Outland Technology KITSILANO User manual

D.600.000.V1
K
ITSIL
ANO
by OUTLAND LIVING
WOOD F I RE PI T
Owner’s Manual
FMI BRANDS INC.
309-19133 26th Avenue | Surrey, B.C. Canada V3Z 3V7 | Toll Free 1-888-514-1663 | Fax [phone]
Model number 600
TABLE OF CONTENTS
Warnings | Parts List | Assembly | Operating Instructions | Cleaning and Care | Storage | Warranty
In the event of a defect please do NOT
return to place of purchase. Contact our
customer service department.
IMPORTANT NOTICE
Toll Free: 1-888-514-1663
Email: [e-mail]
Hours: Mon – Fri, 8am – 4pm, PST

D.600.000.V1
KITSIL ANO WOOD FIRE PIT SAFETY MANUAL
1
KITSILANO
by OUTLAND LIVIN
G
WOOD F IRE PI T
1. Do not operate this fire pit without reading and
understanding the instruction within this manual.
Death, serious injury or property damage
may occur if the warnings and instructions
are not adhered to exactly.
2. This fire pit is for outdoor use only. Do not use
indoors or in a confined space.
3. Ensure fire pit is assembled according to the
instructions prior to use.
4. Do not alter this fire pit or operate it as a partially
constructed product.
5. Always use in accordance with all applicable
regional, provincial, state, federal, national codes.
Consult your local authority and/or fire department
for current conditions such as burn ordinances or
burn bans in your area. Check your local Home
Owner’s Association (HOA) for local regulations
or restrictions such as community conditions,
covenants and restrictions (CC&Rs) regarding the
use of your property.
6. This fire pit should only be used with adult
supervision and is not intended to be operated by
children.
7. Inspect the fire pit for damage prior to every use. Do
not operate your fire pit if any damage is detected.
8. Do not operate this fire pit under overhangs or near
trees, shrubs or any other combustible material.
9. Do not operate this fire pit near any flammable
liquids, vapors or compressed gas cylinders.
10. Do not use any accelerants such as gasoline,
kerosene, alcohol or lighter fluid to start or refresh a
fire.
11. Do not burn rubbish, painted or stained wood,
plastics or styrofoam in the fire pit.
12. Do not wear flammable or loose clothing around the
fire pit when lighting or when in operation.
13. Do not operate this fire pit in windy conditions.
14. Dry, seasoned hardwood burns best and creates less
smoke. Softwoods such as Pine and Cedar throw
sparks.
15. Ensure the fire screen is secured in place during
operation. This will prevent sparks and burning
embers from escaping. Always use the fire tool
provided to remove the fire screen and/or place the
fire screen in position.
16. Do not overload the fire pit. The amount of fuel
(wood) should not exceed 70% of the total volume
with the fire screen deployed. If any part of the fire pit
is glowing red the fire pit is overloaded.
17. Do not touch any part of the fire pit while it is in
operation. All surfaces should be considered a burn
hazard while in use. To avoid burns ensure the fire pit
has cooled completely prior to handling.
18. Always use the fire tool provided to adjust the
damper when the fire pit is in operation.
19. Do not attempt to move, adjust or manipulate the fire
pit while it is in use. The fire pit can only be moved or
manipulated once it is extinguished and completely
cooled.
20. Do not operate the fire pit on a combustible
surface or a surface which is not heat resistant.
It is recommended to place the fire pit on a non-
flammable, heat resistant surface such as stones,
concrete or pavers.
21. Do not leave an operating fire pit unattended
especially in the vicinity of children and/or pets.
22. Empty the fire pit prior to every use. Do not dispose
of ashes unless certain the fire pit has completely
cooled.
23. The fire pit should be cleaned on a regular basis.
24. It is recommended that you keep an approved fire
extinguisher and/or a 10 gallon bucket of water
within easy reach in the event that you need to
extinguish an uncontained fire.
WARNINGS: Save this owner’s manual for future reference.
Owners Manual

1-888-514-1663 | WWW.OUTLANDFIREBOWL.COM 2
10mm Wrench
Philips Screw Driver
REQUIRED TOOLS (NOT SUPPLIED):
SUPPLIED PARTS & HARDWARE LIST:
PART
NUMBER QUANTITY DESCRIPTION PICTURE
A 1 Fire Tool
B 1 Fire Screen
C 1 Fire Bowl
D 1 Fire Grate
E 1 Vent Cover
F 1 Damper
G 1 Damper Lever
H 1 Base Ring
I 1 Ash Catcher
J 2 Legs
PART
NUMBER QUANTITY DESCRIPTION PICTURE
K1x
Fire Screen
Assembly
M6
L1x
Ash Catcher
Assembly
M6x30
M1x
Vent -
Dampener
Assembly
M6x30
N8x
Base Ring
- Legs
Assembly
M6x12

