
SECTION 2: IGNITION (continued)
STEP 4
***SLOWLY*** turn cylinder valve to the FULLY open position
to avoid tripping the CSA excess flow safety device in the gas
regulator. For more information about the CSA excess flow safety
device see STEP 8 (What is an Excess Flow Safety Valve? (EFV).
STEP 5
Leak Test all connections. See section labeled “Leak Test” (page 4).
STEP 6
Using a lighter or match, ignite
lighter and hold flame slightly
above the burner, then open the
valve on the appliance slowly by
turning (counter-clockwise) until
the unit ignites.
STEP 7
Once the unit is burning normally
set the dial to desired flame
height.
STEP 8: TROUBLESHOOTING
GOT A LOW FLAME?: If your firebowl experiences low flame, or
flame height does not appear to be normally adjusted by the gas
knob, it is likely that the gas cylinder is low in fuel, or the excess flow
safety device has been tripped in the gas regulator.
CORRECTIVE ACTION:
a. Confirm your gas cylinder is NOT empty.
b. Close the propane cylinder valve.
c. Open and then close the appliance gas knob valve to release
pressure.
d. Be sure the appliance valve is OFF.
e. Disconnect the gas hose from the propane cylinder.
f. Gently tap the gas regulator housing on the ground once or twice.
g. Reconnect the gas hose to the propane cylinder.
h. Slowly and fully open the propane cylinder valve.
Perform a Leak Test and follow the Ignition sequence.
TIP: Try tapping the regulator on the ground or hard surface 3 times.
Sometimes, this will reset the safety device in the regulator.
WARNING:
Ensure that no parts of your body, clothing, or any other
combustible material are above the burner before, during and
after ignition.
WHAT IS AN EXCESS FLOW SAFETY VALVE?
(EFV)
The EFV is a safety mechanism contained within the gas
regulator. The purpose of the EFV is to restrict the gas supply
if too much gas is flowing too quickly through the gas hose.
For example this could happen if the gas hose was severed.
It is normal that your Firebowl EFV trips if you open the
propane tank valve too quickly or if you leave the Firebowl
gas knob open before lighting, or both.
EXCESS FLOW
VALVE
GAS REGULATOR
GAS
HOSE

7
STEP 1
Turn cylinder valve to the “Closed” position.
STEP 2
Turn appliance valve to the “Off” position by pushing and turning
knob clockwise.
STEP 3
Allow unit to cool for at least five (5) minutes before relighting.
SECTION 4: EXTINGUISHING THE APPLIANCE
WARNING:
The rocks are HOT!
WARNING:
Don’t burn yourself! Do not touch or handle the firebowl when
hot! To avoid injury always allow the firebowl to cool down for
at least 30 minutes before moving and handling the appliance.
Never handle rocks which have not been allowed to cool from
exposure to flame. Never attempt to rearrange rocks while unit
is ignited.
If there are no flames present,
as demonstrated in the image
to the left, the appliance is likely
not burning. If this is the case,
IMMEDIATELY turn the valve
to the “off” position if it is not
already and repeat the ignition
procedure as outlined in Section 2.
Upon igniting the appliance,
visually verify that the burner is
indeed burning as demonstrated
in the image to the left. The
presence of flames will confirm
that the burner is burning.
Periodically check that the burner
flame is present during operation
by visually inspecting the burner
to ensure the presence of flames.
SECTION 3: PERIODIC INSPECTION OF BURNER FLAMES

8
SECTION 5: FIREBOWL MAINTENANCE
REGULAR CLEANING & MAINTENANCE
Your Firebowl requires periodic maintenance to keep it in good running order. Follow the steps below to ensure your appliance will
provide you with the best possible performance:
1. Keep your Firebowl out of the rain and store it in a dry place when not in use. Your firebowl is made from steel and will naturally form
rust if left out in the rain for extended lengths of time.
2. Always inspect and clear all valve and gas orifices of any foreign debris including spider webs prior to lighting. If any doubt there may
be a nest inside, use a pipe cleaner up the tube. See section ‘REMOVING INSECT NESTS’.
3. Clean any plugged burner orifices with a small paper clip.
4. Ensure that you clean the bowl of your firebowl after every use to keep it looking GREAT. Simply wipe the outer edge of the firebowl
with a damp paper towel or cloth to remove any combustion particulates. Do not use flammable or corrosive cleaning products on or
near this unit.
LAVA ROCKS
Your non-toxic natural lava rocks will form cracks and turn brown and black under normal operating
conditions. This does not affect the functionality of your firebowl.
The image shown is a visual reference on what the lava rocks will look like over time while under
normal operating conditions.
WARNING NOTES:
• Expected burn time; the anticipated burn time for your Firebowl
using a full 20 lb (9kg) propane cylinder is between 7 and 11 hours
depending on flame height setting and complete cylinder fill.
• This device has been engineered to provide the maximum
amount of heat and comfort. If you experience any signs of your
propane cylinder ‘freezing off’ or start to experience lower flames
than usual, please simply turn the burner control setting to low for
5–10 minutes or replace the cylinder with a full one.
• Elevation and temperature affect the performance (flame height)
of gas appliances.
• Ignite this unit only when safely placed on a non- combustible
surface.
• Never use this appliance in tall grass.
• This is NOT a toy.
• Children should be supervised at all times when using this unit
without exception.
• Please ensure that all adults and children which use or are near a
unit in use are aware of the hazard of high-surface temperatures
present on the unit during use and should use caution and stay
away to avoid burns or clothing ignition.
• Do not place any objects other than supplied rocks inside the
burner component of the Firebowl.
• Do not add wood or any other materials to the fire. It is designed
to safely combust propane only.
• Do not connect to a remote gas supply.
• Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and any
gas control which has been under water.
• Do not leave this appliance in the rain.

9
REMOVING INSECT NESTS
Clean the burner tubes often and especially if the appliance has
been sitting unused for a period of time. You must remove the gas
valve to gain access to the burner tube for cleaning.
BURNER TUBE CLEANING INSTRUCTIONS:
STEP 1
Ensure the appliance valve(s) are OFF and the cylinder valve is
closed.
STEP 2
Disconnect LPG Cylinder.
STEP 3
Locate and remove the gas valve body assembly mounting screws
and nuts.
WARNING:
Small critters like
spiders and earwigs
can quickly build nests
inside the burner tube
which can obstruct
gas flow and impact
the flame height and
heat performance of
your appliance. More
seriously, a nest or
blockage of the burner
tube can cause a back
flame event, damage
to your appliance, or even extreme operator injuries!
STEP 4
Remove the gas valve body assembly.
STEP 5
Use a flashlight to look inside the burner tube. Use a long flexible
pipe cleaner, or long small utensil to clean out any debris or nest
material. An air tool to
blow out the burner
is helpful, but please
wear eye protection.
M4 Nut
M4 Washer
M4 x 12mm Screw
Gas Valve
Body Assembly
Model may not look exactly as shown.
Use a pipe cleaner or
long small utensil here
to clean out any debris
or nest material.
Burner Tub e
Burner
Tube
Gas Valve
Orifice
STEP 6
When the burner tube is determined to be clear, reinstall the gas
valve body assembly.
IMPORTANT: Align gas valve orifice inside burner tube.

10
NOTES

11
Manufactured by FMI Brands Inc. 107-19052 26 Avenue, Surrey BC, Canada V3Z 3V7 • Toll Free: 1-888-514-1663
The Flame mark is a registered trademark of FMI Brands Inc.
AVAILABLE BY: HEININGER
