Heinner HWM-5080VA++ User manual

AUTOMATIC WASHING MACHINE
Model: HWM-5080VA++
Model: HG-150SS
www.heinner.ro
•Automatic washing machine
•Loading capacity: 5 kg
•Spin capacity: 800 rpm
•Energy class: A++

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
1
Thank you for purchasing this product!
I. INTRODUCTION
Before using the appliance, please read carefully this instruction manual and keep it for future
reference.
This instruction manual is designed to provide you with all required instructions related to the
installation, use and maintenance of the appliance.
In order to operate the unit correctly and safety, please read this instruction manual carefully before
installation and usage.
II. CONTENT OF YOUR PACKAGE
➢Washing machine
➢User manual
➢Warranty card

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
2
III. SAFETY PRECAUTIONS
1. Your machine is designed to be used domestically. Commercial use
will cause your warranty to be cancelled.
2. Keep your pets away from your machine.
3. Please check the packaging of your machine before installation, and
the outer surface after the package is opened. Do not operate
damaged machines or machines with opened package.
4. Have your machine installed only by authorized service. Any
interference to your machine by anyone other than authorized
services shall cause your warranty to be void.
5. The appliance is not intended for use by people (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge unless they have been given supervision
or instruction concerning use of the appliance by a person responsi-
ble for their safety. Children should be supervised to ensure that they
do not play with the appliance.
6. Use your machine only for laundries that have been specified as
suitable for washing by the manufacturer.
7. Before operating the washing machine, remove the 4 transportation
screws and rubber spacers from the back of the machine. If the
screws are not removed, it may cause heavy vibration, noise and
product malfunction, (voiding the guarantee).
8. Your machine is not covered under warranty for faults caused by any
kind of external factors (pesticides, fire, etc.).
9. Please do not throw away this user manual; keep it for future
reference. You or somebody else might need it in the future.
Note: Machinery specifications may vary depending on the product
purchased.
10. The necessary ambient temperature for your machine’s ideal
operation is 15-25°.
11. Frozen hoses can tear and explode. In regions where temperature is
below zero, ambient temperature might endanger the safe operation
of electronic card.
12. Please ensure that the clothes you will place in your machine do not
contain any foreign substances (nail, needle, coins, lighter, matches,
clip etc.) in their pockets. These foreign substances can damage your
machine.
13. Before starting to use your machine, you may call the nearest
authorized service and request free-of-charge help for installation,
operation and use of your machine.
14. It is recommended to perform the first washing operation in 90˚
Cotton programme and without laundry by inserting ½ scale of
detergent in 2nd compartment of the detergent drawer.
15. As detergent or softener exposed to air for a long time may cause
residues, put your detergent or softener in the detergent drawer at
the beginning of every washing.
16. It is advised that you unplug your machine and close the water inlet
tap if you will not use your machine for a long time. Also, leaving the
door of your machine will prevent the forma- tion of bad odors due to
humidity.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
3
17. Some water might be left in your machine after the trials and tests
conducted due to Quality Control procedures. This will not damage
your machine.
18. Remember that packaging materials of your machine may be
dangerous for children.
19. Keep the packaging materials in a place where children cannot reach
or dispose of them appropriately.
20. Use pre-wash programs only for very dirty laundry.
21. Never open the detergent drawer when the appliance is running.
22. In case of any breakdown, unplug the appliance first and then turn
the tap off. Do not attempt to repair by yourself, always contact for
authorized service advice.
23. The amount of laundry you put in your washing machine should not
exceed the maximum amount indicated.
24. Never force the door to open when the machine is running.
25. Washing floury clothes in your machine damages the machine. Do
not wash floury clothes in your machine.
26. Please adhere to detergent/fabric conditioner manufacturers’ the
use of fabric conditioner or similar products in your machine.
27. Set up your machine in a place where its door can be completely
opened. (Do not set up your machine in places where its door
cannot be fully opened.)
28. Set up your machine at locations that can be fully ventilated and
could have constant air circulation.
You must read these warnings. You can thus protect yourself and
your beloved ones against fatal injuries and risks.
DANGER OF GETTING BURNT!
Do not touch discharging hose and water during discharging as the
appliance may reach high temperatures when running.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
4
DEATH RISK DUE TO ELECTRICAL CURRENT!
1. Do not use multiple receptacles or extension cord.
2. Do not plug in damaged plug sockets.
3. Never pull the cable when unplugging –always grip the plug itself.
4. Do not plug-in or out the plug from the receptacle with wet hands to prevent
electrocution!
5. Never touch the machine with wet hands or feet.
6. Call the nearest authorized service for a replacement if the power cord malfunctions.
FLOODING RISK!
1. Check whether the water runs fast or not before placing the discharge hose on the
sink.
2. Take necessary measures to prevent the slipping of your hose.
3. The backfiring force of a hose that is not placed appropriately can displace the hose.
Prevent the stopper inside your sink from blocking the sink hole.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
5
DANGER OF FIRE!
1. Do not keep inflammable liquids near your machine.
2. The sulphure content of paint removers might cause corrosion. For this reason, never
use paint-removing materials in your machine.
3. Never use products that contain solvent material (like washing gas) in your machine.
4. Remove all the objects in the pockets of your laundries (needle, paperclip, lighter,
matches etc.) when placing them your machine.
Fire and Explosion risk may occur.
FALL AND INJURY HAZARD!
1. Do not climb on your machine. The upper table of your machine may break and you
might get injured.
2. Tidy the hose, cable and packaging of your machine during installation. You might trip
over and fall.
3. Do not turn your machine upside down, or on its side.
4. Do not lift your machine by holding it from extruding parts (detergent drawer, door).
These parts might break and cause you to get injured.
5. There’s the risk of tripping and injury if the materials like hose and cables are not
properly stored after your machine is installed.
Machine must be carried by 2 people or more.
CHILD SAFETY!
1. Do not leave children unattended near the machine. Children might lock themselves
up into the machine and death risk might occur.
2. Door glass and surface might be extremely hot while your machine operates. Thus,
especially touching the machine might give damage to the skins of children.
3. Keep packaging material away from children.
4. Poisoning might occur if the detergent and maintenance materials are consumed, and
eyes or the skin might be irritated if they come into contact with the skin. Keep the
cleaning materials away from the reach of children.
SAVING INFORMATION
Some important information to get more efficiency out of your machine:
The amount of laundry you put in your washing machine should not exceed the maximum
amount indicated. By this way, your machine shall run in saving mode. Not using the pre-wash
feature for little and normal-dirty laundry shall save electricity and water.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
6
V. PRODUCT DESCRIPTION