1. BASE ASSEMBLY:
Install Ash Catcher to Legs using
supplied hardware (Reference Part
Number L)
4. FIRE SCREEN ASSEMBLY
Install supplied hardware to Fire
Screen (Reference Part Number K)
8. YOUR OUTLAND WOOD FIRE PIT
is assembled and ready for use.
5. DROP FIRE BOWL ASSEMBLY into
Base-Ring Assembly ensuring
Damper Lever arm goes under
Base Ring;
6. PLACE FIRE GRATE in bottom of
Fire Bowl;
7. PLACE FIRE SCREEN on Fire Bowl
using Fire Tool (supplied).
2. BASE-RING ASSEMBLY:
Install Base Ring to Legs using
supplied hardware (Reference Part
Number N). Snug hardware finger
tight. Once the Legs sit square and
flat on the ground, fully tighten the
hardware using the required tools
(not supplied).
3. FIRE BOWL ASSEMBLY:
Install Vent - Damper Assembly to
Fire Bowl using supplied hardware
(Reference Part Number M)
D.600.000.V1
KITSIL ANO WOOD FIRE PIT OWNER’S MANUAL
KITSILANO
by OUTLAND LIVIN
G
WOOD F IRE PI T
32

1-888-514-1663 | WWW.OUTLANDFIREBOWL.COM 4
NOTE
• Wear protective, fire proof gloves when tending
the fire.
• Ensure no loose clothing is exposed to the flames.
• Ensure the presence of glowing coals prior to
adding additional wood.
• Do NOT use any accelerants such as gasoline,
alcohol, lighter fluid etc.
3
WARNING FOR YOUR SAFETY:
Prior to using this fire pit ensure you have read and understood all of the WARNINGS outlined on Page 1
of this manual. Failure to follow all of the WARNINGS and INSTRUCTIONS can cause property damage,
personal injury or death.
OPERATING INSTRUCTIONS:
LIGHTING:
1. Lay out a layer of kindling on the fire grate. Kindling
is made of items that can light and burn quickly, such
as twigs, newspaper or wood chips. Make a small
pile of kindling in the middle. This is where you will
light the fire.
2. Stack firewood loosely in a teepee formation on top
of the kindling to optimize airflow. Use a few large
pieces of firewood as well as smaller sticks for the
fire to feed off of.
3. Ensure the damper is open to allow maximum
airflow during lighting.
4. Use a long match or a BBQ lighter to ignite the
kindling.
5. Use a poker to stir the embers as the fire burns
down. This ignites any unburned wood. As long
as you maintain hot red embers in the fire pit you
can maintain the fire and the heat by adding more
firewood.
6. Place the fire screen in position using the fire tool
provided.
TENDING THE FIRE:
Logs will need to be added and/or re-positioned to keep
the fire burning.
1. Remove the fire screen using the fire tool provided.
Ensure to place the fire screen on a non-combustible
and heat resistant surface.
2. Using the fire tool, arrange the coals in the pit to
accept additional logs and create additional airflow.
Do NOT over fill the fire pit with wood. Log size
should never exceed the dimension of the fire pit.
3. Using the fire tool, adjust the damper as required to
desired flame intensity.
4. Replace the fire screen using the fire tool provided.
EXTINGUISHING THE FIRE:
• Allow the fire to burn itself out naturally. Do NOT
leave a burning fire unattended.
• It is NOT recommended to use water to extinguish
the fire. This can be dangerous due to the steam
created and the possibility of sweeping hot embers
out over the edge of the fire pit and/or through the
damper holes. The rapid cooling can also cause
damage to the fire pit surface.
• Do NOT touch the ashes to determine if they have
cooled sufficiently. Hold your hand just above and
feel for radiant heat.
• Always dispose of ashes in a metal ash can or pail.