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
7

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
8
REMOVING THE SCREWS
1. Before operating the washing machine, remove the 4 transportation screws and
rubber spacers from the back of the machine. If the screws are not removed, it
may cause heavy vibration, noise and product malfunction, (voiding the
guarantee).
2. For this reason, transportation safety screws shall be loosened by being rotated in
counter-clockwise using an appropriate wrench.
X4
X4
3. Transportation screws shall be removed by pulling out.
4. Fit the plastic transportation screw taps delivered in accessories bag to the palces
where transportation screws have been removed.
5. The transportation safety screws should be stored to be used in case of
transportation.
X4
NOTE: You should absolutely remove the transportation screws of your machine
before the first usage. Faults occurring in the machines operated with
transportation screw fitted shall be out of scope of warranty.
VI. INSTALLATION

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
9
ADJUSTMENT
Do not install your machine on a carpet or such grounds that would prevent the ventilation
of its base. To ensure silent and vibration-free operation of your machine, it should be
deployed on a non-sliding and firm ground. You can adjust the balance of your machine
through the stays. Loosen the plastic adjustment nut.
Adjust the stays upward and downward by rotating them.
After maintaining the balance, compress the plastic adjustment nut upward again.
Never put cardboard, wood or suchlike materials under your machine if you are intending
to stabilize the distortions on the ground.
When cleaning the ground, on which your machine rests, be careful not to disorder stays
stabilization.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
10
ELECTRICAL CONNECTION
•Your washing machine is set to 220-240V and 50Hz.
•The mains cord of your washing machine is equipped with a specific earthed plug. This
plug should always be inserted to a earthed socket of 10 amps.
•The current value of the fuse should be 10 amps. Fuse current value of the power line
connected to this plug should also be 10 amperes.
•If you don’t have such a receptacle and fuse confirming with this, please have it done
by a qualified electrician.
•We do not take the responsibility of the damages that occur due to ungrounded usage.
NOTE: Operating your machine under low voltage will cause the life cycle of your
machine to be reduced and its performance to be restricted.
WATER INLET HOSE CONNECTION
•Your machine may have either a single inlet (cold) or double water inlets (cold/hot)
based on its specifications. White-capped hose should be connected to cold water inlet
and red-capped hose to hot water inlet (applicable for machines with double water
inlets).
•To eliminate water leakages in points of contact, 1 or 2 nuts are provided in the hose
package (applicable for machines with double water inlets). Fit these nuts to the ends
of new water inlet hoses on the side of faucet.
•Mount new water inlet hoses to a ¾ ˝, threaded faucet.
•Connect the white-elbow end of the water inlet hoses to the white-filtered water inlet
valve on the rear side of the machine and the red-elbow end to red-filtered one
(applicable for machines with double water inlets). Tighten plastic parts of the
junctions using your hand. In uncertain conditions, have the connection works be done
by a qualified plumber.
•Flow of water with pressure of 0,1-1 Mpa will allow your machine to operate more
efficiently.) (0,1 Mpa pressure means that more than 8 litres of water will flow through
a fully-tapped faucet per one minute.)
•Ensure that points of contact do not leak by tapping the faucet completely after
carrying making the connections.
•Ensure that the new water inlet hoses are not bent, broken, crushed and resized.
•If your machine has double hot water inlets, the temperature of hot water inlet should
be maximum 70°C.
3/4”
3/4”