D.600.000.V1
KITSIL ANO WOOD FIRE PIT SAFETY MANUAL
5
KITSILANO
by OUTLAND LIVIN
G
WOOD F IRE PI T
CLEANING AND CARE:
INSPECTION:
Your fire pit should be inspected regularly to ensure
proper operation and to extend the product life. An
inspection should only be performed when you have
ensured the fire is completely extinguished and all
components have completely cooled off.
• Inspect fire screen for any damage which could
cause burning embers to escape. Also ensure the
handle is properly secured.
• Ensure the damper is free from debris.
• Check that all fasteners are present and secure.
• Inspect the fire pit for obvious signs of damage and/
or rust.
• If any parts are found to be damaged do NOT
operate the fire pit until repairs have been
completed.
• Some rusting is anticipated to occur during the life
of this product as normal wear and weathering.
If rust damage has occurred which could cause
burning embers to escape or which compromises
the structural integrity of the fire pit - do NOT operate
the fire pit - the product is at end of life - dispose
of or recycle the fire pit according to your local
regulations.
CLEANING:
Your fire pit should be cleaned regularly to ensure proper
operation and to extend the product life. Cleaning should
only be performed when you have ensured the fire
is completely extinguished and all components have
completely cooled off.
• It is normal for slight discolorations to exist after
multiple uses of your fire pit.
• The surfaces can be cleaned with a mild dish
washing soap.
• For more aggressive stains a citrus based cleanser or
BBQ cleaning solution can be used.
• Use clean, warm water for rinsing.
• Do NOT use abrasive cleaners or you will risk
damaging the fire pit.
STORAGE:
Your fire pit should be stored properly to extend the
product life. Storage should only be attempted when you
have ensured the fire is completely extinguished and all
components have completely cooled off.
• Ensure the fire pit is free from ashes and debris.
• Ensure the fire pit is cool and dry.
• For optimum results keep original product packaging
and reuse for storage.
• Store in the included vinyl cover for added protection
(if included with your model fire pit). Check www.
outlandfirebowl.com for optional accessories.
• It is recommended that the fire pit is stored in a dry,
well protected space.

1-888-514-1663 | WWW.OUTLANDFIREBOWL.COM 6 1-888-514-1663 | WWW.OUTLANDFIREBOWL.COM
WARRANTY: 1 YEAR LIMITED WARRANTY
– Customers in Canada and USA
All components are warranted for a period of 1 year after
date of purchase by the original owner against defects
in materials and workmanship under normal use. This
warranty does NOT cover normal wear and weathering,
assembly and/or maintenance OR use in a commercial
application. At FMI Brands’ sole discretion, products
under warranty will be repaired and/or replaced at
no charge to the customer. Any returns sent back to
FMI Brands must be sent via prepaid freight and in the
original retail packaging.
For warranty service contact FMI Brands at the address,
phone numbers or internet site and email listed in this
owner’s manual. Be sure to have your sales receipt, date
of purchase and catalogue/model numbers available
when calling. All warranty service will be coordinated
by the FMI Brands’ Surrey, British Columbia, Canada
service center.
This warranty is extended only to the original purchaser.
Proof of purchase will be required before warranty
service is rendered. The sales receipt is the only valid
proof of purchase. This warranty only covers failures
due to defects in materials or workmanship which
occur during normal use. Failures and/or damage
which result from accident, negligence, misuse, abuse,
neglect, mishandling, alteration or modification, failure
to maintain, improper assembly or maintenance,
service by unauthorized agency or use of unauthorized
components or damage that is attributable to acts of
God are NOT covered.
***THERE ARE NO EXPRESS WARRANTIES
EXCEPT AS LISTED ABOVE***
***PURCHASER ASSUMES ALL RISKS IN THE
ASSEMBLY AND OPERATION OF THIS UNIT***
***IMPORTANT NOTICE***
In the event of a defect please do NOT return to place of purchase.
Contact our customer service department:
Toll Free:1-888-514-1663 Email: [e-mail]
Hours: Mon – Fri, 8am – 4pm, PST
***FAILURE TO FOLLOW WARNINGS AND
OPERATIONAL INSTRUCTIONS CONTAINED IN
THIS MANUAL CAN RESULT IN SEVERE PROPERTY
DAMAGE AND/OR PERSONAL INJURY***
IN NO EVENT WILL FMI BRANDS, OR ITS
DIRECTORS, OFFICERS OR AGENTS BE LIABLE
TO THE PURCHASER OR ANY THIRD PARTY,
WHETHER IN CONTRACT, IN TORT, OR ON ANY
OTHER BASIS, FOR ANY INDIRECT, SPECIAL,
PUNITIVE, EXEMPLARY, CONSEQUENTIAL, OR
INCIDENTAL LOSS, COST, OR DAMAGE ARISING
OUT OF OR IN CONNECTION WITH THE SALE,
MAINTENANCE, USE, OR INABILITY TO USE
THE PRODUCT, EVEN IF FMI BRANDS OR ITS
DIRECTORS, OFFICERS OR AGENTS HAVE BEEN
ADVISED OF THE POSSIBILITY OF SUCH LOSSES,
COSTS OR DAMAGES, OR IF SUCH LOSSES,
COSTS, OR DAMAGES ARE FORESEEABLE. IN
NO EVENT WILL FMI BRANDS, OR ITS OFFICERS,
DIRECTORS, OR AGENTS BE LIABLE FOR ANY
DIRECT LOSSES, COSTS OR DAMAGES THAT
EXCEED THE PURCHASE PRICE OF THE PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY
TO THE PURCHASER.
This limited warranty gives you specific legal rights
and you may also have other rights which vary from
jurisdiction to jurisdiction. The provisions of the United
Nations Convention on Contracts for the Sales of Goods
shall not apply to this limited warranty or the sale of
products covered by this limited warranty.