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
11
Note: Use only the new water inlet hose coming with your machine while making
water inlet connections of your machine. Never use old, used or damaged water
inlet hoses.
WATER DISCHARGE CONNECTION
•The end of water discharge hose can be fitted to a specific apparatus directly attached
to dirty water discharge hole or outlet joint of the basin elbow.
•Never attempt to extend the water discharge hose by jointing.
•Do not put discharging hose of your machine in a vessel, bucket or sink.
•Make sure that the water discharge hose does not bend, buckle, be crushed or
extended. Please note: The water drain hose should be mounted at a height maximum
100 cm from the ground.
~ 95 cm
~ 145 cm
~ 140 cm
~ 95 cm
˜ 95cm
˜ 150cm

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
12
VII. CONTROL PANEL
You can use the liquid level determination plate when you want to wash your laundry
with liquid detergent. You can use your liquid detergents in all programs without
prewashing. Place the liquid detergent aparatus in the second compartment (which is
available inside the machine) of the detergent drawer and set the detergent amount.
(Use the recommended amount of liquid detergent by detergent producers).
Do not exceed the MAX level, use only for liquid detergent, do not use this aparatus for
powder detergent and take it out.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
13
Machinery specifications may vary dependind on the product purchased.
Main wash detergent compartment:
In this compartment, only materials like detergent (liquid or powder), lime preventer and
such can be used. You can find the liquid detergent aparatus inside your machine at first
installation.
Fabric conditioner, starch, detergent compartment:
You can use softener for your laundry (recommended amount and type by the producer is
recommended). Sometimes the fabric conditioners you use for your laundry mar remain
in this compartment. The reason for this is that the conditioner is not viscous. To prevent
this situation, more viscuous liquid softeners are recommended to be used or the softener
could be thinned and then used.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
14
Pre-wash detergent compartment:
This compartment must only be used when the pre-wash feature is selected.
Pre-wash feature is recommended for very dirty laundry.

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
15
You can select the programme you want to wash your laundry in through programme knob.
You may set the programme selection operation by rotating the programme knob in both
directions.
Ensure that the programme knob is exactly on the programme you want to select.
VII. PROGRAM KNOB

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
16
From the function leds of your machine, you can see how much longer it will start to run
after, the auxiliary functions you have selected and the stage of the programme you are
running on your pre wash / wash state, rinsing stage, spinning stage).
Furthermore, electronic display will warn you by means of led combinations that will turn
on its display when a fault occurs on your machine and notify you of the completion of the
washing programme by revealing expression of “Finished” on the display as soon as the
washing programme you have selected has finished as well.
VIII. ELECTRONIC DISPLAY

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
17
SEPARATING LAUNDRIES
•Your laundry has product labels on them that specifiy their specifications. Wash or dry
your laundry according to the specifciations on the product label.
•Separate your laundries according to their types (cotton, synthetic, sensitive, wool
etc.), their temperatures (cold, 30°, 40°, 60°, 90°) and degree of contamination (slightly
stained, stained, highly stained).
•Never wash your coloured and white laundry together.
•Wash your coloured laundries separately in the first washing as they may bleed.
•Ensure that there are no metallic materials on your laundries or in the pockets; if so,
take them up.
CAUTION: WARNING: Faults that will emerge in case of penetration of foreign
substances into your machine are not included within the scope of warranty.
•Zip up and button up your laundries.
•Remove the metallic or plastic hooks of tulle curtains or curtains or place them in a
washing net or bag and then muzzle them.
•Reverse textiles such as pants, knitwear, t-shirt and sweat suit.
•Wash socks, handkerchief and suchlike small laundries in a washing net.
IX. USING YOUR APPLIANCE

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
18

www.heinner.com 5Kg, 220-240V~50Hz, 800rpm
19
PUTTING LAUNDRIES IN THE MACHINE
•Open the door of your machine.
•Spread your laundries in your machine.
NOTE: Maximum loading capacity may vary based on the laundry type you will wash,
degree of contamination and the programme you have chosen. Do not exceed maximum
dry loading capacity indicated in the programme table for washing programmes.
You can take the following table of weights as an example:
Laundry type
Weight (gr)
Towel
200
Linen
500
Nathrobe
1200
Quilt cover
700
Pillow slip
200
Underwear
100
Tablecloth
250
•Put each item of laundry separately.
•Ensure that no laundry is stuck between the cover and bellow seal when closing
the door of your machine.
•Push the door of your machine until hearing the locking sound to close it.
•Close the door of your machine properly, otherwise your machine will not start the
washing operation.
